PARTS(GA101/GC101)
USE AT7402A
4. Folding tripod
Bowl base
a: Loose the locking knobs of each stages and adjust the legs to minimum
length, then locking all the knobs.
Leg tube
Patent united lock for two stage lock
-
Retractable easy hook
Locking knob of ground speader
Pull ring
Ground spreader
Foot with spike
Anti slide rubber pad
-
A
Pad removing tab
-
G
B
C
D
b: One hand catch the bowl base, another hand pull the middle spreader "G"
and fold it. Then pull out retractable easy hook "D" and wrap around legs and
bind them together.
D
J
E
F
G
I H
