Avoid placing the monitors between 1-2.2 m from the
Step 5
wall due to wall cancellation.
Speaker distance
to the front wall
5 cm
When you move the speaker closer to the wall, the
cancellation moves higher in frequency range.
Cancellation
frequency and
wall behind the
speaker
You can easily fi nd the cancellation
frequencies with the Genelec AcoustiTape.
Ordercode MAI-0079.
8
Basics of system setup.
OK
Avoid
OK
1 m
2,2 m
SPL
40 200 f
SPL
40 200 f
A monitor should not be placed closer than 1.2 m
Step 6
from the fl oor.
Point the monitors towards your listening position, do
Step 7
not tilt more than 15 degrees.
Normal listening position height is between 1.2 and
1.4 m.
Monitor heights
(ITU-R BS.775-1
standard)
‹15° ‹15°
Monitor setup guide
1.2 m
‹15°
1.2-1.4 m
