Table of Content
Quick Installation ................................................ 4
1.1 Layout............................................................................ 4
1.2 Item Checklist ............................................................... 5
1.3 Jumpers ........................................................................ 5
1.4 Connectors ................................................................... 8
1.5 Form Factor................................................................. 16
Feature................................................................ 18
2.1 Motherboard Components Placement ..................... 18
2.2 Block Diagram ............................................................ 20
2.3 Specifications ............................................................. 21
Hardware Setup ................................................. 24
3.1 Before Installation ...................................................... 24
3.2 Install the Processor .................................................. 25
3.3 Install Memory Modules ............................................ 26
3.5 ATX Power Supply connector ................................... 28
3.6 Back Panel .................................................................. 30
FB11351000000
KV200/KV200-R Version 1.1A
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the kv200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IWILL kv200

Summary of Contents for IWILL kv200

  • Page 1: Table Of Contents

    2.3 Specifications ............. 21 Hardware Setup ..........24 3.1 Before Installation ............24 3.2 Install the Processor ..........25 3.3 Install Memory Modules ..........26 3.5 ATX Power Supply connector ........28 3.6 Back Panel ..............30 FB11351000000 KV200/KV200-R Version 1.1A...
  • Page 2 4.8 Power Management Setup ......... 60 4.9 PnP/ PCI Configurations ..........66 4.10 PC Health Status ............69 4.11 Iwill Smart Setting ............. 70 4.12 Load Fail Safe Defaults ..........73 4.13Load Optimized Defaults .......... 74 4.14 Set Supervisor/ User Password Setting ....75 4.15 Save &...
  • Page 3 Chapter 1 Quick Installation On board Audio ..........6.1 Audio Features ............119 6.2 Driver Installation ............120 6.3 The Audio Rack ............124 6.4 The Application Program Setup ......134 6.5 About Recording 24bit Audio Setting ..... 139 6.6 SPDIF/IN (SPDIF version only) ........ 144 6.7 Loopback (bypass) mode Setup ......

  • Page 4: Quick Installation

    Chapter 1 Quick Installation 1 Quick Installation 1.1 Layout...

  • Page 5: Item Checklist

    Chapter 1 Quick Installation 1.2 Item Checklist [√] The motherboard [√] Operation manual [√] 40-pin ATA/66 cable [√] Floppy cable [√] Power Installer CD Optional USB riser kit Thermal Sensor for System Display Cache Riser Card Infrared port cable Display Cache Riser Card Optional Module (SPDIF version only) 1.3 Jumpers 1.3.1 Clear CMOS jumper(CMOS)
  • Page 6 Chapter 1 Quick Installation 1.3.2 PCI compatibility jumper 1.3.3 IDE RAID jumper(KV200-R Only)
  • Page 7 Chapter 1 Quick Installation 1.3.4 Audio jumper...

  • Page 8: Connectors

    Chapter 1 Quick Installation 1.4 Connectors 1.4.1 CPU fan header (J41) 1.4.2 Auxiliary fan header(J39) 1.4.3 System fan header (J40)
  • Page 9 Chapter 1 Quick Installation 1.4.4 Infrared connector (IR) 1.4.5 Wake-ON-LAN header...

  • Page 10: Smbus Connector

    Chapter 1 Quick Installation 1.4.6 Wake On Moden 1.4.7 SmBus connector...
  • Page 11 Chapter 1 Quick Installation 1.4.8 ATX power connector (J37)
  • Page 12 Chapter 1 Quick Installation 1.4.9 Front panel connector (J43)
  • Page 13 Chapter 1 Quick Installation...

  • Page 14: Internal Usb Connector

    Chapter 1 Quick Installation 1.4.10 Aux-In connector(Aux_IN) 1.4.11 CD_In connector(CD_IN) 1.4.12 Internal USB connector The motherboard has two USB ports onboard. The extra two USB support can only functionable with the additional USB riser kit.
  • Page 15 Chapter 1 Quick Installation 1.4.15 Internal connector for COM port. 1.4.16 SPDIF connector(Optional)

  • Page 16: Form Factor

    Chapter 1 Quick Installation 1.5 Form Factor...
  • Page 17 Chapter 1 Quick Installation...

  • Page 18: Feature

    Chapter 2 Feature 2 Features 2.1 Motherboard Components Placement...
  • Page 19 Chapter 2 Feature ) y l ) y l c i t i d i e l l...

  • Page 20: Block Diagram

    Chapter 2 Feature 2.2 Block Diagram...

  • Page 21: Specifications

    Chapter 2 Feature 2.3 Specifications Processor I/F (Socket A) Supports 1 processor through Socket A Supports DDR_200MHz FSB (Front Side Bus) Supports AMD Duron CPU from 600 MHz to 700 MHz Supports AMD Athlon (T-Bird) CPU from 750 MHz to 1GHz CPU Frequency/Voltage Select Supports CPU VIO adjustable by BIOS Supports CPU Multiplier selection by BIOS...
  • Page 22 Supports Floppy interface Supports 16550A UART interface Supports ECP/EPP interface Supports PS2 interface Supports SIR interface Supports USB interface RAID onboard (KV200-R only) Supports 2 ATA100 channels Supports RAID Level 0/1 Supports Win9X/WinNT/Win2K Sound support C-Media HW Sound controller on board...
  • Page 23 Chapter 2 Feature Supports DMI Supports PnP Supports BIOS ROM Flash Control H/W & S/W protection Supports Suspend to RAM (STR) Supports Manually Assign PCI IRQ Others ATX Form Factor 305mm x 227mm...

  • Page 24: Hardware Setup

    Chapter 3 Hardware Setup Hardware Setup 3.1 Before Installation For installation, you may need some or all of the following tools: Medium size flat blade screwdriver Medium size Phillips head screwdriver A 3/16 inch nut driver or wrench o l l n i l t a l k i l...

  • Page 25: Install The Processor

    Chapter 3 Hardware Setup 3.2 Install the Processor...

  • Page 26: Install Memory Modules

    Chapter 3 Hardware Setup 3.3 Install Memory Modules The motherboard has three Dual Inline Memory Module (DIMM) sockets and supports the maximum memory size up to 1.5GB. These DIMM sockets only support 3.3V unbuffered SDRAM modules. The motherboard also support SPD (Serial Presence Detect) architecture to provide the best choice for performance vs.
  • Page 27 Chapter 3 Hardware Setup Step 3:Insert the RAM module into the DIMM socket. Step 4:Press the latches into the notches of the RAM module.

  • Page 28: Atx Power Supply Connector

    Chapter 3 Hardware Setup 3.5 ATX Power Supply Connector 3.5.1 Power on procedures t p i c t i . f f t e l c t i c t i o l l t i n...
  • Page 29 Chapter 3 Hardware Setup l l i l l i l l i 3.5.2 Power off procedures t p i l l a c i l c t i c i t y l l l l a...

  • Page 30: Back Panel

    Chapter 3 Hardware Setup 3.6 Back Panel l a i . t r l a i l a i l a i l e l t n i l e l c i t t i d . o i c i t i d i o l l...
  • Page 31 Chapter 3 Hardware Setup l l i...

  • Page 32: Bios Setup

    Chapter 4 BIOS Setup BIOS Setup 4.1 PhoenixNet Introduction PhoenixNet is a service that provides PC users with best-of-breed, free, software services to support their PC hardware and software and to turn their computer into a powerful tool for communication, entertainment, education and business 4.1.1 Internet Launch System The PhoenixNet Internet Launch System (ILS) is a patent-...
  • Page 33 Chapter 4 BIOS Setup 4.1.3 PhoenixNet Online Services & i t n r i v i t c ¡K : s l...
  • Page 34 Chapter 4 BIOS Setup 4.1.4 User Boot f n i 4.1.5 Internet Access & t l u & l i a s l l c i l . l i...

  • Page 35: Bios Setup

    4.2.1 Upgrade BIOS The BIOS can be upgraded from a diskette with the Award Flash utility — AWDFLASH.EXE. The BIOS image file, and update utility are available from IWILL’s WEB site: www. iwill.net 4.2.2 Enter BIOS setup program Power-on the system by either pressing the Power-On button, or by using any of the power-on features provided by the motherboard.
  • Page 36 Chapter 4 BIOS Setup 4.2.3 Using BIOS setup program ! Up Move to the previous field " Down Move to the next field Move to the field on the left hand # Left side Move to the field on the right hand $ Right side Quit from setup program without...

  • Page 37: Main Menu

    Chapter 4 BIOS Setup 4.3 Main Menu The main menu allows you to select from several setup pages. Use the arrow keys to select among these pages and press <Enter> key to enter the sub-menu. A brief description of each highlighted selection appears at the bottom of the screen.

  • Page 38: Standard Cmos Features

    Chapter 4 BIOS Setup 4.4 Standard CMOS Features 4.4.1Date This field specifies the current date. The date format is <month>, <day>, and <year>. 4.4.2 Time This field specifies the current time. The time format is <hour>, <minute>, and <second>. The time is calculated based on the 24-hour (military-time) clock.
  • Page 39 Chapter 4 BIOS Setup 4.4.3 IDE Primary Master / Primary Slave / Secondary Master / Secondary Slave Press “Enter” to enter next page for detail hard drive setting. 4.4.3.1 IDE HDD Auto-Detection Auto-Detect the HDDs Capacity, and its parameters, ex: Cylinder, Head and Sector. 4.4.3.2 IDE Primary Master / Primary Slave / Secondary Master / Secondary Slave This field specifies type of drive that corresponds to...
  • Page 40 Chapter 4 BIOS Setup 4.4.3.5 Cylinders Set the number of cylinders for this hard disk. 4.4.3.6 Heads Set the number of read/write heads 4.4.3.7 Precomp Setting a value of 65535 means no hard disk 4.4.3.8 Sectors Set the number of sectors per track 4.4.4 Drive A / Drive B This field specifies the traditional type of floppy drives.
  • Page 41 Chapter 4 BIOS Setup 4.4.6 Video f i c f i c 4.4.7 Halt On l a t l l i l l i , l l l l i , l l l l i , l l...

  • Page 42: Base Memory

    Chapter 4 BIOS Setup 4.4.8 Base Memory The POST (Power-On Self Test) determines the amount of base (conventional) memory installed in the system. The value of the base memory is typically 640K. This field has no options. 4.4.9 Extended Memory The BIOS determines how much extended memory is present during the POST.

  • Page 43: Advanced Bios Features

    Chapter 4 BIOS Setup 4.5 Advanced BIOS Features...

  • Page 44: Virus Warning

    Chapter 4 BIOS Setup 4.5.1 Virus Warning When this function is enabled, the BIOS monitor the boot sector and partition table of the hard disk drive for any attempt at modification. If an attempt is made, the BIOS will halt the system and then display an error message. Afterwards, if necessary, you can run an anti-virus program to locate and remove the problem before any damage is done.

  • Page 45: Quick Power On Self Test

    Chapter 4 BIOS Setup 4.5.5 Quick Power On Self Test This field allows the system to skip certain tests while booting. This will decrease the time needed to boot the system. 4.5.6 First / Secondary / Third / Other Boot Device The BIOS attempts to load the operating system from the devices in the sequence selected in these items.

  • Page 46: Gate A20 Option

    Chapter 4 BIOS Setup 4.5.11Gate A20 Option This field configures how the gate A20 is handled. The gate A20 is a device used to address memory above 1 MB. At first, the gate A20 was handled from a pin on the keyboard. While some keyboards still provide this support, it is more common, and much faster, for modern system chipsets to provide support for gate A20.

  • Page 47: Security Option

    Chapter 4 BIOS Setup 4.5.14Typematic Delay (Msec) When enabled, typematic delay allows you to select the time delay between when the key is first pressed and when the acceleration begins. 4.5.15Security Option This field configures how the system security is handled. It works conjunction with SETTING SUPERVISOR / USER PASSWORD page to control the security level of the system.

  • Page 48: Video Bios Shadow

    Chapter 4 BIOS Setup 4.5.18Video BIOS Shadow When enabled, the video BIOS will be copied to system memory and increase the video speed. 4.5.19C8000-CBFFF/CC000-CFFFF/D0000-D3FFF Shadow D4000-D7FFF/D8000-DBFFF/DC000-DFFFF Shadow , e l...

  • Page 49: Advanced Chipset Features

    Chapter 4 BIOS Setup 4.6 Advanced Chipset Features This setup page is used to specify advanced features available through the chipset. The default settings have been chosen carefully for most operating conditions. DO NOT change the value of any field in this setup page without full understanding.

  • Page 50: Sdram Cycle Length

    Chapter 4 BIOS Setup DRAM Settings The first chipset settings deal with CPU access to dynamic random access memory (DRAM). The default timings have been carefully chosen and should only be altered if data is being lost. Such a scenario might well occur if your system had mixed speed DRAM chips installed.

  • Page 51: Memory Hole

    Chapter 4 BIOS Setup 4.6.4 Memory Hole In order to improve performance, certain space in memory is reserved for ISA cards. This memory must be mapped into the memory space below 16MB. 4.6.5PCI Dynamic Bursting When enabled, every write transaction goes to the write buffer, and burstable transactions will then burst on the PCI bus, and non-burstable transactions won’t burst on the PCI bus.

  • Page 52: Video Ram Cacheable

    Chapter 4 BIOS Setup 4.6.8 Video RAM Cacheable When enabled, access to the video memory located at A0000H to BFFFFH will be cached. 4.6.10 AGP Aperture Size This field specifies the size of system memory that can be used for AGP graphics aperture. 4.6.11AGP-4X Mode This item allows you to enable/disable the AGP-4X Mode.

  • Page 53: Integrated Peripherals

    Chapter 4 BIOS Setup 4.7 Integrated Peripherals...
  • Page 54 Chapter 4 BIOS Setup 4.7.1 On-Chip Primary IDE Channel 0 This field enables or disables the onboard IDE controller. 4.7.2 On-Chip SecondaryIDE Channel 1 This field enables or disables the onboard IDE controller. 4.7.3 Primary Master / Slave PIO Secondary Master / Slave PIO These fields configure the PIO (Programmable Input Output) transfer mode for each IDE devices.

  • Page 55: Init Display First

    Chapter 4 BIOS Setup 4.7.4Primary Master / Slave UDMA Secondary Master / Slave UDMA If you select Auto, the IDE controller uses Ultra DMA 33/66 Mode to access Ultra DMA-capable IDE devices. 4.7.5 Init Display First This item allows you to decide which slot to activate first, either PCI slot or AGP slot.

  • Page 56: Ide Hdd Block Mode

    Chapter 4 BIOS Setup 4.7.6.4 SB DMA Use Select This item allows you to selec sound blaster DMA channel. 4.7.6.5 MIDI Port This item allows you to selec MIDI Port enable/ disable. , e l 4.7.6.6 MIDI Address Port This item allows you to selec MIDI Port I/O address. 4.7.6.7 Game port Address This item allows you to select game port enable/ disable.

  • Page 57: Onboard Fdc Controller

    Chapter 4 BIOS Setup 4.7.9Onboard FDC Controller This field enables or disables the onboard floppy controller. 4.7.10Onboard Serial Port 1 / 2 These fields configure the onboard serial ports. There are several port addresses and IRQ channels to select from. c i t .

  • Page 58: Onboard Parallel Port

    Chapter 4 BIOS Setup 4.7.11.2IX, RX inverting enable 4.7.12 Onboard Parallel Port This field configures the onboard parallel port. There are several port addresses and IRQ channels to select from. l e l 4.7.13Parallel Port Mode This field configures the operating mode of an onboard parallel port.

  • Page 59: Epp Mode Select

    Chapter 4 BIOS Setup 4.7.15EPP Mode Select When the Parallel Port Mode field is configured as EPP, ECP+EPP mode, the EPP version needs to be specified. Please refer to ypur peripheral document before selecting field.

  • Page 60: Power Management Setup

    Chapter 4 BIOS Setup 4.8 Power Management Setup Each power-saving mode has a respective timer. The value of the timer can be assigned or reloaded and it will count down to zero. When the timer equals to zero, the system will be forced into the related suspend or power-saving mode.

  • Page 61: Power Management

    Chapter 4 BIOS Setup 4.8.1Power Management This feature allows the user to select the default parameters for the power-saving mode. f i f y f i 4.8.1.1 APM HDD Power Down Timer This field specifies the time the system enters HDD power down.

  • Page 62: Acpi Suspend Type

    Chapter 4 BIOS Setup 4.8.2 ACPI Suspend Type There are several ACPI modes used to save computer’s energy. l l a l l i l l a . f f 4.8.3 PM Control by APM When enabled, an Advanced Power Management (APM) protocol will be activated to handle the power-saving mode.

  • Page 63: Video Off Method

    Chapter 4 BIOS Setup 4.8.5 Video off Method c i t t i n l a i n i l 4.8.6MODEM Use IRQ This determines the IRQ in which the Modem can use. 4.8.7 PWR-Off Mode by PWR-BTTN This field specifies the function of power button. 4.8.8 Wake Up Events These are I/O events whose occurrence can prevent the system from entering a power-saving mode, or can awaken...
  • Page 64 Chapter 4 BIOS Setup 4.8.8.1 VGA When ON, your can set the VGA to awaken the system. 4.8.8.2 LPT & COM When On, any activity from one of the listed system peripheral devices or IRQs wakes up the system. 4.8.8.3 HDD & FDD When On, any activity from either hard disk drive or floppy disk drive wakes up the system.
  • Page 65 Chapter 4 BIOS Setup 4.8.8.7 PWROn/Resume by Alarm When enabled, you can set the date and time to automatically power-on your PC (similar to an alarm clock). The alarm from RTC (real-time clock) automatically turns on the system. , n i 4.8.8.8 Primary INTR t l u 4.8.8.9Primar INTR...

  • Page 66: Pnp/ Pci Configurations

    Chapter 4 BIOS Setup 4.9 PnP/ PCI Configurations...

  • Page 67: Pnp Os Installed

    Chapter 4 BIOS Setup 4.9.1 PNP OS Installed The field specifies whether a Plug and Play operating system is installed. 4.9.2 Reset Configuration Data Normally, you leave this field Disabled. Select Enabled to reset Extended System Configuration Data (ESCD) when you exit Setup if you have installed a new add-on and the system reconfiguration has caused such a serious conflict that the operating system can not boot.
  • Page 68 Chapter 4 BIOS Setup 4.9.3.1 IRQ Resources When resources are controlled manually, assign each system interrupt a type, depending on the type of device using the interrupt. 4.9.3.1.1IRQ3/4/5/7/9/10/11/12/14/15 assigned to 4.9.4 PCI / VGA Palette Snoop This field controls the ability of a primary PCI graphics controller to share a common palette with an ISA/VESA video or MPEG card.

  • Page 69: Pc Health Status

    Chapter 4 BIOS Setup 4.10 PC Health Status This page is monitoring your status of computer. On the screen displays CPU/System temperature, FAN speed, and voltages.

  • Page 70: Iwill Smart Setting

    Chapter 4 BIOS Setup 4.11 Iwill Smart Setting...
  • Page 71 Chapter 4 BIOS Setup 4.11.1 Iwill MicroStepping MicroStepping Microstepping is Iwill's anther step forward to provides users a fuss free CPU frequency set up procedure. It contains two main functions, Auto Detecting CPUs speed and Micro Adjustable CPU FSB speed.
  • Page 72 Chapter 4 BIOS Setup 4.11.2VIO Voltage Setting 4.11.2BIOS-ROM Flash Protect The main function of BIOS-ROM Flash Protect prevents the virus of computers to destory the system of computers. When JP16 is set on 1-2 , the Flash ROM pretection mode will be controlled by this field.

  • Page 73: Load Fail Safe Defaults

    Chapter 4 BIOS Setup 4.12 Load Fail Safe Defaults When you press <Enter> on this item you get a confirmation dialog box with a message similar to: Pressing ‘Y’ loads the BIOS default values for the most stable, minimal-performance system operations.

  • Page 74: Load Optimized Defaults

    Chapter 4 BIOS Setup 4.13 Load Optimized Defaults When you press <Enter> on this item you get a confirmation dialog box with a message similar to:...

  • Page 75: Set Supervisor/ User Password Setting

    Chapter 4 BIOS Setup 4.14 Set Supervisor/ User Password Setting...
  • Page 76 Chapter 4 BIOS Setup These setup pages are used for password setting. When a password has been enabled and the Security Option field is set as Setup, you will be required to enter the password every time you try to enter BIOS Setup program. This prevents an unauthorized person from changing any part of your system configuration.

  • Page 77: Save & Exit Setup

    Chapter 4 BIOS Setup 4.15 Save & Exit Setup Saves current CMOS value and exit BIOS setup program.

  • Page 78: Exit Without Saving

    Chapter 4 BIOS Setup 5.16 Exit Without Saving Abandons all CMOS value changes and exits BIOS setup program.
  • Page 79 Chapter 4 BIOS Setup...

  • Page 80: Ide Raid Setup

    Chapter 5 IDE RAID Setup IDE RAID Setup (KV200-R only) 5.1 Introduction to RAID RAID (Redundant Array of Independent Disks) is an array of multiple independent hard disk drives that provide high performance and fault tolerance. A RAID disk subsystem improves I/O (input/output) performance over a computer using only a single drive.

  • Page 81: Raid Levels

    Chapter 5 IDE RAID Setup 5.2 RAID Levels 5.2.1Selecting a RAID Level The factors you need to consider when selecting a RAID level are listed below. t l u y l l c i t l i f . s l r i u c i l r r i...
  • Page 82 Chapter 5 IDE RAID Setup y l l e l i t i r e l i t i r 5.2.3 RAID 1 RAID 1 duplicates all data from one drive to a second drive. RAID 1 provides complete data redundancy, but at the cost of doubling the required data storage capacity.

  • Page 83: Configuring To Raid Utility

    Chapter 5 IDE RAID Setup 5.3 Configuring to RAID Utility . y l 5.3.1 Configuring Arrays Organize the physical disk drives in arrays after the drives are connected to HyperDisk100. Each array can consist of one to four physical disk drives. HyperDisk supports up to two arrays.
  • Page 84 Chapter 5 IDE RAID Setup 5.3.4 Configuring Arrays Attached all physical disk drives, perform the following actions to prepare a RAID disk array: < > l < > v i r v i r , l e c i l c i l c i l i t i...
  • Page 85 Chapter 5 IDE RAID Setup...
  • Page 86 Chapter 5 IDE RAID Setup 5.3.4.1 Array Information This section of the screen displays all the disk arrays configured. Use this section to create, delete or edit the existing configurations. The disk arrays are displayed as a node in a tree, like Windows Explorer. When opened, each node displays the properties of the array: array configuration type or RAID level (stripe, mirror,or...
  • Page 87 Chapter 5 IDE RAID Setup Press F1 to run auto configuration. When you do this automatically creates arrays based on the available physical drives. Auto mode configures for stripe mode only. The stripe size is set to the optimum level. 5.3.5.5 Create Array (F2) Press F2 to create a disk array.
  • Page 88 Chapter 5 IDE RAID Setup There is no default setting for this field. You must select the drives for the configured array. When this field is selected, a pop-up window displays all the available physical drives with check-boxes. Use the arrow navigation keys and press the Spacebar to select or deselect the drive or drives to be part of the array.
  • Page 89 Chapter 5 IDE RAID Setup This determines which of the configured arrays should be used for booting the system whenRAID utility is selected as the boot device. The options are Yes or No.You can select the boot device from the system BIOS setup.
  • Page 90 Chapter 5 IDE RAID Setup...
  • Page 91 Chapter 5 IDE RAID Setup 5.3.7 Restroe Old Configuration(F4) Press F4 to restore the configuration that was there before you entered the RAID setup utility. Caution Use this option with caution. When you delete an array, you lose the array configuration and the data saved in the array. 5.3.8 delete Array(F5) Press F5 to delete a currently configured array.

  • Page 92: Operation System Installation

    Chapter 5 IDE RAID Setup 5.4 Operation System Installation This section contains the procedures for installing the Windows 95/98 and Windows NT operating systems. 5.4.1 Installing the Windows 95/98 Driver Use the following procedure to install Windows 95/98 onto Raid-configured drives. l l a o l l s i l...
  • Page 93 Chapter 5 IDE RAID Setup i t r t s i v i r e l l l l i l l o e l l l l i l l o l l o i t r v i r i t r v i r v i r...
  • Page 94 Chapter 5 IDE RAID Setup 5.4.3 Confirming windows 95/98 Driver Installation Use the following procedure to confirm that the driver is installed properly. i t r i t r t s i i l c v i r i l c v i r v i r .
  • Page 95 Chapter 5 IDE RAID Setup 5.4.4 Installing windows NT4.0 and windows 2000 Divers Use the following procedure to install Windows NT 4.0/ Windows 2000 onto RAID-configured drives. t a l < > o l l t a l e l i <...
  • Page 96 Chapter 5 IDE RAID Setup 5.4.5Updating the Windows NT4.0 Driver Use the following procedure to update the driver or install the driver in an existing system booted from regular IDE or SCSI drive . l e v i r e l l "...
  • Page 97 Chapter 5 IDE RAID Setup 5.4.6 Confirming the Windows NT4.0 Driver Installation Use the following procedure to confirm that the driver is installed properly . l e f I . v i r . y l 5.4.7 Installing DOS For DOS, no driver installation is necessary. The Adapter ROM BIOS contains the low-level driver good for DOS.

  • Page 98: Software Utilities

    Chapter 5 IDE RAID Setup 5.5 Software Utilities Insert the Power Installar in your computer and run the following program: When you setup Hyper Disk RAID Utility,after install NT service Pack 5 or later, Internal Explorer 5 and Management Console (MMC) The first installation screen displays.
  • Page 99 Chapter 5 IDE RAID Setup On the second installation screen, select the components that you want to install. The components are: -Control panel applet and Property page -MMC Snap-in When you select a component from the list, a description of the component displays below the list, as shown below.
  • Page 100 Chapter 5 IDE RAID Setup 5.5.1.2 MMC Snap-in MMC (Microsoft Management Console) is a common platform for launching management applications in the Windows environment. HyperDisk100 Console plugs into MMC to provide the ability to manage arrays, physical drives, and the activity log. 5.5.2 HyperDisk Console 5.5.2.1 Overview HyperDisk Console is a MMC (Microsoft...
  • Page 101 Chapter 5 IDE RAID Setup 5.5.2.6 Toolbar The toolbar displays menus, such as Action and View, and icons you can use to perform actions or access help. The toolbar is located over the object and information frames. 5.5.3 Hyper Disk Console Properties To view general settings and tool settings, right click on the HyperDisk Console directory tree in the left frame.
  • Page 102 Chapter 5 IDE RAID Setup Select Properties from the context menu. The HyperDiskonsole Properties window displays. You can use the General settings tab to set how often HyperDisk100 Console checks the arrays for errors. You can set the interval between checks from 0.5 seconds to 120 seconds.
  • Page 103 Chapter 5 IDE RAID Setup Select the Tools setting tab for options for rebuilding, and the activity log file. Check the settings that you want to use.
  • Page 104 Chapter 5 IDE RAID Setup c i t c i t d l i d l i f i c c i t . d l d l i d l i d l i o l l d l i , d l .
  • Page 105 Chapter 5 IDE RAID Setup 5.5.4 HyperDisk Console Toolbar Icons Context menu items display in the toolbox. These include items such as actions, display options, and help. You can also use the items on the toolbar to go to a previous screen, open a file, and save a file.
  • Page 106 Chapter 5 IDE RAID Setup 5.5.5Arrays Object Select Arrays from the Console tree in the object frame to view the following information about the arrays: -the array name, -array mode (performance or reliability), -status (online, degraded, or offline), -logical drive(s) in this array, -physical drive(s) is this array, and -capacity of the array.
  • Page 107 Chapter 5 IDE RAID Setup 5.5.6Array Context Menus 5.5.6.1 Object frame You can right click on the arrays in the object and information frames to view context menus. Right click on Arrays in the Console tree and select Properties. The following screen displays the array settings, and error counter limit for the selected array.
  • Page 108 Chapter 5 IDE RAID Setup 5.5.6.2 Information frame Right click on an array in the information frame. The following menu displays: 5.5.7Physical Drives Object Select Physical Drives in the object frame to view the following information about the physical disks: -the physical drive connection (primary or secondary, master or slave), -model number of the drive,...
  • Page 109 Chapter 5 IDE RAID Setup The icon next to the drive name (such as Primary Master) in the Information frame is color coded. Green means no system problems, yellow means there are errors, and red warns of a critical problem which could cause the system to fail.
  • Page 110 Chapter 5 IDE RAID Setup 5.5.7Physical Drives Context Menus 5.5.8.1 Object frame Select Physical Drives in the object frame. The context menu displays. You can view the properties or access help. 5.5.8.2 Information frame Select a drive in the right frame. Right click on the drive. The following screen displays the general settings for the selected physical drive:...
  • Page 111 Chapter 5 IDE RAID Setup Errror log view:Select this menu item to view the list of errors for the drive. Rebuild array:Select this option to rebuild an array that has errors. The following screen displays. The Spy Service icon (in the bottom right corner of the screen) is red, indicating a failed drive.
  • Page 112 Chapter 5 IDE RAID Setup 5.5.8.3 Physical Drive Errors Error codes for the physical drives display when you select the error log view. The codes are t p i y f i 5.5.9 Physical Drives Toolbar 5.5.9.1 Physical drive icons The following icons display in the toolbar only when you select Physical Drives in the Console tree directory, then a drive in the right frame.
  • Page 113 Chapter 5 IDE RAID Setup Rebuild array:Use this icon to rebuild an array for the selected drive.
  • Page 114 Chapter 5 IDE RAID Setup 5.5.10Activity Log Object The Activity Log object displays information about activity related to the arrays and physical drive.
  • Page 115 Chapter 5 IDE RAID Setup 5.5.11Activity Log Context Menu The following context menu displays when you right click on the Activity Log File. The menu items are: h Delete log file, and h Help. 5.5.12Activity Log Toolbar Icons The following icon displays in the toolbar only when you select Activity Log file in the Console tree directory.
  • Page 116 Chapter 5 IDE RAID Setup Appendix RAID Terminology Physical Drive The physical drive is the IDE hard disk that is connected by cable to the HyperDisk100 card. The hard drive contains platters which are coated with material so that allows them to record data magnetically.

  • Page 117: Consistency Check

    Chapter 5 IDE RAID Setup automatically when a drive fails. Rebuilding can start automatically at boot up also if the mirror drive is degraded and a spare is available. If a hot spare is not available, the failed disk drive must be replaced with a new disk drive so that the data on the failed drive can be rebuilt.

  • Page 118: On Board Audio

    Chapter 6 On board Audio 6 On board Audio The on board 4.1 channel PCI Audio on Iwill motherboards offer a new generation PCI audio solution: it utilizes the state-of-the-art CRL® 3D Audio technology (HRTF 3D positional audio), and supports Microsoft® Direct Sound ® 3D and Aureal®’s A3D®...

  • Page 119: Audio Features

    Chapter 6 On board Audio 6.1 Audio Features 6.1.1 Special Features 32 bit PCI bus master. Full duplex playback and recording, built-in 16 bits CODEC. HRTF 3D positional audio, supports both Direct Sound 3D® & A3D® interfaces, supports earphones, two and four channel speakers mode.

  • Page 120: Driver Installation

    Chapter 6 On board Audio 6.2 Driver Installation 6.2.1 DOS Installation Before beginning the installation, please make sure that your hard disk has sufficient space(min. 4MB). Insert the Power Installer CD into the CD-ROM Drive. i t u i t i l .
  • Page 121 Chapter 6 On board Audio l l a , e l l l i l l a k i l : s i " t l u n i l , " t " " t " " K y f i i l c n i l l c i...
  • Page 122 Chapter 6 On board Audio 6.2.3 Win 95/98 Un-Installation In the cases you are experiencing some technical difficulties (the sound device is not function properly). It is suggested that you proceed with the un-install procedure: v i r . t i o l l l l a If you want to completely remove the drivers, you can also...
  • Page 123 Chapter 6 On board Audio S " " t r g i l S " " g " . " l i l c " t l u " a " t " s A " " d " t s i l v i r i "...

  • Page 124: The Audio Rack

    Chapter 6 On board Audio 6.3 The Audio Rack 6.3.1 Introduction By means of a user-friendly interface (as easy as operating your home stereo system), this PCI audio rack provides you with the control over your PC’s audio functions, including the advantage of four speakers mode enable/ disable, and perfect digital sound ( SPDIF version ONLY) input / output.
  • Page 125 Chapter 6 On board Audio 6.3.2About Audio Rack The Audio Rack is consisted of several major components. 6.3.2.1 Control Center Controls the display of the PCI Audio Rack’s components. 6.3.2.2 MIDI Player Plays MIDI music files, and allows you to create your personal song playlists, and play the song files.
  • Page 126 Chapter 6 On board Audio 6.3.4.1 Sel (or Trk) field: If you have multiple selections in your playlist, this shows the number of the current selection or CD track. 6.3.4.2 Current File or Track: The name of the current MIDI file, wave audio file, or CD track.
  • Page 127 Chapter 6 On board Audio 6.3.5.1 Volume Control: Clicking on this button shows and allows you to use the output level controls. 6.3.5.2Recording Control: Clicking on this button shows and allows you use the input level controls. 6.3.5.3 Input and Output Level Sliders and Buttons: For each input or output signal type, the control slider controls the loudness whereas the horizontal slider controls the balance between the two speakers.
  • Page 128 Chapter 6 On board Audio d Wave: Controls wave (voice) playback or the recording levels. e FM: Controls the FM music playback or the recording level. f Aux-in: Controls the Aux-in music play or the recording level. g PC-SPK: Controls the external PC speaker input level. h CD: Controls the CD drive output level, for CD drives configured to play their audio output through the PCs...
  • Page 129 Chapter 6 On board Audio 7.3.5.4 Mute Buttons: Toggle between muting and enabling the signal. A button with a lit LED is enabled, and when it is not lit, it means it is mute. Several output signals can usually be enabled at once. 6.3.6 MP3 Player MP3 player can play both wave files and MP3 files.

  • Page 130: The 4 Speakers System

    The settings’ window when one of the SPDIF functions is enabled. (SPDIF version ONLY) 6.3.7 The 4 Speakers System The on board audio on Iwill motherboards provide 2 wave channels (front/rear + subwoffer), known as the 4.1 speakers system. When games or application programs via DirectSound®...
  • Page 131 Chapter 6 On board Audio 6.3.7.2The positions of the speakers Put your speakers the way the following picture suggests, to deliver the best audio result. 6.3.7.3 The mixer setup There is a 4 speakers option in the volume control of the mixer, and when you enable this option, it means the rear speakers are connected to Line-in/Rear jack.
  • Page 132 SONY® and Philips®. It is commonly used in audio industry now adays. 6.3.9 IWILL Opti-Link(SPDIF VERSION ONLY) Opti-Link™ is an optical in / out put module that allows users to export and inport audio signal with a superior qulaity.
  • Page 133 Chapter 6 On board Audio 6.3.10Opt-Link Installation 6.3.11Optical SW Setting...

  • Page 134: The Application Program Setup

    Chapter 6 On board Audio 6.4 The Application Program Setup(Please install) STEP 1:When the connection between devices and Opti-Link™ is done, please go to the Start menu and select PCI Audio Applications \ Audio Environment Setting.
  • Page 135 Chapter 6 On board Audio l l i...
  • Page 136 Chapter 6 On board Audio Please note that signal beam may cause severe damage to the eyes. For your safety, please point the output end to a piece of white paper to check if thebeam is in function STEP 2: Please connect the output signal to the MD input, then play the music via the MP3 player:...
  • Page 137 Chapter 6 On board Audio l l i...
  • Page 138 Chapter 6 On board Audio...

  • Page 139: About Recording 24Bit Audio Setting

    Chapter 6 On board Audio About Recording 24bit Audio Setting l l i...
  • Page 140 Chapter 6 On board Audio The un-selected area will be gray out.
  • Page 141 Chapter 6 On board Audio The un-selected area will be gray out.
  • Page 142 Chapter 6 On board Audio The un-selected area will be gray out.
  • Page 143 Chapter 6 On board Audio...

  • Page 144: Spdif/In (Spdif Version Only)

    Chapter 6 On board Audio 6.6 SPDIF/IN (SPDIF version only) 6.6.1Portable CD / MD Player (output) to Iwill® Opti- Link™ (optical input) Setup. i l s , e l c i t c i t l l i c i t...
  • Page 145 Chapter 6 On board Audio 6.6.2 Standard CD / MD Player (output) to Iwill® Opti- Link™ (optical input) Setup. c i t c i t c i t c i t l l i - i t c i t...
  • Page 146 Chapter 6 On board Audio...
  • Page 147 Chapter 6 On board Audio...

  • Page 148: Loopback (Bypass) Mode Setup

    Chapter 6 On board Audio 6.7 Loopback (bypass) mode Setup 7.7.1CD-ROM (Digital Output) to Opti-Link™ (SPDIF/IN) Setup t i g l l i...
  • Page 149 Chapter 6 On board Audio...
  • Page 150 Chapter 6 On board Audio " " y...
  • Page 151 Chapter 6 On board Audio...

  • Page 152: Power Installar Cd

    Chapter 7 Power Installer CD Power Installer CD 7.1 Software Installation The attached Power Installer CD contains all the necessary drivers, utilities. It provides an easy way for users to install the needed drivers without going through a complicated process. The Power Installer CD is able to auto-detect and display the drivers, utilities needed for your motherboard.

  • Page 153: How To Use The Power Installer Cd

    Chapter 7 Power Installer CD 7.2 How to use the Power installer CD The Power Installer CD supports the Auto Run program under Windows 98/95/2000 and Windows NT operating systems. All the necessary drivers, utilities and manual for this motherboard will show on the screen.
  • Page 154 Chapter 7 Power Installer CD s r i < > i l i t l u < > l i t y t i < > t i x t e l l l a l l i c i t y l l v i r v i r...

  • Page 155: Install Driver

    You may just click on the High Point XStore Pro shown on screen that needs to be installed, then follow the prompts to complete setup. 7.4.6 How to install RAID 100 Install Guide (KV200-R Only) TheDrivers Location:Drivers\AMIRaid\Win9x Please follow the steps on the document to complete setup.

  • Page 156: Install Software Utility

    7.5.4 How to use Adobe Acrobat Reader You may just click on the Adobe Acrobat Reader shown on screen then follow the prompts to complete setup. 7.5.5 Management Console (MMC)(KV200-R only ) Please follow the steps on section of IDE RAID Setup to complete setup.
