USER MANUAL
MANUEL DE UTILISATION
MANUAL DEL USUARIO
SAFETY
OPERATION
MAINTENANCE
For your own safety please read this manual before attempting to operate your new unit. Failure to follow instructions
can result in serious personal injury. Spend a few moments to familiarize yourself with your blower before each use.
Pour votre sécurité, lisez entièrement ce manuel avant d'utiliser votre nouvel outil. Le non respect des instructions
peut résulter en des accidents graves. Prenez quelques instants pour vous familiariser avec le souffleur avant
chaque utilisation.
Para su propia seguridad, favor de leer este manual antes de intentar operar su unidad nueva. Si no se siguen estas
instrucciones se pueden provocar serias heridas personales. Favor de dedicar un poco de tiempo para familiarizarse
cada vez que se utilice la unidad.
PN 9096-320104(2)
MB3200
Gas Blower
Souffleur à essence
Soplador de Gasolina
SECURITE
FONCTIONNEMENT
ENTRETIEN
WARNING • PLEASE READ
AVERTISSEMENT • LIRE ATTENTIVEMENT
ADVERTENCIA • FAVOR DE LEER
MB3201
Gas Blower / Vac
Souffleur à essence / Aspirateur
Soplador de Gasolina / Aspiradora
© McCulloch Corporation, 2003 • Printed in Taiwan
SEGURIDAD
OPERACION
MANTENIMIENTO
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MB3200 and is the answer not in the manual?

Questions and answers

Related Manuals for McCulloch MB3200

Summary of Contents for McCulloch MB3200

  • Page 1 For your own safety please read this manual before attempting to operate your new unit. Failure to follow instructions can result in serious personal injury. Spend a few moments to familiarize yourself with your blower before each use. Pour votre sécurité, lisez entièrement ce manuel avant d’utiliser votre nouvel outil. Le non respect des instructions peut résulter en des accidents graves.
  • Page 2 Les réparations autres que les entretiens à effectuer par l’utilisateur devraient être confiées à un Service Après-Vente McCulloch agréé. La garantie du fabricant sera nulle en cas de dommages ou de conditions rendant le produit inutil- isable à la suite d’un entretien inadéquat.

  • Page 3: Especificaciones

    (MB3201) ....32cc (2,0ci) Poids à sec (MB3200) ....5,1kg (11,2 livres) (MB3201) .
  • Page 4 13. TUBOS DEL SOPLADOR 14. CABLE DE LA BUJIA / BUJIA 15. TUBOS DE ASPIRACION** 16. BOLSA PARA ASPIRAR** 17. MANGO LATERAL** 18. SEGURO DEL GATILLO DE ESTRANGULACION 19. BULBO DE CEBADO 20. ARNES** **MB3200 - No se utilizar con esto modelos. modéles.*...

  • Page 5: Choses A Faire

    ABILIDAD DEL USUARIO. La unidad incluye una pantalla del parachispas. Los kits de la pantalla del parachis- pas de repuesto están disponibles en su Centro de Servicio Autorizado McCulloch más cercano enlistado bajo “SIERRAS” en las páginas amarillas del directorio telefónico.
  • Page 6 ANSI Z87.1. (B) Do not allow bystanders in work area. (C) Do not point blower nozzle in direction of people or pets. 11. To reduce the risk of injury associated with contacting rotating parts, stop the engine before installing or remov- ing attachments.

  • Page 7: What Not To Do

    4. DO NOT TOUCH or let your hands or body come in contact with a hot muffler or spark plug wire. 5. DUE TO THE DANGER of exhaust fumes, never operate blower in a confined or poorly ventilated area. 6. NEVER POINT BLOWER in the direction of people, animals, buildings, automobiles, or windows, etc.
  • Page 8 3-3. INTERNATIONAL SYMBOLS - SYMBOLES INTERNATIONAUX SIMBOLOS INTERNACIONALES Minimum operating distance. Distance minimale d’opération. Distancia mínima de operación. Hearing and eye protection are required Le port de protections auditives et oculaires est nécessarie Se requiere protección para los oídos y para los ojos Use of these personal safety items is highly recommended to reduce the risk of accidental injury.
  • Page 9 1. Twist blower nozzle (A) clockwise into the straight blower tube (B) until tight (Figure 4-1A). 2. Insert the straight blower tube (B) into the blower housing (C). Align tabs (D) on tube with grooves (E) in the housing (Figure 4-1B).
  • Page 10 To install vacuum bag: 1. Insert vacuum tube (A) into blower housing (B). Align tabs (D) on tube with grooves (E) in housing (Figure 4-3A). 2. Push tube in to ridge (F) and twist counterclockwise 3/8 turn to lock into position (Figure 4-3B).
  • Page 11 1. Slide handle (A) into the groove in the housing (B). Secure with the two screws (C) (Figure 4-4A). 4-5. INSTALLATION OF SPARK ARRESTER A spark arrester screen is required when using your blower on U.S. National Forest Lands. Check your local state requirements. 1. Remove the 2 small muffler screws (A) (Figure 4-5A).

  • Page 12: Mixing Fuel

    No utilizar nunca una mezcla de combustible que haya estado almacenada mas de 90 días. Si se va a utilizar un lubricante de 2 ciclos que no sea el Custom Lubricant (Lubricante Común) McCulloch, este debe ser un aceite de 2 ciclos de primera calidad para motores de 2 ciclos enfriados por medio de aire y mezclados con una relación de 40:1.

  • Page 13: Fuel Mixing Table

    Certains carburants conventionnels sont mélangés avec des oxydisants tels l’acool ou l’éther afin de se conformer aux standards pour la pureté de l’air. Votre moteur McCulloch est conáu de manière à pouvoir utiliser toute essence pour automobile, carburants avec oxy- disants inclus, tout en vous procurant un fonctionnement satisfaisant.

  • Page 14: Starting A Cold Engine

    6 - OPERATING INSTRUCTIONS - FONCTIONNEMENT INSTRUCCIONES DE OPERACION Fig. 6-1A 6-1. STARTING A COLD ENGINE Fill fuel tank with proper gas and oil mixture. See Fuel and Lubrication. Set unit on ground so that it rests on housing feet. 1.
  • Page 15 This could cause rope to snag or fray and also damage the starter assembly. 6-2. STOPPING THE ENGINE Emergency Stopping Procedure. When it is necessary to stop blower engine immediate- ly, DEPRESS and HOLD the “OFF” switch until the engine stops completely.

  • Page 16: Blower Operations

    7-1. FONCTIONNEMENT DE LE SOUFFLEUR Votre souffleur McCulloch est conçue de manière à pouvoir enlever tous débris de patios, pelouses, buissons… et autres endroits diffi- cile à atteindre où les débris peuvent s’accumuler.
  • Page 17 Watch out for children, pets, open windows or freshly washed cars, and blow debris safely away. Use the full blower nozzle extension so the air stream can work close to the ground. After using blowers and other equipment, CLEAN UP! Dispose of debris in trash receptacles.

  • Page 18: Fonctionnement De L'aspirateur

    (MB3201 Blower / Vac Models only) Blower Units If your unit is vac-capable and was not equipped with a vacuum kit, a vacuum attach- ment accessory kit is available for purchase at your nearest McCulloch Authorized Service Center. WARNING NEVER OPERATE VACUUM WITHOUT VACUUM BAG PROPERLY ATTACHED, AS FLYING DEBRIS COULD CAUSE INJURY TO OPERATOR AND BYSTANDERS.
  • Page 19 To Operate Vacuum: 1. Follow correct starting procedures as explained in this manual. 2. Allow engine to return to idle. Put the shoulder harness on so the strap is over your right shoulder. Put the vacuum bag strap on so it is over your left shoulder.

  • Page 20: Air Filter

    8-1. AIR FILTER CAUTION NEVER operate blower without the air filter or dust and dirt will be sucked into the engine and damage it. The air filter must be kept clean. If it becomes damaged, install a new filter. 8-1. FILTRE A AIR ATTENTION NE JAMAIS utiliser le souffleur sans filtre;...

  • Page 21: Fuel Cap / Fuel Filter

    Fig. 8-1A To Clean Air Filter: 1. Remove 2 screws (A) holding air filter cover in place, remove cover (B) and lift filter (C) from air box (Figure 8-1A and B). 2. Wash filter in soap and water. DO NOT USE GASOLINE! 3.

  • Page 22: Carburetor Adjustment

    Le carburateur a été réglé en usine pour une performance optimale. Si un ajustement est nécessaire, veuillez apporter votre appareil au Centre de Service Après-Vente McCulloch agréé le plus proche dont vous trouverez l’adresse dans les pages jaunes de l’annuaire télé- phonique.
  • Page 23 8-6. VACUUM BAG CLEANING A dirty bag will obstruct airflow, thereby reducing vacuum efficiency. To Clean Bag: 1. Detach vacuum bag from unit. 2. Open zipper and remove contents. 3. Turn bag INSIDE OUT and shake vigorously. This procedure should be performed on a regular basis.

  • Page 24: Removing A Unit From Storage

    9. Store unit in a cool, dry place away from any source of ignition such as an oil burner, water heater, etc. 8-8. REMOVING A UNIT FROM STORAGE 1. Remove spark plug. 2. Pull starter rope briskly to clear excess oil from combustion chamber. 3.

  • Page 25: Troubleshooting The Engine

    9- TROUBLESHOOTING THE ENGINE DEPANNAGE DU MOTEUR DETECCION y CORRECCION DE FALLAS DEL MOTOR PROBLEM PROBLEME PROBLEMA Unit won’t start or starts but will not run. L’outil ne démarre pas ou démarre et cale. La unidad no arranca o arranca pero no opera.
  • Page 26 STOP ARRÊT ALTO NE PAS retourner ce produit au point de vente. S'adresser Para problemas o preguntas, NO devolver este producto a la tienda U.S.A. Imported by: MTD LLC P.O. Box 361131 Cleveland, OH 44136-0019 Canada Imported by / Importé par: MTD PRODUCTS LIMITED 97 Kent Avenue Kitchener, ON...
