LC-37D44E/S/RU-BK/GY
CHAPTER 1.
LC37D44E-BK

SPECIFICATIONS

[1] SPECIFICATIONS
Item
LCD panel
Resolution
Video Colour System
TV TV-Standard Analogue
Function
Digital
Receiving VHF/UHF
Channel
CATV
TV-Tuning System
STEREO/BILINGUAL
Brightness
Viewing angles
Audio amplifier
Speaker
Terminals Antenna
RS-232C
EXT 1
EXT 2
EXT 3
EXT 4
EXT 5
EXT 6
EXT 7
C. I. (Common Interface)
OUTPUT
Headphones
Power Requirement
Power Consumption
Weight
Operating temperature
• As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for
product improvement without prior notice. The performance specification figures indicated are nominal values of production
units. There may be some deviations from these values in individual units.
NOTE
• Refer to inside back cover for dimensional drawings.

Optional accessory

The listed optional accessories are available for the
LCD colour TV. Please purchase them at your nearest
shop.
• Additional optional accessories may be available in near
future. When purchasing, please read the newest catalogue
for compatibility and check the availability.
37" LCD COLOUR TV, Model: LC-37D44E, LC-37D44S, LC-37D44RU
37" Advanced Super View & BLACK TFT LCD
1,049,088 pixels (1,366 x 768)
PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60
CCIR (B/G, I, D/K, L,L')
DVB-T (2K/8K OFDM)
E2–E69ch, F2–F10ch, I21–I69ch, IR A–IR Jch, (Digital: E5–E69ch)
Hyper-band, S1–S41ch
Auto Preset 999 ch: non-Nordic / 9999 ch: Nordic (ATV: 99 ch), Auto Label, Auto Sort
NICAM/A2
450 cd/m (in Dynamic Mode)
2
H : 176° V : 176°
10W x 2
(145 mm x 35 mm) x 2
UHF/VHF 75 Ω Din type (Analogue & Digital)
9 pin mini D-sub
SCART (AV input, Y/C input, RGB input, TV output)
SCART (AV input/output, Y/C input, RGB input, AV Link)
S-VIDEO (Y/C input), RCA pin (AV input)
Ø 3.5 mm jack (Audio input), 15 pin mini D-sub (PC)
Audio in, Component in
HDMI, Ø 3.5 mm jack (Audio input)
HDMI
EN50221, R206001
RCA pin (Audio)
Ø 3.5 mm jack (Audio output)
AC 220–240V, 50 Hz
146 W (0.9 W Standby) (Method IEC60107)
14.5 kg (Display only), 17.0 kg (Display with stand)
0°C to + 40°C
Wall mount bracket
(LC-37D44E, LC-37D44S, LC-37D44RU)
1 – 1
Service Manual
Part name Part number
AN-37AG5
