Installation Instructions
This document describes the installation, programming, testing,
and troubleshooting procedures for installing Concord 2.0 secu-
rity systems.
About This Manual ............................................... 5
UL-Listed Installations ............................. 5
California State Fire Marshall
Listed Installations .................................... 6
Planning the Installation ........................................ 6
Standard Panel ............................................... 6
SuperBus 2000 Touchpads ............................. 6
SuperBus 2000 RF Receivers ........................ 6
Power Line Carrier Card ................................ 7
Phone Supervision Card ................................. 7
Supervised Wireless Siren ............................. 7
Module ........................................................... 7
SnapCards ...................................................... 7
Module (HIM) ................................................ 7
Module (HOM) .............................................. 7
Verification Module ....................................... 7
Installing the System ............................................. 7
Determine the Panel Location ........................ 8
Guidelines ...................................................... 8
Mounting the Panel ........................................ 9
Identify Panel Components .......................... 10
Installing Antennas ...................................... 10
Carrier Card ................................................. 11
Supervision Card .......................................... 11
Installing Optional SnapCards ..................... 11
Zone Inputs .................................................. 12
Connecting Speakers .................................... 13
15-Watt Speaker ...................................... 14
Hardwire Interior Speaker ...................... 14
Connecting Piezo Sirens .............................. 14
Exterior Sirens ........................................ 15
Interior Sirens ......................................... 15
Wireless Sirens ............................................. 15
Audio Verification Module .......................... 16


Document No. 466-1512-01 August 2, 2000
Preliminary
Fixed Display Touchpads ............................. 16
Interface/Voice Module............................ 18
Energy Saver Module............................... 19
4-Relay Output Module .......................... 20
2000 Devices ................................................ 20
Installing an RJ-31X Phone Jack ................. 20
Panel with a DB-8 Cord ............................... 21
Powering Up the Panel ................................. 22
Programming the Panel ....................................... 22
Entering Program Mode ............................... 22
Tiers and Menus ........................................... 23
Programming Tier 1 Menu Items ................. 24
Programming Tier 2 Menu Items ................. 24
Using Shortcut Numbers ......................... 25
Security Menu ......................................... 25
Phones Menu ........................................... 27
Phone Options Menu ............................... 30
Timers Menu ........................................... 34
Light Control Menu ................................ 36
Touchpad Options Menu ......................... 36
Reporting Menu ...................................... 37
Siren Options Menu ................................ 41
Sensors Menu .......................................... 42
Audio Verification Menu ........................ 44
Accessory Modules Menu ....................... 45
Onboard Options Menu ........................... 48
Exiting Programming Mode ......................... 50
Time and Date Menu ............................... 50
User Codes Menu .................................... 50
Options Menu .......................................... 52
Set Up Schedules Menu .......................... 53
Energy Saver Menu ................................. 55
System Version Menu ............................. 55
Downloader Programming ........................... 56

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Concord and is the answer not in the manual?

Questions and answers

Related Manuals for ITI Concord

Summary of Contents for ITI Concord

  • Page 1: Table Of Contents

     Installation Instructions  This document describes the installation, programming, testing, and troubleshooting procedures for installing Concord 2.0 secu- rity systems. Document No. 466-1512-01 August 2, 2000 Preliminary About This Manual ..........5 Connecting Alphanumeric and Fixed Display Touchpads ......16 Special Installation Requirements ....
  • Page 2 Installation Instructions Testing the System ..........56 Basic System Commands ......56 Testing Zones/Sensors ........56 If a Wireless Sensor Does Not Test ..57 Testing Phone Communication .....57 Testing Central Station/Pager Communication ..........57 Testing Outputs and Sirens ......58 Testing Light Control ........58 Testing the Energy Saver Module (ESM) ..58 Changing Fixed Display LCD Touchpad Chime and Trouble Beep Tones ...59 Testing Audio Verification Module (AVM)
  • Page 3 Declaration of Conformity (DoC) Interactive Technologies, Inc. declares that the ITI model no. 60-792-95R is in conformity with Part 15 of the FCC Rules. Operation of this product is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired...
  • Page 4 L ´ Indice de charge de cet produit est ____________. Trademarks ITI, SuperBus, and ITI ToolBox are registered trademarks of Interactive Technologies, Inc. Concord and SnapCard are trademarks of Interactive Technologies, Inc. X-10 is a registered trademark of X-10 (USA), Inc.

  • Page 5: About This Manual

    LCD Touchpad (60-746-01), 2x20 LCD Touchpad (60- less Learn Mode Door/Window Sensor (60-499) 803), or VFD Touchpad (60-804) ITI SAW PIR Sensor (60-639-95R), ITI Crystal PIR Sen- Standard Class II 24 VAC, 30 VA Power Transformer sor (60-703-95R), or DS924i PIR Sensor (60-511-01-95)

  • Page 6: Ul-Canada Listed Installations

    2-wire smoke detectors. (ULC-S545-M89) Built-In SuperBus 2000 Receiver (60-792-01-95R only): Allows use of up to 16 or 32 ITI Basic system as described for “UL Listed Installations” plus: 319.5 MHz. crystal and/or SAW Learn Mode wireless Hardwire Smoke Detector: sensors and touchpads.

  • Page 7: Power Line Carrier Card

    Installing the System Power Line Carrier Card SuperBus 2000 8Z Input Module (HIM) Adding this card (which requires that the panel be powered using a Power Line Carrier Transformer) adds the following Provides eight additional hardwire zone inputs. capabilities to the system: Allows the use of Supervised Wireless Sirens.

  • Page 8: Determine The Panel Location

    Installing the System Determine the Panel Location Table 1 describes the maximum wire length allowed between compatible devices and the panel, including the maximum cur- rent draw of each device. Before permanently mounting the panel, determine panel loca- Table 1. Maximum Device Wire Length and Current Draw tion using the following guidelines: Centrally locate the panel with relation to detection Device...

  • Page 9: Mounting The Panel

    Installing the System Table 3 describes the minimum current draw of each device Table 4. Device Wiring Requirements when the panel is operating only from the backup battery. For Device Wire Requirements 24-hour backup, the total current draw of all SnapCards connected to the panel and devices connected to +12 BUS 2-Wire Smoke Detectors 2-conductor, 22-gauge, 330 feet...

  • Page 10: Identify Panel Components

    Installing the System Identify Panel Components Installing Antennas Before installing devices and making wiring connections, Install the antennas (included with panel) into the inside termi- familiarize yourself with the main panel components. Figure 3 nal of each antenna terminal block on the combination hard- shows the main component locations for the hardwire circuit wire/wireless panel (see Figure 5).

  • Page 11: Installing The Optional Power Line Carrier Card

    Installing the System Installing the Optional Power Line Carrier Installing Optional SnapCards Card (60-755) The SnapCard Header on the right side of the panel allows for installation of one SnapCard. The Power Line Carrier card lets you add Supervised Wireless Sirens for alarm and status sounds and X-10 Lamp Modules for Install the desired SnapCard onto the panel SnapCard Header controlling lights.

  • Page 12: Connecting Detection Devices To Panel Zone Inputs

    Circuits to the Panel Figure 11 shows the typical wiring for a Detection Systems model DS922 (ITI part no. 13-082) motion detector. The mini- mum available panel voltage for hardwired PIR motion detec- tors is 8.5 VDC (9.5 VDC for UL listed installations).

  • Page 13: Connecting 4-Wire Smoke Detectors

    4 4 9 A T only 4-wire smoke detectors that operate at these power limits. Connect up to five Sentrol (ESL) model 449AT (ITI part no. 13-360) smoke detectors to panel power and zone 8 input as shown in Figure 13.

  • Page 14: 15-Watt Speaker

    Installing the System 15-Watt Speaker (13-060) Connect two units to the panel terminals with speakers in series (16 ohms), as shown in Figure 16. Use this speaker for exterior siren applications. Connect the speaker to the panel as shown in Figure 14. SPEAKER SPEAKER SPLICE...

  • Page 15: Exterior Sirens

    Installing the System Exterior Sirens Slim Line Hardwire Interior Siren (60-483-01) Connect the siren to the panel as shown in Figure 19. Hardwire Exterior Siren (13-046) Note The volume switch settings inside the siren do not Connect the siren to panel as shown in Figure 17. affect the siren output.

  • Page 16: Connecting An Interrogator 200 Audio Verification Module

    Repeat step 6. For supervised wireless siren installations: Note Hardwire Concord 2.0 panels must have a SuperBus 2000 RF Receiver installed for supervised wireless siren operation. Power up the panel (see “Powering Up the Panel” later in this section).

  • Page 17: Installing Superbus 2000 Modules

    Installing the System Installing SuperBus 2000 Modules receivers must be installed outside the cabinet. SuperBus modules can be installed inside the panel cabinet or away from the panel. Use the following guidelines when installing modules inside the panel cabinet: Up to 16 bus modules can be connected to the panel. (15 modules for the RF panel since receiver counts as 1.) MOUNTING Up to 3 modules can be mounted inside the cabinet.

  • Page 18: Superbus 2000 Phone Interface/Voice Module

    Installing the System SuperBus 2000 Phone Interface/Voice Module (60- 777-01) P H O N E I N T E R F A C E / V O I C E P H O N E I N T E R F A C E / V O I C E M O D U L E T E R M I N A L S T R I P 1 M O D U L E T E R M I N A L S T R I P 2 The Phone Interface/Voice Module...

  • Page 19: Energy Saver Module

    Installing the System Wiring—Speaker (Status and Alarm Messages) SuperBus 2000 8Z Input Module (60-774) Make the following connection only if the Phone Interface/ Voice module is being installed in partition 1 and alarm sounds Connect the SuperBus 2000 8Z Input Module to the panel as are desired from the speaker connected to the terminals.

  • Page 20: 4-Relay Output Module

    Installing the System 4-Relay Output Module (60-770) Installing an RJ-31X Phone Jack (13-081) Connect the SuperBus 2000 4-Relay Output Module to the Use the following guidelines when installing an RJ-31X phone panel as shown in Figure 32. jack for system control by phone and central station monitor- ing.

  • Page 21: Connecting The Phone Line To The Panel With A Db-8 Cord

    Installing the System TELCO HOUSE RJ-31X DB-8 CORD JACK PLUG RJ-31X JACK TELCO PROTECTOR 8573G86A.DSF BLOCK RJ-31X Figure 34. Connecting the DB-8 Cord to the Panel and PHONE RING RJ-31X Jack LINE WIRE Check the phones on the premises for dial tone and the ability to dial out and make phone calls.

  • Page 22: Powering Up The Panel

    Programming the Panel Powering Up the Panel Programming the Panel After connecting and wiring all devices to the panel, you are For on-site system programming, an alphanumeric touchpad is ready to apply AC and backup battery power to the panel. required.

  • Page 23: Touchpad Button Programming Functions

    Programming the Panel Touchpad Button Programming Functions TIER 2 MENUS In program mode, touchpad buttons let you navigate to all PHONE LIGHT SECURITY PHONES TIMERS installer programming menus for configuring the system. Table OPTIONS CONTROL 6 describes the touchpad button functions in program mode. Table 6.

  • Page 24: Programming Tier 1 Menu Items

    Programming the Panel Programming Tier 1 Menu Items Partition 1 Copy (System Programming) This section guides you through programming tier 1 menu (Default = none) After programming all settings pertaining items as they appear in sequence. Depending on whether to partition 1, you can make an exact copy to use for parti- you’re installing a new system or changing programming in an tion 2.

  • Page 25: Using Shortcut Numbers

    Programming the Panel Using Shortcut Numbers Installer Code (Security-Global) (0001) (Default = 4321) The 4-digit installer code is used for entering To go directly to a setting in tier 2, you can enter the shortcut program mode and changing system settings. If a dealer code number for that setting.
  • Page 26 Programming the Panel Quick Arm (Security—Partition 1-2) Auto Stay Arming (Security—Partition 1-2) (partition 1: 0011, partition 2: 0021) (partition 1: 0014, partition 2: 0024) (Defaults = off) Quick Arm allows system arming without (Defaults = on) This setting determines whether or not the using an access code.

  • Page 27: Phones Menu

    Programming the Panel Phones Menu Keyswitch Style (Security—Partition 1-2) (partition 1: 0016, partition 2: 0026) (Defaults = transition) This feature allows users to select how The PHONES menu lets you set up central station reporting for they want the system to behave when armed/disarmed by a the system.
  • Page 28 Programming the Panel High Level Rpts (Phones—CS Phone 1-3) Open/Close Rpts (Phones—CS Phone 1-3) (cs phone 1: 0101, cs phone 2: 0111, cs phone 3: (cs phone 1: 0104, cs phone 2: 0114, cs phone 3: 0121) 0124) (Defaults: CS Phone 1 = on, CS Phone 2 and 3 = off) When (Defaults = off) This setting determines whether opening and this setting is on, the following conditions report to the central closing reports are sent to the central station.
  • Page 29 Programming the Panel The following describes how to program the phone settings Low Level Rpts (Phones—Pager Phone 1-5) that appear under PAGER PHONE 1 through 5. (pager 1: 0132, pager 2: 0142, pager 3: 0152, pager 4: 0162, pager 5: 0172) Phone Number (Phones—Pager Phone 1-5) (Defaults = off) This setting determines whether the following...

  • Page 30: Phone Options Menu

    Programming the Panel The following describes how to program the phone settings Latchkey Reports (Phones—Pager Phone 1-5) that appear under DOWNLOADER PHONE. (pager 1: 0135, pager 2: 0145, pager 3: 0155, pager 4: 0165, pager 5: 0175) Phone Number (Phones—Downloader Phone) (Defaults = on) This setting determines whether the panel (0180) reports to a pager when the system is armed or disarmed,...
  • Page 31 Programming the Panel Auto Phone Test (Phone Options—Global) Comm Failure (Phone Options—Global) (02001) (02003) (Default = off) This setting determines if the panel sends a (Default = on) This setting determines whether the panel acti- phone test automatically to the central station or a pager on a vates trouble beeps to alert users on the premises that commu- predetermined schedule.
  • Page 32 Programming the Panel Dial Abort Delay (Phone Options—Global) Dial Tone Detect (Phone Options—Global) (02006) (02010) (Default = 30 sec) This setting determines how much time the (Default = on) When this setting is on, the panel does not user has to abort a panel report. begin dialing until it detects a dial tone.
  • Page 33 Programming the Panel Ring/Hang/Ring (Phone Options—Partition 1-2) Toll Saver (Phone Options—Partition 1-2) (partition 1: 0212, partition 2: 0222) (partition 1: 0214, partition 2: 0224) (Defaults = on) This setting determines how the panel picks (Defaults = on) This setting determines whether the panel up (seizes) the phone line.

  • Page 34: Timers Menu

    Programming the Panel Timers Menu Phone Test Freq. (Timers—Global) (0302) (Default = 7 days) This setting determines how often the The TIMERS menu lets you set up the various system feature panel conducts the automatic phone test (see “Auto Phone times that affect the whole system (global) or a specific parti- Test”...
  • Page 35 Programming the Panel Daylight Saving (Timers—Global) Extended Delay (Timers—Partition 1-2) (0306) (partition 1: 0312, partition 2: 0322) (Default = on) When this setting is on, the panel clock auto- (Defaults = 4 minutes) This setting determines how much matically adjusts for daylight saving time changes. time the user has (after arming the system) to enter or exit the premises through a “designated extended delay door”...

  • Page 36: Light Control Menu

    Programming the Panel Light Control Menu Touchpad Options Menu The LIGHT CONTROL menu lets you set up light activation The TOUCHPAD OPTIONS menu lets you set up touchpad for a specific partition. panic and arming operation. The following describes how to program the light control set- The following section describes the touchpad option settings tings that appear under PARTITION 1 and PARTITION 2.

  • Page 37: Reporting Menu

    Programming the Panel Police Panic (Touchpad Options—Partition 1-2) Buffer Control (Reporting—Global) (partition 1: 0512, partition 2: 0522) (06001) (Defaults = on) This setting determines whether touchpad (Default = off) When this setting is on, only arming level police panic buttons are enabled (on) or disabled (off). changes are logged in the buffer (memory) of the panel.
  • Page 38 ƒ and the display flashes the entered setting. Press shows the new setting. Note As with all ITI panels, hardwire smoke detectors con- nected to Concord 2.0 or SnapCard hardwire zones (Reporting—Global) Receiver Failure do not send restorals.
  • Page 39 Programming the Panel The following sections describe the settings that appear under RF Supv Report (Reporting—Global) REPORTING—PARTITION 1-2. (06013) (Default = weekly) This setting determines whether the panel Opening Reports (Reporting—Partition 1-2) sends daily or weekly reports to the central monitoring station (partition 1: 06100, partition 2: 06200) when the panel detects a supervisory condition in a wireless device.
  • Page 40 Programming the Panel Duress Option (Reporting—Partition 1-2) Latchkey Format (Reporting—Partition 1, 2) (partition 1: 06104, partition 2: 06204) (06106—partition 1, 06206—partition 2) (Defaults = off) When this setting is on, the system can be (Defaults = off) This setting determines whether the selected controlled using a programmed duress code (see SECU- partition is set up for basic (off) or advanced (on) latchkey RITY—PARTITION n —DURESS CODE).

  • Page 41: Siren Options Menu

    Programming the Panel Siren Options Menu Alarm Verify (Reporting—Partition 1-2) (partition 1: 06108, partition 2: 06208) (Defaults = off) This setting determines whether the panel The SIREN OPTIONS menu lets you set up siren operation and reports to the central monitoring station after a single sensor supervision.

  • Page 42: Sensors Menu

    SuperBus 2000 RF Receiver. have added to the system. For all Concord 2.0 panels, the siren must be learned into sensor group 33 for the system to process radio DELETE SENSORS lets you delete zones and sensors signals from wireless sirens.
  • Page 43 Programming the Panel The following describes how to program the sensor settings Sensor Text (Sensors) that appear under LEARN SENSORS. (081) (Default = none) Use the following guidelines to “name” zone Learn Sensors (Sensors) and sensor locations: (080) Use the item numbers that appear in “Appendix B, Table (Default = none) The following describes how to add (learn) B.2”...

  • Page 44: Audio Verification Menu

    Programming the Panel Audio Verification Menu Delete Sensors (Sensors) The AUDIO VERIFICATION menu lets you set up the audio (082) verification module (AVM) operation in partition 1. If you (Default = none) The following procedure describes how to want audio verification for partition 2, you must install a remove hardwire zone and wireless sensor numbers from “stand-alone”...

  • Page 45: Accessory Modules Menu

    Programming the Panel Accessory Modules Menu Silent Talkback (Audio Verification—Partition 1) (0903) (Default = off) This setting determines whether the central The ACCESSORY MODULES menu gives you access to the station operator can speak to persons on the premises (on) or following menus: only listen (off) during a silent or duress alarm audio session.
  • Page 46 Use these settings to program the output points of any 15) and Device ID numbers. installed SuperBus 2000 Hardwire Output Module. The installer programs a HOM output point into the Concord 2.0 To delete learned Unit Numbers: security panel by entering three kinds of information.
  • Page 47 Programming the Panel Status Beeps (Acc. Modules—Bus Devices Temperature (Acc. Modules—Bus Devices —Unit ID —Keypad Options) —Unit ID —Energy Options) (Default = on) This setting determines whether or not the (Default = none) This setting lets you adjust the Energy Saver selected touchpad sounds status beeps.

  • Page 48: Onboard Options Menu

    Programming the Panel Onboard Options Menu Output Text (Acc. Modules—SnapCards —Ouput Text ) (10110—output 1, 10111—output 2, 10112—output 3, 10113—output 4) The ONBOARD OPTIONS menu lets you set up the following built-in options: (Defaults = none) Entering text for an output allows the user to control it directly or by schedule.
  • Page 49 Programming the Panel The following sections describe the settings that appear under Output Text (Onboard Options ONBOARD OPTIONS—OUTPUT PROGRAMMING. Output Text —Output 1, 2) (1120—output 1, 1121—output 2) Output 1, 2 (Onboard Options Output Programming (Defaults = none) Use the following guidelines to “name” Output 1: partition assign—11100, configuration—11101 onboard outputs: Output 2: partition assign—11110, configuration—11111...

  • Page 50: Exiting Programming Mode

    Programming the Panel Exiting Programming Mode Date (Time and Date) (021) (Default = 01/01/00) This setting lets you adjust the panel cal- After all installer/dealer programming is completed, use the endar to the correct month, day, and year. following procedure to exit programming mode. To set the Date: To exit programming mode: ƒ...
  • Page 51 Programming the Panel Direct Bypassing (User Codes—Reg. User Codes System Tests (User Codes—Reg. User Codes —User NN) —User NN) (030nn1 where nn=user number 00-59) (030nn4 where nn=user number 00-59) (Default = off) This setting determines whether or not a spe- (Default = off) This setting determines whether or not a spe- cific user code provides access to the “bypass sensors”...

  • Page 52: Options Menu

    (040) Module is connected to the panel. (Default = on) When this setting is on, the panel can commu- nicate with ITI ToolBox software for programming the sys- To adjust status sound Volume: tem from off-site. A or B until the display shows OPTIONS, then 1.

  • Page 53: Set Up Schedules Menu

    Programming the Panel Chime On Close (Options) (045) Set Up Schedules (Default = off) When this setting is on, the panel sounds a sin- 05XXY where XX = schedule 00 thru 15 and Y = start gle chime when a perimeter door or window is closed. (0)/stop(1) 0 thru 8—Monday thru Sunday (2–8)) To turn Chime On Close off or on: (Defaults = 00:00) This menu lets you set up start/stop times...
  • Page 54 Programming the Panel Outputs Attach Schedules To Events (065xnn where nn = Schedule number [0 to 15] and x = output number [1 to 6] minus 1) Latchkey Reports Attach Schedules To Events (060nn—Opening, 061nn—Closing where nn = (Defaults = off) This setting lets you attach outputs to a time Schedule number [0 to 15]) schedule.

  • Page 55: Energy Saver Menu

    Programming the Panel Energy Saver Menu Attach Lights to Sensors Menu The ATTACH LIGHTS TO SENSORS menu lets you assign a The ENERGY SAVER menu lets you set the energy saver mod- light number to a sensor. Each time the sensor is activated, the ule low- and high-setpoints.

  • Page 56: Downloader Programming

    Testing the System Downloader Programming Table 8. Basic Touchpad Operating Commands Command System Response 1 + CODE Disarms system to OFF The panel can be programmed remotely using ToolBox. Use the information you recorded in Appendix A to inform the 2 + CODE Arms system to STAY downloading operator of the programming requirement for this...

  • Page 57: If A Wireless Sensor Does Not Test

    For example, a “Troubleshooting” section to resolve the problem. pager display of For wireless sensors that don’t respond, use an ITI RF Sniffer 999 002 7468 indicates the following: (60-401) test tool to verify that the sensor is transmitting. Con-...

  • Page 58: Testing Outputs And Sirens

    Testing the System Table 10 describes pager sensor/zone number and user number Testing Light Control report codes. Table 10. Pager Sensor/Zone and User Number Codes Test all lights plugged into X-10 Lamp Modules to verify house code and light number settings. Code Sensor/Zone or User Number To test light control:...

  • Page 59: Changing Fixed Display Lcd Touchpad Chime And Trouble Beep Tones

    Testing the System Changing Fixed Display LCD Touchpad To test the module from the central station: Chime and Trouble Beep Tones Inform the central station that you will be sending an alarm and testing an AVM. Give them the programming selections you made for the panel (see “Audio Verification Menu”...
  • Page 60 Testing the System DRAFT 8/17/00...

  • Page 61: Troubleshooting

    Troubleshooting Troubleshooting This section describes what to do if you experience problems with system operation. If after performing the troubleshooting procedures the panel still malfunctions, please call Technical Support at 1-800-777-2624. Topics are divided into separate tables for easy reference. Table 1, “Panel Power,”...
  • Page 62 Troubleshooting Table T1: Panel Power Problem Action/Solution Panel does not power up. Touchpads don’t dis- 1. Verify that the panel transformer is plugged into an unswitched outlet. 2. Check the AC circuit breaker to be sure the circuit is live. play or respond.
  • Page 63 Troubleshooting Table T2: Access Codes Problem Action/Solution Customer cannot remember access code(s). 1. Check your records to see if you have the customer’s access code(s) on file. 2. Verify the access code(s) using the Downloader. 3. Clear memory and reprogram the panel locally. Installer cannot remember install code.
  • Page 64 Troubleshooting Table T4: Bypassing Problem Action/Solution Touchpad indicates Invalid and/or “Invalid” is 1. Attempting to bypass a 24-hour sensor that cannot be bypassed (group 26 fire sensors). heard when you attempt to bypass a sensor. 2. Sensor is not active in the current arming level. System cancels sensor bypass when you try to 1.
  • Page 65 Troubleshooting Table T7: Alphanumeric Touchpads Problem Action/Solution Display shows all ************. 1. Touchpad is not connected to panel bus terminals or is wired incor- rectly. Check and correct wiring. 1. Check that panel is powered up. Display is blank. 2. Check for touchpad power and/or bus miswiring, opens, or shorts. 3.
  • Page 66 Troubleshooting Table T10: Sirens Problem Action/Solution Piezo sirens connected to Snap Card, or onboard 1. Check for incorrect wiring between siren and panel; correct where necessary. (panel) outputs 1 and/or 2 don’t produce any 2. Output has not been configured (set up) to activate sirens. Enter pro- alarm sounds.
  • Page 67 Troubleshooting Table T13: Wireless Sensor Zones Problem Action/Solution System doesn’t respond (in sensor test or when 1. Verify that receiver antennas are installed and connections are secure. 2. Check that the wireless sensor battery(s) are installed. armed) when sensor is tripped. 3.
  • Page 68 Troubleshooting Table T15: Phones Problem Action/Solution Loss of dial tone at on-site phones after wiring 1. Wait 2 minutes and try again. The panel may be busy trying to report to the central station. RJ-31X jack or connecting the DB-8 cord. 2.

  • Page 69: Appendix A: System Planning Worksheets

    Interior Siren 60-641 Long-Life Door/Window Sensor 13-046 Hardwire Exterior 145 mA Siren 60-461* Shock Sensor SuperBus 2000/Miscellaneous Components 60-459* Sound Sensor (ITI) 60-746- 2x16 LCD Alphanu- 90 mA 60-462* Glass Guard Sensor meric Touchpad 60-506 Smoke Sensor 60-820 Fixed English LCD...
  • Page 70 Appendix A: System Planning Worksheets Table A.3 Zone and Sensor Assignments Module Module RF Zone Bus ID Input Group Partition Zone/Sensor Text Number Number DRAFT 8/17/00...
  • Page 71 Appendix A: System Planning Worksheets Table A.3 Zone and Sensor Assignments Module Module RF Zone Bus ID Input Group Partition Zone/Sensor Text Number Number DRAFT 8/17/00...
  • Page 72 Appendix A: System Planning Worksheets Table A.4 System Settings Index and Record Setting (reference) Shortcut Setting Table A.4 System Settings Index and Record default Setting (reference) Shortcut Setting Duress Option (p. 40) Off 06104, 06204 1_____________ default 2_____________ Edit Sensors (p. 44) None Installer Programming—8 + Installer/Dealer CODE + 00 Entry Delay (p.
  • Page 73 Appendix A: System Planning Worksheets Table A.4 System Settings Index and Record Table A.4 System Settings Index and Record Setting (reference) Shortcut Setting Setting (reference) Shortcut Setting default default Line Fail Delay (p. 33) None 0213 Recent Closings (p. 39) On 06102, 06202 1_____________ 2_____________...

  • Page 74: Appendix B: Reference Tables

    Local Special Notify the user when a door is opened. Special Instant Chime Sounds emit from a local annunciator. Chime √ 1, 2, 3 (Note: If using a PIR motion sensor, use only ITI part no. 60-511.) DRAFT 8/17/00...
  • Page 75 Appendix B: Reference Tables Table B.1 Sensor Group Characteristics Name Application Alarm Delay Restoral Supervisory Chime Active Report (Level 1 Levels only) √ √ √ Fire 24-hour fire, rate-of-rise heat, and smoke Fire Instant 1, 2, 3 sensors. √ √ Output Hardwire Output Module (HOM) lamp Silent...
  • Page 76 Appendix B: Reference Tables Table B.2 Sensor Text and Item Numbers 093—Interior 139—Pool 185—0 094—Intrusion 140—Porch 186—1 001—Aborted 047—Detector 095—Invalid 141—Power 187—2 002—AC 048—Dining 096—Is 142—Press 188—3 003—Access 049—Disarmed 097—Key 143—Program 189—4 004—Active 050—Door 098—Kids 144—Progress 190—5 005—Activity 051—Down 099—Kitchen 145—Quiet 191—6 006—Alarm...

  • Page 77: Appendix C: Reference Tables

    Appendix C: Reference Tables Appendix C: Reference Tables Table C.1 System Event Trigger Numbers System Event Description Trigger Table C.1 System Event Trigger Numbers Interior Siren Activation follows all sys- System Event Description Trigger tem noises AVM Trip (pulse) When an AVM alarm occurs, output is deacti- Null Trigger Activated only by schedule...
  • Page 78 Appendix C: Reference Tables Table C.2 Sensor Group Event Trigger Numbers Table C.3 Sensor Number Event Trigger Numbers Sensor Group Trigger Sensor State Trigger State Trigger Number Group 16 in alarm Sensor 12 in alarm open Group 17 in alarm Sensor 13 in alarm open...
  • Page 79 Appendix C: Reference Tables Table C.3 Sensor Number Event Trigger Numbers Sensor State Trigger State Trigger Table C.4 System Feature Event Trigger Numbers Number Feature State Trigger Sensor 47 in alarm open Sensor 48 in alarm open Phone Test initiated Sensor 49 in alarm open...
  • Page 80 Appendix C: Reference Tables Notes for Table C.6 Response Numbers If an event does not trigger sirens, siren tracking response Table C.5 Response Characteristics numbers activate without turning on the output. If sirens are triggered by another event, the output pulses to match Response Description the siren.

  • Page 81: Programming Mode Menus And Settings

    Programming Mode Menus and Settings Programming Mode Menus and Settings To enter Programming Mode: 8 + Installer or Dealer Code + 0 + 0 TIER 1 MENUS TIER 2 MENUS Security Phones (Continued) System Programming CS Phone 3 Partition 2 CS Phone 2 Global Partition 1...
  • Page 82 Programming Mode Menus and Settings TIER 2 MENUS (cont.) Phone Options Phones (cont.) Pager Pager Pager Pager Pager Downloader Partition 2 Global Partition 1 Phone 1 Phone 2 Phone 3 Phone 4 Phone 5 Phone Local Phone Local Phone Phone Number Phone Number Phone Number Phone Number...
  • Page 83 Programming Mode Menus and Settings TIER 2 MENUS (cont.) Touchpad Timers Light Control Options Global Partition 1 Partition 2 Global Partition 1 Partition 2 Partition 1 Partition 2 Entry Delay Entry Delay Latchkey Zones Fire Panic Supervs. Time Entry Lights Entry Lights Fire Panic 32 secs (32-240...
  • Page 84 Programming Mode Menus and Settings TIER 2 MENUS (cont.) Reporting Sensors Siren Options Learn Delete Sensor Text Edit Sensors Partition 2 Global Partition 1 Global Partition 1 Sensors Sensors Sn P1 Gnn Text for Immediate Siren Verify Opening Rpts 24 Hour Tamper Opening Rpts Sensor Partition Delete Sensor...
  • Page 85 Programming Mode Menus and Settings TIER 2 MENUS (cont.) Audio Verification Accessory Modules Partition 1 Maximum of 16 Bus Devices SnapCards bus devices. Audio Verify Unit - ID On Off 0900 100nn (nn=00-15) Audio Mode 0901 Output Output Programming Text Fire Shutdown On Off 0902...
  • Page 86 Programming Mode Menus and Settings Press B to return TIER 2 MENUS to Security Menu. Onboard Options Output Output Inputs Text Programming Smoke Verify Output 1 Output 2 Output 1 Output 2 On Off 1121 1120 1100 Partition Partition Two-Wire Smk Output 1 Output 2 Assign...

  • Page 87: System Wiring Notes

    System Wiring Notes Note 1 Note 6 Class II power transformer must be plugged into an unswitched AC power re- For UL Listed installations, wire multiple supervised hardwire smoke detec- ceptacle. Do not short the transformer terminals together. The transformer tors (10 maximum) only as shown.

  • Page 88: System Wiring Diagram

    SYSTEM WIRING DIAGRAM ALL PANEL TERMINAL CONNECTIONS ARE CLASS II POWER LIMITED 8690G13A.DSF (See notes on other side.) ZONE 2-WIRE 2-WIRE SMOKE + 12 OUTPUT OUTPUT MIC. ZONE ZONE ZONE ZONE ZONE ZONE ZONE HOUSE HOUSE TELCO SMOKE TELCO POWER SPEAKER RING RING...

  • Page 89: Index

    Immediate Beeps 41 Program Report 39 user 50 Installer Code 25 programming COMM Failure 31 Downloader 56 Concord Key Beeps 47 programming menus basic commands 56 Keychain Star Is No Delay 37 Tier 2 Keychain Touchpad Arming Accessory Modules 45...
  • Page 90 Index System Master Code 51, 52 Quick Arm 26 System Tests 51 Quick Exit 26 System Time 50 System Version 55 Receiver Failure reports 38 Recent Closings 39 Temperature 47 relay outputs 47 testing Remote Access 32, 51 central station/pager com- Response Numbers 80 munication 57 RF Low Battery Report 38...

This manual is also suitable for:

Concord rf 2.0

Table of Contents

Save PDF
