TS SPECS
Resonant Frequency (fs)
DC Resistance (Re)
Mechanical (Qms)
Electromagnetic (Qes)
Total Q (Qts)
Compliance Equivalent Volume (Vas)
Mechanical Compliance of Suspension (Cms)
BL Product (Bl)
Diaphragm Mass inc. Airload (Mms)
Sound Pressure Level (SPL)
X-Max
It is recommended to build your enclosure from at least 3/ 4" thick MDF (medium density fiber-
board). Make sure the enclosure is sealed airtight.

Calculating External Volume

To calculate box volume, measure the outside Width x Height x Depth of
the enclosure. Example 12" x 14" x 9"=1512 ÷ 1728" Cubic feet
Next you must convert cubic inches into cubic feet. To do this, you must
divide the cubic inches total by 1728". Example 1512 ÷ 1728=.875 Cubic feet

Calculating Internal Volume

To calculate the internal (net) volume of the above box you must first multiply
the thickness of the wood you are using by Two(2). Example 3/4" x 2= 1.5"
Next subtract 1.5 from each of the outside measurements of the box.
12 - 1.5 = 10.5
Multiple the new totals (H x W x D) Example: 10.5 x 12.5 x 7.5 = .5696
Next you must convert cubic inches into cubic feet. To do this, you must
divide the cubic inch total by 1728". Example 984.375 ÷ 1728=.5696
cubic feet.

PRODUCT SPECIFICATIONS

CALCULATING ENCLOSURES

Width
WDX12 3KD2
47.87 Hz
14.61 mM
39.49 mm/N
Height
14 - 1.5 = 12.5
WDX15 3KD2
1.8 Ω x 2
3.81
0.67
0.57
32.35 mm/N
21.19 T
279.86 g
85.6 dB
13.5 mm
Depth
9 - 1.5 = 7.5
46.40Hz
1.8 Ω x 2
3.58
0.82
0.66
34.80 mM
21.55 T
363.63 g
88.1 dB
13.5 mm
