Monitors
6010A
8020B
8030A / 8130A
8040A / 8240A
8050A / 8250A
1032A
8260A
1037C
1038CF / 1238CF
1038B
1034B
1039A
1035B
1036A
* ) Maximum short term sine wave acoustic output on axis in half space, averaged from
100 Hz to 3 kHz @ 1m
Subwoofers
5040A
7050B
7060B / 7260A
7070A / 7270A
7071A / 7271A
7073A
2 6
Fundamentals
SPL short term RMS
-3 dB LF
@ 1 m *)
extension
73 Hz 93 dB
66 Hz 95 dB
55 Hz 100 dB
45 Hz 105 dB
35 Hz 110 dB
40 Hz 113 dB
26 Hz 113 dB
35 Hz 116 dB
55 Hz 118 dB
33 Hz 120 dB
32 Hz 123 dB
29 Hz 126 dB
29 Hz 131 dB
19 Hz 131 dB
Frequency SPL short term RMS
+/-3 dB @ 1 m
35 - 85 Hz 96 dB
25 - 85 Hz 100 dB
19 - 85 / 120 Hz 108 dB
19 - 85 / 120 Hz 112 dB
19 - 85 / 120 Hz 118 dB
19 - 85 / 120 Hz 124 dB
Room Subwoofers Subwoofers
volume for 2-channel for 5-channel
up to (Stereo) (Surround)
55 m 5040A 5040A
3
65 m 7050B 7050B
3
75 m 7050B 7060B / 7260A
3
85 m 7060B / 7260A 7070A / 7270A
3
95 m 7070A / 7270A 7071A / 7271A
3
100 m 7070A / 7270A 7071A / 7271A
3
115 m 7071A / 7271A 7071A / 7271A
3
125 m 7071A / 7271A 7073A
3
125 m 7071A / 7271A 7073A
3
170 m 7071A / 7271A 7073A
3
200 m 7073A 2 x 7073A
3
240 m 7073A 2 x 7073A
3
400 m 2 x 7073A 3 x 7073A
3
400 m 2 x 7073A 3 x 7073A
3
Monitor setup guide
