Page 1: Installation Instructions
Installation instructions BI453 and BI603 models Built-in oven NZ AU... -
Page 2: Safety And Warnings
Safety and warnings WARNING! Cut Hazard Take care - panel edges are sharp. Failure to use caution could result in injury or cuts. Important! To avoid hazard, follow these instructions carefully before installing or using this product. Please make this information available to the person installing the product as it could reduce your installation costs. - Page 3 Contents Product and cabinetry dimensions Installing the oven Installing the cooktop Important! SAVE THESE INSTRUCTIONS...
- Page 4 Product and cabinetry dimensions Single oven models 16-20 mm 2.5 mm Installation diagrams for illustration purposes only Ensure the cavity is completely sealed with no gaps Product and cabinetry dimensions (mm) overall height of product overall width of product overall depth of product (without handle) height of chassis width of chassis...
- Page 5 Product and cabinetry dimensions Double oven models Ensure the cavity is completely sealed with no gaps Product and cabinetry dimensions (mm) overall height of product 1077 overall width of product overall depth of product (without handle) height of chassis 1060 width of chassis depth of chassis depth of oven frame and control panel...
- Page 6 Product and cabinetry dimensions Built-in oven/cooktop combination Dimensions as BENCHTOP Please refer to cooktop per single oven installation instructions p/n 599100 model BI603 OVEN Ensure the cavity is completely sealed with no gaps Product and cabinetry dimensions (mm) minimum inside width of cavity overall width of cavity inside height of cavity overall height of cavity...
- Page 7 Product and cabinetry dimensions Built-in oven/microwave combination model Ensure the cavity is completely sealed with no gaps Product and cabinetry dimensions (mm) overall height of product overall width of product depth of microwave (excl.frame and control panel) depth of microwave frame and control panel width of microwave chassis depth of oven chassis depth of oven frame and control panel...
- Page 8 Installing the oven...
- Page 9 Installing the cooktop Please refer to cooktop installation instructions p/n 599100...
- Page 12 Copyright © Fisher & Paykel 2005. All rights reserved. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time.
