Assembly — Attaching the Fan Blade
1
Attaching the fan blade to the fan

assembly

□ Attach the ve fan blades (A) to the fan motor assembly
(H) using the blade screws (AA) and ber washers (BB),
three for each blade. Tighten all screws securely.
NOTE: When installing the blades, ensure the sides with
"THIS SIDE UP" face the ceiling.
Assembly — Hanging the Fan
2
Attaching the mounting bracket to
the electrical box
WARNING: To reduce the risk of fire, electric shock, or
other personal injury, mount the fan only to an outlet box or
supporting system marked acceptable for fan support, and
use the mounting screws provided with the outlet box.
□
Place the slots from mounting bracket (B) over the two
screws provided with the outlet box. Slide the mounting
bracket (B) until it locks in place at the narrow section
of the slots.
□
Securely tighten the two mounting screws.
AA
BB
A
H
8
B
B
