LevelOne FCS-1151 Specifications

H.264 2-Megapixel PoE

Network Camera

H/W Version: 1
LevelOne FCS-1151 is a professional-series fixed
network camera featuring super image quality and
exceptional bandwidth efficiency. It is especially
suitable for wide open spaces such as building
entrances and airports, or applications requiring
accurate identification, such as human faces in banks
or vehicle license plates in parking lots.
Featuring a 2-Megapixel sensor, and H.264/MPEG-4/
MJPEG compression technology, video streams can
be individually configured to meet different needs
1. Light Sensor
2. Lens
3. Built-in Microphone
4. LAN Port
Key Features
- 2-Megapixel CMOS Sensor
- Removable IR-cut Filter for Day & Night Function
- Real-time H.264, MPEG-4 and MJPEG Compression
(Triple Codec)
- Multiple Streams Simultaneously
- Video Cropping for Bandwidth Saving
- ePTZ for Data Efficiency
- Tamper Detection for Unauthorized Changes
- Built-in 802.3af Compliant PoE
- Built-in SD/SDHC Card Slot for On-board Storage
- *Free 32-CH Monitoring Software Included
*Please visit www.level1.com for free 64-CH Monitoring Software (Supports iCamSecure Apple App and iOS Safari)

9 10
1 2 3 4 5 6
5. Reset
6. MIC & Video Switch
7. GPIO
or bandwidth constraints, thereby further reducing
bandwidth and storage requirements. Users can
receive multiple streams simultaneously in different
resolutions, frame rates and image qualities for
viewing on different platforms.
Together with PoE, QoS, activity adaptive streaming,
and the included 32-CH LevelOne IP CamSecure Lite
surveillance management software, the FCS-1151
is indisputably the top choice for reliable and high
performance surveillance.
11 12
7 8
8. DC Power In
9. MIC in
10. LEDs
Works Well With
FCS-1151
13
11. Audio / Video Out
12. SD/SDHC Card slot
13. 4-pin Auto lris Connector
FSW-0503
4 FE PoE + 1FE Switch
NVR-0216
16-CH Network Video Recorder
