Owners &
Freestanding Woodstoves
Installation Manual
F1100 Video
www.regency-fi re.com
French Manual: http://bit.ly/N4yDmr
MODELS:
F1100S
F3100L
Tested by:
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
908-288e
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
03/11/14
Advertisement
Table of Contents
Related Manuals for Regency F1100S
Summary of Contents for Regency F1100S
- Page 1 Owners & Freestanding Woodstoves Installation Manual F1100 Video www.regency-fi re.com French Manual: http://bit.ly/N4yDmr MODELS: F1100S F3100L Tested by: Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference.
- Page 2 The pride of workmanship that goes into each of our products will give you years of trouble-free enjoyment. Should you have any questions about your product that are not covered in this manual, please contact the REGENCY DEALER in your area.
-
Page 3: Table Of Contents
TABLE OF CONTENTS SAFETY LABEL Screen Door ..............19 Contemporary Door Handle.........19 Operating Instructions ..........21 Copy Of Safety Label For F1100S .........4 Copy Of Safety Label For F3100L .........5 OPERATING INSTRUCTIONS DIMENSIONS First Fire ..............21 Draft Control ..............21 F1100S Unit Dimensions ..........6 Ash Disposal..............22... -
Page 4: Safety Label
SAFETY LABEL COPY OF SAFETY LABEL FOR F1100S This is a copy of the label that accompanies We have printed a copy of the contents here NOTE: Regency units are constantly being each Regency Small Freestanding Woodstove for your review. -
Page 5: Copy Of Safety Label For F3100L
COPY OF SAFETY LABEL FOR F3100L This is a copy of the label that accompanies We have printed a copy of the contents here NOTE: Regency units are constantly being each Regency Large Freestanding Woodstove for your review. improved. Check the label on the unit and if (F3100L). -
Page 6: Dimensions
DIMENSIONS F1100S UNIT DIMENSIONS Classix Door Contemporary Door Regency F1100/F3100 Freestanding Woodstove... -
Page 7: F3100L Unit Dimensions
INSTALLATION F3100L UNIT DIMENSIONS Classix Door Contemporary Door Regency F1100/F3100 Freestanding Woodstove... -
Page 8: Residential Installation
MODULAR INSTALLATION OPTIONS The following items are required when assembling your Regency Stove. F1100 and F3100 units - the Rear Heat Defl ector is supplied with the stove, but if you choose not to use it you must use the Airmate instead. -
Page 9: Minimum Clearance To Combustible Materials
11" 6" 6" 23" 12.5" 18" with Rear Defl ector 13" 5" 9" 25" 11.5" 21" Large F3100L with Airmate 18" 9.5" 10" 32" 16" 23.5" with Rear Defl ector 20" 12" 10" 34" 18.5" 23.5" Regency F1100/F3100 Freestanding Woodstove... - Page 10 INSTALLATION Minimum Alcove Clearance and Clearance to Combustible Materials The Regency Freestanding models have been alcove approved and must be installed with a listed double wall connector to the ceiling level. Note: Minimum alcove ceiling height - 84" Maximum depth of alcove - 36"...
-
Page 11: Stove Assembly Prior To Installation
See Diagrams 2 & 3. Shown with contemporary door Diagram 1 4) Push the Regency logo Diagram 4 into the two holes in Shown with classic door... -
Page 12: Step By Step Chimney And Connector Installation
4" duct pipe the 6" (152mm) fl ue dia. is 28.28 sq.in. with a mesh grill at the outside termination. At- tach the pipe to the 2 tabs with screws. Horizontal Installation Regency F1100/F3100 Freestanding Woodstove... -
Page 13: Masonry Chimney
Maintain proper clearance to the structure as recommended by the manufacturer. The chimney must be the required height above the roof or other obstructions for safety and proper draft operation. The space heater is to be connected to a factory-built chimney conforming to CAN/ULC-S629, Standard for 650 C Factory-Built Chimneys. Regency F1100/F3100 Freestanding Woodstove... -
Page 14: Combustible Wall Chimney Connector Pass-Throughs
24 gage minimum sheet metal supports. See that the supports are fastened securely to wall surfaces on all sides. Make sure fasteners used to secure chimney fl ue liner. Regency F1100/F3100 Freestanding Woodstove... -
Page 15: Recommended Heights For Woodstove Flue
Recommended Flue Height Elevation Example a) Example b) 1000' 18.72' 21.84' 2000' 19.44' 22.68' WARNING: Operate only with door fully 5000' 21.60' 25.20' closed - open feed door to feed fi re only. 8000' 23.76' 27.72' Regency F1100/F3100 Freestanding Woodstove... -
Page 16: Listed Components For Mobile Home Installation
INSTALLATION LISTED COMPONENTS FOR MOBILE HOME INSTALLATION The Regency Small and Large Freestanding pedestal units are approved for installation in a Mobile Home if one of the following pipe systems is used. U.S. Installation* AMERI-TEC HS Canadian Installations* Qty.Part #... -
Page 17: Stainless Steel Smoke Defl Ector Adjustment / Replacement
To replace the defl ector, loosen off both bolts and slide defector upward and out. Install new defector and hand tighten bolts. Ensure positive location of the defector prior to hand tightening. WARNING: Operation of the unit with out proper installation of smoke defl ector will void warranty. Regency F1100/F3100 Freestanding Woodstove... -
Page 18: Brick Flue Baffl E & Secondary Air Tube Installation
INSTALLATION BRICK FLUE BAFFLE & Small Stove F1100S SECONDARY AIR TUBE 1) If the two air tubes are installed continue on to Step 2), if not, follow the instructions below. INSTALLATION Install the air tube into the holes in the side channels. -
Page 19: Brick Installation
WARNING: FAILURE TO USE RE- MOVABLE HANDLE AS PER IN- STRUCTIONS MAY CAUSE SERIOUS BURNS. GLASS INSTALLATION Your Regency stove is supplied with 5 mm CONTEMPORARY DOOR Neoceram ceramic glass that will withstand the highest heat that your unit will produce. In HANDLE... - Page 20 Do not cut or 5) Place the ash plug tool beside the lid, then remove the grounding prong from this plug. slide the ash drawer inside. Refer to the Ash Drawer Operating section. Regency F1100/F3100 Freestanding Woodstove...
-
Page 21: Operating Instructions
fi re start more Regency Stove causing a draft down your at the rear of the pedestal is not installed. The rapidly.) chimney. -
Page 22: Ash Disposal
17) If you burn the unit too slowly or at too low 7) Your Regency stove can be very hot. You may be a setting your unit will not be operating as seriously burned if you touch the stove while it is 2) Always leave 1/2 to 1 inch of ash in the bottom effi... -
Page 23: Creosote
The door latch may require adjustment as the door It is very important to carefully maintain your fi re- material must be used. Regency uses AMATEX # 10- gasket material compresses after a few fi res. Re- place stove, including burning seasoned wood and 863KR 7/8"... -
Page 24: Parts List
INSTALL EITHER "AIR MATE" 948-102 Spring Handle - Small Gold OR "REAR AIR DEFLECTOR" 948-136 Spring Handle - Small Nickel 846-515 Complete Fan/Blower Assy (120 V) 910-684 Power Cord (120 V) MAIN ASSEMBLY BLOWER/FAN (OPTION) SCREEN DOOR (OPTION) Regency F1100/F3100 Freestanding Woodstove... -
Page 25: Main Assembly With Contemporary Door
Complete Fan/Blower Assy (120 V) 910-684 Power Cord (120 V) 910-142 Thermodisc Fan AutoON/OFF 910-138 Manual/Auto Switch (2-way) 910-140 Fan Speed Switch HI/OFF/LOW (3-way) 910-157/P Fan/Blower Motor (120 V) 063-954 Air Tube - 1" F3100 (Qty:1) Regency F1100/F3100 Freestanding Woodstove... -
Page 26: Pedestal, Bottom Shield & Leg Options
Ash Plug Tool Handle 140) 850-126 Legs - Cast Black 850-127 Legs - Cast Gold 850-128 Legs - Cast Brush Nickel 948-216 Regency Logo - Gold 948-223 Regency Logo - Nickel *Not available as a replacement part. Regency F1100/F3100 Freestanding Woodstove... -
Page 27: Firebrick
Brick Partial: 1-1/4" x 1-1/4" x 9" Brick Partial: 1-1/4" x 3-1/8" x 4-1/2" Brick Partial: 1-1/4" x 3-3/8" x 9" Brick Partial: 1-1/4" x 4-1/2" x 8" Brick Partial: 1-1/4" x 4-1/4" x 8" *Not available as a replacement part. Regency F1100/F3100 Freestanding Woodstove... - Page 28 NOTES Regency F1100/F3100 Freestanding Woodstove...
- Page 29 NOTES Regency F1100/F3100 Freestanding Woodstove...
- Page 30 NOTES Regency F1100/F3100 Freestanding Woodstove...
- Page 31 The authorized selling dealer is responsible for all in-fi eld service work carried out on your Regency product. FPI will not be liable for results or costs of workmanship from unauthorized service persons or dealers.
- Page 32 Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ F1100 Video Regency and Classic are trademarks of FPI Fireplace Products International Ltd. Printed in Canada © Copyright 2014, FPI Fireplace Products International Ltd. All rights reserved.
