SENTINEL
HOT WATER MODELS SE-70 THROUGH SE-245
GAS-FIRED CAST-IRON BOILERS FOR NATURAL AND L.P . PROPANE GASES
INSTALLATION AND OPERATING INSTRUCTIONS
CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . PAGE
Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2,3
Boiler Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Boiler Foundation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Chimney Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Minimum Clearance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Draft Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Vent Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Vent Damper Installation . . . . . . . . . . . . . . . . . . . . . . . . . 5,6
Gas Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Electrical Controls and Wiring . . . . . . . . . . . . . . . . . . . . . . 7
Boiler Room Air Supply and Ventilation . . . . . . . . . . . . . . 7
Water Piping at Boiler . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Filling and Venting Water Systems . . . . . . . . . . . . . . . . . . 8
Burner Adjustment, Checking Gas Input. . . . . . . . . . . . . 10
General Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Water Level Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Annual Inspection and Cleaning . . . . . . . . . . . . . . . . . . . 11
Safety Check for Control Systems. . . . . . . . . . . . . . . . . . 12
Keeping Area Clear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Sequence of Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Pump or Valve Zoning of Water Boilers . . . . . . . . . . . . . . . . 14
Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Appendix A & B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Appendix C, D & E . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
WARNING
This boiler, gas piping and accessories must be installed,
connected, serviced and repaired by a trained, experienced
service technician, familiar with all precautions required for
gas-fired equipment and licensed or otherwise qualified, in
compliance with the authority having jurisdiction.
Heating Contractor
Address
Phone Number
®
IMPORTANT
READ ALL OF THE FOLLOWING
WARNINGS AND STATEMENTS
BEFORE READING THE
INSTALLATION INSTRUCTIONS
LIQUEFIED PETROLEUM (L.P .)
PROPANE GAS-FIRED BOILERS
Installation location ONLY as permitted in paragraph entitled
"LIQUEFIED PETROLEUM (L.P .) PROPANE GASFIRED
BOILER LOCATION" on page 4 of this instruction book.
The above warning does not apply to NATURAL gas-
fired boilers.
The installation must conform to the requirements of the
authority having jurisdiction or, in the absence of such
requirements, to the National Fuel Gas Code, ANSI Z223.1-
CSA B149.1-00 for natural gas and
latest edition or
propane
. The installation must also conform to the
additional requirements in this Slant/Fin Instruction Book.
In addition, where required by the authority having jurisdic-
tion, the installation must conform to American Society of
Mechanical Engineers Safety Code for Controls and Safety
Devices for Automatically Fired Boilers, No. CSD-1 or
B149.1-00 for natural gas and propane
conflict in the above requirements, then the more stringent
requirement will apply.
This manual must be left with owner and should be hung on
or adjacent to the boiler for reference.
Boiler Model Number
Boiler Serial Number
Installation Date
Printed in Canada 0207
Part No. 46-0569
WARNING
. If there is any
Publication No. SE-40
CSA
Rev. C

Advertisement

Table of Contents
loading

Summary of Contents for Slant/Fin SENTINEL SE-70

  • Page 1: Table Of Contents

    Protection from Freezing/Water Treatment ... 12 additional requirements in this Slant/Fin Instruction Book. Keeping Area Clear ......12 Sequence of Operations .
  • Page 2: Dimensions

    Sentinel Dimensions MODEL SE-70 to SE-245 Vent Damper* (shown horizontally Vent Damper* (shown vertically Install manual gas main 19 mm (3/4") shutoff valve 1524 mm Blocked Vent to air eliminating (5 ft.) above floor, when Safety Switch system (by others) 276 mm required by local code.
  • Page 3: Installation Requirements

    Burners electrical connections must be in accordance with Canadian Elec- trical Code C22.1 Part 1. Pilot This installation must also conform to the additional requirements in this Slant/Fin Instruction Book. Burner Access NATURAL GAS-FIRED BOILER LOCATION Door Provide a level, solid foundation for the boiler. Location should be as near as possible to chimney or outside wall so that the flue pipe from boiler is short and direct.
  • Page 4: Chimney Requirements

    Sentinel C. Inspect for proper and tight construction. Any restrictions or WARNING obstructions must be removed. An existing chimney may LIQUEFIED PETROLEUM (L.P .) PROPANE require cleaning. GAS-FIRED BOILER LOCATION REQUIRES SPECIAL ATTENTION D. Chimney or vent must extend at least 914 mm (3 feet) above Liquefied Petroleum (L.P .) propane gas is heavier than air.
  • Page 5: Vent Damper Installation

    I. This device is design certified by CSA for use ONLY on spe- Figure 1. cific Slant/Fin gas boiler models. These boilers must also be equipped with a plate which states that the boiler must or may be used with a Slant/Fin automatic vent damper device and indicates the proper vent damper model number.
  • Page 6 Sentinel C. NOW, PROCEED AS FOLLOWS: 1. Separate the vent pipe directly on top of the draft hood or diverter and place damper in position as shown in figures 1–6. The vent damper must be installed so that the damper position indicator is in a visible location after installation.
  • Page 7: Gas Piping

    Sentinel D. All gas piping used should be inspected thoroughly for GAS PIPING cleanliness before makeup. A sediment trap must be pro- A. Local installation codes apply. The pipe joint compound vided, as illustrated on page 2. used on threads must be resistant to the action of liquefied petroleum gases.
  • Page 8: Water Piping At Boiler

    Sentinel IF BOILERS ARE INSTALLED ADJACENT TO OTHER FUEL I. FILLING AND VENTING WATER SYSTEMS BURNING EQUIPMENT, THE AREA OF FREE OPENINGS OPERATING INSTRUCTIONS MUST BE APPROPRIATELY INCREASED TO ACCOMMODATE THE ADDITIONAL LOAD. A. Fill the system with water. Vent or purge off air. Openings must never be reduced or closed.
  • Page 9 Sentinel C. Use only your hand to push in or turn the gas control knob. Never use tools. If the knob will not push in or turn by hand, don't try to repair it, call a qualified service technician. Force or attempt- ed repair may result in a fire or explosion.
  • Page 10: Burner Adjustment, Checking Gas Input

    Figure 8. Valve VR8204 or VR8304 4. The higher heating value* of gas varies substantially for different localities. Consult with Slant/Fin’s Technical Service Dept. for re-orificing procedures if any of the following apply: a. Boiler (burner) is overfiring. CAUTION! National Fuel Gas Code ANSI Z223.1-latest edition or CSA...
  • Page 11: Care And Maintenance

    Sentinel final operating position. Use of a mirror may be helpful to C. PIPING: check piping and accessories for leaks. observe flames. Note that burner ports are on top of main D. CHIMNEY VENTING SYSTEM: check for obstructions burner tube. and leaks.
  • Page 12: Safety Check For Control Systems

    Sentinel systems to protect against freeze-up in the event of JACKET TOP power failure or control shutdown when the building is unoccupied. It should be recognized that unless the FLUE COLLECTOR (FLUE COVER) building is kept above freezing temperature by some means, the plumbing system is not protected.
  • Page 13: Sequence Of Operations

    Sentinel SEQUENCE OF OPERATION FOR SENTINEL BOILERS EQUIPPED WITH CONTINUOUS BURNING PILOTS (HONEYWELL) LIGHTED PILOT HEATS THERMOCOUPLE AND KEEPS PILOTSTAT OPEN. THERMOSTAT CALLS FOR HEAT CIRCULATOR ENERGIZED HIGH LIMIT CONTACTS CLOSED? NO FURTHER (IF COMBINATION AQUASTAT LOW WATER CUT-OFF (WHEN USED) ACTION CONTROL USED) CONTACTS CLOSED?
  • Page 14: Pump Or Valve Zoning Of Water Boilers

    Pump zoning system using R8230C Relays. *For zoning diagrams, combination controls without T Z terminals and non-combination control systems, consult Slant/Fin Zoning Tech. Bulletin. NOTE: Pumps are powered from C1 . Total pump load must not exceed 7.4 amp rating of combination control pump switch.
  • Page 15: Troubleshooting Guide

    Sentinel GENERAL TROUBLESHOOTING GUIDE FOR SERVICEPEOPLE BURNERS FAIL TO OPERATE CAUSE REMEDY 1. Safety pilot out, or flame too low. 1. Check, clean, re-light. See instructions. 2. Gas supply valve shut off. 2. Open gas valve(s). 3. Electric switch open. 3.
  • Page 16: Replacement Parts

    IF REPLACEMENT PARTS ARE NEEDED and parts maybe obtained locally. All other controls and parts should be identified by and ordered from Slant/Fin. Relief/Safe- When parts are needed, refer to boiler model and serial number ty valves must be ASME rated for the pressure and gross output shown on the boiler name/rating plate.Whenever possible refer...
  • Page 17: Appendix C, D & E

    Use of non-oxygen diffusion barrier underfloor tubing The boiler warranty does not cover leaks resulting from boiler with a heat exchanger, Slant/Fin recommends the corrosion caused by the use of underfloor plastic tubing use of underfloor plastic tubing with an oxygen diffusion without an oxygen diffusion barrier.
  • Page 18 Sentinel...
  • Page 19 Sentinel...
  • Page 20 SLANT/FIN LTD/LTEE, 6450 Northam Drive, Mississauga, Ontario L4V 1H9 • Phone: (905) 677-8400 / FAX: (905) 677-1829 / Order Desk Fax: (905) 677-9015 www.slantfin.ca / E-mail: orderdesk@slantfin.ca / info@slantfin.ca...
