Mitel 6800i Series SIP Phones
41-001562-00 REV01
RELEASE 4.0.0 SP1 TR-069 CONFIGURATION GUIDE

Advertisement

Table of Contents
loading

Related Manuals for Mitel 6863i

Summary of Contents for Mitel 6863i

  • Page 1 Mitel 6800i Series SIP Phones 41-001562-00 REV01 RELEASE 4.0.0 SP1 TR-069 CONFIGURATION GUIDE...
  • Page 2 ). The information is subject to change without notice and should not be construed in any way as a commitment by Mitel or any of its affiliates or subsidiaries. Mitel and its affiliates and subsidiaries assume no responsibility for any errors or omissions in this document. Revisions of this document or new editions of it may be issued to incorporate such changes.

  • Page 3: Table Of Contents

    Table of Contents Welcome..............1 TR-069 Protocol Support .

  • Page 4: Welcome

    Mitel 6800i Series SIP Phones Release 4.0.0 SP1 TR-069 Configuration Guide WELCOME This document provides information about Technical Report (TR)-069 protocol support for the 6800i Series (6863i, 6865i, 6867i, and 6869i) SIP IP Phones. TR-069 PROTOCOL SUPPORT The IP Phones support the TR-069 protocol. This protocol is a bi-directional HTTP-based protocol that provides a means of communication between Customer-Premises Equipment (CPE) (e.g.

  • Page 5: Tr-069 Functionality Support

    Limited to parameters specified in “TR-069 Parameter Descriptions” page 3. Note: Users are limited to parameters that are specified by Mitel. Please contact Mitel for a list of these parameters. GetParameterValues Required Limited to parameters specified in “TR-069 Parameter Descriptions”...

  • Page 6: Behaviors

    VoiceService.X_Aastra_GlobalVoiceProfile corresponds to Mitel Sip Global Settings and has only 1 line object • VoiceService.1.VoiceProfile.{1} corresponds to Mitel SIP settings per line i and has only 1 line object • Constant number of lines mapped to the number of Voice Profile (profile remove is not...
  • Page 7 TR-069 Protocol Support Each of these parameters are described as follows: PARAMETER – CONFIGURATION FILES tr69 startup.cfg, mac.cfg DESCRIPTION Enables/disables TR-069 communciation. FORMAT Boolean DEFAULT VALUE RANGE 0 (disabled) 1 (enabled) EXAMPLE tr69: 1 PARAMETER – CONFIGURATION FILES tr69 server startup.cfg, mac.cfg DESCRIPTION Specifies the IP or domain name of the TR-069...
  • Page 8 Mitel 6800i Series SIP Phones Release 4.0.0 SP1 TR-069 Configuration Guide PARAMETER – CONFIGURATION FILES tr69 server path startup.cfg, mac.cfg DESCRIPTION Specifies the server path of the TR-069 Auto-Configuration Server (ACS). This is the path to which the phone sends TR-069 messages.

  • Page 9: Support For Getting Capabilities, General Profiles, And Other Static Parameters

    They are always located on the VoiceService SubTree, and on each line a SIP account can be configured. For example: Device.VoiceService.VoiceProfile.1 corresponds to Line 1 on the Mitel Web UI. Once a SIP account is fully configured, the line will be registered. Administrators also have the option to delete the Voice Profile.

  • Page 10: Tr-111

    Mitel 6800i Series SIP Phones Release 4.0.0 SP1 TR-069 Configuration Guide TR-111 The phones support the TR-111 protocol as a requirement for TR-069. TR-111 applies the TR-069 to remote manage home networking devices (i.e. it can access a phone that is inside a private network from a server outside).

  • Page 11: Inform Upon Receipt Of Sip Notify Check-Sync Support

    TR-069 Protocol Support PARAMETER – CONFIGURATION FILES tr69 periodic inform time startup.cfg, mac.cfg DESCRIPTION An absolute time reference in UTC to determine when the CPE will initiate the periodic inform method calls. FORMAT String DEFAULT VALUE 1970-01-01T00:00:00 RANGE The STRING is specified in the following form: “YYYY-MM-DDThh:mm:ss”...

  • Page 12: Configuring The Inform Upon Receipt Of Sip Notify Check-Sync Feature Using The Configuration Files

    Mitel 6800i Series SIP Phones Release 4.0.0 SP1 TR-069 Configuration Guide CONFIGURING THE INFORM UPON RECEIPT OF SIP NOTIFY CHECK-SYNC FEATURE USING THE CONFIGURATION FILES PARAMETER – CONFIGURATION FILES tr69 check sync startup.cfg, mac.cfg DESCRIPTION Specifies the behavior of the phone when it receives a SIP NOTIFY containing a check-sync event.

  • Page 13: Log File Download From Cpe

    TR-069 Protocol Support When the phone receives the request to backup, it uploads the local.cfg or server.cfg file to the server depending on the FileType argument defined (i.e. “1 Vendor Configuration File” = local.cfg, “X_Aastra Server Configuration File” = server.cfg). The protocol supported for configuration file upload from the CPE are HTTP, TFTP, and FTP.

  • Page 14: Passive And Active Notification

    If a parameter is configured to "Passive notification", when this parameter is modified through the Mitel Web UI, the new value of the parameter is sent to the ACS with the periodic inform. If there is no notification set, no inform message is sent to inform the ACS when the value of the parameter is modified.

  • Page 15: Secured Connection Support

    TR-069 Protocol Support SECURED CONNECTION SUPPORT The following parameters are available allowing Administrators the ability configure a secure connection between the CPE and ACS: • tr69 trusted certificates • tr69 private key • tr69 server authentication required Each of these parameters are described as follows: PARAMETER –...

  • Page 16: Privatekey.pem Example

    Mitel 6800i Series SIP Phones Release 4.0.0 SP1 TR-069 Configuration Guide PARAMETER – CONFIGURATION FILES tr69 server authentication startup.cfg, mac.cfg required DESCRIPTION If this parameter is set to 0, Simple TLS handshake will be enabled. If this parameter is set to 1, Client-authenticated TLS handshake will be enabled..

  • Page 17: Factory Reset

    (e.g. DNSServer). However, you may have to reboot the phone in order for the change to take effect. OUI AND PRODUCT CLASS The above data structure is common across all the TR-069 supported Mitel SIP phones. The table below summarizes the supported phones and their corresponding OUI and Product Class. SUPPORTED MITEL MODELS...

  • Page 18: Appendix A - Sample Configuration

    Mitel 6800i Series SIP Phones Release 4.0.0 SP1 TR-069 Configuration Guide APPENDIX A - SAMPLE CONFIGURATION The following is an example detailing how the TR-069 parameters can be defined within the configuration files: # enable tr69 tr69: 1 #username and password for the ACS...

  • Page 19: Appendix B - Xml Data Model Schema

    Appendix B - XML Data Model Schema APPENDIX B - XML DATA MODEL SCHEMA The following is a schema that can be used as a template for a customized XML data model: <?xml version=”1.0” encoding=”UTF-8” standalone=”yes”?> <xsi:tr69model xmlns:xsi=”http://www.w3.org/2001/XMLSchema-instance”> <entry xsi:type=”tr69Object” write=”” mode=”1”> <name>Device.</name>...
  • Page 20 Mitel 6800i Series SIP Phones Release 4.0.0 SP1 TR-069 Configuration Guide <child write=”” mode=”1”> <name>LAN.</name> <description></description> <parameter write=”W” mode=”1”> <name>AddressingType</name> <description></description> </parameter> <parameter write=”W” mode=”1”> <name>DNSServers</name> <description></description> </parameter> <parameter write=”W” mode=”1”> <name>DefaultGateway</name> <description></description> </parameter> <parameter write=”W” mode=”1”> <name>IPAddress</name> <description></description> </parameter>...
  • Page 21 Appendix B - XML Data Model Schema <child write=”” mode=”1”> <name>ManagementServer.</name> <description></description> <parameter write=”W” mode=”1”> <name>ConnectionRequestPassword</name> <description></description> </parameter> <parameter write=”” mode=”1”> <name>ConnectionRequestURL</name> <description></description> </parameter> <parameter write=”W” mode=”1”> <name>ConnectionRequestUsername</name> <description></description> </parameter> <parameter write=”W” mode=”1”> <name>NATDetected</name> <description></description> </parameter> <parameter write=”W” mode=”1”> <name>ParameterKey</name> <description></description>...
  • Page 22 Mitel 6800i Series SIP Phones Release 4.0.0 SP1 TR-069 Configuration Guide </parameter> <parameter write=”W” mode=”1”> <name>Username</name> <description></description> </parameter> </child> </entry> </xsi:tr69model>...

  • Page 23: Appendix C - Standard Supported Tr-069 Parameters

    Appendix C - Standard Supported TR-069 Parameters APPENDIX C - STANDARD SUPPORTED TR-069 PARAMETERS The following is a list of the standard supported TR-069 parameters. This list includes the Mitel specific set of extended parameters that Mitel supports (for example, X_Aastra_RTCP_Report).
  • Page 24 Mitel 6800i Series SIP Phones Release 4.0.0 SP1 TR-069 Configuration Guide PARAMETER READ/WRITE TYPE SIZE RANGE Device.ManagementServer.ConnectionRequestUsername string Device.ManagementServer.ConnectionRequestPassword string Device.ManagementServer.STUNEnable boolean Device.ManagementServer.STUNServerAddress string Device.ManagementServer.STUNServerPort Device.ManagementServer.NATDetected boolean Device.ManagementServer.UDPConnectionRequestAddress string Device.LAN Device.LAN.AddressingType string Device.LAN.IPAddress string Device.LAN.SubnetMask string Device.LAN.DefaultGateway string Device.LAN.DNSServers string Device.LAN.MACAddress...
  • Page 25 Appendix C - Standard Supported TR-069 Parameters PARAMETER READ/WRITE TYPE SIZE RANGE Device.Services.VoiceService.1.Capabilities.SRTP boolean Device.Services.VoiceService.1.Capabilities.SRTPKeyingMethods string Device.Services.VoiceService.1.Capabilities.SRTPEncryptionKeySizes string Device.Services.VoiceService.1.Capabilities.RTPRedundancy boolean Device.Services.VoiceService.1.Capabilities.DSCPCoupled boolean Device.Services.VoiceService.1.Capabilities.EthernetTaggingCoupled boolean Device.Services.VoiceService.1.Capabilities.PSTNSoftSwitchOver boolean Device.Services.VoiceService.1.Capabilities.FaxT38 boolean Device.Services.VoiceService.1.Capabilities.FaxPassThrough boolean Device.Services.VoiceService.1.Capabilities.ModemPassThrough boolean Device.Services.VoiceService.1.Capabilities.ToneGeneration boolean Device.Services.VoiceService.1.Capabilities.ToneDescriptionsEditable boolean Device.Services.VoiceService.1.Capabilities.PatternBasedToneGeneration boolean Device.Services.VoiceService.1.Capabilities.FileBasedToneGeneration boolean Device.Services.VoiceService.1.Capabilities.RingGeneration boolean Device.Services.VoiceService.1.Capabilities.RingDescriptionsEditable...
  • Page 26 Mitel 6800i Series SIP Phones Release 4.0.0 SP1 TR-069 Configuration Guide PARAMETER READ/WRITE TYPE SIZE RANGE Device.Services.VoiceService.1.Capabilities.SIP.EventSubscription boolean Device.Services.VoiceService.1.Capabilities.SIP.ResponseMap boolean Device.Services.VoiceService.1.Capabilities.SIP.TLSAuthenticationProtocols string Device.Services.VoiceService.1.Capabilities.SIP.TLSAuthenticationKeySizes string Device.Services.VoiceService.1.Capabilities.SIP.TLSEncryptionProtocols string Device.Services.VoiceService.1.Capabilities.SIP.TLSEncryptionKeySizes string Device.Services.VoiceService.1.Capabilities.SIP.TLSKeyExchangeProtocols string Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.Enable string Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.Reset boolean Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.NumberOfLines Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.Name string Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.STUNEnable boolean Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.STUNServer...
  • Page 27 Appendix C - Standard Supported TR-069 Parameters PARAMETER READ/WRITE TYPE SIZE RANGE Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.SIP.X_Aastra_BackupProxyServerPort 0-65535 Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.SIP.X_Aastra_BackupOutboundProxySupport Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.SIP.X_Aastra_BackupOutboundProxy string Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.SIP.X_Aastra_BackupOutboundProxyPort 0-65535 Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.SIP.X_Aastra_mode Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.SIP.X_Aastra_centralizedConference string Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.SIP.X_Aastra_listUri string Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.SIP.TimerT1 0-65535 Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.SIP.TimerT2 0-65535 Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.SIP.ReInviteExpires 0-65535 Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.SIP.RegisterExpires 0-65535 Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.SIP.DSCPMark 0-63 Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.SIP.X_Aastra_SymmetricUDPSignaling 0-65535 Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.SIP.X_Aastra_SIPTransportProtocol 0-65535 Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.SIP.X_AastraUseBasicCodecs 0-65535 Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.SIP.X_AastraCustomizedCodecs string Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.SIP.X_AastraTaggingEnabled...
  • Page 28 Mitel 6800i Series SIP Phones Release 4.0.0 SP1 TR-069 Configuration Guide PARAMETER READ/WRITE TYPE SIZE RANGE Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.RTP.RTCP.X_AastraRTCPPort 0-127 Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.RTP.RTCP.SRTP Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.RTP.RTCP.SRTP.X_Aastra_SRTP_mode Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.Line Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.Line.1 Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.Line.1.X_Aastra_ScreenName string Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.Line.1.X_Aastra_ScreenName2 string Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.Line.1.SIP Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.Line.1.SIP.AuthUserName string Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.Line.1.SIP.AuthPassword string Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.Line.1.SIP.URI string Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.Line.1.CallingFeatures Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.Line.1.CallingFeatures.Enable boolean Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.Line.1.CallingFeatures.CallerIDName string Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.Line.1.CallingFeatures.MWIEnable boolean Device.Services.VoiceService.1.X_Aastra_GlobalVoiceProfile.Line.1.-Ringer...
  • Page 29 Appendix C - Standard Supported TR-069 Parameters PARAMETER READ/WRITE TYPE SIZE RANGE Device.Services.VoiceService.1.VoiceProfile.i.X_Aastra_DTMFMethod Device.Services.VoiceService.1.VoiceProfile.i.X_Aastra_DTMFOutBand Device.Services.VoiceService.1.VoiceProfile.i.SIP Device.Services.VoiceService.1.VoiceProfile.i.SIP.ProxyServer string Device.Services.VoiceService.1.VoiceProfile.i.SIP.ProxyServerPort 0-65535 Device.Services.VoiceService.1.VoiceProfile.i.SIP.RegistrarServer string Device.Services.VoiceService.1.VoiceProfile.i.SIP.RegistrarServerPort 0-65535 Device.Services.VoiceService.1.VoiceProfile.i.SIP.UserAgentDomain string Device.Services.VoiceService.1.VoiceProfile.i.SIP.OutboundProxy string Device.Services.VoiceService.1.VoiceProfile.i.SIP.OutboundProxyPort 0-65535 Device.Services.VoiceService.1.VoiceProfile.i.SIP.X_Aastra_BackupProxyServer string Device.Services.VoiceService.1.VoiceProfile.i.SIP.X_Aastra_BackupProxyServerPort 0-65535 Device.Services.VoiceService.1.VoiceProfile.i.SIP.X_Aastra_BackupOutboundProxySupport Device.Services.VoiceService.1.VoiceProfile.i.SIP.X_Aastra_BackupOutboundProxy string Device.Services.VoiceService.1.VoiceProfile.i.SIP.X_Aastra_BackupOutboundProxyPort 0-65535 Device.Services.VoiceService.1.VoiceProfile.i.SIP.X_Aastra_mode Device.Services.VoiceService.1.VoiceProfile.i.SIP.X_Aastra_centralizedConference string Device.Services.VoiceService.1.VoiceProfile.i.SIP.X_Aastra_listUri string...
  • Page 30 Mitel 6800i Series SIP Phones Release 4.0.0 SP1 TR-069 Configuration Guide PARAMETER READ/WRITE TYPE SIZE RANGE Device.Services.VoiceService.1.VoiceProfile.i.SIP.X_AastraTaggingEnabled Device.Services.VoiceService.1.VoiceProfile.i.SIP.X_AastraTOSPriorityMap string Device.Services.VoiceService.1.VoiceProfile.i.RTP Device.Services.VoiceService.1.VoiceProfile.i.RTP.DSCPMark 0-63 Device.Services.VoiceService.1.VoiceProfile.i.RTP.VLANIDMark Device.Services.VoiceService.1.VoiceProfile.i.RTP.EthernetPriorityMark Device.Services.VoiceService.1.VoiceProfile.i.RTP.RTCP Device.Services.VoiceService.1.VoiceProfile.i.RTP.RTCP.Enable boolean Device.Services.VoiceService.1.VoiceProfile.i.RTP.RTCP.LocalCName string Device.Services.VoiceService.1.VoiceProfile.i.RTP.RTCP.X_AastraRTCPDSCPMark 0-63 Device.Services.VoiceService.1.VoiceProfile.i.RTP.RTCP.X_AastraRTCPPort 0-127 Device.Services.VoiceService.1.VoiceProfile.i.RTP.RTCP.SRTP Device.Services.VoiceService.1.VoiceProfile.i.RTP.RTCP.SRTP.X_Aastra_SRTP_mode Device.Services.VoiceService.1.VoiceProfile.i.Line Device.Services.VoiceService.1.VoiceProfile.i.Line.1 Device.Services.VoiceService.1.VoiceProfile.i.Line.1.X_Aastra_ScreenName string Device.Services.VoiceService.1.VoiceProfile.i.Line.1.X_Aastra_ScreenName2 string Device.Services.VoiceService.1.VoiceProfile.i.Line.1.SIP...
  • Page 31 Appendix C - Standard Supported TR-069 Parameters PARAMETER READ/WRITE TYPE SIZE RANGE Device.Services.VoiceService.1.VoiceProfile.i.Line.1.-Ringer.X_Aastra_RingTone Note: With parameters containing VoiceProfile.i, the “i” indicates the Voice Profile number. Depending on the phone model, there are up to 9 Voice Profiles corresponding to a specific line on the phone. See “Voice Profile”...
