ENTERING THE PROGRAM MODE....................................................................................... 2
SELECTING THE MODULE TO PROGRAM.......................................................................... 2
PROGRAMMING A LOCATION ............................................................................................. 2
NX1192E ENGLISH LIBRARY................................................................................................ 3
NX1192E AMERICAN SPANISH LIBRARY ........................................................................... 4
LOADING FACTORY DEFAULTS.......................................................................................... 4
ENROLLING MODULES AND KEYPADS.............................................................................. 4
PROGRAMMING THE NX1192E LCD KEYPADS ................................................................. 5
USING THE FUNCTION MENU .............................................................................................. 5
79 1
ADJUSTING THE VIEW / BRIGHTNESS OF THE LCD.................................... 5
7 9 2
PROGRAMMING CUSTOM MESSAGES IN THE KEYPAD ............................. 6
79 3
SET KEYPAD OPTIONS.................................................................................... 6
79 4
SET KEYPAD NUMBER AND PARTITION ....................................................... 7
KEYPAD FUNCTIONS ............................................................................................................ 7
79 0
READING THE EVENT LOG ............................................................................. 7
POSSIBLE LOG MESSAGES ........................................................................... 8
79 5
79 7
SET SYSTEM TIME AND DATE........................................................................ 9
70
ADJUST KEYPAD TONE................................................................................... 9
7N
VIEW ZONE STATUS ........................................................................................ 9
73
VIEW ALARM MEMORY.................................................................................... 9
74 4
TEST FUNCTION............................................................................................. 10
74 5
DISPLAY TEST FUNCTION ............................................................................ 10
74 6
LIGHT CONTROL FOR X-10 DEVICES .......................................................... 10
74 7
HOUSE CODES FOR X-10 DEVICES............................................................. 10
74 9
CHANGE LANGUAGES................................................................................... 10
75
CHANGING USER CODES ............................................................................. 11
76
ASSIGNING AUTHORITY LEVEL ................................................................... 11
77
RESET FUNCTION.......................................................................................... 12
PARTITIONED SYSTEMS OPERATION .............................................................................. 12
LIGHTS IN PARTITIONING MASTER MODE.................................................................. 12
DISPLAYS IN THE PARTITIONING MASTER MODE..................................................... 13
SERVICE DISPLAY............................................................................................................... 14
NX1192E MAXIMUM WIRE RUN.......................................................................................... 16
SPECIFICATIONS ................................................................................................................. 16
1
NX1192E LCD KEYPAD
INSTALLATION MANUAL

Table of Contents

Advertisement

Table of Contents
loading

Related Manuals for Interlogix NX1192E

Summary of Contents for Interlogix NX1192E

  • Page 1: Table Of Contents

    NX1192E ENGLISH LIBRARY....................3 NX1192E AMERICAN SPANISH LIBRARY ................4 LOADING FACTORY DEFAULTS..................4 ENROLLING MODULES AND KEYPADS................4 PROGRAMMING THE NX1192E LCD KEYPADS ..............5 USING THE FUNCTION MENU ....................5 79 1 ADJUSTING THE VIEW / BRIGHTNESS OF THE LCD........5 7 9 2 PROGRAMMING CUSTOM MESSAGES IN THE KEYPAD ......

  • Page 2: Entering The Program Mode

    ENTERING THE PROGRAM MODE To enter the Program Mode, press [7]-[8]. At this time, the LCD screen will prompt you for the programming code. Next, enter the "Go To Program Code" (FACTORY DEFAULT IS [9]- [7]-[1]-[3]). If the "Go To Program Code" is valid, the LCD screen will prompt you for the device address you wish to program.

  • Page 3: Nx1192E English Library

    [U] key. When done editing the line, enter the [#] key to escape from the edit mode. Table 1.1 English " < > & Ü  ž NX1192E ENGLISH LIBRARY ALARM DURESS INSTANT STORAGE AREA EAST INTERIOR PORCH STUDY...

  • Page 4: Nx1192E American Spanish Library

    Table 1.2 American Spanish ü í ú < á ñ " > ó & Ü é Ñ NX1192E AMERICAN SPANISH LIBRARY ABAJO DESPACHO GERENCIA PANICO SENSOR ALARMA DETECTOR GOLPE PARED SILENCIOSA ALMACEN DISPARO HABITACION PASILLO SIRENA ARRIBA DOBLE TECHNOLOGIA HUMO...

  • Page 5: Programming The Nx1192E Lcd Keypads

    PROGRAMMING THE NX1192E LCD KEYPADS This section describes how to program the address and partition of each keypad, as well as the options that are available. The address of the keypad is important because this is how the panel supervises the keypads. The factory default for the “Master Code” is [1]-[2]-[3]-[4] when using a 4-digit code, or [1]-[2]-[3]-[4]-[5]-[6] for a 6-digit code.

  • Page 6: Programming Custom Messages In The Keypad

    U 9 2 PROGRAMMING CUSTOM MESSAGES IN THE KEYPAD NOTES: The messages (custom, zone, and shutdown) are transferred to other LCD keypads after this mode is exited. All keypads must be addressed and enrolled for this to happen. Set the keypad numbers with [7]-[9]-[4] prior to programming custom messages. If a keypad is added after messages are programmed, you should either program ALL messages in it, or enter custom message programming on an existing keypad and make changes.

  • Page 7: Set Keypad Number And Partition

    KEYPAD FEATURES NOT USED SILENT KEYPAD? Enable Silent Keypad Option. If enabled, only the entry/exit and sounder chime are silenced. DING DONG CHIME? Enable Ding Dong Sound for Chime. If off, chime will be a single tone. (Refer to NX8-E Installation manual, location 40) 5 SEC.

  • Page 8: Possible Log Messages

    contains the following information. User or Zone ID Event 2SHQ   Indicates partition Date and 7 indicates an Time (Month/Date) shown in 24-hour format event not reported This screen shows an opening of Partition 3 on September 25 at 5:27 p.m. by user 75. The [7] shows that this event is not programmed to be reported to the central monitoring station.

  • Page 9: Set Elapsed Time In Minutes Since Last Autotest

    Listen In - A listen in function has been activated. Listen In Service Start - Technician is on site. Service Start Service End Service End - Technician is off site. Code Entry Code Entry - A code has been entered. First Open - Reports when the first partition is disarmed.

  • Page 10: Test Function

    U4 4 TEST FUNCTION The test will be performed as programmed. 1) Enter [U]-[4]-[4] If the siren test is performed, enter a user code to silence the siren. U4 5 DISPLAY TEST FUNCTION All of the display pixels and LED indicators will flash. 1) Enter [U]-[4]-[5] 2) Press any key to end test.

  • Page 11: Changing User Codes

    CHANGING USER CODES Note: For partitioned systems, someone changing the code of another person must have access to all or more partitions than the user being changed. The LCD Screen will prompt for a code. 1) Enter [U]-[5] 2) Enter [master code] The LCD Screen will prompt for a user number.

  • Page 12: Reset Function

    15 minutes. PARTITIONED SYSTEMS OPERATION The NX1192E can be programmed to operate all the system partitions simultaneously. To set the multi-partition mode, use the U U9 3 function, and answer "YES" to the question "Master keypad?"...

  • Page 13: Displays In The Partitioning Master Mode

    DISPLAYS IN THE PARTITIONING MASTER MODE Armed and Ready Status The LCD screen will display the Armed and Ready status of ALL eight (8) partitions if any or all of the areas is armed or not ready. 5HDG\  This display is reflecting all 8 areas are Ready, and Area $UPHG  5 is disarmed.

  • Page 14: Service Display

    ƒ To operate an individual area, enter the number of the partition you wish to operate. The LCD keypad will now operate as a single area keypad. All keys and functions entered will affect this individual partition only. The lights and LCD display represent the status of that partition only.
  • Page 15 &RQWURO The main power to your system is not on. 3RZHU7URXEOH &RQWURO The standby battery is low. /RZ%DWWHU\ ([SDQVLRQ An auxiliary reporting device has failed to $X[&RPP)DLO communicate, i.e. NX580, NX582, etc. ([SDQVLRQ A short circuit of an expansion devices power 2YHUFXUUHQW supply has occurred.

  • Page 16: Nx1192E Maximum Wire Run

    The following chart provides the device numbers that will be reported for trouble conditions. KEYPAD PARTITION NX1192E MAXIMUM WIRE RUN (Note: These numbers are for one keypad at the end of the wire. When connecting more than one keypad to the end of the wire, a heavier gauge wire will be required.)
