Home Decorators DURANGO Use And Care Manual

52 inch ceiling fan

Advertisement

Quick Links

Item
#000-000
Model #SW1478 ORB
USE AND CARE GUIDE
DURANGO 52 INCH CEILING FAN
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. - 6 p.m., EST, Monday-Friday
1-877-527-0313
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DURANGO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Home Decorators DURANGO

  • Page 1 Item #000-000 Model #SW1478 ORB USE AND CARE GUIDE DURANGO 52 INCH CEILING FAN Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. - 6 p.m., EST, Monday-Friday 1-877-527-0313 HOMEDEPOT.COM/HOMEDECORATORS THANK YOU...
  • Page 2: Table Of Contents

    Table of Contents Operation ..............Table of Contents ............2 Remote Control Operating Instructions ......Safety Information ............2 Reverse Function Button Operating Instructions ....Installing the Remote Control Holder ......Warranty .................3 Care and Cleaning ............Pre-installation .............. Specifications ................Troubleshooting ............
  • Page 3: Warranty

    Warranty We warrant the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a period of 15 years after the date of purchase by the original purchaser. We also warrant that all other fan parts, excluding any glass or acrylic blades, to be free from defects in workmanship and material at the time of shipment from the factory for a period of one year after the date of purchase by the original purchaser.
  • Page 4: Hardware Included

    Pre-Installation (continued) HARDWARE INCLUDED NOTE: Hardware shown to actual size unless noted otherwise in the table below. Part Description Quantity Blade screw Fiber washer (not to scale) Blade holder screw Balance kit (not to scale) Remote control holder mounting screws Wire nuts Cross pin (not to scale) (preassembled) Hitch pin (preassembled)
  • Page 5: Package Contents

    Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Blade Blade holder Mounting bracket Light kit plate Canopy 17W LED asembly Canopy cover Glass shade Hanger ball (preassembled) Receiver Downrod (preassembled) Remote control Couping cover Remote control holder Fan motor assembly 12V Battery HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-877-527-0313 for further assistance.
  • Page 6: Installation

    Installation MOUNTING OPTIONS WARNING: To reduce the risk of fire, electric shock, or personal injury, mount the fan to an outlet box marked acceptable for fan support using the screws provided with the outlet box. An outlet box commonly used for the support of lighting fixtures may not be acceptable for fan support and may need to be replaced.
  • Page 7: Assembly

    Assembly — Hanging the Fan Attaching the downrod to the Attaching the mounting bracket to fan motor assembly the electrical box □ Loosen the two set screws (KK) from the fan motor WARNING: To reduce the risk of fire, electric shock, or assembly (H) coupling.
  • Page 8 Assembly — Hanging the Fan (continued) Attaching the coupling cover, canopy Hanging the fan motor assembly cover, and canopy to the downrod from the mounting bracket □ Slip the coupling cover (G), canopy cover (D), and canopy □ Lift the fan motor assembly (H) into position, and place the (C) onto the downrod (F).
  • Page 9 Assembly — Hanging the Fan (continued) Preparing the receiver and remote control WARNING: To avoid possible electrical shock, ensure the electricity is turned off at the main fuse box before wiring. CAUTION: Do not use with a wall light dimmer switch. If you feel you do not have enough electrical NOTE: wiring knowledge or experience, have your fan installed...
  • Page 10: Making The Electrical Connections

    Assembly — Hanging the Fan (continued) Making the electrical connections WARNING: To avoid possible electrical shock, ensure the electricity is turned off at the circuit breaker or main fuse box before wiring. WARNING: Check to see that all connections are tight, including the ground, and that no bare wire is visible at the Black White...
  • Page 11 Assembly — Hanging the Fan (continued) Securing the fan motor assembly to the mounting bracket □ Remove one screw (LL) from the mounting bracket (B) and loosen the other screw (LL) approximately 1/4 turn. □ Carefully raise the canopy (C) up to the mounting bracket (B), and ensure the loosened screw (LL) is inserted into the key hole on the canopy (C).
  • Page 12: Attaching The Fan Blades

    Assembly — Attaching the Fan Blade Assemblies Fastening the blade assemblies to the fan motor assembly □ Attach the fan blades (A) to the blade holders (I) by using three blade screws (AA) and ber washers (BB). Tighten screws (AA) and ber washers (BB) securely. □...
  • Page 13: Installing The Light Kit

    Assembly — Installing the Light Kit Attaching the light kit plate Attaching the 17W LED Assembly to the mounting ring to the light kit plate □ □ Remove one of three screws (MM) from the fan motor Remove one of three screws (NN) from the light kit assembly (H) mounting ring, and loosen the other two plate (J), and loosen the other two screws (NN), but do screws (MM), but do not remove.
  • Page 14 Assembly — Installing the Light Kit (continued) Installing the glass shade □ Attach the glass shade (L) to the light kit plate (J) by twisting tightly.
  • Page 15: Operation

    Operation REMOTE CONTROL OPERATING INSTRUCTIONS Install a 12V battery (P) into the remote control (N). To prevent damage to the remote control, remove the battery if not used for long periods of time. WARNING: Do not short-circuit, disassemble, heat up, connect improperly, or dispose of used batteries in re.
  • Page 16: Installing The Remote Control Holder

    Operation (continued) INSTALLING THE REMOTE CONTROL HOLDER □ Attach the remote control holder (O) with the two remote control holder mounting screws (EE). Care and Cleaning Do not □ □ Check the support connections, brackets, and blade Do not use water when cleaning. Water could damage the attachments twice a year.
  • Page 17: Troubleshooting

    Troubleshooting WARNING: Ensure the power is off at the electrical panel box before you attempt any repairs. Refer to the section “Making the Electrical Connections” on page 11. Problem Solution □ Check main and branch circuit fuses or breakers. □ Check line wire connections to the fan and switch wire connections in the switch housing.
  • Page 18: Service Parts

    Service Parts Part Description Part Description Blade Blade screw Mounting bracket Fiber washer Canopy Blade holder screw Canopy cover Balance kit Hanger ball Remote control holder mounting screws Downrod Wire nuts Coupling cover Cross pin Hitch pin Fan motor assembly Blade holder Lock pin Light kit plate...
  • Page 19 Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. - 6 p.m., EST, Monday-Friday 1-877-527-0313 HOMEDEPOT.COM/HOMEDECORATORS Retain this manual for future use.
