Product End-of-Life Disassembly Instructions
Product Category: Notebooks and Tablet PCs
Marketing Name / Model
[List multiple models if applicable.]
HP Elitebook 820 G2 Notebook PC
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions
for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU
directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as
applicable.
Item Description
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
Batteries
Mercury-containing components
Liquid Crystal Displays (LCD) with a surface greater
than 100 sq cm
Cathode Ray Tubes (CRT)
Capacitors / condensers (Containing PCB/PCT)
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
External electrical cables and cords
Gas Discharge Lamps
Plastics containing Brominated Flame Retardants
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Components and waste containing asbestos
Components, parts and materials containing
refractory ceramic fibers
EL-MF877-00
Template Revision B
Notes
With a surface greater than 10 sq cm
All types including standard alkaline and lithium coin
or button style batteries
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries
Includes background illuminated displays with gas
discharge lamps
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
PSG instructions for this template are available at
EL-MF877-01
Quantity
of items
included
in product
1
2
0
1
0
0
0
0
0
0
0
0
0
Page 1

Advertisement

   Related Manuals for HP EliteBook 820 G2

   Summary of Contents for HP EliteBook 820 G2

  • Page 1

    Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).

  • Page 2

    Components, parts and materials containing radioactive substances 2.0 Tools Required List the type and size of the tools that would typically be used to disassemble the product to a point where components and materials requiring selective treatment can be removed. Tool Description Tool Size (if applicable)

  • Page 3

    MANUFACTURING PROCESS INSTRUCTIONS MECHANICAL ASSEMBLY MODEL :Snicker FA DIS ASS‘Y Sub-assembly name: Document No.: Snicker FA DIS ASS'Y SOP Written by: Nydia Lee Revision: Date: 2014/11/12 Page: A. Current station version list Station Ver. Station Ver. Station Ver. Station Ver. B.

  • Page 4

    Standard Operation Procedure Document No. : Snicker FA DIS ASS’Y SOP 1(1/1) Station : 2014/11/12 Disassemble Service Door Name Ver. : Date Step: 1. Press and slide the release button to left, at the same time, slide the service door downward.

  • Page 5

    Standard Operation Procedure Document No. : Snicker FA DIS ASS’Y SOP 2(1/1) Station : 2014/11/12 Name Ver. : Date Disassemble Battery Step: 1. Slide the two knobs to the unlocked position. (Fig.1) 2. Disassemble the battery. (Fig.2) “Unlocked” Fig.1 Fig.1 Fig.2 Notes : If finding anything uncommon, notice foreman or assistant at once.

  • Page 6

    Standard Operation Procedure Document No. : Snicker FA DIS ASS’Y SOP 3(1/1) Station : 2014/11/12 Name Disassemble HDD Ver. : Date Step: 1. Loosen HDD bracket set screw * 4. 2. Disassemble the HDD. Fig.1 Notes : If finding anything uncommon, notice foreman or assistant at once. Holding fixture list (holding fixture standard) Holding fixture list (holding fixture standard) Electric cross screwdriver(#1)

  • Page 7

    Standard Operation Procedure Document No. : Snicker FA DIS ASS’Y SOP 4(1/1) Station : 2014/11/12 Name Ver. : Date Disassemble SSD Card & DDR Step: 1. Loosen screw * 1, then disassemble SSD card. (Fig.1) 2. Disassemble DDR. (Fig.2) Fig.1 Fig.2 Notes : If finding anything uncommon, notice foreman or assistant at once.

  • Page 8

    Standard Operation Procedure Document No. : Snicker FA DIS ASS’Y SOP 5(1/1) Station : 2014/11/12 Name Disassemble WWAN card Ver. : Date Step: 1. Disassemble WWAN cable. (Fig.1) 2. Loosen screw * 1. (Fig.2) 3. Disassemble the WWAN. (Fig.3) Fig.1 Fig.2 Fig.3 Notes : If finding anything uncommon, notice foreman or assistant at once.

  • Page 9

    Standard Operation Procedure Document No. : Snicker FA DIS ASS’Y SOP 6(1/1) Station : 2014/11/12 Name Loosen Bottom Case Screws Ver. : Date Step: 1. Loosen screw * 3. (Fig.1) Fig.1 2. Loosen KB set screw * 2. (Fig.2) Fig.1 Fig.2 Notes : If finding anything uncommon, notice foreman or assistant at once.

  • Page 10

    Standard Operation Procedure Document No. : Snicker FA DIS ASS’Y SOP 7(1/1) Station : 2014/11/12 Name Disassemble WLAN Card & CNTR Ver. : Date Step: Fig.1 1. Disassemble WLAN cable, loosen screw * 1, disassemble the WLAN. (Fig.1/Fig.2) 2. Disassemble e-DP CNTR. (Fig.3) Fig.2 Fig.3 Notes : If finding anything uncommon, notice foreman or assistant at once.

  • Page 11

    Standard Operation Procedure Document No. : Snicker FA DIS ASS’Y SOP 8(1/1) Station : 2014/11/12 Name Loosen Bottom Case Screws Ver. : Date Step: 1. Loosen bottom case screw * 4 (M2.5*4). (Fig.1) Fig.1 Fig.1 Fig.2 Fig.1 Notes : If finding anything uncommon, notice foreman or assistant at once. Holding fixture list (holding fixture standard) Holding fixture list (holding fixture standard) Electric cross screwdriver(#1)

  • Page 12

    Standard Operation Procedure Document No. : Snicker FA DIS ASS’Y SOP 9(1/1) Station : 2014/11/12 Name Loosen Bottom Case Screws Ver. : Date Step: 1. Loosen bottom case screw * 10. (Fig.1) Fig.1 Fig.1 Fig.2 Fig.1 Notes : If finding anything uncommon, notice foreman or assistant at once. Holding fixture list (holding fixture standard) Holding fixture list (holding fixture standard) Electric cross screwdriver(#1)

  • Page 13

    Standard Operation Procedure Document No. : Snicker FA DIS ASS’Y SOP 10(1/1) Station : 2014/11/12 Name Ver. : Date Disassemble Keyboard Step: 1. Open BASE unit (30 °)(Fig.1), poke the position (marked in red circle) by T8 screwdriver. (Fig.2) 2. Open the machine and disassemble keyboard. (Fig.3) Fig.1 Fig.2...

  • Page 14

    Standard Operation Procedure Document No. : Snicker FA DIS ASS’Y SOP 11(1/1) Station : 2014/11/12 Name Ver. : Date Release CNTR and FFC Step: 1. Disassemble backlight FFC, KB FFC, Stickpoint FFC CNTR. (Fig.1) 2. Disassemble power FFC, smart card FFC, finger/B FFC CNTR.

  • Page 15

    Standard Operation Procedure Document No. : Snicker FA DIS ASS’Y SOP 12(1/1) Station : 2014/11/12 Name Loosen Screws and Disassemble Top Case Ver. : Date Step: Fig.1 1. Loosen TOP CASE screw (M2.5*4) * 2. (Fig.1) 2. Disassemble TOP CASE. (Fig.2) Fig.2 Notes : If finding anything uncommon, notice foreman or assistant at once.

  • Page 16

    Standard Operation Procedure Document No. : Snicker FA DIS ASS’Y SOP 13(1/1) Station : 2014/11/12 Name Loosen M/B Screws Ver. : Date Step: 1. Loosen MB screw * 3 (M2*3). (Fig.1) 2. Loosen thermal module screw *4 & FAN SET screw * 2.

  • Page 17

    Standard Operation Procedure Document No. : Snicker FA DIS ASS’Y SOP 14(1/1) Station : 2014/11/12 Name Disassemble Speaker & Fan CNTR Ver. : Date Step: Speaker cable CNTR 1. Disassemble speaker CNTR & FAN CNTR. (Fig.1) 2. Put the MB/TOP module in the bag. Fig.1 FAN cable CNTR Fig.2...

  • Page 18

    Standard Operation Procedure Document No. : Snicker FA DIS ASS’Y SOP 15(1/1) Station : 2014/11/12 Name Ver. : Date Disassemble Cable Routing on Base Step: 1. Put the machine on support fixture. (Fig.1) 2. Disassemble WLAN/WWAN cable. (Fig.2) Fig.1 Fig.2 Mylar Notes : If finding anything uncommon, notice foreman or assistant at once.

  • Page 19

    Standard Operation Procedure Document No. : Snicker FA DIS ASS’Y SOP 16(1/1) Station : 2014/11/12 Name Ver. : Date Loosen Hinge Screws Step: 1. Put the machine on support fixture. (Fig.1) 2. Loosen screw * 4, separate LCM and BU. (Fig.2) Fig.1 Fig.2...
