ASSEMBLY

Assembly requires two people. Place all parts of the PROFORM
packing materials. Do not dispose of the packing materials until assembly is completed.
Assembly requires a phillips screwdriver
mallet .
1. Feed the console wire down through the Upright (3)
as shown. While another person holds the Upright
near the Frame (1), tie the console wire and the
Sensor Wire (25) together as shown in drawing 1a.
Next, connect the console wire to the Sensor Wire.
Gently pull the Resistance Cable (26) and the
console wire out of the top of the Upright (3) until
there is no slack between the Upright and the
Frame (1).
Slide the Upright (3) onto the welded bolts on the
Frame (1). Be careful to avoid pinching the
Resistance Cable (26) and the Sensor Wire (25).
Tighten a 3/8Ó Nylon Locknut (29) onto each welded
bolt.
2. Feed the console wire back down into the Upright (3).
Attach the Console (6) to the Upright with four #8 x
3/4Ó Round Head Screws (16). Be careful to avoid
pinching the console wire.
Press the Resistance Knob (50) onto the Resistance
Control (26).
485E in a cleared area and remove the
¨
, two adjustable wrenches
1
Console
Wire
1a
Console
Wire
25
2
6
16
6
, and a rubber
26
3
29
26
1
50
Console
Wire
26
3
Console
Wire
25
