Assembly — Hanging the Fan (continued)
8
Securing the fan motor assembly to the mounting bracket
Remove one screw (KK) from the mounting bracket (B) and loosen the other screw (KK) approximately 1/4 turn.
Carefully raise the canopy (C) up to the mounting bracket (B), and ensure the loosened screw (KK) is inserted into the key hole on
the canopy (C). Rotate the canopy (C) clockwise.
Secure the canopy (C) by replacing the screw (KK) previously removed and tightening the screw (KK) previously loosened.
Place the canopy cover (D) on the canopy (C), and rotate the canopy cover (D) clockwise until it locks into position.
B
KK
12
KK
C
D
