Front Unit - Icom IC R8500 Service Manual Addendum

Feb. 2009
SECTION 6

[FRONT UNIT]

REF ORDER
NO. NO.
ME1 5510000440 MTR ME-36 (KL-218U-49) RX1768
S1 2260001260 SW SW-118 (SDDFA3)
W8 8900006680 CBL OPC-643 (N:14 L:80)
W9 8900006690 CBL OPC-644 (N:9 L:80)
W10 8900006700 CBL OPC-645 (N:6 L:60)
W11 8900006700 CBL OPC-645 (N:6 L:60)
EP1 6450001230 E.OTH HLJ0999-01-480
EP2 6910013810 E.OTH RMS20-100-201-1C
[DISP UNIT]
REF ORDER
NO. NO.
IC1 1140006021 S.IC HD6433833A74HV (RX-1768)
IC2 1130007960 S.IC SED1522F0C (QFP15-100PIN
IC3 1130011130 S.IC BU4030BF-E2
IC4 1110005711 S.IC S-80842CLUA-B63-T2G
IC5 1180001111 S.IC PQ20VZ51J00H S
IC6 1140009211 S.IC CAT24C01BW-TE13
Q1 1530002280 S.TR 2SC4081 T106 S
Q2 1590000720 S.TR DTA144EUA T106
Q3 1590000430 S.TR DTC144EUA T106
Q4 1590000720 S.TR DTA144EUA T106
Q5 1590000430 S.TR DTC144EUA T106
Q6 1590000680 S.TR DTC114EUA T106
Q7 1590000430 S.TR DTC144EUA T106
D1 1750000550 S.DIO 1SS355 TE-17
D2 1750000550 S.DIO 1SS355 TE-17
X1 6050009661 S.XTL MA-406 (9.8304 MHz-F)
R1 7030003800 S.RES ERJ3GEYJ 105 V (1 M)
R2 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R3 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R4 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R5 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R6 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R7 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R8 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R9 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R10 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R11 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R12 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R13 7030003800 S.RES ERJ3GEYJ 105 V (1 M)
R14 7030003800 S.RES ERJ3GEYJ 105 V (1 M)
R15 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R16 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R17 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R18 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R19 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R20 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R21 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R22 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k)
R23 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R24 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R25 7030003450 S.RES ERJ3GEYJ 122 V (1.2 k)
R26 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R27 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R28 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R29 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R30 7030003800 S.RES ERJ3GEYJ 105 V (1 M)
R31 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R32 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R33 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R34 7030003800 S.RES ERJ3GEYJ 105 V (1 M)
R35 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R36 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R37 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R38 7030003760 S.RES ERJ3GEYJ 474 V (470 k)
R39 7030003720 S.RES ERJ3GEYJ 224 V (220 k)
R40 7030003720 S.RES ERJ3GEYJ 224 V (220 k)
R41 7210002850 VAR RV-305 (RK09L1140) 10KB
R42 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R43 7210002850 VAR RV-305 (RK09L1140) 10KB
R44 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R45 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R46 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R47 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
PARTS LIST
DESCRIPTION M.
LOCATION
DESCRIPTION M.
LOCATION
[DISP UNIT]
H/V REF ORDER
NO. NO.
R49 7030003600 S.RES
R50 7030003600 S.RES
R51 7030003520 S.RES
R52 7030003320 S.RES
R53 7030003320 S.RES
R54 7030003680 S.RES
R55 7030003800 S.RES
R56 7030006060 S.RES
R57 7030006060 S.RES
C1 4030007020 S.CER
C2 4030007020 S.CER
C3 4030006900 S.CER
C4 4030006900 S.CER
C5 4510009280 S.ELE
C7 4030006900 S.CER
C9 4510008540 S.ELE
H/V
C10 4030006860 S.CER
C11 4030006860 S.CER
C12 4030009000 S.CER
C13 4030006900 S.CER
C14 4030006900 S.CER
C15 4030006880 S.CER
C16 4030006880 S.CER
C17 4030006880 S.CER
C18 4030006880 S.CER
C19 4030006880 S.CER
C20 4030006900 S.CER
C21 4030006900 S.CER
C22 4030006900 S.CER
C23 4030011600 S.CER
RL1 6330001420 S.RLY
J2 6510019281 S.CNR
J3 6510019291 S.CNR
J4 6510019361 S.CNR
J5 6510019361 S.CNR
J6 6510019371 S.CNR
J8 6510003401 CNR
DS1 5030001360 LCD
DS2 5080000370 LMP
DS3 5080000370 LMP
DS4 5080000370 LMP
DS5 5080000370 LMP
S1 2230000970 SW
W1 7120000470 JMP
W2 7120000470 JMP
EP2 8930041151 LCT
[SW-A UNIT]
REF ORDER
NO. NO.
J1 6510019621 CNR
[SW-B UNIT]
REF ORDER
NO. NO.
J1 6510019631 CNR
[VR-A UNIT]
REF ORDER
NO. NO.
R1 7210002860 VAR
J1 6510019361 S.CNR
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
1
DESCRIPTION M.
ERJ3GEYJ 223 V (22 k)
ERJ3GEYJ 223 V (22 k)
ERJ3GEYJ 472 V (4.7 k)
ERJ3GEYJ 101 V (100)
ERJ3GEYJ 101 V (100)
ERJ3GEYJ 104 V (100 k)
ERJ3GEYJ 105 V (1 M)
ERJ12YJ100U (10)
ERJ12YJ100U (10)
C1608 CH 1H 120J-T
C1608 CH 1H 120J-T
C1608 JB 1H 103K-T
C1608 JB 1H 103K-T
EEE1EA4R7SR
C1608 JB 1H 103K-T
EEE1CA100SR
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C2012 JB 1C 224K-T
C1608 JB 1H 103K-T
C1608 JB 1H 103K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 103K-T
C1608 JB 1H 103K-T
C1608 JB 1H 103K-T
C1608 JB 1E 104K-T
ATQ203SAZ
52610-0971 (0990)
52610-1471 (1490)
52610-0671 (0690)
52610-0671 (0690)
B3B-ZR-SM4-TF (LF) (SN)
B04B-EH-S (LF) (SN)
DLC-7982YBGT
HRS-4160A
HRS-4160A
HRS-4160A
HRS-4160A
ESB-64620
ERDS2T0
[FRA], [DEN], [CHN] only
ERDS2T0
[FRA], [DEN], [CHN] only
SRCN-1768-SP-N-W-1 (SHJ)
[OTH] only
DESCRIPTION M.
52030-0929 (0910)
DESCRIPTION M.
52030-1429 (1410)
DESCRIPTION M.
RV-306 (RK0972210) 10KB/10KB
52610-0671 (0690)
S.=Surface mount
H/V
LOCATION
H/V
LOCATION
H/V
LOCATION
H/V
LOCATION
