Section 3

Ice Machine Operation

Component Identification

AIR CONDENSER
HARVEST VALVE
CONDENSER WATER
REGULATING VALVE
REMOTE COUPLINGS
WATER DUMP VALVE
COMPRESSOR
WATER WATER COOLED
DRAIN HOSE
SV1604G
CONDENSER MODEL
DISTRIBUTION
ICE THICKNESS
HIGH PRESSURE CUTOUT/
TUBE
PROBE
MANUAL RESET
EVAPORATOR
(When applicable)
ICE/OFF/CLEAN
SWITCH
WATER
WATER
PUMP
CURTAIN
WATER
TROUGH
SV1605
BIN SWITCH
Figure 3-1. Component Identification (Typical Q450 Shown)
