Invacare P7E Parts Catalog

Invacare P7E Parts Catalog

Power wheelchair
Hide thumbs Also See for P7E:

Advertisement

Quick Links

Download this manual
Parts Catalog
Issued: Apr 4, 2014
P7E™
Power Wheelchair

Advertisement

loading

Related Manuals for Invacare P7E

Summary of Contents for Invacare P7E

  • Page 1 Parts Catalog Issued: Apr 4, 2014 P7E™ Power Wheelchair...
  • Page 2 Phone Numbers © 2014 Invacare Corporation. Elyria, Ohio. Invacare, Yes, you can., and the Medallion Design are registered trademarks and P7E and MKIV are trademarks of Invacare Corporation. Bussman is a registered trademark of Cooper Industries. MIDI is a registered trademark of Littelfuse Inc,, Dynamic is a registered trademark of Dynamic Controls Limited.
  • Page 3 Front Riggings - Pivot/Slide Tube & Footplate - P904 and T934A ........... Motor Gearbox Assembly ......................Packaging - Literature - Decals ....................Upholstery - Back & Seat ......................Warranty Replacement Parts ....................Wheel Locks ..........................Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 4 TABLE of CONTENTS Page Description Number Wheels - Rear .......................... Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 5 Packaging - Literature - Decals Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 6 NLA - Owner's Manual NOTE: A - Not Shown B - Invacare logo added and model decal changed 1/11/2000. When replacing frames or crossbraces before 1/11/2000 order decals in pairs to match. Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 7 .6 oz Black NLA - Paint, Touch-Up, 80P 1073892-NLA .6 oz Evergreen w/ Navy NLA - Paint, Touch-Up, 101P 1101325-NLA .6 oz Jeweled Green Upholstery Color U05 Black Lightweight Vinyl Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 8 Frames - Back Canes & Hardware Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 9 Screw, Hex Head (1/4-20 x 1-1/4") 1028372 Back Cane Assembly, 10 Degree Bend A - Specify frame color. NOTE: B - Decals not included with frame. C - Before 4/1/96 D - After 3/31/96 Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 10 Crossbraces - Hardware - Seat Extensions Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 11 F - Pivot Link is no longer available as a service part individually. Order part #7200188 Pivot Link w/ Hardware (not shown) as a replacement. Includes items 2-4, 7 and 8. Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...

  • Page 12: Seat Upholstery

    Specify upholstery color when ordering. See Frame Finishes, Touch-Up Paints and Upholstery Color page. Back Upholstery Back Width Back Height 16" 16" W 8881017856 18" W 8881016582 Specify upholstery color when ordering. See Frame Finishes, Touch-Up Paints and Upholstery Color page. Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 13 NOTE: For headrest extension upholstery, see titled page under accessories "Headrest Extension, Upholstery and Hardware" Hardware Back and Seat Part Number Upholstery Hardware Consists of: 1027057 8 ea. Screw with Washer (10 x 7/8") Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 14 Headrest Extension - Upholstery & Hardware Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 15 NLA - Upholstery, Headrest, Nylon (18" W) 8881052778 Headrest Extension Assembly, Nylon, Chrome (16" 8881052780 Headrest Extension Assembly, Nylon, Chrome (18" A - Specify upholstery color U240 when ordering. NOTE: B - Includes items 1-8 Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 16 Fixed Height Arms & Hardware Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 17 B - Specify frame color from Frame Finishes, Touch-Up Paints and Upholstery Color page. C - Stainless steel clothing guards were replaced w/ABS plastic. Chairs manufactured before 7/30/97 should be ordered in pairs to match. Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 18 Adjustable Height Arms & Hardware Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 19 B - Specify frame color when ordering from Frame Finishes, Touch-Up Paints and Upholstery Color page. C - Stainless steel clothing guards were replaced w/ABS plastic. Chairs manufactured before 7/30/97 should be ordered in pairs to match. Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 20 Casters & Forks Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 21 B - Chairs manufactured before 6/9/97 order in pairs (#1071666). C - Forks must be ordered in pairs for chairs manufactured before 10/5/98. D - Includes items 7 and 8 Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 22 Rear Wheels & Motor Hardware Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 23 A - As of 10/20/99 the "solid" flat free insert was replaced by a "foam fill" process. When a flat free insert is requested, a complete wheel must be ordered. B - Before 3/31/96 C - After 4/1/96 D - No Longer Available. Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 24 Wheel Locks and Hardware Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 25 NLA - Wheel Lock Assembly - Right 1061613-NLA NLA - Wheel Lock Assembly - Left 1018739 Washer (1/4 x 5/8 x 3/32") 7930326 Package, Screw, Hex Head (1/4-20 x 3/4") Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 26 Motor Gearbox Assembly Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 27 NLA - Brake, Spring Set with Screws 1038361-NLA NLA - Kit, Motor/Brake Covers with Screws 561-005 Kit, Motor Brush w/o Cap - Internal, Long Cap (Pair) A - Before 3/31/96 NOTE: B - After 4/1/96 Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 28 Battery Boxes - Chargers - Harnesses - Trays Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 29 Cord, AC Power, 115VAC, 2 Prong Off-Board (11' 6" L) 1083929 Cable, Charger Extension, Round Plug (24" L) 1095502 Package, Tie Wrap (11-1/2" L) 1058491-NLA NLA - Connector Boot, Wire Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 30 M1 - CTE charger looks exactly the same as Dynamic's charger except for the company name that is silk screened on the narrow side panel, where the charger plug is (hard wired) attached. Serial number starts with 04A00000001. Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 31 P93 Footrest and Hardware Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 32 A - Specify frame color from Frame Finishes, Touch-Up Paints and Upholstery Color Page #20 Pivot/Slide Tube and Footplate Side Standard 2" Longer 4" Longer Right 1057969 1086503-NLA 1086504-NLA Left 1057970 1086505-NLA 1086506-NLA Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 33 PW93 Footrest and Hardware Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 34 B - As of 8/15/03, the Threaded Insert was revised from 3 to 5 Holes. Threaded Insert is Backward Compatible and does not require ordering in Pairs. #23 Pivot/Slide Tube with Footplate Side Standard 2" Longer 4" Longer Right 1074149 1086494-NLA 1086495-NLA Left 1074150 1086497-NLA 1086498-NLA Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 35 P904/T934A Legrest and Hardware Due to a change to the Legrest Calf Pad size made on 4/23/12, you must also order the hardware kit (1066591) when ordering replacement Calf Pads. Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 36 1035539 Handle, Release, Black - Right 1035540 Handle, Release, Black - Left 47565X057 Bushing (7/32 x 3/8 x 11/32") 1028707 Spring, Release - Right 1028708 Spring, Release - Left Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 37 J - Includes Screws and Instruction Sheet. K - Due to a change to the Legrest Calf Pad size made on 4/23/12, you must also order the hardware kit (1066591) when ordering replacement Calf Pads. Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 38 Package, Phillips Head Screw (#8-32 x 3/8") 1070168 Plug, Push, Footplate 1017237 Pivot/Slide Tube w/ Aluminium Footplate Assembly, Chrome - Right 1017238 Pivot/Slide Tube w/ Aluminium Footplate Assembly, Chrome - Left Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 39 MKIV RII Joystick, Controller and Hardware Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 40 NLA - Disk, 3.5 H.D. Floppy with V.S. Software 1091637-NLA NLA - Adaptor, Null Modem 1091636-NLA NLA - Service Manual - V.S. Software Kit 1095204 Cable, Virtual Service, Charger/Modem Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 41 M - Part numbers 1026572 and 1027280 are available for individual sale. N - Spacer allows the half clamps to grip securely around the 3/4" arm tube O - Not Shown P - After 10/3/00 Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 42 INT. Controller and Hardware Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 43 2-1/2") NOTE: A - Not Shown B - Includes items 5, 6, and 8. C - Spacer allows the half clamps to grip securely around the 3/4" arm tube Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 44 E - Includes 4 ea. Screw, Phillips Pan Head (10-32 x7/8"); 4 ea. Washer (1/4 x 3/4 x 3/32"); 4 ea. Locknut (10-32) F - Includes Device, Non-Removable and Carton. Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 45 Power Wheelchair Tool Kit Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 46 1 ea. Wire, Grounding with Hand Strap and Clip 1 ea. Leads, 1" Test 1 ea. Light, Pen with Invacare Logo 1 ea. Tape Measure, Compact with Invacare Logo 1 ea. Screwdriver, Pen-Size Phillips/Flat Head 1 ea. Cable, Virtual Service Charger/Modem Form No.

  • Page 47: Warranty Replacement Parts

    Single Mode Round Plug w/ AC Power Line Cord, CTE Corp. See Note(s) A NOTE: A - See "Battery Boxes - Chargers - Harnesses - Trays" Category for more information. Form No. 95-167 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 48 Invacare Corporation www.invacare.com © 2014 Invacare Corporation. All rights reserved. Republication, duplication or modification in whole or in part is prohibited without prior written permission from Invacare. Trademarks are identified by ™ One Invacare Way Technical Support Customer Service and ®. All trademarks are owned by or...
