LevelOne FCS-1070 User Manual

Levelone fcs-1070; wcs-2070 day/night ip network cameras
Hide thumbs Also See for FCS-1070:
Table of Contents

Advertisement

Quick Links

Download this manual
LevelOne
FCS-1070/WCS-2070
Day/Night IP Network Cameras
User Manual
Ver 1.0.0 – 0606

Advertisement

Table of Contents
loading

Related Manuals for LevelOne FCS-1070

Summary of Contents for LevelOne FCS-1070

  • Page 1 LevelOne FCS-1070/WCS-2070 Day/Night IP Network Cameras User Manual Ver 1.0.0 – 0606...

  • Page 2: Before You Use This Product

    Before You Use This Product The use of surveillance devices may be prohibited in your country by law. The Network Camera is not only a high-performance web-ready camera but also can be part of a flexible surveillance system. It is the user’s responsibility to ensure that the operation of such devices is legal before installing this unit for its intended use.
  • Page 3 Package Contents Network Camera + IR Len Camera stand Power adapter Wrench Antennas (WCS-2070 only) Software CD...

  • Page 4: Table Of Contents

    Table of Contents ..........................1 EFORE RODUCT ..............................2 ACKAGE ONTENTS ................................3 NSTALLATION Hardware Installation..............................3 Software Installation..............................5 Initial Access to the Network Camera ...........................9 Installing Plug-in ....................................9 Check Network Settings ................................... 9 Add Password to Prevent Unauthorized Access..........................10 .................................11 OW TO Authentication................................
  • Page 5 CCD Settings ....................................38 Audio....................................39 Motion Detection .................................41 Application Setup.................................42 Weekly Schedule..................................... 42 Event Operation ....................................42 Sequential Operation..................................43 Naming rule of snapshot file................................44 Viewing System Log ..............................47 Viewing System Parameters............................47 Factory Default................................47 ..................................48 PPENDIX A. Troubleshooting...............................48 C. URL commands of Network Camera........................52 Overview ......................................

  • Page 6: Package Contents

    Installation Hardware Installation Please verify that your product package contains all the accessories listed in the foregoing Package Contents. Depending on the user’s application, an Ethernet cable may be needed. The Ethernet cable should meet the specs of UTP Category 5 and not exceed 100 meters in length.
  • Page 7 To install in wireless LAN (WCS-2070 only) If the Ethernet is not available while power on, the Network Camera will search for any access point with the SSID “default”. Once any access point is found, the LED will turn green to wait for installation.

  • Page 8: Software Installation

    Software Installation In this manual, "User" refers to whoever has access to the Network Camera, and "Administrator" refers to the person who can configure the Network Camera and grant user access to the camera. At the end of the hardware installation, the Administrator must place the product software CD into the CD-ROM drive of the PC running in MS Windows.
  • Page 9 Upon Installation Wizard’s start up, a searching box will pop up. This program searches for product on the same LAN: After searching, Network Cameras will be located by the Installation Wizard. There may be several entries shown in the window. The Administrator may differentiate the Network Cameras with the MAC address.
  • Page 10 of finding IP address is seeking from 192.168.0.99, to 192.168.0.254. If any of the address inside this range is free, the Network Camera will be assigned to this IP address, and its subnet mask would be 255.255.255.0. If none of the addresses is free, the Network Camera will try the range from 192.168.0.2 to 192.168.0.98.
  • Page 11 For more detailed usage of the Installation Wizard, please refer to the user’s manual of the Installation Wizard.

  • Page 12: Initial Access To The Network Camera

    Initial Access to the Network Camera Installing Plug-in For the initial access to the Network Camera in Windows, the web browser may prompt for permission to install a new plug-in for the Network Camera after a period of time of downloading. Permission request depends on the Internet security settings of the user’s PC or notebook.

  • Page 13: Add Password To Prevent Unauthorized Access

    Add Password to Prevent Unauthorized Access The default Administrator’s password is the MAC Address, which marks at the bottom label of your FCS-1070/WCS-2070. The Administrator should immediately implement a new password as a matter of prudent security practice. Once the Administrator’s password is saved, the Network Camera will ask for the user’s name and password before each access.

  • Page 14: How To Use

    How to Use Authentication After opening the web browser and typing in the URL of the Network Camera, a dialogue window pops up to request a username and password. The foreground is the login window and the background shows the message if authentication fails.

  • Page 15: Primary User's Capabilities

    Primary User’s Capabilities Main Screen with Camera View The main page layout has two parts: Configuration functions: The camera can be configured using these user interfaces. Camera View: What the camera sees.
  • Page 16 The Configuration: “Digital Output” Clicking on the “On” or “Off” button turns the digital output to either on or off status. “Snapshot” Clicking on the “Snapshot” can get a JPEG format image of the current camera view in another window. “Client Settings”...

  • Page 17: Client Settings

    Client Settings There are four settings for the client side. Media Options - For the User to determine whether to receive video, audio or both. Protocol Options – Which allows choosing on connection protocol between client and server. There are two protocol choices to optimize your usage – UDP and HTTP. The UDP protocol allows for more real-time audio and video streams.

  • Page 18: Administrator's Capabilities

    Administrator’s Capabilities Fine-tuning for Best Performance There are a few choices the Administrator is allowed to maximize the capabilities of the Network Camera. Best performance generally equates to the fastest image refresh rate with the best video quality, and at the lowest network bandwidth as possible. The six factors, “Size”, “Maximum frame rate”, “Video codec type”, “Key frame interval”, “Fix bit rate”, and “Fix quality”...
  • Page 19 quality. The maximum frame rate is 25 fps in a 50Hz system and 30 fps in a 60Hz system. If your network bandwidth is more than 384Kbps, you can fix the bit rate according to your bandwidth and set the maximum frame rate to 25 fps or 30 fps. If you are shooting fast-moving images, you may want to slow the maximum frame rate down to 20 fps in order to lower the rate of data transmission.

  • Page 20: Opening Accounts For New Users

    Opening Accounts for New Users Protect Network Camera by Passwords The Network Camera is shipped without any password by default. That means everyone can access the Network Camera including the configuration as long as the IP address is known. It is necessary to assign a password if the Network Camera is intended to be accessed by others.

  • Page 21: Build A Multimedia Web Attraction Site

    password and disable all the privileges. Share the account to your friends to access your camera. Build a Multimedia Web Attraction Site Demo on Multiple Sites – Mid-scale Service The Network Camera can allow ten visitors on-line simultaneously. After Installation, focus the Network Camera on any object you wish to share, and tell the visitors to type in the web browser address.
  • Page 23 1. Click on “Configuration” on the homepage, 2. Click on “Mail & FTP” in the left column, 3. Fill in the FTP related settings including server, server port, user name and password, as well as the upload path if it is specified by the web space, 4.
  • Page 24 Example of an auto-refresh web page: <html> <head> <title>Example - auto refresh</title> </head> <body> <p align=left> <font size="7" face="Comic Sans MS" color="#FF0000"> MiniAVServer Demo </font> </p> <p align=left> <!-- Begin of scripts to auto refresh the image. Change the IP address in the image URL and refreshrate if necessary.

  • Page 25: Build A Security Application

    Build a Security Application The Administrator can combine options on the application page to perform many useful security applications. There are two trigger sources coming from attached devices, such as for motion detection. There are also two kinds of actions responding to such events, including uploading snapshots over the Internet and driving other attached devices.
  • Page 26 11. Fine-tune using the “Sensitivity” and “Percentage” fields to best suit the camera’s environment. Higher ”Sensitivity” detects the slighter motion. Higher “Percentage” discriminates smaller objects, 12. Clicking on “Save” enables the activity display. Green means the motion in the window is under the watermark set by the Administrator and red means it is over the watermark, 13.

  • Page 27: Definitions In Configuration

    Definitions in Configuration Only the Administrator can access system configuration. Each category in the left column will be explained in the following pages. The bold texts are the specific phrases on the Option pages. The Administrator may type the URL below the figure to directly enter the frame page of configuration.

  • Page 28: System Parameters

    System Parameters "Host name" The text displays the title at the top of the main page. “Turn off the LED indicator” Check this option to shut off the LED on the rear. It can prevent the camera’s operation being noticed. "Keep current date and time"...

  • Page 29: User Group Administration

    User Group Administration “Root password” Change the Administrator’s password by typing in the new password identically in both text boxes. The typed entries will be displayed as asterisks for security purposes. After pressing , the web browser will ask the Administrator for the new password for access.

  • Page 30: Edit User

    Edit User Type the new password, change the privilege and press to modify the account. <url> http://<Network Camera>/setup/edituser.vspx <Network Camera> is the domain name or original IP address of the Network Camera.

  • Page 31: Network Settings

    Network Settings Any changes made on this page will need to restart the system in order to validate the changes. Make sure every field is entered correctly before clicking on "Get IP address automatically" & “Use fixed IP address” The default status is “Get IP address automatically”. This can be tedious having to perform software installation whenever the Network Camera starts.
  • Page 32 work with the port opened by the firewall. “UDP video channel port” This can be something other than the default port 5003 in order to work with the port opened by the firewall. <url> http://<Network Camera>/setup/network.vspx <Network Camera> is the domain name or original IP address of the Network Camera.

  • Page 33: Wireless (Wcs-2070 Only)

    Wireless (WCS-2070 only) “SSID” (Service Set Identifier), it is a name that identifies a wireless network. Access Points and wireless clients attempting to connect to a specific WLAN (Wireless Local Area Network) must use the same SSID. The default setting is default. Note: The maximum length of SSID is 32 single-byte characters and SSID can’t be any of “, <, >...

  • Page 34: Ddns & Upnp

    128 bites key length: 26 Hex digits or 13 characters. Note: When 22(“), 3C(<) or 3E(>) are input in network key, the key format can’t be changed to ASCII format. <url> http://<Network Camera>/setup/wireless.vspx <Network Camera> is the domain name or original IP address of the Network Camera. DDNS &...
  • Page 35 “Enable UPnP” This turns on or off the UPnP function. When UPnP is turned off, the camera cannot be found through network neighbors in MS Windows XP. If the UPnP network component is installed in Windows XP, the hostname of the Network Camera will be shown with bracketed IP address in the Network neighbors.

  • Page 36: Mail & Ftp

    Mail & FTP SMTP “1st SMTP (mail) server” The domain name or IP address of the external email server. “1st SMTP account name” Granted account name on the email server. “1st SMTP password” Granted password on the email server. “1st recipient email address” The email address of recipients for snapshots or log file. Multiple recipients must be separated by semicolon, ‘;’.
  • Page 37 be open for upload. “1st FTP passive mode” The Network Camera is located inside the network protected by a firewall, data connection for FTP may be prohibited. By selecting passive mode, the FTP can bypass the rule and allow snapshot upload to proceed. If the passive mode is selected, the Network Camera can automatically attempt for active mode, if the external FTP server does not support passive mode.

  • Page 38: Video Codec Parameters

    Video Codec Parameters “Text on video” The text will be displayed in the black bar above the video window with a timestamp. The timestamp is captured from date and time of the Network Camera that is maintained by a built-in real-time clock. “Color”...
  • Page 39 <url> http://<Network Camera>/setup/video.vspx <Network Camera> is the domain name or original IP address of the Network Camera.

  • Page 40: Image Settings

    Image Settings Click on “Image Settings” to pop up another window for tuning "Brightness", “Contrast”, “Hue” and "Saturation" for video compensation. Each field has eleven levels ranged from -5 to +5. The User may press “Preview” to fine-tune the image. When the image is O.K., press “Save”...

  • Page 41: Ccd Settings

    CCD Settings Click on “CCD Settings” button, the CCD settings window will pop up. “IRIS mode” selection allows you to select between DC drive or Video drive to fit your auto iris lens. “IRIS level” let users to adjust the aperture size of your auto iris lens.

  • Page 42: Audio

    Audio “Transmission mode” There are five options to select. For all the modes, only one client can talk to the server at the same time. “Full-duplex (Talk and listen simultaneously)” In this mode, the User can talk to the server while listening sound from the server simultaneously.
  • Page 43 <url> http://<Network Camera>/setup/audio.vspx <Network Camera> is the domain name or original IP address of the Network Camera.

  • Page 44: Motion Detection

    Motion Detection “Enable motion detection” Check this option to turn on motion detection. Click on this button to add a new window. At most three windows can exist simultaneously. Use the mouse to click, hold and drag the window frame to resize or the title bar to move. Clicking on the ‘x’...

  • Page 45: Application Setup

    Application Setup Weekly Schedule “Sun” ~ “Sat” Select the days of the week to perform the following operations. “Snapshots begin at” Set the time to start operations. “Snapshots stop at” Set the time to stop operations. Setting identical begin time and stop time means 24-hour operation.

  • Page 46: Sequential Operation

    Sequential Operation “Snapshot interval” The Network Camera will send snapshots at the specified intervals to the external server. “Send snapshots by email” This selects the uploading method following the intervals set above. The snapshot will be attached in the email with the subject title “Periodic snapshots”. “Send snapshots by FTP”...

  • Page 47: Naming Rule Of Snapshot File

    Naming rule of snapshot file Assume the Snapshot file name prefix is <prefix> Method Sequential Event with date and time suffix _20050107175903.jpg _20050107180653_1_pre.jpg <prefix> <prefix> <prefix>_20050107180654_2_pre.jpg <prefix>_20050107180655_3_pre.jpg <prefix>_20050107180659_4_trg.jpg <prefix>_20050107180700_5_pos.jpg (according to the sending order) <prefix>.jpg <prefix>_1_pre.jpg <prefix>_2_pre.jpg <prefix>_3_pre.jpg <prefix>_4_trg.jpg <prefix>_5_pos.jpg (according to the sending order) Email <prefix>.jpg...
  • Page 48 Note: Network Camera...
  • Page 49 <url> http://<Network Camera>/setup/app.vspx <Network Camera> is the domain name or original IP address of the Network Camera.

  • Page 50: Viewing System Log

    Viewing System Log Click on the link on the configuration page to view the system log file. The content of the file provides useful information about configuration and connections after system boot-up. Viewing System Parameters Click on this link on the configuration page to view the entire system’s parameter set. The content is the same as those in CONFIG.INI.

  • Page 51: Appendix

    Appendix A. Troubleshooting Status LED After powering up, the Network Camera performs a self-diagnostic to detect any hardware defects. The following table lists the LED patterns in general. In case of any fatal error, the LED will blink in a pattern other than those below. Condition LED color During self-diagnostic after power on...
  • Page 52 B. Frequently Asked Questions Q What if I forget my password? A After the Administrator's password has been assigned, every access to the Network Camera needs authentication. If you are one of the managed users, you have to ask the Administrator for the password.
  • Page 53 Q The image is not clear enough. A Rotate the lens to adjust the focus after the Network Camera has been installed in the proper position. The image settings and white balance can be fine tuned to achieve the best visual effect.
  • Page 54 In general, the transfer rate in a general local network environment can achieve over 200 kilobytes per second and approximately 10 to 20 pictures per second from a regular environment. Q How can I keep the Network Camera as private as possible? A The Network Camera is designed for surveillance purposes and has many flexible interfaces.

  • Page 55: Url Commands Of Network Camera

    C. URL commands of Network Camera For some customers who already have their own web site or web control application, Network Camera can be easily integrated through convenient URLs. This section lists the commands in URL format corresponding to the basic functions of Network Camera. Overview This section specifies the external HTTP based application programming interface.

  • Page 56: General Cgi Url Syntax And Parameters

    URL syntax examples are written with "Example:" in bold face followed by a short description and a light grey box with the example. Example: request a single snapshot image http://mywebserver/cgi-bin/video.jpg General CGI URL syntax and parameters CGI parameters are written in lower-case and as one word without any underscores or other separators.

  • Page 57: Set Server Parameter Values

    <parameter pair> where <parameter pair> is <parameter>=<value>\r\n [<parameter pair>] <length> is the actual length of content. Example: request IP address and it’s response Request: http://192.168.0.123/cgi-bin/admin/getparam.cgi?network_ipaddress Response: HTTP/1.0 200 OK\r\n Content-Type: text/html\r\n Context-Length: 33\r\n \r\n network.ipaddress=192.168.0.123\r\n Set server parameter values Note: This request require administrator access Method: GET/POST Syntax: http://<servername>/cgi-bin/admin/setparam.cgi? [nosync=<value>&]<parameter>=<value>...

  • Page 58: Available Parameters On The Server

    omit this parameter, it will redirect to an empty page. (note: The return page can be a general HTML file(.htm, .html) or script executable (.vspx) file. It can not be a CGI command. It can not have any extra parameters. This parameter must be put at end of parameter list) Return: HTTP/1.0 200 OK\r\n...
  • Page 59 ledoff Do not turn off the led indicator (r/w) Turn off the led indicator date <yyyy/mm/dd> year, month and date separated by slash. (r/w) <keep> keep date unchanged <auto> Using NTP to sync date/time automatically time <hh:mm:ss> hour, minute and second separated by (r/w) colon.
  • Page 60 language <text string shorter than The webpage language 16 characters> webpageversion <text string shorter than The version of webpage 39 characters> enableir(r/w) Turn on the IR control Turn off the IR control ptzenabled 32-bit integer Indicate the operations of camera supported (r ) Group: Security NAME...
  • Page 61 (r/w) (restart) <blank> dns1 <IP address> primary DNS server (r/w) (restart) <blank> dns2 <IP address> secondary DNS server (r/w) (restart) <blank> smtp1 <domain name or IP primary SMTP server (r/w) address, string shorter <blank> than 40 characters> mailto1 <string shorter than 80 mail recipient address (r/w) characters>...
  • Page 62 ftppasvmode1 Enable passive mode of primary FTP server (r/w) Disable passive mode of primary FTP server ftp2 <domain name or IP secondary FTP server (r/w) address, string shorter than 40 characters > ftpport2 <positive number less secondary FTP port (r/w) than 65535>...
  • Page 63 txrate "NONE", "1M", "2M", Transmit rate in Mbps (r/w) "5.5M", "11M", "6M", "9M", <Auto> "12M", "18M", "24M", "36M", "48M", "54M", "Auto" for 802.11g preamble Long Long preamble (r/w) Short Short preamble encrypt Enable data encription (r/w) Disable data encription authmode Auto Automatic mode (r/w)
  • Page 64 Group: Video NAME VALUE DESCRIPTION text <text string shorter than enclosed caption (r/w) 14 characters> <blank> codectype MPEG4 (r/w) MJPEG keyinterval 1, 3, 5, 10, 30, 60, 90, Key frame interval (r/w) <120> size half (r/w) half x 2 normal normal x 2 double color...
  • Page 65 set maximum frame rate to 25 fps 30 (for NTSC only) set maximum frame rate to 30 fps modulation NTSC (r/w)(in server version only) AUTO (restart) actualmodulation NTSC (in built-in CCD version only) flip flip image (r/w) normal image mirror mirror image (r/w) normal image...
  • Page 66 enableaec (r/w) Disable Enable Group: Image NAME VALUE DESCRIPTION brightness <-5 ~ 5> Adjust brightness of image according to mode (r/w) settings. <0> saturation <-5 ~ 5> Adjust saturation of image according to mode (r/w) settings. <0> contrast <-5 ~ 5> Adjust contrast of image according to mode (r/w) settings.
  • Page 67 Group: Motion NAME VALUE DESCRIPTION enabled disable motion detection (r/w) enable motion detection winenabled_<1~3> disable motion window #1 (r/w) enable motion window #1 winname_<1~3> <text string shorter than name of motion window #1 (r/w) 14 characters > <blank> winleft_<1~3> Left coordinate of window position. 0 ~ 352 for CCD (r/w) <0>...

  • Page 68: Application Page Cgi Command

    <blank> passwordkey Text string shorter than 20 Your password or key to login ddns service (r/w) characters. provider <blank> update 0, 1 Update the above ddns settings to take effect Group: UPNP NAME VALUE DESCRIPTION enable 0, 1 Enable or disable the UPNP service. (r/w) <1>...
  • Page 69 [&delay=<value>][&prevnum=<value>][&ssfprefix=<value>][&dihigh=<value>] [&dilow=<value][&dirise=<value>][&difall=<value>][&motion1=<value] [&motion2=<value>][&motion3=<value>][&ioalarm=<value>] [&mdalarm=<value] [&ioupload=<value>][&mdupload=<value>][&seqop=<value>][&sinter=<value>] [&smethod=<value>][&suffix=<value>][&resetdo=<value>] Return: HTTP/1.0 200 OK\r\n Content-Type: text/plain\r\n Content-Length: <length>\r\n \r\n <depends on method value> If(method == get || method == set) tue=<value>\r\n wed=<value>\r\n … Else if(method == normal) Application page contents parameter Value description Get parameters, if no parameter followed, all the method parameters value will be listed.
  • Page 70 Disable/Enable Thursday weekly schedule check box Disable/Enable Friday weekly schedule check box Disable/Enable Satday weekly schedule check box Begin time of weekly schedule hh:mm:ss begin_time End time of weekly schedule end_time hh:mm:ss Disable/Enable all the time except for the above exclude schedule check box Disable/Enable Event operation...

  • Page 71: Drive The Digital Output

    Example: Enable sequential send snapshot by every 1 second with email. http://myserver/setup/app.vspx?method=set&exclude=1&eventop=0&seqop=1& smethod=mail&sinter=1 Drive the digital output Note: This request requires the privilege of I/O access control. Method: GET/POST Syntax: http://<servername>/cgi-bin/setdo.cgi?do1=<state>[&do2=<state>] [&do3=<state>][&do4=<state>][&return=<return page>] Where state is H, L. H means NC (normal close) connected with COMMON and L means NO (normal open) connected with COMMON.

  • Page 72: Query Status Of The Digital Output

    Return: HTTP/1.0 200 OK\r\n Content-Type: text/plain\r\n Content-Length: <length>\r\n \r\n [di1=<state>]\r\n [di2=<state>]\r\n [di3=<state>]\r\n [di4=<state>]\r\n where <state> can be H or L. Example: Query the status of digital input 1 Request: http://myserver/cgi-bin/getdi.cgi?di1 Response: HTTP/1.0 200 OK\r\n Content-Type: text/plain\r\n Content-Length: 7\r\n \r\n di1=H\r\n Query status of the digital output Note: This request requires the privilege of I/O access control.

  • Page 73: Capture Single Snapshot

    [do1=<state>]\r\n [do2=<state>]\r\n [do3=<state>]\r\n [do4=<state>]\r\n where <state> can be H or L. Example: Query the status of digital output 1 Request: http://myserver/cgi-bin/getdo.cgi?di1 Response: HTTP/1.0 200 OK\r\n Content-Type: text/plain\r\n Content-Length: 7\r\n \r\n do1=H\r\n Capture single snapshot Note: This request require normal user privilege Method: GET/POST Syntax: http://<servername>/cgi-bin/video.jpg...

  • Page 74: Account Management

    Account management Note: This request requires administrator privilege Method: GET/POST Syntax: http://<servername>/cgi-bin/admin/editaccount.cgi? method=<value>&username=<name>[&userpass=<value>][&privilege=<value>] [&privilege=<value>][…][&return=<return page>] parameter value description method Add an account to server. When using this method, “username” field is necessary. It will use default value of other fields if not specified. delete Remove an account from server.

  • Page 75: System Logs

    return <return page> Redirect to the page <return page> after the parameter is assigned. The <return page> can be a full URL path or relative path according the the current path. If you omit this parameter, it will redirect to an empty page. System logs Note: This request require administrator privilege Method: GET/POST...

  • Page 76: System Information

    Content-Type: text/plain\r\n Content-Length: <configuration file length>\r\n \r\n <configuration data>\r\n System Information Note: This request requires normal user privilege Method: GET/POST Syntax: http://<servername>/cgi-bin/sysinfo.cgi Server will return the system information. Return: HTTP/1.0 200 OK\r\n Content-Type: text/plain\r\n Content-Length: <system information length>\r\n \r\n Model=<model name of server>\r\n HostName=<host name of server>\r\n Location=<video on text of server>\r\n [Preset<0>=<first preset location>\r\n]...

  • Page 77: Technical Specifications

    140 mm(L) * 70mm(W) * 55 mm(H) TCP/IP, HTTP, SMTP, FTP, Telnet, NTP, DNS UPnP, DDNS and DHCP - Power Physical Consumption: FCS-1070: MAX 7W; 10BaseT Ethernet or 100BaseT Fast Ethernet WCS-2070: MAX 9.4 W Auto negotiation Adapter input: 100-240VAC, 50/60Hz, 0.4A Wireless Ethernet Adapter output: 12VDC, 1.5A...
