Icom IC R8500 Service Manual Addendum page 183

Jul. 2008
[PLL-B UNIT]
REF ORDER
NO. NO.
C402 4030006860 S.CER C1608 JB 1H 102K-T
C403 4030006860 S.CER C1608 JB 1H 102K-T
C404 4030006860 S.CER C1608 JB 1H 102K-T
C405 4030006860 S.CER C1608 JB 1H 102K-T
C406 4030006860 S.CER C1608 JB 1H 102K-T
C407 4030006860 S.CER C1608 JB 1H 102K-T
C408 4030006860 S.CER C1608 JB 1H 102K-T
C409 4030006860 S.CER C1608 JB 1H 102K-T
C410 4030006860 S.CER C1608 JB 1H 102K-T
C411 4030006860 S.CER C1608 JB 1H 102K-T
C412 4030006860 S.CER C1608 JB 1H 102K-T
C413 4030006900 S.CER C1608 JB 1H 103K-T
C414 4030006990 S.CER C1608 CH 1H 080D-T
C415 4030007110 S.CER C1608 CH 1H 680J-T
C416 4030007140 S.CER C1608 CH 1H 121J-T
C417 4030007030 S.CER C1608 CH 1H 150J-T
C418 4030007130 S.CER C1608 CH 1H 101J-T
C419 4030006860 S.CER C1608 JB 1H 102K-T
C420 4030006860 S.CER C1608 JB 1H 102K-T
C421 4030007000 S.CER C1608 CH 1H 090D-T
C422 4030007110 S.CER C1608 CH 1H 680J-T
C423 4030007030 S.CER C1608 CH 1H 150J-T
C424 4030006860 S.CER C1608 JB 1H 102K-T
C425 4030006860 S.CER C1608 JB 1H 102K-T
C426 4030009530 S.CER C1608 CH 1H 030B-T
C427 4030007060 S.CER C1608 CH 1H 270J-T
C428 4030009920 S.CER C1608 CH 1H 050B-T
C429 4030006860 S.CER C1608 JB 1H 102K-T
C430 4030008920 S.CER C1608 JB 1H 473K-T
C431 4510008540 S.ELE EEE1CA100SR
C432 4030008920 S.CER C1608 JB 1H 473K-T
C433 4030006860 S.CER C1608 JB 1H 102K-T
C434 4030006860 S.CER C1608 JB 1H 102K-T
C435 4030007050 S.CER C1608 CH 1H 220J-T
C436 4030007050 S.CER C1608 CH 1H 220J-T
C437 4030007050 S.CER C1608 CH 1H 220J-T
C438 4030007050 S.CER C1608 CH 1H 220J-T
C439 4030007050 S.CER C1608 CH 1H 220J-T
C440 4030007050 S.CER C1608 CH 1H 220J-T
C441 4030007050 S.CER C1608 CH 1H 220J-T
C442 4030007050 S.CER C1608 CH 1H 220J-T
C443 4030007050 S.CER C1608 CH 1H 220J-T
C444 4030007050 S.CER C1608 CH 1H 220J-T
C445 4550006050 S.TAN TEESVA 0J 106M8R
C446 4030011600 S.CER C1608 JB 1E 104K-T
C447 4030006860 S.CER C1608 JB 1H 102K-T
C448 4030006860 S.CER C1608 JB 1H 102K-T
C449 4030006860 S.CER C1608 JB 1H 102K-T
C450 4030006860 S.CER C1608 JB 1H 102K-T
C451 4030007170 S.CER C1608 CH 1H 221J-T
C452 4030006860 S.CER C1608 JB 1H 102K-T
C453 4030006860 S.CER C1608 JB 1H 102K-T
C454 4030007050 S.CER C1608 CH 1H 220J-T
C455 4550000510 S.TAN TEESVA 1V 473M8R
C456 4030006900 S.CER C1608 JB 1H 103K-T
C457 4030007090 S.CER C1608 CH 1H 470J-T
C458 4030007090 S.CER C1608 CH 1H 470J-T
C459 4030007090 S.CER C1608 CH 1H 470J-T
C460 4030007090 S.CER C1608 CH 1H 470J-T
C461 4030007090 S.CER C1608 CH 1H 470J-T
C462 4030007090 S.CER C1608 CH 1H 470J-T
C463 4030007090 S.CER C1608 CH 1H 470J-T
C464 4030006860 S.CER C1608 JB 1H 102K-T
C465 4030006860 S.CER C1608 JB 1H 102K-T
CP1 6910009670 S.CHK HK3-S-T
CP3 6910009670 S.CHK HK3-S-T
J7 6510018450 CNR TMP-S01X-B1
W21 8900004510 CBL OPC-452 A
WS1 8600035471 RX1768 P01*J01PL-1
WS2 8970022380 RX1768 COAXIAL TUBE (3)/PL
RX1768 1.5D COAXIAL TUBE (4)/PL
WS3 8970022390
WS4 8600035480 RX1768 J05PL
DESCRIPTION M.
LOCATION
T 233.5/69.2
T 228.4/68.7
T 228/72.6
T 235.3/72.4
T 230.2/76.4
T 157.2/9.2
T 160/11.6
T 160.7/14.2
T 165.7/16.9
T 169.4/15.1
T 168.7/8.7
T 173/13.3
T 176/13.1
T 175.2/15.7
T 179.5/15.7
T 181/14.2
T 182.4/15.7
T 156.2/7.3
T 130.2/12.2
T 128.9/12.2
T 127.6/12.2
T 128.1/10.2
T 118.7/14.2
T 130.8/8.4
T 128.2/8.4
T 128.2/7.1
T 126.3/7.2
T 117.2/7.5
T 225.1/20.3
T 201.1/7.7
T 224.3/17.5
T 224.3/16.1
T 135.6/83
T 65.1/76.7
T 68.1/76.9
T 68.5/75.6
T 71.2/75.3
T
T 72.5/76.6
T 75.2/78.7
T 76.2/76.1
T 76.2/74.8
T 79.3/74.8
T
T 160.7/12.9
T 219.5/50.3
T 107.4/101.7
T 102.7/102
T 105/95.8
T 105/83.3
T 166.1/8.7
T 161.3/9.2
T 58.1/87.7
T 131.6/70.8
T 128.3/71.4
T 207.9/50.3
T 200.8/41.4
T 201.3/52.6
T 207.9/47.5
T 207.9/53.1
T 199.3/50.5
T 149.6/47
T 161.8/7.3
T 164.2/14.9
T 104.1/89.9
T 106.9/32.6
[VCO-C UNIT]
H/V REF ORDER
NO. NO.
Q1 1560001311 S.FET MMBFU310LT1G
Q2 1530003450 S.TR
Q3 1560001311 S.FET MMBFU310LT1G
Q4 1530003450 S.TR
D1 1720000261 S.VCP 1SV214 (TPH2,F)
D2 1720000261 S.VCP 1SV214 (TPH2,F)
D3 1720000261 S.VCP 1SV214 (TPH2,F)
D4 1720000261 S.VCP 1SV214 (TPH2,F)
D5 1750000531 S.DIO
D6 1720000261 S.VCP 1SV214 (TPH2,F)
D7 1720000261 S.VCP 1SV214 (TPH2,F)
D8 1790000540 S.VCP MA338 (TX)
D9 1790000540 S.VCP MA338 (TX)
D10 1750000531 S.DIO
L1 6200003001 S.COL NLV32T-R22J
L3 6200003331 S.COL NLV32T-1R0J
L4 6200003251 S.COL NLV32T-R39J
L5 6200003331 S.COL NLV32T-1R0J
L6 6200003331 S.COL NLV32T-1R0J
L7 6200003001 S.COL NLV32T-R22J
L9 6200003331 S.COL NLV32T-1R0J
L10 6200003251 S.COL NLV32T-R39J
L11 6200003331 S.COL NLV32T-1R0J
L12 6200008080 S.COL LQW2BHNR22J03L
L13 6200002400 S.COL LQW31HNR10J03L
R2 7030003200 S.RES ERJ3GEYJ 100 V (10)
R3 7030003320 S.RES ERJ3GEYJ 101 V (100)
R4 7030003320 S.RES ERJ3GEYJ 101 V (100)
R5 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k)
R6 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k)
R7 7030003320 S.RES ERJ3GEYJ 101 V (100)
72/78.2 R8 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k)
R10 7030003200 S.RES ERJ3GEYJ 100 V (10)
R11 7030003320 S.RES ERJ3GEYJ 101 V (100)
R12 7030003320 S.RES ERJ3GEYJ 101 V (100)
R13 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k)
R14 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k)
58.7/81 R15 7030003320 S.RES ERJ3GEYJ 101 V (100)
R16 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R17 7030003860 S.RES ERJ3GE JPW V
C1 4030011340 S.CER C1608 CH 1H 471J-T
C2 4030011340 S.CER C1608 CH 1H 471J-T
C4 4030006850 S.CER C1608 JB 1H 471K-T
C5 4030006850 S.CER C1608 JB 1H 471K-T
C6 4030009530 S.CER C1608 CH 1H 030B-T
C7 4030009530 S.CER C1608 CH 1H 030B-T
C8 4030009500 S.CER C1608 CH 1H 0R5B-T
C9 4510008500 S.ELE EEE1CA101WP
C10 4030006850 S.CER C1608 JB 1H 471K-T
C11 4030006850 S.CER C1608 JB 1H 471K-T
C12 4030006970 S.CER C1608 CH 1H 060D-T
C13 4030006850 S.CER C1608 JB 1H 471K-T
C14 4030006850 S.CER C1608 JB 1H 471K-T
C15 4030009530 S.CER C1608 CH 1H 030B-T
C16 4030009530 S.CER C1608 CH 1H 030B-T
C17 4030009500 S.CER C1608 CH 1H 0R5B-T
C18 4510008500 S.ELE EEE1CA101WP
C19 4030006860 S.CER C1608 JB 1H 102K-T
C20 4030006970 S.CER C1608 CH 1H 060D-T
C24 4030007050 S.CER C1608 CH 1H 220J-T
C25 4030007050 S.CER C1608 CH 1H 220J-T
C26 4030006860 S.CER C1608 JB 1H 102K-T
C27 4030007050 S.CER C1608 CH 1H 220J-T
C28 4030006860 S.CER C1608 JB 1H 102K-T
C29 4030007050 S.CER C1608 CH 1H 220J-T
C30 4030018630 S.CER C2012 CH 1H 472J-T
C31 4030018630 S.CER C2012 CH 1H 472J-T
J1 6510004960 CNR
J3 6910008021 CNR
J4 6510004960 CNR
J5 6910008021 CNR
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
6
DESCRIPTION M.
2SC4835-R (TX)
2SC4835-R (TX)
1SV271 (TPH3,F)
1SV271 (TPH3,F)
3022-02B
IPS-1323-PT
3022-02B
IPS-1323-PT
S.=Surface mount
H/V
LOCATION
