■ Other set mode
TX Delay (50M)
Sets the transmission's timing for the 50 MHz band.
See the previous item "TX Delay (HF)" for more de-
tails.
Time–Out Timer (CI–V)
Turns the Time-Out Timer function ON (3, 5, 10, 20
or 30 minutes) or OFF. If a continuous transmission
exceeds the selected time period, the transmission
will be cut off, to prevent a prolonged transmission.
(default: OFF)
NOTE: This function will be activated only when
you transmit using CI-V commands, or pushing
.
TRANSMIT
Quick SPLIT
When this item is set to ON, holding down
for 1 second sets the unselected VFO's readout fre-
quency to the selected VFO's readout frequency and
activates split operation.
(default: ON)
See page 6-7 for details.
FM SPLIT Offset(HF)
Sets the offset (difference between transmit and
receive frequencies) for the quick split function. This
setting is used for HF bands in FM mode only and is
used to input the repeater offset for an HF band.
The offset frequency can be set from –9.999 MHz to
+9.999 MHz in 1 kHz steps. (default: –0.100 MHz)
FM SPLIT Offset(50M)
Sets the offset (difference between transmit and re-
ceive frequencies) for the quick split function. This
setting is used for 50 MHz band FM mode only, and is
used to input the repeater offset for the 50 MHz band.
The offset frequency can be set from –9.999 MHz to
+9.999 MHz in 1 kHz steps. (default: –0.500 MHz)
SPLIT LOCK
When this item is ON, the main dial can be used to
adjust the transmit frequency while pushing [XFC]
even while the lock function is activated.
(default: OFF)
See pages 6-6 and 6-7 for split frequency operation
details.
(continued)
SPLIT
12-13
OFF
OFF
ON
–0.100MHz
–0.500MHz
OFF
12
SET MODE
