Quick start guide
TL92273/TL92373/TL92473
This quick start guide provides you with basic instructions only.
For more complete instructions, refer to the Abridged user's
manual provided in the package, or see the Complete user's
manual at www.telephones.att.com/manuals.
Parts checklist
Your package contains:
• Handset • Battery compartment cover
(2 for TL92273) (2 for TL92273)
(3 for TL92373) (3 for TL92373)
(4 for TL92473) (4 for TL92473)
• Charger with power adapter • Battery
(1 for TL92273) (2 for TL92273)
(2 for TL92373) (3 for TL92373)
(3 for TL92473) (4 for TL92473)
• Telephone base • Wall mount bracket
• Telephone line cord • Abridged user's manual
• Telephone base power adapter • Quick start guide
Basic steps to set up & operate your phone
Basic installation
1 Install telephone base & charger
Install handset battery
2
Install telephone base on the wall (optional)
3
Common settings
Set date and time
4
Set ringer volume
5
Add a Bluetooth cell phone / headset
6
Download a cell phone directory
7
Record own announcement
8
9 Set number of rings
Common operations
10 Directory
11 Caller ID
1
Install telephone base & charger
Click!
Plug!
DSL filter
If you have DSL high-speed
Plug!
Internet service, a DSL filter
(not included) is required.
Click!
Plug!
2
Install handset battery
1 2 3
Plug!
4
• Charge for at least 30 minutes
before initial settings.
• Charge for 11 hours before initial
use.
Light on!
3
Install telephone base on the wall (optional)
Follow the instructions below only if you would like to mount the
telephone on a wall.
1 2
Align!
Unplug!
Unplug!
Align!
3
Plug!
If you have DSL high-speed
Internet service, a DSL filter
(not included) is required.
4 5
Align!
Align!
INSTALLATION COMPLETED!
Keep reading for common settings and operations.
4
Set date and time
Set the date/time before using the answering system.
Using a cordless handset:
1. Press MENU -> Press q/p to Set date/time -> Press SELECT.
2. Enter the month (MM), day (DD) and year (YY) -> Press NEXT.
3. Enter the hour (HH) and minute (MM).
4. Press q/p to choose AM or PM -> Press SAVE.
5
Set ringer volume
You can set the ringer volume level to one of the six levels or turn the
ringer off.
Using a cordless handset:
1. Press MENU -> Press q/p to Ringers -> Press SELECT.
2. Press SELECT to select Ringer volume.
3. Press q/p to choose the desired level -> Press SET.
6
Add a Bluetooth cell phone / headset
To use a Bluetooth enabled cellular phone or headset with your
telephone, you must first pair and connect your Bluetooth cellular phone
or headset with the telephone base.
Bluetooth wireless technology operates within a short range (up to 30
feet). Keep the connected device within 15 feet of the telephone base for
optimal performance.
Click!
To pair and connect a cell phone using a cordless handset:
1. Press MENU -> Press q/p to Bluetooth -> Press SELECT.
2. Press SELECT to select Add device.
3. Press SELECT to select Add cellular.
4. Disconnect the cell phone from any Bluetooth device -> Press NEXT.
5. Place the cell phone next to the telephone base.
NEXT
6. Press to turn on the telephone base discoverable mode.
7. Turn on the Bluetooth feature of your cell phone and search for or
add new advices. Once your cell phone finds your AT&T phone (AT&T
DECT 6.0), press the appropriate key on your cell phone to continue
the pairing process.
• Enter the cell phone passcode (typically 0000) if required ->
Press SET.
• Enter the PIN (default PIN: 0000) of the telephone base into your
cell phone if required.
To pair and connect a headset using a cordless handset:
1. Press MENU -> Press q/p to Bluetooth -> Press SELECT.
2. Press SELECT to select Add device.
3. Press q/p to Add headset -> Press SELECT.
4. Disconnect your headset from any Bluetooth device -> Press NEXT.
5. Set your headset to discoverable mode -> Press NEXT.
6. Press q/p to choose your headset if required -> Press SELECT.
• Enter the PIN (typically 0000) of your headset if required and
press NEXT.
