Page 1 Manitowoc Indigo™ Series QuietQube Ice Machines Technician’s Handbook This manual is updated as new information and models are released. Visit our website for the latest manual. www.manitowocice.com America’s #1 Selling Ice Machine Part Number STH026 2/12...
Page 3: Safety Notices
Safety Notices As you work on Manitowoc equipment, be sure to pay close attention to the safety notices in this handbook. Disregarding the notices may lead to serious injury and/or damage to the equipment. Throughout this handbook, you will see the following...
Page 4 ! Caution Proper installation, care and maintenance are essential for maximum performance and trouble- free operation of your Manitowoc equipment. If you encounter problems not covered by this handbook, do not proceed, contact Manitowoc Foodservice. We will be happy to provide assistance.
Page 5: Table Of Contents
Ice Machine Heat of Rejection ..28 I1470C/I1870C/I2170C Installation on a Manitowoc Bin ..29 Ice Machine on a Dispenser Installation 30 Lineset Applications ....31 QuietQube®...
Page 6 Component Identification I Model Single Evaporator Models ..37 Ice Beverage Models ....38 ICVD0695/ICVD0895/ICVD1095/ICVD1195/ ICVD1295/ICVD1495 ....39 ICVD1895/ICVD2195 .
Page 7 Set-Up Menu ..... . . 72 Language ..... . 72 Time &...
Page 8 Operational Checks ....101 General ......101 Ice Thickness Check .
Page 9 Component Check Procedures Electrical Components ....159 Control Board, Display board and Touch Pad ......159 Control Board Relay Test .
Page 10 System Contamination Clean-Up ..210 Determining Severity Of Contamination 210 Cleanup Procedure ....212 Replacing Pressure Controls Without Re- moving Refrigerant Charge ..215 Liquid Line Filter-Driers .
Page 11: General Information
General Information How to Read a Model Number HEAD SECTIONS Part Number STH026 2/12...
Page 12: Icvd Condensing Units
ICVD CONDENSING UNITS AIR-COOLED ICVD 1495 3 CONDENSING CONDENSING UNIT MODEL UNIT SERIES 3 PHASE Ice Cube Sizes Regular Dice Half Dice 1-1/8" x 1-1/8" x 7/8" 7/8" x 7/8" x 7/8" 3/8" x 1-1/8" x 7/8" 2.86 x 2.86 x 2.22 cm 2.22 x 2.22 x2.22 cm 0.95 x 2.86 x 2.22 cm Warning...
Page 13: Model/Serial Number Location
Warning All Manitowoc ice machines require the ice storage system (bin, dispenser, etc.) incorporate an ice deflector. Prior to using a non-Manitowoc ice storage system with other Manitowoc ice machines, contact the manufacturer to assure their ice deflector is compatible with Manitowoc ice machines.
Page 14: Model Numbers
Model Numbers QUIETQUBE® MODELS ® Ice Machine Head ICVD Condensing Section Unit ID0682C IY0684C ICVD0695 IB0694YC ID0872C IY0874C ICVD0895 IB0894YC ID1072C ICVD1095 IY1074C IB1094YC ICVD1195 ID1472C ICVD1495 IY1474C ID1872C ICVD1895 IY1874C ID2172C ICVD2095 IY2174C ID3072C ICVD3095 IY3074C Part Number STH026 2/12...
Page 15: Ice Machine Warranty Information
If the OWNER WARRANTY REGISTRATION CARD is not returned, Manitowoc will use the born on date recorded in the control board or the date of sale to the Manitowoc Distributor as the first day of warranty coverage for your new ice machine.
Page 16: Commercial Warranty Coverage
COMMERCIAL WARRANTY COVERAGE Manitowoc Ice, (hereinafter referred to as the "COMPANY") warrants for a period of thirty-six months from the installation date (except as limited below) that new ice machines manufactured by the COMPANY shall be free of defects in material or workmanship...
Page 17 COMPANY within five (5) days from the installation date. To obtain warranty service or information regarding your Product, please contact us at: MANITOWOC ICE 2110 So. 26th St. P.O. Box 1720, Manitowoc, WI 54221-1720 Telephone: 920-682-0161 Fax: 920-683-7585 www.manitowocice.com Part Number STH026 2/12...
Page 18: Residential Ice Machine Limited Warranty
RESIDENTIAL ICE MACHINE LIMITED WARRANTY WHAT DOES THIS LIMITED WARRANTY COVER? Subject to the exclusions and limitations below, Manitowoc Ice, Inc. (“Manitowoc”) warrants to the original consumer that any new ice machine manufactured by Manitowoc (the “Product”) shall be free of defects in material or workmanship for the...
Page 19 WHAT ARE MANITOWOC ICE’S OBLIGATIONS UNDER THIS LIMITED WARRANTY? If a defect arises and Manitowoc receives a valid warranty claim prior to the expiration of the warranty period, Manitowoc shall, at its option: (1) repair the Product at Manitowoc’s cost, including standard...
Page 20 (5) defects or damage to any Product that has not been installed and/or maintained in accordance with the instruction manual or technical instructions provided by Manitowoc. To the extent that warranty exclusions are not permitted under some state laws, these exclusions may not apply to you.
Page 21 REGISTRATION CARD To secure prompt and continuing warranty service, this warranty registration card must be completed and sent to Manitowoc within thirty (30) days from the sale date. Complete the registration card and send it to Manitowoc. Part Number STH026 2/12...
Page 22 This Page Intentionally Left Blank Part Number STH026 2/12...
Page 23: Installation
PERSONAL INJURY POTENTIAL Remove all ice machine panels before lifting. Warning I1470C/I1870C/I2170C ice machines are not approved for use on Manitowoc B570 bins. ! Caution The ice machine head section must be protected if it will be subjected to temperatures below 32°F (0°C).
Page 24: Location Of Ice Machine
Location of Ice Machine HEAD SECTION The location selected for the ice machine head section must meet the following criteria. If any of these criteria are not met, select another location. • The location must be free of airborne and other contaminants.
Page 25: Ice Beverage Models
ICE BEVERAGE MODELS • Ice/Beverage Ice Machines require the installation of a thermostat to maintain dispenser ice level. The thermostat ships with the ice machine. • The ice machine head is installed with the electrical inlet, water supply inlet, refrigeration tubing and water drain entering from the back of the ice machine.
Page 26: Location Of Icvd Condensing Units
Location of ICVD Condensing Units The location selected for the ICVD Condensing Unit must meet the following criteria. If any of these criteria are not met, select another location. • ICVD0895/ICVD1095/ICVD1495/ICVD1895/ ICVD2195 Only - The air temperature must be at least -20°F (-28.9°C) but must not exceed 130°F (54.4°C).
Page 27: Clearance Requirements
Clearance Requirements ICVD I0680C - I0870C Ice Machine Condensing I1070C - I2170C Head Section Unit 5" (12.7 cm) *0” (0 cm) Sides 5" (12.7 cm) *0” (0 cm) Back 5" (12.7 cm) 48” (122 cm) Standard Connections Back 3” (7.6 cm) Connections Out Top Front 48”...
Page 28: Ice Machine Heat Of Rejection
Ice Machine Heat of Rejection Heat of Rejection Series Ice Machine Peak Conditioning* I0600 9000 13900 I0850 13000 16000 I1000 16250 18600 I1200 20700 24500 I1400 23500 27000 I1800 30000 35000 *BTU/Hour Because the heat of rejection varies during the ice making cycle, the figure shown is an average.
Page 29: I1470C/I1870C/I2170C
I1470C/I1870C/I2170C Installation on a Manitowoc Bin Dual evaporator models will not function correctly with the stock bin deflector. An ice deflector kit is required for installation and is ordered separate. Order appropriate kit (30” or 48”) for your bin. The stock bin deflector must be removed and replaced with the correct deflector to prevent injury.
Page 30: Ice Machine On A Dispenser Installation
Adapters are not included with the ice machine, dispenser or bin and must be ordered separately. When a non- Manitowoc adapter is used, verify the adapter is compatible with Manitowoc Ice/Beverage Ice Machines prior to installation.
Page 31: Lineset Applications
! Caution The 60-month compressor warranty (including the 36-month labor replacement warranty) will not apply if the Manitowoc Ice Machine, Condenser or QuietQube® Condensing Unit were not installed according to specifications. This warranty also will not apply if the refrigeration system is modified with a condenser, heat reclaim device, or other parts or assemblies not manufactured by Manitowoc Ice.
Page 32: Quietqube® Remote Condensing Unit
QUIETQUBE® REMOTE CONDENSING UNIT Remote Single QuietQube® Circuit Line Set* Ice Machine Condenser I0670C ICVD0695 IB0670C RC-26 I0870C ICVD0895 RC-36 IB0870C RC-56 I1070C ICVD1095 IB1090C ICVD1195 I1470C ICVD1495 RC-25 RC-35 I1870C ICVD1895 RC-55 I2170C ICVD2095 RC-28 RC-38 RC-58 Minimum Suction Liquid *Line Set Insulation...
Page 33: Additional Refrigerant Charge For 51' To 100' Line Sets
(included with Manitowoc line sets) to energize the contactor coil and verify the LPCO & HPCO are closed. This circuit also initiates a time delay whenever the LPCO or HPCO open. Failure to properly wire the iCVD condensing unit or ice machine head section will result in a non-operational machine.
Page 34: Calculating Allowable Lineset Distance
CALCULATING ALLOWABLE LINESET DISTANCE Line Set Length The maximum length is 100' (30.5 m). Line Set Rise/Drop The maximum rise is 35' (10.7 m). The maximum drop is 15' (4.5 m). 35 FT. (10.7 M) MAXIMUM DISTANCE SV1751 35 ft. (10.7 m) Rise: The maximum distance the Condenser or Condensing Unit can be above the ice machine.
Page 35 Calculated Line Set Distance The maximum calculated distance is 150' (45.7 m). Line set rises, drops, horizontal runs (or combinations of these) in excess of the stated maximums will exceed compressor start-up and design limits. This will cause poor oil return to the compressor. Make the following calculations to make sure the line set layout is within specifications.
Page 36 This Page Intentionally Left Blank Part Number STH026 2/12...
Page 37: Component Identification
Component Identification I Model Single Evaporator Models Part Number STH026 2/12...
Page 38: Ice Beverage Models
Ice Beverage Models ELECTRICAL WATER DISTRIBUTION TUBE COMPARTMENT THICKNESS PROBE DISPLAY & TOUCHPAD WATER WATER INLET CURTAIN VALVE WATER TROUGH DUMP VALVE ELECTRICAL COMPARTMENT LUMINICE COOL VAPOR VALVE LIQUID LINE DISCHARGE DRIER LINE CHECK VALVE LIQUID LINE SOLENOID VALVE SHUT OFF RECEIVER VALVES Part Number STH026 2/12...
Page 39: Icvd0695/Icvd0895/Icvd1095/Icvd1195/ Icvd1295/Icvd1495
ICVD0695/ICVD0895/ICVD1095/ICVD1195/ ICVD1295/ICVD1495 HEAD PRESSURE CONDENSER CONTROL VALVE FAN MOTOR ACCESS VALVE ELECTRICAL COMPARTMENT CONDENSER LPCO COMPRESSOR CHECK VALVE LIQUID LINE AND SUCTION LINE CONNECTION SUCTION ACCESS VALVE POINTS ACCUMULATOR Part Number STH026 2/12...
Page 40: Icvd1895/Icvd2195
ICVD1895/ICVD2195 ACCESS VALVES CONDENSER FAN MOTOR (ICVD3095 HAS 2 FANS) ELECTRICAL CONDENSER COMP. HEAD PRESSURE CONTROL VALVE LIQUID LINE SUCTION LINE CONNECTION POINTS CHECK VALVE Not Used On Scroll Compressors SUCTION ACCESS VALVE ACCUMULATOR COMPRESSOR Part Number STH026 2/12...
Page 41: Maintenance
An extremely dirty ice machine must be taken apart for cleaning and sanitizing. Manitowoc Ice Machine Cleaner and Sanitizer are the only products approved for use in Manitowoc ice machines. Part Number STH026 2/12...
Page 42 (Manitowoc Cleaner part number 94-0546-3 and Manitowoc Sanitizer part number 94-0565-3). It is a violation of Federal law to use these solutions in a manner inconsistent with their labeling. Read and understand all labels printed on bottles before use.
Page 43: Cleaning/Sanitizing Procedure
CLEANING/SANITIZING PROCEDURE This procedure must be performed a minimum of once every six months. • The ice machine and bin must be disassembled cleaned and sanitized. • All ice produced during the cleaning and sanitizing procedures must be discarded. • Removes mineral deposits from areas or surfaces that are in direct contact with water.
Page 44: Cleaning / Sanitizing Procedure
(Manitowoc Cleaner part number 94-0546-3 and Manitowoc Sanitizer part number 94-0565-3). It is a violation of Federal law to use these solutions in a manner inconsistent with their labeling. Read and understand all labels printed on bottles before use.
Page 45 Step 1 Open the front door to access the evaporator compartment. Ice must not be on the evaporator during the clean/sanitize cycle. Follow one of the methods below: • Press the power switch at the end of a harvest cycle after ice falls from the evaporator(s). •...
Page 46 Step 4 Wait until the clean cycle is complete (approximately 24 minutes). Then disconnect power to the ice machine (and dispenser when used). Warning Disconnect the electric power to the ice machine at the electric service switch box. Step 5 Remove parts for cleaning. Please refer to the proper parts removal for your ice machine.
Page 47: Sanitizing Procedure
Step 7 Use 1/2 of the cleaner/water mixture to clean all components. The cleaner solution will foam when it contacts lime scale and mineral deposits; once the foaming stops use a soft-bristle nylon brush, sponge or cloth (NOT a wire brush) to carefully clean the parts. Soak parts for 5 minutes (15 - 20 minutes for heavily scaled parts).
Page 48 Step 11 Use 1/2 of the sanitizer/water solution to sanitize all food zone surfaces of the ice machine and bin (or dispenser). Use a spray bottle to liberally apply the solution. When sanitizing, pay particular attention to the following areas: •...
Page 49 Step 15 Wait until the water trough refills and the display indicates add solution (approximately 1 minute). Add the proper amount of Manitowoc Ice Machine Sanitizer to the water trough by pouring between the water curtain and evaporator. Model Amount of Sanitizer...
Page 50: Parts Removal For Cleaning/Sanitizing
PARTS REMOVAL FOR CLEANING/SANITIZING Single Evaporator Ice Machines. O f f O n / O f f M o d e A. Remove the water curtain • Gently flex the curtain in the center and remove it from the right side. •...
Page 51 D. Remove the ice thickness probe • Compress the hinge pin on the top of the ice thickness probe. • Pivot the ice thickness probe to disengage one pin then the other. The ice thickness probe can be cleaned at this point without complete removal. If complete removal is desired, disconnect the ice thickness control wiring from the control board.
Page 52 Ice Beverage Ice Machines A. Remove splash shield • Grasp the top center of splash shields. • Lift up and then out. B. Remove ice thickness probe • Compress the hinge pin on the top of the ice thickness probe. •...
Page 53 C. Remove the water trough • Depress tabs on right and left side of the water trough. • Allow front of water trough to drop as you pull forward to disengage the rear pins. D. Remove the water level probe •...
Page 54 Dual Evaporator Ice Machines A.Remove front splash shield • Grasp the top of the splash shield. • Lift up and then out. B. Remove evaporator splash shields • Grasp the top center of splash shields. • Lift up and then out. C.
Page 55 D. Remove ice thickness probe • Compress the hinge pin on the top of the ice thickness probe. • Pivot the ice thickness probe to disengage one pin then the other. The ice thickness probe can be cleaned at this point without complete removal. If complete removal is desired, disconnect the ice thickness control wiring from the control board.
Page 56 Ice Thickness Probe & Water Level Probe Clean the probes using the following procedure. 1. Mix a solution of Manitowoc ice machine cleaner and water (2 ounces of cleaner to 16 ounces of water) in a container. 2. Soak probes in container of cleaner/water solution...
Page 57 Water Inlet Valve The water inlet valve normally does not require removal for cleaning. Refer to “Water System Checklist” page 136, if you are troubleshooting water related problems. 1. When the ice machine is off, the water inlet valve must completely stop water flow into the machine. Watch for water flow.
Page 58 Water Dump Valve The water dump valve normally does not require removal for cleaning. To determine if removal is necessary: 1. Locate the water dump valve. 2. Press the power button and stop ice making. 3. While the ice machine is in the freeze mode, check the water trough to determine if the dump valve is leaking.
Page 59 During cleaning, do not stretch or damage the NOTE: spring. 1. Remove the tubing from the dump valve by twisting the clamps off. 2. Remove the valve body, twist off. COIL SPRING PLUNGER NYLON GASKET DIAPHRAM MOUNTING BRACKET VALVE BODY Dump Valve Disassembly Part Number STH026 2/12...
Page 60 This Page Intentionally Left Blank Part Number STH026 2/12...
Page 61: Operation
Power Button Cleaning Button Manitowoc LCD Display Navigation Arrows Menu Checkmark Button Operation Control Panel Features The control panel offers a series of pressure sensitive buttons and a four-line interactive display panel. BUTTONS Powers the ice machine when in the Power Button: On/Off Mode.
Page 62: Display Panel
Moves the display from the Home Menu Button: Screen, where ice machine status, alerts and messages are viewed, to the Main Menu, where machine information and its event log can be accessed, machine and Energy Saver settings can be adjusted, and service issues can be addressed. The Left arrow moves the Left and Right Arrows: display to the previous screen, allowing the user to...
Page 63: Menu Navigation Overview
Menu Navigation Overview Menu Navigation Overview AuCS On/Off Clean Timer Button Button Initiated Press Left Arrow From Main Menu Home Screen AuCS Clean Clean Function Function When When Alert Message Present Present Menu Alerts Messages Button Menu Menu Main Menu Function (Optional) Password Entry Energy...
Page 64: Display Panel Navigation
Display Panel Navigation [ L a n g u a g e > ] ▼ T i m e & D a t e > T i m e C o n f i g > U n i t s >...
Page 65 A cursor (underline) is used within lines Cursor: where actual settings can be adjusted. In these screens, use the Up and Down arrows to make changes to the value underlined. Move the cursor from digit to digit using the Right and Left arrows. Use the Checkmark to move the cursor down one line.
Page 66: Alerts And Messages
Alerts and Messages When messages and alerts exist, they will be highlighted and can be selected with the Left arrow. Alerts displayed will have priority over messages. O f f O n / O f f M o d e For example, if alerts are appearing in the fourth line of the display: 1.
Page 67: Main Menu
Machine Info Set-Up Energy Saver Factory Defaults Service Exit Main Menu Main Menu From the Home screen, press the Menu button to enter the Main menu, where you can choose to see machine information, make setup changes, set the Energy Saver mode, or enter the Service Menu. Part Number STH026 2/12...
Page 68: Machine Info Menu
Machine Info Menu From the Main menu, ensure that Machine Info is highlighted and press the Checkmark to view a list including capacity, model number, IMH (Ice Machine Head) serial number, condenser serial number, warranty, installation date, date of manufacture and software version.
Page 69: Password Entry
Password Entry A password is not required, although a password can be turned on to prevent unauthorized control setting modification. You can use the Factory Default Password of "1234" or enter a four digit custom pin number of your choosing. To turn on the password feature use the following procedure.
Page 70 To enter a four digit password of your choosing use the following procedure. 1. Press the Menu button. 2. From the Main menu, use the Down arrow to highlight setup and press the Right arrow. 3. Use the Down arrow to select Edit Password and press the Right arrow.
Page 71: Reset Password To Factory Defaults
RESET PASSWORD TO FACTORY DEFAULTS The password can be reset to the factory defaults when required. The default factory password is 1234. To reset the ice machine to factory defaults use the following procedure. 1. Press the Menu button. 2. From the Main menu, use the Down arrow to highlight Defaults.
Page 72: Set-Up Menu
Set-Up Menu From the Main menu, use the Down arrow to navigate to Set-Up and press the Checkmark. Select and customize machine settings on this menu. Press the Left arrow to return to previous screens. LANGUAGE 1. From the Set-Up menu, use the Down arrow to highlight Language.
Page 73 4. Press the Checkmark. The date will appear on the first line of the display (Mo/Day/Yr) and the time will appear on the second line (24 Hour). The month will have a blinking cursor. 5. Using the Up or Down arrow, adjust the month, if necessary.
Page 74: Time Configuration
TIME CONFIGURATION 1. From the Set-Up menu, use the Down arrow to highlight Time Config. 2. Press the Checkmark. On this screen, you can choose whether the date will be displayed as Mo/Day/Yr or Day/Mo/Yr by highlighting your choice and pressing the Checkmark. Selecting one will deselect the other.
Page 75: Ice Clarity
ICE CLARITY In areas with poor potable water quality, the ice machine makes cloudy ice. Setting Ice Clarity to ON will add additional water during the freeze cycle to dilute the water that contains a high content of dissolved solids in the water trough. This feature decreases production and increases water usage.
Page 76: Password On
PASSWORD ON A password can be added to prevent unauthorized changes to ice machine settings. 1. From the Set-Up menu, use the Down arrow to highlight Password On. 2. Enter the password and press the Checkmark. 3. Press the Left arrow to return to previous screens and to the Set-Up menu.
Page 77: Iaucs Runtime
IAUCS RUNTIME Automatic Cleaning System is an optional accessory and will perform a cleaning cycle at a set time interval. 1. From the Set-Up menu, use the Down arrow to highlight AuCS RunTime. 2. Press the Checkmark. On this screen, you can choose to turn the feature ON or OFF by highlighting your choice and pressing the Checkmark.
Page 78: Water Filter
WATER FILTER The ice machine has a feature that displays a replace water filter reminder at a set time interval. 1. From the Set-Up menu, use the Down arrow to highlight Water Filter. 2. Press the Checkmark. You can record the filter type on this screen by highlighting Filter Type and pressing the Checkmark.
Page 79: Usb Setup
USB SETUP Refer to “Upgrading Firmware with a Flash Drive” and “Exporting Data to a Flash Drive” for more information on this setting. FACTORY DEFAULTS The entire setup can be reset to the factory defaults. 1. From the Set-Up menu, use the Down arrow to highlight Fact Deflts.
Page 80: Energy Saver Menu
Energy Saver Menu From the Main menu, use the Down arrow to navigate to Energy Saver and press the Checkmark. Set up an energy saving ice program, enable the Water Miser and view usage statistics from this menu. Press the Left arrow to return to previous screens.
Page 81: Ice Program
ICE PROGRAM To save energy and water, the ice machine can be programmed to only power up during time periods that the ice will be used or when the bin level is being depleted by heavy use. Important Setting an ice program will take the ice machine out of the On/Off Mode and the Power button will be disabled.
Page 82: Water Miser
WATER MISER Water Miser is a feature that reduces water usage by eliminating flush cycles. Enabling this feature is only recommended for systems with de-ionized or reverse osmosis filtering. 1. From the Energy Saver menu, use the Down arrow to highlight Water Miser. 2.
Page 83: Service Menu
Service Menu From the Main menu, use the Down arrow to navigate to Service and press the Checkmark. This menu is intended for the use of trained service personnel. Below is and overview of the service menu. The following pages list the navigation options available by drilling into the menus with the down arrow.
Page 84: Data History
DATA HISTORY Press the Checkmark with Data History highlighted to view a list of eight-digit dates (Current, Current + 1 ... Current + 5), along with Lifetime (be sure to use the Down arrow to reveal all the available information). For each of the dates, use the Checkmark to view: •...
Page 85: Real Time Data
REAL TIME DATA Press the Checkmark with Real Time Data highlighted to get readings on Time & Temp, Inputs and Outputs (be sure to use the Down arrow to reveal all the available information). Use the Checkmark to view: Time and Temperature •...
Page 86 Outputs • Status Off/On - Displays stage of cycle • Water Pump Off/On • Hot Gas Valve 1 Off/On • Hot Gas Valve 2 Off/On • Air Pump Off/On • Water Valve Off/On • Dump Valve Off/On • Compressor Control Off/On •...
Page 87: Diagnostics
DIAGNOSTICS Press the Checkmark with Diagnostics highlighted to enter screens where you can run diagnostics on the control board, sensors and switches. Control Board • Self Check • Enable Relays • Exit Temperature Sensors • T1 Thermistor Temperature • T2 Thermistor Temperature •...
Page 88: Manual Harvest
MANUAL HARVEST Press the Checkmark with Manual Harvest highlighted to initiate a manual harvest. Manual Harvest • Harvest Started • Exit REPLACE CONTROL BOARD Press the Checkmark with Replace Control Board highlighted to program the replacement control board. The data can copied from the defective control board (refer to exporting data to a flash drive page 98), or entered manually through the Indigo interface.
Page 89: Event Log Menu
EVENT LOG MENU From the Service menu, use the Down arrow to navigate to Event Log and press the Checkmark. Ensure View ELog is highlighted and press the Checkmark to see the first event code, when it occurred and how many times. Use the Down arrow to view information on subsequent event codes.
Page 90: Event Log
EVENT LOG Refer to the following table for Event Code descriptions. Code Description Long Freeze Cycle Long Harvest Cycle Input Power Loss High Condenser Temperature High Pressure Control Opened Spare Starving TXV or Low On Charge TXV Fault #1 Evaporator Flooding #2 Evaporator Flooding Refrigeration Fault Curtain Switch Fault - Open more than 12 hours...
Page 91 Event Log Detail Detail Event Log Service Definition Definition E-Log Display Text Error Description Long Freeze 6 consecutive 60 Minute Freeze cycles = shut down and flash the SL#1 light on board Long Freeze Long Harvest 3 consecutive - 3.5 Minute Harvests logs SL#2 in memory, but runs until 500 long harvest cycles occur. Long Harvest When power is interrupted to the ice machine the control board will log the event in the ELOG and Power Supply (Event Log only -...
Page 92 Detail Event Log Service Definition E-Log Display Text Error Description Definition The compressor discharge temperature did not increase by at least 10 F, and the evaporator Refrigeration System (Refrig Refig Fault temperature did not decreased by at least 10 F - Measured from Refrigeration Start up to Two Minutes Fault) into the Freeze cycle.
Page 93 Detail Event Log Service Definition Definition E-Log Display Text Error Description T1 Fault T1 Sensor Each thermistor reading is monitored continuously using six second average values. During Pre-chill T2 Fault T2 Sensor a thermistor had a six second average thermistor values fall outside of the valid temperature range. T3 Fault T3 Sensor T4 Fault...
Page 94: Usb Flash Drive Specifications And Formatting
USB FLASH DRIVE SPECIFICATIONS AND FORMATTING Updating firmware on Indigo™ model ice machines requires a properly formatted 2 GB or smaller USB flash drive. All USB flash drives must be formatted before use to remove any software programs or files currently on the flash drive.
Page 95 Windows XP Computers: 1. Insert USB flash drive; your computer may indicate: • “Found New Hardware” follow the prompts to install the USB flash drive • USB flash drive may auto launch - Close auto launch window. 2. To access Disk Management: •...
Page 96: Upgrading Firmware With A Flash Drive Or Transferring Setup Data To Multiple Machines
UPGRADING FIRMWARE WITH A FLASH DRIVE OR TRANSFERRING SETUP DATA TO MULTIPLE MACHINES Important The flash drive must be formatted before using, All files and software on the flash drive are removed during the formatting process. Refer to page 94 USB Flash Drive Specifications and Formatting.
Page 97 USB Connector Bin Switches Thermostat Display Light Micro Light Thermistors Clean Light Harvest Light SL-1 Light SL-2 Light Dump Valve Transformer Left Bin Switch Light Right Bin Switch Light Water Level Probe Light Display Ice Thickness Probe Light RS485 RT Harvest Bin LED Compressor Battery...
Page 98: Exporting Data To A Flash Drive
EXPORTING DATA TO A FLASH DRIVE Data can be copied from the control board memory to a flash drive and used to transfer setup and/or cycle data to a replacement control board or to transfer setup information to multiple ice machines. Data may also be requested by service department personnel for analysis or as an aid to troubleshooting.
Page 99 USB Connector Bin Switches Thermostat Display Light Micro Light Thermistors Clean Light Harvest Light SL-1 Light SL-2 Light Dump Valve Left Bin Switch Light Transformer Right Bin Switch Light Water Level Probe Light Display Ice Thickness Probe Light RS485 RT Harvest Bin LED Compressor Battery...
Page 100: Safe Operation Mode
SAFE OPERATION MODE Allows the ice machine to operate up to 72 hours if the ice thickness probe (E19 fault) and/or water level probe sensors fail (E20 fault). • When the control board starts the safe mode an alert is flashed on the LCD display to notify the end-user they have a production problem.
Page 101: Operational Checks
Operational Checks GENERAL Manitowoc ice machines are factory-operated and adjusted before shipment. Normally, new installations do not require any adjustment. To ensure proper operation, always follow the Operational Checks: • when starting the ice machine for the first time •...
Page 102: Ice Thickness Check
ICE THICKNESS CHECK After a harvest cycle, inspect the ice cubes in the ice storage bin. The ice thickness probe is factory-set to maintain the ice bridge thickness at 1/8" (3 mm). NOTE: Make sure the water curtain is in place when performing this check.
Page 103: Sequence Of Operation
Sequence of Operation QUIETQUBE® MODELS The power button must be depressed and the NOTE: water curtain/ice dampers must be in place on the evaporator before the ice machine will start. INITIAL START-UP OR START-UP AFTER AUTOMATIC SHUT-OFF Water Purge Before the compressor starts, the water pump and water dump solenoid are energized to purge the ice machine of old water.
Page 104: Freeze Sequence
FREEZE SEQUENCE Pre chill The water inlet valve energizes and the compressor lowers the temperature of the evaporator(s) before the water pump(s) is energized. The water fill valve will remain energized until water completes the water level probe circuit. Freeze The water pump(s) energizes and water flows over the evaporator.
Page 105: Harvest Sequence
HARVEST SEQUENCE Water Purge The air pump(s) (when used) and the harvest valve(s) open at the beginning of the water purge to divert refrigerant gas into the evaporator. The water pump continues to run, and the water dump valve energizes to purge the water in the water trough. ICVD Condensing Unit: When the refrigerant pressure is low enough to open the fan cycling pressure control the condenser fan...
Page 106: Automatic Shut-Off
AUTOMATIC SHUT-OFF Automatic Shut-Off Ice Machine Section: Shuts off when: • The storage bin is full at the end of a harvest sequence. • The sheet of cubes fails to clear the water curtain and holds it open. • Ice contacts the bin level thermostat probe (when used).
Page 107 Single & Twin Evaporator QuietQube® Models Energized Parts Chart Contactor Ice Making Refrigeration Length of Water Liquid Line Water Harvest Water Inlet Sequence of Compressor & Air Pumps Dump Solenoid Pump Valve (s) Valve Time Condenser Fan Valve Valve Operation Motor Start-Up - Initial or After Auto Shut Off...
Page 108 Single & Twin Evaporator QuietQube® Models Energized Parts Chart (Continued) Contactor Ice Making Refrigeration Length of Water Liquid Line Water Harvest Water Inlet Sequence of Compressor & Air Pumps Dump Solenoid Pump Valve (s) Valve Time Condenser Fan Valve Valve Operation Motor Harvest Sequence...
Page 109: Safety Timers
SAFETY TIMERS The control board has the following non-adjustable safety timers: • The ice machine is locked into the freeze cycle for 6 minutes before a harvest cycle can be initiated (8 minutes on dual evaporator models).This can be overridden by initiating a manual harvest. Refer to “Manual Harvest”...
Page 110 This Page Intentionally Left Blank Part Number STH026 2/12...
Page 111: Troubleshooting
Troubleshooting Safety Limits In addition to standard safety controls, the control board has built in safety limit controls which protect the ice machine from major component failures. Safety limits are stored and indicated by the control board after three cycles. The number of cycles required to stop the ice machine varies for each safety limit.
Page 112: Analyzing Why A Safety Limit Stopped The Ice Machine
Eliminate all electrical components and external causes first. If it appears that the refrigeration system is causing the problem, use Manitowoc’s Freeze Cycle Refrigeration System Operational Analysis Table, along with detailed charts, checklists, and other references to determine the cause.
Page 113: Safety Limit #1
• Contactor not energizing • Compressor electrically non-operational • Defective fan cycling control • Defective fan motor Miscellaneous • Non-Manitowoc components • Improper refrigerant charge • Defective head pressure control • Defective harvest valve • Defective compressor • TXV starving or flooding (check bulb mounting) •...
Page 114: Safety Limit #2
Ice thickness probe out of adjustment • Ice thickness probe dirty • Bin switch closed/defective • Premature harvest Refrigeration System • Non-Manitowoc components • Improper refrigerant charge • Defective head pressure control valve • Defective harvest valve • TXV flooding (check bulb mounting) •...
Page 115 This Page Intentionally Left Blank Part Number STH026 2/12...
Page 116 This Page Intentionally Left Blank Part Number STH026 2/12...
Page 117: Troubleshooting By Symptom
Troubleshooting By Symptom The troubleshooting procedures follow flow charts. There are four symptoms, the symptom that you are experiencing will determine which flow chart to use. The flow chart asks yes and no questions to determine the problem. The flow chart will direct you to a procedure to correct the problem.
Page 118 Reset To Factory Defaults Before starting troubleshooting procedures, reset the control board to factory defaults to prevent misdiagnosis. Before resetting to factory defaults do one of the following: A. Copy settings to a usb device and flash settings into the control board when diagnostics are complete.
Page 119: Symptom #1 Ice Machine Will Not Run
SYMPTOM #1 ICE MACHINE WILL NOT RUN ICE MACHINE STOPS RUNNING OR HAS A HISTORY OF SHUTTING DOWN START Are there any lights on or flashing on the control board? Is there an Alert or Refer to Alert/Error Log Line voltage at wires Error Logged? 55 &...
Page 120 Refer to display & control Display light Control board fuse board diagnostics flashing is good? heartbeat? Install the water curtain/damper. Replace fuse & determine which Refer to display & control component caused fuse to blow board diagnostics Bin switch light on? All water curtains or (Multi evap all lights on?) dampers in place?
Page 121 Is magnet on the Replace the water water curtain/damper curtain/damper. Press power button to start ice making, does safety limit light flash? Refer to bin switch diagnostics. Ice machine starts? Refer to Safety Limit #1 long freeze cycle Which light flashes? Refer to display &...
Page 122 Diagnosing an Ice Machine That Will Not Run Warning High (line) voltage is applied to the control board (terminals #55 and #56) at all times. Removing control board fuse or pressing the power button will not remove the power supplied to the control board. 1.
Page 123: Diagnosing A Condensing Unit That Will Not Run
DIAGNOSING A CONDENSING UNIT THAT WILL NOT RUN If the ice machine water pump is not energized, refer to “Diagnosing an Ice Machine that Will Not Run. 1. Verify primary voltage is supplied to ice machine condensing unit and the fuse/circuit breaker is closed.
Page 124: Symptom #2 Low Production, Long Freeze
SYMPTOM #2 LOW PRODUCTION, LONG FREEZE Ice Machine has a Long Freeze Cycle. Ice Formation is Thick Thin on Top or Bottom of Evaporator Low Production How to Use the Freeze Cycle Refrigeration System Operational Analysis Table GENERAL These tables must be used with charts, checklists and other references to eliminate refrigeration components not listed on the tables and external items and problems which can cause good refrigeration...
Page 125 PROCEDURE Step 1 Complete the “Operation Analysis” column. Read down the left “Operational Analysis” column. Perform all procedures and check all information listed. Each item in this column has supporting reference material to help analyze each step. While analyzing each item separately, you may find an “external problem”...
Page 126: Quietqube® Models- Freeze Cycle Refrigeration System Operational Analysis Tables
QUIETQUBE® MODELS- Freeze Cycle Refrigeration System Operational Analysis Tables I Model QuietQube® Single Expansion Valve Operational Analysis Published 24 hour ice production________________ Calculated (actual) ice production_______________ Ice Production NOTE: The ice machine is operating properly if the ice fill patterns is normal and ice production is within 10% of charted capacity.
Page 127 I Model QuietQube® Single Expansion Valve Operational Analysis Safety Limits Refer to “Analyzing Safety Stops on safety limit: Stops on safety limit: Stops on safety limit: Stops on safety limit: Limits” page 112 to eliminate 1 or 2 1 or 2 1 or 2 all non-refrigeration problems.
Page 128 I Model QuietQube® Single Expansion Valve Operational Analysis Suction line temp. at Suction line temp. at Suction line temp. at Suction line temp. at Suction Line Temperature the suction shut-off the suction shut-off the suction shut-off the suction shut-off Attach a temperature probe valve is greater than valve is greater than valve is less than...
Page 129 QUIETQUBE® MODELS- Freeze Cycle Refrigeration System Operational Analysis Tables Twin Expansion Valve – I1470C/I1870C/I2170C Models Operational Analysis Published 24-hour ice production __________ Calculated (actual) 24-hour ice production __________ Ice Production NOTE: The ice machine is operating properly if the ice fill pattern is normal and ice production is within 10% of charted capacity.
Page 130 Twin Expansion Valve – I1470C/I1870C/I2170C Models Operational Analysis Safety Limits Refer to “Analyzing Stops on Stops on Stops on Stops on Safety Limits” page 112 to safety limit: safety limit: safety limit: safety limit: 1 or 2 1 or 2 1 or 2 eliminate all non-refrigeration problems.
Page 131 Twin Expansion Valve – I1470C/I1870C/I2170C Models Operational Analysis No audible No audible No audible Audible refrigerant flow refrigerant flow through refrigerant flow through refrigerant flow through through left or right Harvest Valve left or right valve in left or right valve in left or right valve in valve in Freeze cycle Freeze cycle...
Page 132: Quietqube® Models - Freeze Cycle Refrigeration System Operational Analysis Table Procedures
QUIETQUBE® MODELS - FREEZE CYCLE REFRIGERATION SYSTEM OPERATIONAL ANALYSIS TABLE PROCEDURES The following is the procedures for completing each step of the Freeze Cycle Refrigeration System Operational Analysis Tables. Each procedure must be performed exactly for the table to work correctly. Before Beginning Service Ice machines may experience operational problems only during certain times of the day or night.
Page 133 QuietQube® Models - Ice Production Check The amount of ice a machine produces directly relates to the operating water and air temperatures. This means a condensing unit with a 70°F (21°C) outdoor ambient temperature and 50°F (10°C) water produces more ice than the same model condensing unit with a 90°F (32°C) outdoor ambient temperature and 70°F (21°C) water.
Page 134 • Another ice machine is required. • More storage capacity is required. • Relocating the existing equipment to lower the load conditions is required. Contact the local Manitowoc Distributor for information on available options and accessories. Part Number STH026 2/12...
Page 135 QuietQube® Models - Installation/Visual Inspection Checklist Inadequate Clearances • Check all clearances on sides, back and top. Ice machine is not level • Level the ice machine Condenser is dirty • Clean the condenser Water filtration is plugged (if used) •...
Page 136 QuietQube® Models - Water System Checklist A water-related problem often causes the same symptoms as a refrigeration system component malfunction. Water system problems must be identified and eliminated prior to replacing refrigeration components. Water area (evaporator) is dirty • Clean as needed Water inlet pressure not between 20 and 80 psig (1-5 Bar, 138-552 kPa).
Page 137 Evaporator ice formation pattern analysis is helpful in ice machine diagnostics. Analyzing the ice formation pattern alone cannot diagnose an ice machine malfunction. However, when this analysis is used along with Manitowoc’s Freeze Cycle Refrigeration System Operational Analysis Tables, it can help diagnose an ice machine malfunction.
Page 138 2. Extremely Thin at Evaporator Outlet There is no ice, or a considerable lack of ice formation, at the outlet of the evaporator. Examples: No ice at all on the outlet half of the evaporator, but ice forms on the inlet half of the evaporator.
Page 139 IB MODELS - ICE FORMATION PATTERN Tubing routing for Ice Beverage evaporators is different. The evaporator outlet is moved lower on the evaporator. • IB600 and IB800 evaporators outlets exit roughly 1/2 way down the evaporator. Extremely Thin at the Evaporator Outlet will first be visible near the middle of the evaporator •...
Page 140 QuietQube® Models - Analyzing Discharge Pressure in the Freeze Cycle 1. Determine the ice machine operating conditions: Air temp. entering condenser______ Air temp. around ice machine______ Water temp. entering sump trough______ 2. Refer to Operating Pressure table (starting on page 221) for ice machine being checked. Use the operating conditions determined in step 1 to find the published normal discharge pressures.
Page 141 • Dirty/Defective water regulating valve • Water regulating valve out of adjustment Other • Overcharged • Non-condensable (air) in system • Wrong type of refrigerant • Non-Manitowoc components in system • High side refrigerant lines/component restricted Part Number STH026 2/12...
Page 142 Defective fan cycle control, stuck closed (page 185) Water Cooled Condensers • Water Regulating Valve out of adjustment • Water Regulating Valve Defective Other • Undercharged • Wrong type of refrigerant • Non-Manitowoc components in system • Liquid line/component restricted Part Number STH026 2/12...
Page 143 QuietQube® Models - Analyzing Suction Pressure The suction pressure gradually drops throughout the freeze cycle. The actual suction pressure (and drop rate) changes as the air and water temperature entering the ice machine changes. These variables also determine the freeze cycle times. To analyze and identify the proper suction pressure drop throughout the freeze cycle, compare the published suction pressure to the published freeze...
Page 144 Wrong type of refrigerant • Non condensable in system Components • Harvest valve leaking - continue the table • TXV flooding - continue the table • Defective compressor - continue the table Other • Non-Manitowoc components in system Part Number STH026 2/12...
Page 145 Improper Refrigerant Charge • Undercharged • Wrong type of refrigerant Other • Non-Manitowoc components in system • Improper water supply over evaporator – refer to “Water System Checklist” (page 136) • Restricted/plugged liquid line drier • Restricted/plugged tubing in suction side of refrigeration system •...
Page 146 The best way to diagnose a harvest valve is by using Manitowoc’s Ice Machine Freeze Cycle Refrigeration System Operational Analysis Table. Use the following procedures to determine if a harvest valve is remaining partially open during the freeze cycle.
Page 147 QuietQube® Models - Analyzing Freeze Cycle Suction Line Temperature Suction line temperature alone cannot diagnose an ice machine. However, comparing this temperature during the freeze cycle, along with using Manitowoc’s Symptom #2 - Refrigeration System Operational Analysis Table, can help diagnose an ice machine malfunction.
Page 148 QuietQube® Model Final Analysis The column with the highest number of Checkmarks identifies the refrigeration problem. COLUMN 1 - HARVEST VALVE LEAKING Replace the valve as required. COLUMN 2 - LOW CHARGE/TXV STARVING Normally, a starving expansion valve only affects the freeze cycle pressures, not the harvest cycle pressures.
Page 149 COLUMN 3 - TXV FLOODING OR REFRIGERANT OVERCHARGE A loose or improperly mounted expansion valve bulb causes the expansion valve to flood. Check bulb mounting, insulation, etc., before changing the valve. Verify refrigerant amount is correct by weighing recovered refrigerant before replacing a TXV. COLUMN 4 - COMPRESSOR Replace the compressor.
Page 150: Symptom #3 Harvest Problems
SYMPTOM #3 HARVEST PROBLEMS Melted Out Ice Cube Normal Ice Cube Definition of a harvest problem; At the end of a 3.5 minute harvest cycle the slab of ice is still contacting the evaporator. The slab of ice may or may not be removable by hand.
Page 151: Symptom #3 Quietqube® Models With Icvd Condensing Units
SYMPTOM #3 QUIETQUBE® MODELS WITH ICVD CONDENSING UNITS ICE MACHINE WILL NOT HARVEST - FREEZE CYCLE NORMAL, CUBES ARE NOT MELTED Ice Machine Will Not Harvest - Freeze Cycle Is Normal and Ice Cubes Are Not Melted Afte Ice Machine Will Not Harvest - Freeze Cycle Is Normal and Ice Cubes Are Not Melted After Harvest START Refer to Sequence of Operation Is the Harvest Valve(s)
Page 152 Replace Is Head Pressure high & Harvest Suction Pressure low Valve in harvest? Is Head Pressure low & Not a refrigeration problem, No; Harvest PSI Normal Suction Pressure low in harvest? Clean & Inspect Evaporator Feel temperature of Receiver after 30 seconds Feels Warm to Hot into harvest cycle Cold...
Page 153 Cold Feel temperature of Liquid Line Backseat Liquid Line Shut Feels Hot at rear of Head Section Off Valve or Replace Cold Look for Restriction, Feel temperature of Liquid Line Feels Hot Correct Line Set Size, at Condensing Unit & Proper Insulation Cold Does the Condenser Fan Motor Refer to Fan Cycling...
Page 154 IMPORTANT Feel temperature of Discharge Line Headmaster is not Weigh charge as you are recovering, after 30 seconds into Harvest Cycle in 100% Bypass if incorrect evacuate & recharge, (refer to Harvest Headmaster Diagnostics) if correct then proceed Refrigerant Charge Refrigerant Charge is Correct is Incorrect...
Page 155: Symptom #4 Quietqube® Models With Icvd Condensing Units
SYMPTOM #4 QUIETQUBE® MODELS WITH ICVD CONDENSING UNITS Ice Machine Will Not Harvest - Freeze Cycle Is Normal and Ice Cubes Are Melted After Harvest START Level Ice Back of cubes are melted Is Ice Machine level? at end of harvest cycle? Machine Refer to Is water flow over the evaporator at...
Page 156 Is the evaporator dirty or damaged? (Dry evaporator first then check) Refer to Symptom #2 Refer to Cleaning Freeze Cycle Operational Procedures Analysis Table...
Page 157 This Page Intentionally Left Blank Part Number STH026 2/12...
Page 158 This Page Intentionally Left Blank Part Number STH026 2/12...
Page 159: Component Check Procedures
Component Check Procedures Electrical Components CONTROL BOARD, DISPLAY BOARD AND TOUCH FUNCTION The control board, display board and touch pad provide user input and control the ice machine sequence of operation. NOTE: Anytime power is supplied to wires #55 & #56 on the control board, the “Display”...
Page 160 Control Board Diagnostics 1. Micro light is not flashing a heartbeat. 2. Disconnect line voltage power supply to the ice machine and wait a minimum of 15 seconds, then reapply power. A. Micro light flashes - continue with step 3. B.
Page 161 Touch Pad Diagnostics Follow the control board diagnostics to the Status Passed display. Perform the following keystrokes on the display. • Display reads Status Passed, press the right arrow • Display reads Pass Yes, press the right arrow • Display reads Key Pad Test, press the right arrow 4.
Page 162: Control Board Relay Test
CONTROL BOARD RELAY TEST The control board can be set to energize all relays for 3.5 minutes. This allows testing to verify control board relays are closed and line voltage is available for ice machine components - Water pump, dump valve, water inlet valve, harvest valve(s), air compressor, contactor/compressor/fan motor - The fan cycle control must close to energize the fan motor.
Page 163: Usb Flash Drive Specifications And Formatting
USB FLASH DRIVE SPECIFICATIONS AND FORMATTING Updating firmware on Indigo™ model ice machines requires a properly formatted 2 GB or smaller USB flash drive. All USB flash drives must be formatted before use to remove any software programs or files currently on the flash drive.
Page 164 Windows XP Computers: 1. Insert USB flash drive; your computer may indicate: • “Found New Hardware” follow the prompts to install the USB flash drive • USB flash drive may auto launch - Close auto launch window. 2. To access Disk Management: •...
Page 165: Upgrading Firmware With A Flash Drive Or Transferring Setup Data To Multiple Machines
UPGRADING FIRMWARE WITH A FLASH DRIVE OR TRANSFERRING SETUP DATA TO MULTIPLE MACHINES Important Do not use a flash drive with a built-in software program, such as Sandisk brand. 1. Drag and drop the file from your email onto a flash drive or refer to Exporting data to a flash drive to transfer settings to multiple machines.
Page 166 USB Connector Bin Switches Thermostat Display Light Micro Light Thermistors Clean Light Harvest Light SL-1 Light SL-2 Light Dump Valve Transformer Left Bin Switch Light Right Bin Switch Light Water Level Probe Light Display Ice Thickness Probe Light RS485 RT Harvest Bin LED Compressor Battery...
Page 167: Exporting Data To A Flash Drive
EXPORTING DATA TO A FLASH DRIVE Data can be copied from the control board memory to a flash drive and used to transfer setup and/or cycle data to a replacement control board or to transfer setup information to multiple ice machines. Data may also be requested by service department personnel for analysis or as an aid to troubleshooting.
Page 168 USB Connector Bin Switches Thermostat Display Light Micro Light Thermistors Clean Light Harvest Light SL-1 Light SL-2 Light Dump Valve Left Bin Switch Light Transformer Right Bin Switch Light Water Level Probe Light Display Ice Thickness Probe Light RS485 RT Harvest Bin LED Compressor Battery...
Page 169: Main Fuse
MAIN FUSE FUNCTION The control board fuse stops ice machine operation if electrical components fail, causing high amp draw. SPECIFICATIONS The main fuse is 250 Volt, 8 amp. Warning High (line) voltage is applied to the control board (terminals #55 and #56) at all times. Removing the control board fuse or pressing the On/Off button will not remove the power supplied to the control board.
Page 170: Bin Switch
BIN SWITCH FUNCTION Movement of the water curtain/ice dampers control bin switch operation. The bin switch has two main functions: 1. Terminating the Harvest cycle and returning the ice machine to the Freeze cycle. This occurs when the bin switch is opened and closed again within 30 seconds during the Harvest cycle.
Page 171 Diagnostics SYMPTOMS Bin Switch Fails Open • The ice machine will not start an ice making cycle and the display indicates “Curtain Open”. • The ice machine will run in the clean cycle. Bin Switch Fails Closed • When running a “Long Harvest” alert is displayed and safety limit 2 indicated.
Page 172 3. Disconnect bin switch wire from control board. 4. Jumper control board bin switch wire to ground, press the power button and observe the display and control board lights. A. Curtain switch closes, control board light energizes and ice machine starts - Replace bin switch B.
Page 173: Water Level Control Circuitry
WATER LEVEL CONTROL CIRCUITRY FUNCTION The water level probe controls the water level by sensing whether water is or is not contacting the water level probe. The water level probe has three sensing probes. Two probes are equal in length and are used to measures conductivity for diagnostics, ice clarity and water miser options.
Page 174 Diagnostics SYMPTOMS • Water trough overfills • Water trough will not fill • Display indicates a “Long Freeze” alert and may or may not also indicate a safety limit 1 • Ice production is low WATER TROUGH OVERFILLING DURING THE FREEZE CYCLE Step 1 Press the power button and turn off the ice machine.
Page 175 Step 6 Wait until the pre-chill cycle begins, then jumper water level probe connection #2 & #3 at the control board. A. Water level light energizes and water flow stops - Repair wire or replace water level probe. B. Water level light does not energize and water continues to flow - Replace control board.
Page 176 WATER WILL NOT RUN INTO THE SUMP TROUGH DURING THE FREEZE CYCLE Step 1 Verify water is supplied to the ice machine. Step 2 Scroll to Service/Diagnostics/Inputs and press down arrow until Wtr Low and Wtr High are displayed. A. Yes is displayed - Control board is receiving a sensing water signal.
Page 177: Ice Thickness Probe (Harvest Initiation)
ICE THICKNESS PROBE (HARVEST INITIATION) FUNCTION The ice thickness probe senses ice on the evaporator and signals the control board to start a harvest cycle. After ice forms on the evaporator, the ice will contact the ice thickness probe and a harvest cycle is initiated. SPECIFICATIONS Freeze Time Lock-In Feature The ice machine control system incorporates a freeze...
Page 178 Ice Thickness Check The ice thickness probe is factory-set to maintain the ice bridge thickness at 1/8 in. (32 mm). Make sure the water curtain/splash shields NOTE: are in place when performing this check. It prevents water from splashing out of the water trough. 1.
Page 179 Diagnostics SYMPTOMS Premature harvest • Display indicates ITP Failure • Low ice production • Thin ice in bin • Freeze cycles are faster than published cycle times Will not harvest • Display indicates ITP Failure • Low ice production • Thick ice in bin •...
Page 180 ICE MACHINE DOES NOT CYCLE INTO HARVEST If ice is on the evaporator initiate a manual harvest cycle by performing the following keystrokes. • Press Menu • Scroll down to Service and press right arrow • Scroll down to Manual Harvest and press right arrow - A new freeze cycle will start after the manual harvest cycle is complete.
Page 181: High Pressure Cutout (Hpco) Control
HIGH PRESSURE CUTOUT (HPCO) CONTROL FUNCTION Stops the ice machine if subjected to excessive high- side pressure. The HPCO control is normally closed, and opens on a rise in discharge pressure. SPECIFICATIONS. Specifications Cut-Out Cut-In 440 psig ±10 Automatic Reset (3103 kPa ±69 31 bar ±.69) (Must be below 300 psig (2068 kPa 20.68 bar) to reset.) SYMPTOM...
Page 182 CHECK PROCEDURE Symptom #1 Machine is off and the display indicates “Delay xx min, HPCO Active”. 1. Leave all wiring connectors attached and perform testing within the 60 minute time delay period 2. Check for line voltage at P9 connector on control board (Two wire connector adjacent to 9 pin connector).
Page 183 Symptom #2 Machine is running and the display indicates “HPC Fault” and an alert triangle 1. Navigate to the event log on the Service menu. Scroll down to HPC Fault #5. Open the event and view when and how often HPCO Fault has occurred.
Page 184: Low Pressure Cutout (Lpco) Control
LOW PRESSURE CUTOUT (LPCO) CONTROL FUNCTION Signals the control board to energize and de-energize the ice machine when suction pressure rises above or falls below setpoint. The LPCO control is closed at pressures above setpoint and opens at pressures below setpoint. Specifications Cut-Out Cut-In...
Page 185: Fan Cycle Control
FAN CYCLE CONTROL FUNCTION Cycles the fan motor on and off to maintain proper operating discharge pressure. The fan cycle control closes on an increase, and opens on a decrease in discharge pressure. SPECIFICATIONS Specifications Cut-Out Model Cut-In (Close) (Open) ICVD0695 ICVD0895 ICVD1095...
Page 186: Thermistors
THERMISTORS FUNCTION Thermistor resistance values change with temperature. The value supplied to the control board is used to identify temperature at the thermistor location. SPECIFICATIONS Temperature of Thermistor Resistance °C °F K Ohms (x 1000) -30° - -20° -22° - -4° 820.85 - 466.35 -20°...
Page 187 Four thermistors are located on the ice machine. They are labeled T1, T2, T3, T4 T1 - Remote Condensing Unit Models • Liquid line temperature sensor located at the inlet of the receiver. T2 - Remote Condensing Unit Models • Liquid line temperature sensor located at the outlet of the receiver.
Page 188 Thermistor Matrix Part Number STH026 2/12...
Page 189 SYMPTOM Alert icon on the display is flashing and the alert indicates a T1, T2, T3, or T4 Fault. CHECK PROCEDURE • Press the Menu button. • Scroll down to Service and press right arrow. • Scroll down to Diagnostics and press right arrow •...
Page 190: Harvest Assist Air Pump
HARVEST ASSIST AIR PUMP FUNCTION The air pump breaks the vacuum between the sheet of ice and the evaporator which results in shorter harvest cycles. SPECIFICATIONS 115 Volt or 230 Volt - matches the ice machine voltage. CHECK PROCEDURE 1. The air pump is wired in parallel with the harvest valve - Verify the ice machine is in the harvest cycle and the harvest valve is energized.
Page 191: Compressor Electrical Diagnostics
COMPRESSOR ELECTRICAL DIAGNOSTICS The compressor does not start or will trip repeatedly on overload. Check Resistance (Ohm) Values Compressor windings can have very low ohm NOTE: values. Use a properly calibrated meter. Perform the resistance test after the compressor cools. The compressor dome should be cool enough to touch (below 120°F/49°C) to assure that the overload is closed and the resistance readings will be accurate.
Page 192 CHECK MOTOR WINDINGS TO GROUND Check continuity between all three terminals and the compressor shell or copper refrigeration line. Scrape metal surface to get good contact. If continuity is present, the compressor windings are grounded and the compressor should be replaced. COMPRESSOR DRAWING LOCKED ROTOR To determine if the compressor is seized, check the amp draw while the compressor is trying to start.
Page 193: Diagnosing Start Components
DIAGNOSING START COMPONENTS If the compressor attempts to start, or hums and trips the overload protector, check the start components before replacing the compressor. Capacitor Visual evidence of capacitor failure can include a bulged terminal end or a ruptured membrane. Do not assume a capacitor is good if no visual evidence is present.
Page 194 Relay The relay has a set of contacts that connect and disconnect the start capacitor from the compressor start winding. The contacts on the relay are normally closed (start capacitor in series with the start winding). The relay senses the voltage generated by the start winding and opens the contacts as the compressor motor starts.
Page 195 PTCR The PTCR allows current to flow through the start winding at compressor startup. Current flow heats the ceramic discs in the PTCR. The electrical resistance increases with temperature and stops all except a trickle of current flow through the start winding. The small flow of current keeps the PTCR hot (260°F/ 127°C) and the start winding out of the circuit.
Page 196 PTCR Operation Check 1. Visually inspect the PTCR. Check for signs of physical damage. The PTCR case temperature may reach NOTE: 210°F (100°C) while the compressor is running. This is normal. Do not change a PTCR just because it is hot. 2.
Page 197 This Page Intentionally Left Blank Part Number STH026 2/12...
Page 198: Refrigeration Components
Refrigeration Components HEAD PRESSURE CONTROL VALVE Manitowoc remote systems require head pressure control valves with special settings. Replace defective head pressure control valves only with “original” Manitowoc replacement parts. Refrigerant Charge Verification The correct amount of refrigerant (name plate charge) is required to operate correctly at all ambient conditions.
Page 199 Freeze Cycle Operation All Models The R404A head pressure control valve is non adjustable. At ambient temperatures of approximately 70°F (21°C) or above, refrigerant flows through the valve from the condenser to the receiver inlet. At temperatures below this (or at higher temperatures if it is raining), the head pressure control dome’s nitrogen charge closes the condenser port and opens the bypass port from the compressor discharge line.
Page 200 Diagnostics FREEZE CYCLE - QUIETQUBE® REMOTE CONDENSING UNIT 1. Determine if the coil is clean. 2. Determine the air temperature entering the condenser. 3. Determine if the head pressure is high or low in relationship to the outside temperature. (Refer to the proper “Cycle Times/24-Hour Ice Production/ Refrigerant Pressure Charts”...
Page 201 Harvest Cycle QUIETQUBE ® REMOTE CONDENSING UNIT QuietQube® ice machines may fail in the harvest cycle when the refrigerant charge and ambient temperature create a marginal undercharge of refrigerant. The ice machine may be able to make a full sheet of ice, but fails in the harvest cycle when the receiver runs out of liquid refrigerant.
Page 202 HARVEST CYCLE DIAGNOSTICS QUIETQUBE ® REMOTE CONDENSING UNIT The headmaster control valve diverts the compressor discharge gas to the ice machine receiver in the harvest cycle. All refrigerant flow through the condenser in the harvest cycle stops. Symptoms of a headmaster valve that will not seat 100% closed (completely bypass the condenser) in the harvest cycle are:...
Page 203 Step 3 Details Grasp Here with Hands to Compare Temperatures LIQUID LINE FROM CONDENSER HARVEST CYCLE HEADMASTER CONTROL VALVE FAILURE LIST Temperature of the compressor discharge line and liquid line to the ice machine receiver feel the same 30 seconds into the harvest cycle. •...
Page 204: Suction Accumulator Operation
SUCTION ACCUMULATOR OPERATION Liquid refrigerant collects in the suction accumulator during the harvest cycle and is removed during the freeze cycle. The liquid refrigerant is returned to the compressor through a screen and orifice in the suction accumulator J tube. Passing the liquid through the orifice causes a pressure drop;...
Page 205: Recovery/Evacuation/Charging Procedures Quietqube® Models
Important Replace the liquid line drier after recovering the refrigerant and before evacuating and recharging. Use only a Manitowoc (OEM) liquid line filter-drier to prevent voiding the warranty. Warning Recovery/evacuation of a QuietQube remote ®...
Page 206: Connections
CONNECTIONS Manifold gauge sets must utilize low loss fittings to comply with U.S. Government rules and regulations. Make these connections: Ice Machine Head Section - All Models 1. Suction side of the compressor through the suction shut-off valve or suction access valve. 2.
Page 207: Recovery/Evacuation Procedures
CONNECTIONS MUST BE MADE AT THREE POINTS FOR COMPLETE REFRIGERANT RECOVERY ON ® QUIETQUBE MODELS. Refrigerant Recovery Connections Ice Machine Head RECOVERY/EVACUATION PROCEDURES 1. Press the power button to stop the ice machine. and disconnect all power to the ice machine and condensing unit.
Page 208: Charging Procedures
CHARGING PROCEDURES 1. The ice machine must be off. 2. Close the vacuum pump valve and the low side manifold gauge valve. 3. Open the refrigerant cylinder and add the proper refrigerant charge (shown on nameplate) into the system high side (receiver service valve and discharge line shut-off valve).
Page 209 This Page Intentionally Left Blank Part Number STH026 2/12...
Page 210: System Contamination Clean-Up
This section describes the basic requirements for restoring contaminated systems to reliable service. Important Manitowoc Ice assumes no responsibility for the use of contaminated refrigerant. Damage resulting from the use of contaminated refrigerant is the sole responsibility of the servicing company.
Page 211 Contamination Cleanup Chart Required Cleanup Symptoms/Findings Procedure No symptoms or suspicion of Normal contamination evacuation/recharging procedure Moisture/Air Contamination symptoms Refrigeration system open to atmosphere for longer than Mild contamination 15 minutes cleanup procedure Refrigeration test kit and/or acid oil test shows contamination Leak in water cooled condenser...
Page 212: Cleanup Procedure
CLEANUP PROCEDURE Mild System Contamination 1. Replace any failed components. 2. If the compressor is good, change the oil. 3. Replace the liquid line drier. If the contamination is from moisture, use NOTE: heat lamps during evacuation. Position them at the compressor, condenser and evaporator prior to evacuation.
Page 213 Severe System Contamination 1. Remove the refrigerant charge. 2. Remove the compressor and inspect the refrigeration lines. If burnout deposits are found, install a new harvest valve, replace the manifold strainer, TXV and harvest pressure regulating valve. 3. Wipe away any burnout deposits from suction and discharge lines at compressor.
Page 214 Important Dry nitrogen is recommended for this procedure. This will prevent CFC release. 9. Follow the normal evacuation procedure, except replace the evacuation step with the following: A. Pull vacuum to 1000 microns. Break the vacuum with dry nitrogen and sweep the system.
Page 215: Replacing Pressure Controls Without Removing Refrigerant Charge
REPLACING PRESSURE CONTROLS WITHOUT REMOVING REFRIGERANT CHARGE This procedure reduces repair time and cost. Use it when any of the following components require replacement, and the refrigeration system is operational and leak-free. • Fan cycle control (air cooled only) • Water regulating valve (water cooled only) •...
Page 216 USING PINCH-OFF TOOL Part Number STH026 2/12...
Page 217: Liquid Line Filter-Driers
LIQUID LINE FILTER-DRIERS The filter-driers used on Manitowoc ice machines are manufactured to Manitowoc specifications. The difference between a Manitowoc drier and an off- the-shelf drier is in filtration. A Manitowoc drier has dirt-retaining filtration, with fiberglass filters on both the inlet and outlet ends.
Page 218: Suction Filter
SUCTION FILTER The suction filter on QuietQube® ICVD condensing units traps particulate only, and do not contain a desiccant. The filter needs replacement when: 1. The pressure drop across the drier exceeds 2 psig. 2. A compressor is replaced. 3. Refrigeration system contains contaminants. Part Number STH026 2/12...
Page 219: Total System Refrigerant Charge
TOTAL SYSTEM REFRIGERANT CHARGE NOTE: All machines listed use R-404A refrigerant - This information is for reference only. Refer to the ice machine serial number tag to verify the system charge. Serial plate information overrides information listed on these pages. QuietQube®...
Page 220 This Page Intentionally Left Blank Part Number STH026 2/12...
Page 221: Cycle Times/24-Hour Ice Production/Refrigerant Pressure Charts
Charts Cycle Times/24-Hour Ice Production/ Refrigerant Pressure Charts These charts are used as guidelines to verify correct ice machine operation. Accurate collection of data is essential to obtain the correct diagnosis. • Production and cycle times are for dice cube - Half dice cube cycle times can be 2 - 3 minutes faster, depending on model and ambient temperature.
Page 222: I0680C/Icvd0695
I0680C/ICVD0695 Remote Air-Cooled Condensing Unit Model Characteristics vary depending on operating conditions. CYCLE TIMES Freeze Time + Harvest Time = Total Cycle Time Freeze Time + Harvest Time = Cycle Time Air Temp. Freeze Time Entering Harvest Water Temperature °F/°C Condenser Time °F/°C...
Page 223: Ib0690C/Icvd695
IB0690C/ICVD695 Remote Air-Cooled Condensing Unit Model Characteristics vary depending on operating conditions. CYCLE TIMES Freeze Time + Harvest Time = Total Cycle Time Freeze Time + Harvest Time = Cycle Time Air Temp. Freeze Time Entering Harvest Water Temperature °F/°C Condenser Time °F/°C...
Page 224: I0870C/Icvd895
I0870C/ICVD895 Remote Air-Cooled Condensing Unit Model Characteristics vary depending on operating conditions. CYCLE TIMES Freeze Time + Harvest Time = Cycle Time Air Temp. Freeze Time Entering Harvest Water Temperature °F/°C Condenser Time °F/°C 50/10 70/21 90/32 -20 to 70/ 11.0-12.6 12.1-13.8 13.4-15.4...
Page 225: Ib0890C/Icvd895
IB0890C/ICVD895 Remote Air-Cooled Condensing Unit Model Characteristics vary depending on operating conditions. CYCLE TIMES Freeze Time + Harvest Time = Cycle Time Air Temp. Freeze Time Entering Harvest Water Temperature °F/°C Condenser Time °F/°C 50/10 70/21 90/32 -20 to 70/ 8.5-9.8 9.3-10.7 10.0-11.5...
Page 226: I1070C/Icvd1095
I1070C/ICVD1095 Remote Air-Cooled Condensing Unit Model Characteristics vary depending on operating conditions. CYCLE TIMES Freeze Time + Harvest Time = Total Cycle Time Freeze Time + Harvest Time = Cycle Time Air Temp. Freeze Time Entering Harvest Water Temperature °F/°C Condenser Time °F/°C...
Page 227: Ib1090C/Icvd1195
IB1090C/ICVD1195 Remote Air-Cooled Condensing Unit Model Characteristics vary depending on operating conditions. CYCLE TIMES Freeze Time + Harvest Time = Total Cycle Time Freeze Time + Harvest Time = Cycle Time Air Temp. Freeze Time Entering Harvest Water Temperature °F/°C Condenser Time °F/°C...
Page 228: I1470C/Icvd1495
I1470C/ICVD1495 Remote Air-Cooled Condensing Unit Model Characteristics vary depending on operating conditions. CYCLE TIMES Freeze Time + Harvest Time = Total Cycle Time Freeze Time + Harvest Time = Cycle Time Air Temp. Freeze Time Entering Harvest Water Temperature °F/°C Condenser Time °F/°C...
Page 229: I1870C/Icvd1895
I1870C/ICVD1895 Remote Air-Cooled Condensing Unit Model Characteristics vary depending on operating conditions. CYCLE TIMES Freeze Time + Harvest Time = Total Cycle Time Freeze Time + Harvest Time = Cycle Time Air Temp. Freeze Time Entering Harvest Water Temperature °F/°C Condenser Time °F/°C...
Page 230: I2170C/Icvd2195
I2170C/ICVD2195 Remote Air-Cooled Condensing Unit Model Characteristics vary depending on operating conditions. CYCLE TIMES Freeze Time + Harvest Time = Total Cycle Time Freeze Time + Harvest Time = Cycle Time Air Temp. Freeze Time Entering Harvest Water Temperature °F/°C Condenser Time °F/°C...
Page 231: Wiring Diagrams
Diagrams Wiring Diagrams The following pages contain electrical wiring diagrams. Be sure you are referring to the correct diagram for the ice machine you are servicing. Warning Always disconnect power before working on electrical circuitry. Some components are wired differently on energy efficient machines.
Page 232: All Icvd Models Interconnecting Wiring
ALL ICVD MODELS INTERCONNECTING WIRING Part Number STH026 2/12...
Page 233: I0670C/I0870C/I1070C/I1270C
I0670C/I0870C/I1070C/I1270C QuietQube® Remote Air-cooled - 1 & 3 Ph Part Number STH026 2/12...
Page 234: Ib0690C/Ib0890C/Ib1090C
IB0690C/IB0890C/IB1090C QuietQube® Remote Air-cooled - 1 & 3 Ph Part Number STH026 2/12...
Page 235: Ii1400/I1800/I2170
II1400/I1800/I2170 QuietQube® Remote Air-cooled 1 & 3 Ph Part Number STH026 2/12...
Page 236: Icvd2095
ICVD2095 QuietQube® Remote Air-cooled 3 Ph Part Number STH026 2/12...
Page 237: Electronic Control Board
Electronic Control Board Bin Switches Thermostat Display Light Micro Light Thermistors Clean Light Harvest Light SL-1 Light SL-2 Light Dump Valve Transformer Left Bin Switch Light Right Bin Switch Light Water Level Probe Light Display Ice Thickness Probe Light RS485 RT Harvest Bin LED Compressor...
Page 238: Refrigeration Tubing Schematics
Refrigeration Tubing Schematics REMOTE CONDENSING UNIT MODELS I0670C/I0870C/I1070C/I1270C Condensing Unit COMPRESSOR SUCTION ACCESS VALVE LINE FILTER CHECK VALVE CONDENSER ACCUMULATOR HEAD PRESSURE CONTROL VALVE S TRAP REQUIRED 21’ OR GREATER RISE LIQUID LINE SUCTION SHUT-OFF SHUT-OFF VALVE VALVE Ice Machine Head Section EVAPORATOR HEAT EXCHANGER T4 Thermistor...
Page 239: Ib Models
IB MODELS IB0690C/IB0890C Condensing Unit COMPRESSOR SUCTION ACCESS VALVE LINE FILTER CHECK VALVE CONDENSER ACCUMULATOR HEAD PRESSURE CONTROL VALVE S TRAP REQUIRED 21’ OR GREATER RISE LIQUID LINE SUCTION SHUT-OFF SHUT-OFF VALVE VALVE Ice Machine Head Section EVAPORATOR HEAT EXCHANGER T4 Thermistor Thermistor LLSV...
Page 240 IB1090C SUCTION COMPRESSOR ACCESS VALVE LINE FILTER CHECK VALVE CONDENSER ACCUMULATOR HEAD PRESSURE CONTROL VALVE S TRAP REQUIRED 21’ OR GREATER RISE Ice Machine Head Section LIQUID LINE SHUT-OFF VALVE EVAPORATOR HARVEST VALVE SUCTION SHUT-OFF VALVE HEAT EXCHANGER LLSV DRIER HARVEST VALVE CHECK VALVE RECEIVER...
Page 241: Dual Evaporator Models
DUAL EVAPORATOR MODELS I1470C/I1870C ACCESS VALVE CHECK VALVE SUCTION FILTER CONDENSER ACCUMULATOR COMPRESSOR HEAD PRESSURE CONTROL VALVE S Trap Required 21’ or Greater Rise SUCTION LIQUID LINE SHUT-OFF SHUT-OFF VALVE VALVE T4 Thermistor Thermistor HEAT EXCHANGER EVAPORATOR EVAPORATOR LLSV HARVEST HARVEST VALVE VALVE...
Page 242: I2170C
I2170C SUCTION COMPRESSOR FILTER CONDENSER ACCUMULATOR HEAD PRESSURE CONTROL VALVE S Trap Required 21’ or Greater Rise SUCTION LIQUID LINE SHUT-OFF SHUT-OFF VALVE VALVE T4 Thermistor Thermistor HEAT EXCHANGER EVAPORATOR EVAPORATOR LLSV HARVEST HARVEST VALVE VALVE DRIER CHECK VALVE RECEIVER ACCESS Thermistor VALVE RECEIVER...
Page 243 This Page Intentionally Left Blank Part Number STH026 2/12...
Page 244 This Page Intentionally Left Blank Part Number STH026 2/12...
Page 245 This Page Intentionally Left Blank Part Number STH026 2/12...
Page 246 This Page Intentionally Left Blank Part Number STH026 2/12...
Page 248 Manitowoc Ice 2110 South 26th Street, P.O. Box 1720 Manitowoc, WI 54221-1720, USA Ph: 920-682-0161 Fax: 920-683-7589 Visit us online at: www.manitowocice.com © 2011 Manitowoc Part Number STH026 2/12...

Manitowoc QuietQube Indigo Series Technician's Handbook

General Information

How to Read a Model Number

ICVD Condensing Units

Ice Cube Sizes

Model/Serial Number Location

Model Numbers

Ice Machine Warranty Information

Installation

Location of Ice Machine

Lineset Applications

Ice Machine on a Dispenser Installation 30

Component Identification

I Model Single Evaporator Models

Ice Beverage Models

Icvd0695/Icvd0895/Icvd1095/Icvd1195/ Icvd1295/Icvd1495

Icvd1895/Icvd2195

Maintenance

Cleaning and Sanitizing

Cleaning / Sanitizing Procedure

Menu Navigation Overview

Display Panel

Set-Up Menu

Energy Saver Menu

Service Menu

Operational Checks

Sequence of Operation

Troubleshooting

Safety Limits

Component Check Procedures

Electrical Components

System Contamination Clean-Up

Cycle Times/24-Hour Ice Production/Refrigerant Pressure Charts

Quick Links

Troubleshooting

Related Manuals for Manitowoc QuietQube Indigo Series

Summary of Contents for Manitowoc QuietQube Indigo Series
