Icom IC-F61M Instruction Manual page 16

2
PANEL DESCRIPTION
MONITOR KEY
➥ Activates one of the following functions on each channel inde-
pendently.
• Push and hold for 1 sec. to un-mute the channel (audio is emitted;
'Audible' condition).
• Push to mute the channel (sets to 'Inaudible' only).
NOTE: The un-mute condition ('Audible' condition) may auto-
matically return to the mute condition ('Inaudible' condition)
after the specific time period.
LIGHT KEY
Push to turn the backlight ON for about 5 sec. even if the backlight
function is turned OFF in user set mode.
LONE WORKER KEY
Push to turn the Lone Worker function ON or OFF.
• If the Lone Worker function is activated, the Emergency function is
automatically turned ON after the specific time period has passed
with no operation is performed.
HIGH/LOW KEY
Push to select the transmit output power temporarily or perma-
nently, depending on the pre-setting.
• Ask your dealer for the output power level for each selection.
C.TONE CHANNEL ENTER KEY
Push to enter the continuous tone channel selection mode, and
push [CH Up]/[CH Down] to change the tone frequency/code set-
ting. The selected channel remains set as the continuous tone
channel until another channel is designated as such.
9
