[2] OPERATION MANUAL

Remote control unit

1 (Standby/On)
Enter standby mode or turn on the
power.
2 AV MODE
Select a video setting.
3 0 – 9
Set the channel in TV and DTV mode.
Set the page in Teletext mode.
When one of the 4 Nordic countries
(Sweden, Norway, Finland or
Denmark) is selected in the country
setting of Auto Installation, DTV
channels are 4 digits. When another
country is selected, DTV channels
are 3 digits.
4 (Flashback)
Press to return to the previous selected
channel or external input mode.
5 (WIDE MODE)
Select the wide mode.
6 (Sound mode)
Select the sound multiplex mode.
(See below.)
7 EPG
DTV: To display EPG (Electronic
Programme Guide) screen.
8 ESG
DTV: To display ESG (Electronic Service
Guide) screen.
9 (Teletext)
Select the TELETEXT mode.
DTV: Select DTV data broadcasting and
TELETEXT.
10 / / / (Cursor)
Select a desired item on the setting
screen.
11 END
Exit the menu screen.
12 (Reveal hidden Teletext)
13 (Freeze/Hold)
Using on the remote control unit
DTV mode:
Press to open the multi audio screen.
Analogue TV mode:
Each time you press
tables.
NICAM TV broadcasts selection
Signal Selectable items
Stereo
NICAM STEREO, MONO
NICAM CH A, NICAM CH B,
Bilingual
NICAM CH AB, MONO
Monaural
NICAM MONO, MONO
NOTE
• When no signal is input, the sound mode will display "MONO".
1
2
3
4
5
6
7
8
9
10
11
12
13
14 SURROUND
Switch the surround effects on and off.
15 RADIO
DTV: Switch between RADIO and DTV
mode.
16 (Mute)
Switch the sound on and off.
, the mode switches as illustrated in the following
A2 TV broadcasts selection
Signal
Stereo
Bilingual
Monaural
17 DTV
14
15
16
17
18
18
19
19 P (
20
21
22
23
20
24
25
21 SLEEP
26
22
27
23 DTV MENU
28
24 MENU
29
25 OK
26 RETURN
27
28
29 Colour (Red/Green/Yellow/Blue)
Selectable items
STEREO, MONO
CH A, CH B, CH AB
MONO
1 – 2
LC-37D44E/S/RU-BK/GY
Press to access DTV mode while
watching other input sources, and vice
versa.
(This button will not work if you were
watching DTV immediately before
turning off the TV. In this case first select
any other input source except DTV
using the button.)
( / ) (Volume)
( ) Increase the volume.
( ) Decrease the volume.
/ )
TV/DTV: Select the channel.
External: Switch to TV or DTV input
mode.
Teletext: Move to the next/previous
page.
(INPUT SOURCE)
Select an input source.
(TV, DTV, EXT1, EXT2, EXT3, EXT4,
EXT5, EXT6, EXT7)
Set the sleep timer on (in units of 30
min. up to max. 2 hr. 30 min) and off.
(Display information)
DTV: Display DTV Menu screen.
Display the MENU screen.
Execute a command within the menu
screen.
TV/DTV: Display the programme list.
Return to the previous menu screen.
(Subpage)
(Subtitle for Teletext)
TV/External: To turn the subtitles on and
off.
DTV: Display the subtitle selection
screen.
TELETEXT: Select a page.
DTV: The coloured buttons are used to
select correspondingly to the coloured
items in the menu screen.
