Summary of Contents for Jack Lananne's Power Juicer Elite

  • Page 2 POWER JUICER ELITE...
  • Page 3: Table Of Contents

    POWER JUICER ELITE Contents Important Safety Information Helpful Hints Parts/Main Unit Assembly/Main Unit Assembly/E-Z Loader Attachment Disassembly/Main Unit Cleaning Your Power Juicer Troubleshooting Contents...
  • Page 4: Important Safety Information

    POWER JUICER ELITE Important Safety Information READ THESE SAFEGUARDS CAREFULLY BEFORE USING THIS PRODUCT! When using electrical appliances, basic safety precautions should always be followed including the following: • Always remove power cord from electrical outlet before assembly or disassembly.
  • Page 5: Helpful Hints

    Helpful Hints Follow these helpful hints to obtain the best results from your Power Juicer Elite. • Do not put any fruit or vegetables in your machine until power is turned on and the motor is spinning.
  • Page 6: Parts/Main Unit

    POWER JUICER ELITE Parts Main Unit MAIN UNIT (Fully Assembled) Pusher Filter Blade Chute Lid with Pulp Guard Crescent Tool Pulp (for tightening and removing blade) Collector WARNING: DO NOT OVER TIGHTEN) Receptacle Removable Non-Drip Pegs Spout (Pegs fit into blade.)
  • Page 7: Assembly/Main Unit

    POWER JUICER ELITE Assembly Note: Refer to page 6 for all part names. Main Unit STEP WARNING: Never plug the power cord into an electrical outlet before unit is fully assembled Place base on a dry flat surface with locking bar in down position on the spout side in front of the machine (as shown).
  • Page 8 POWER JUICER ELITE POWER JUICER ELITE Assembly Note: Refer to page 6 for all part names. Main Unit STEP Place blade inside filter, centered over screw peg. Using orange crescent tool, place its pegs into the holes on the blade.
  • Page 9 POWER JUICER ELITE Assembly Note: Refer to page 6 for all part names. Main Unit UPRIGHT POSITION STEP Make sure juice spout is in the downward position. If the juice spout is left in the upright position the juice will not flow.
  • Page 10: Assembly/E-Z Loader Attachment

    POWER JUICER ELITE Note: Refer to page Assembly 6 for all part names. E-Z Loader Attachment Important Safety Information READ THESE SAFEGUARDS CAREFULLY BEFORE USING YOUR E-Z LOADER ATTACHMENT! • TO AVOID PERSONAL INJURY: Never look inside the chute while the machine is running.
  • Page 11: Disassembly/Main Unit

    POWER JUICER ELITE Disassembly Note: Refer to page 6 for all part names. Main Unit STEP WARNING: Before disassembling the unit make sure the power is OFF and remove power cord from the electrical outlet. Place unit on a dry, flat stable surface Remove pusher from chute.
  • Page 12 POWER JUICER ELITE Disassembly Note: Refer to page 6 for all part names. Main Unit STEP Use the crescent tool to remove the blade. Place the two pegs at either end of the crescent tool into the two holes on the blade. Press...
  • Page 13: Cleaning Your Power Juicer

    POWER JUICER ELITE Cleaning Your Power Juicer To Clean Main Unit: • Turn off the power switch and wait until the motor completely stops. • With dry hands, unplug the power cord from electrical outlet. • Disassemble the machine. (See disassembly instructions.) •...
  • Page 14: Troubleshooting

    POWER JUICER ELITE Troubleshooting Problem Possible Reasons and Solution The motor does not run • Check to see if unit is plugged in. after being switched on. • Locking bar is not locked in place properly. • Check if all parts are assembled properly.
  • Page 16 © 2008 Tristar Products, Inc. All rights reserved. Distributed by: Tristar Products, Inc. Wallingford, CT 06494 PJElite_MAN_TP_ENG_V6_100122...
