Monitor Settings - Genelec 6010A Setup Manual

An ideal 5.1 setup.
Correct monitor
placement
L L
LS LS
1 0
Basics of system setup.
C
R R
60° 60° 60° 60°
1110° 0° 0° 111 1110°
-10° -10°
RS RS
+10° +10° +10°

Monitor settings

Set the sensitivity control on all speakers clockwise
Step 1
to full (-6 dBu) to begin with.
More information can be found in the operating
manual of your product.
Input sensitivity
control
If you use an acoustic measurement device like
Step 2
RoomEQ Wizard, measure ear height at the listening
position. Analyse the results and adjust DIP-switches
to achieve as fl at and similar frequency response as
possible in each monitor.
ON
OFF
1 1
If you have a large horizontal surface in front of the
Step 3
monitors, a boost around 160 Hz boost typically
occurs. Some Genelec monitors have a desktop
control DIP switch, which compensates the 160 Hz
boost by -4 dB.
dB
Desktop control
DIP switch
4 dB @ 160 Hz
Monitor setup guide
SENSITIVITY FOR
100 dB SPL @ 1 m
0
+3
-3
+6
-4
+12 -6
dBu
2 2 3 4 4
ON
OFF
1 1 2 2 3 4 4
frequency
1 1
