SERVICE MANUAL

LCD COLOUR TELEVISION
LC-37D44E/S/RU-BK/GY
CONTENTS
[9]
[11] Lamp error detection ...................................3-24
[12] Public Mode (Hotel Mode) ...........................3-25
CHAPTER 4. TROUBLESHOOTING TABLE
[1]
CHAPTER 5. BLOCK DIAGRAM/OVERALL WIRING
[1]
[2]
[3]
CHAPTER 6. PRINTED WIRING BOARD ASSEM-
BLIES
[1]
[2]
[3]
[4]
CHAPTER 7. SCHEMATIC DIAGRAM
[1]
[2]
LC-37D44E/S/RU-BK/GY
No. S88N6LC37D44E
Troubleshooting Table ......................4-1
BLOCK DIAGRAM.........................................5-1
System Block Diagram .........................5-3
Overall Wiring Diagram ......................5-4
Main Unit ......................................................6-1
R/C, Led Unit ................................................6-5
Mini Av Unit ..................................................6-6
Key ...............................................................6-7
DESCRIPTION OF SCHEMATIC DIA-
GRAM............................................................7-1
Schematic Diagram ................................7-2
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LC-37D44E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sharp LC-37D44E

Summary of Contents for Sharp LC-37D44E

  • Page 1: Service Manual

    TopPage LC-37D44E/S/RU-BK/GY SERVICE MANUAL No. S88N6LC37D44E LCD COLOUR TELEVISION LC-37D44E/S/RU-BK/GY MODELS In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its orig- inal condition and only parts identical to those specified should be used.
