TVK-800 User Manual
P/N 1072696A • REV • ISS 13MAY14

Advertisement

Table of Contents
loading

Related Manuals for Interlogix TVK-800

Summary of Contents for Interlogix TVK-800

  • Page 1 TVK-800 User Manual P/N 1072696A • REV • ISS 13MAY14...
  • Page 2 Copyright © 2014 United Technologies Corporation. Interlogix is part of UTC Building and Industrial Systems, a unit of United Technologies Corporation. All rights reserved. Trademarks and Trade names used in this document may be trademarks or patents registered trademarks of the manufacturers or vendors of the respective products.

  • Page 3: Table Of Contents

    Playback a file 33 User management 35 Camera settings 37 Output settings 38 Macro settings 40 Playback files from a recorder 41 Advanced settings 42 Log out of the keypad 44 Reboot the keypad 44 Shutdown 44 TVK-800 User Manual...
  • Page 4 Operating PTZ cameras 64 Setting a preset 64 Calling up a preset 65 Setting a preset tour 66 Calling up a preset tour 67 Setting a shadow tour 68 Calling up a shadow tour 69 Specifications 70 Index 71 TVK-800 User Manual...

  • Page 5: Introduction

    • Displays a decoded camera on the selected window • Displays a decoded camera group on the selected window • Sequences a display of a decoded camera group on a monitor • Sequences a display of a decoded camera group on a monitor group TVK-800 User Manual...

  • Page 6: Package Contents

    Working surface: Place the device on a horizontal solid surface. Avoid exposure to severe vibrations. Caution: Do not attempt to dismantle this product. Any attempt to dismantle or remove the covers from this product will invalidate the warranty and may also result in serious injury. TVK-800 User Manual...

  • Page 7: Description

    Figure 1: Back view of the keypad 1. Touch pen 6. RS-485 interface 2. GND 7. LAN, PoE (802.3af) 3. Line in 8. RS-232 interface 4. Audio out 9. USB interface 5. Reserved 10. 12 VDC power supply 11. Power on/off TVK-800 User Manual...

  • Page 8: Keypad Description

    There are 20 function keys. They allow you to quickly select regularly used functions such as to call up presets or to select a monitor. See Figure 2 above for the location of the function keys on the keypad. The keys are lit blue when inactive and red when active. TVK-800 User Manual...

  • Page 9: Playback Control Dial And Keys

    Keypad > Hardware Settings menu. Note: The keys are also locked when the screen is automatically locked. Playback control dial and keys See Figure 2 on page 6 for the location of playback control on the keypad. TVK-800 User Manual...

  • Page 10: Select Options On The Lcd Display

    Table 1: Operating a multiple video display Description Example Num+MON: Select the video output to Press the 2+MON keys to select monitor be controlled by the decoder, NVR, or DVR. Note: When Num=0, the system enters local live view mode. TVK-800 User Manual...
  • Page 11 Num+PATROL: Call a predefined Press the 1+PATROL keys to call preset preset tour. tour 1. PATTERN Num+PATTERN: Call a predefined Press the SET+1+PATTERN keys to set shadow tour. shadow tour 1. Press the 1+PATTERN keys to call shadow tour 1. TVK-800 User Manual...

  • Page 12: Overview Of The User Groups

    Figure 5: Soft keyboard Click to enter letters or numbers. Click to switch between upper and lower case. Overview of the user groups By default the keypad comes with four user groups: Administrator, Manager, Operator, and Customized User. TVK-800 User Manual...

  • Page 13: Logging In/Out

    The operator only has access to the remote control of DVR/NVR front panels. Custom The customized user only has access to the remote control of DVR/NVRs front panel. Logging in/out 1. Power up the keypad. The following display appears: TVK-800 User Manual...
  • Page 14 Note: The list of menu options available will depend on the user type. To log out of the system: 1. Click the Logout button in one of the configuration screens. You return to the Login screen. TVK-800 User Manual...

  • Page 15: Menu Overview

    8. Advanced Advanced settings: Set AUX1 and AUX2 keys to bidirectional audio and snapshots. Modify network performance and PTZ speed. Set up FTP server settings. 9. Shutdown Log out, reboot, and shutdown the system. TVK-800 User Manual...

  • Page 16: Keypad Configuration Via The Web Browser

    To access the keypad, open a web browser and enter the IP address assigned to the keypad as a web address. In the Login window, enter the Admin user name and password. Admin User ID: admin Password: 1234 IP address: 192.168.1.70 Subnet mask: 255.255.255.0 Port: 8000 TVK-800 User Manual...

  • Page 17: Keypad Management

    Click Save to save the changes. See Figure 8 below. For information on setting up keypad parameters locally, see “Keypad management” on page 24. Figure 8: Keypad management window TVK-800 User Manual...

  • Page 18: Device Management

    The Operator/Custom users can modify their passwords. Note: Only the Administrator can create Managers. However, only Managers can create Operator and Custom users See Figure 10 on page 17. For further information on setting up user parameters, see “User management” on page 35. TVK-800 User Manual...
  • Page 19 Set up a user to access a specific device 1. In the “User Management” window, click for the selected user. The “User- Device” pop-up window appears, listing all the devices available. TVK-800 User Manual...

  • Page 20: Input Settings

    For example, one group can be cameras viewing the car park and another group can be cameras viewing the building entrances. You can set up to 16 camera groups. For further information on setting up input parameters, see “Input settings” on page 49. TVK-800 User Manual...
  • Page 21 1. In the “Input” window, click the Group button. The “Input Settings-Input Group” window appears. 2. Select the desired group number from the Group No. drop-down list. 3. Click the Add Camera button. The “Input Settings-Add Camera” window appears. TVK-800 User Manual...

  • Page 22: Output List

    2. Modify the output’s number. Click to accept. Set up an output group 1. In the Input window, click the Group button. The “Input Settings-Input Group” window appears. 2. Select the desired group number from the drop-down list. TVK-800 User Manual...

  • Page 23: Auxiliary Functions

    High speed. Click Save to save the changes. For further information on setting up these parameters, see “Live view and PTZ speed settings” on page 43. FTP settings You can upload video file and snapshots to an FTP server. TVK-800 User Manual...

  • Page 24: System Status

    3. Enter the file path to which the video files and snapshots are uploaded. 4. Click Apply to save the settings. System status Click System Status to check the boot time of the keypad as well as the number of different devices connected to the keypad. TVK-800 User Manual...
  • Page 25 Figure 15: System Status window TVK-800 User Manual...

  • Page 26: Local Keypad Configuration By The Administrator

    It lists the current version information of the firmware, encoding, panel, and hardware. 2. Click Return to return to the Main menu or click another Keypad menu option. Configure the keypad network settings 1. In the Main menu, click Keypad > Network. The “Keypad-Network Settings” window appears: TVK-800 User Manual...
  • Page 27 There are four values to select: 1:1, 3:1, 1:3, or Not transparent. 7. Mouse speed Set the mouse speed. Select a level between 0 and 2. 8. Brightness Set the screen brightness. Select a level between 0 and 3. TVK-800 User Manual...
  • Page 28 Settings. The “Keypad-Language Settings” appears: 2. Select the desired language. Note: Currently only English is available. 3. Click Apply to save settings. 4. Click Return to return to the Main menu or click another Keypad menu option. TVK-800 User Manual...
  • Page 29 • Use an FTP server • Use an USB flash drive Before you can upgrade the keypad software by FTP, you must first set up an FTP server connection by TFTP or WFTP to transfer the file. TVK-800 User Manual...
  • Page 30 4. Select the upgrade file from the list and click Upgrade to start the upgrade process. The configuration file is digicap.dav. 5. When the upgrade is successful, the keypad automatically reboots. If the upgrade fails, an error message appears. Click to accept. TVK-800 User Manual...

  • Page 31: Device Management

    The “Device-Device List” window lists all the devices that are in communication with the keypad. See Figure 16 on page 30. You can add devices to the keypad either by searching for all the devices available in the same subnet, or by doing a manual search. TVK-800 User Manual...
  • Page 32 Several devices can be selected together if they share the same login user name and password. 3. Click to add the device to the system. The Status column indicates the status of each listed device: TVK-800 User Manual...
  • Page 33 Note: If the information is invalid or the device is offline, the following error message appears, “Failed to add device.” Modify the device name 1. In the Main menu, click Device. The “Device-Device List” window appears. 2. Click for the device you want to modify. The “Device-Modify Device” window appears. TVK-800 User Manual...
  • Page 34 #4 MON Note: Not all DVRs/NVRs support remote control. To remotely control a DVR/NVR using the keypad MON key: 1. Press the keys to call up the monitor of the desired DVR or NVR. The Shortcuts window appears. TVK-800 User Manual...

  • Page 35: Local Live View

    3. To view other cameras listed, press the NEXT PREV keys on the keypad to view the next or previous cameras. Playback a file 1. In the Main menu, click Output. The “Output Settings-Output List” window appears. TVK-800 User Manual...
  • Page 36 Click Search. The results are listed on-screen. 5. Select a file for playback from the list and click the Playback button to play back the file. Note: You can also do instant playback. See “Instant playback” on page 61 for more information. TVK-800 User Manual...

  • Page 37: User Management

    3. Click the Add Device button. 4. In the window that appears, select the desired devices and click to add the device to the selected user. The successfully added devices are then added to the “User-Device” window. TVK-800 User Manual...
  • Page 38 Modify a user password 1. In the Main menu, click User. The “User-User List” window appears. 2. Click for the desired user. The “User-Change Password” pop-up window appears. 3. Enter the new password and verify it. Click to accept. TVK-800 User Manual...

  • Page 39: Camera Settings

    1. In the Main menu, click Input. The “Input Settings-Input” window appears. 2. Click the Input Group button. The “Input Settings-Input Group” window appears. 3. Select the desired group number from the Group No. drop-down list. Up to 16 camera groups can be added. TVK-800 User Manual...

  • Page 40: Output Settings

    You can also playback files from the output channel, such as a DVR or NVR. Display the list of output channels 1. In the Main menu, click Output. The Output Settings-Output window appears. TVK-800 User Manual...
  • Page 41 2. Click the Output Group button. The “Input Settings-Output Group” window appears. 3. Click to select the group number from the drop-down list. 4. Click the Add Output button. The “Add Output” window appears. 5. Select the desired outputs to add to the group. Click Add. TVK-800 User Manual...

  • Page 42: Macro Settings

    Manage a macro 1. In the Main menu, click Macro. The “Macro Settings-Macro List” window appears. All the current macro commands are listed. 2. Click one of the icons to view, run, or delete the selected macro command: TVK-800 User Manual...

  • Page 43: Playback Files From A Recorder

    3. Select the desired file to play back. 4. Click the Playback button. The file starts to play. Remote playback 1. Click the Remote Record Files tab on the “Local Playback” window. The “Remote Record Files” window appears. TVK-800 User Manual...

  • Page 44: Advanced Settings

    1. In the Main menu, click Advanced. The “Advanced Settings” window appears. 2. Click Aux Key to view the “Aux Key” window. The Aux Key 1 and Aux Key 2 options correspond to the AUX 1 and AUX 2 keys on the keypad. TVK-800 User Manual...
  • Page 45 You can upload video files and snapshots to an FTP server. To set up the FTP server settings: 1. In the Main menu, click Advanced. The “Advanced Settings” window appears. 2. Click FTP Settings to view the FTP Settings window. 3. Check Enable FTP box. TVK-800 User Manual...

  • Page 46: Log Out Of The Keypad

    The pop-up window appears, “Restart of the system?” 2. Click to confirm, or to cancel. Shutdown 1. In the Main menu, click Shutdown. Select Shutdown. The pop-up window appears, “Shut down the system?” 2. Click to confirm, or to cancel. TVK-800 User Manual...

  • Page 47: Local Keypad Configuration By The Manager

    4. Click Login. The main screen for the user type appears with the list of menu options available displayed. Note: The list of menu options available will depend on the user type. To log out of the system: 1. Click the Logout button in one of the configuration screens. TVK-800 User Manual...

  • Page 48: Display List Of Accessible Devices

    Local live view The Administrator assigns the cameras that can be viewed by Managers. To live view cameras locally 1. In the Main menu, click Input. The “Input Settings-Input “window appears. TVK-800 User Manual...

  • Page 49: Playback A File

    4. Enter the camera number, record type, and file type as well as the start and end times for playback. Click Search. The results are listed on-screen. 5. Select a file for playback from the list and click Playback to play back the file. TVK-800 User Manual...

  • Page 50: User Management

    1. In the Main menu, click User. The “User-User List” window appears. 2. Click for the desired user. The “User-Device” window appears. 3. Select the desired device for this user and click . Click in the pop-up window to confirm deletion. TVK-800 User Manual...

  • Page 51: Input Settings

    1. In the Main menu, click Input. The “Input Settings-Input” window appears. 2. Click on the desired camera. The “Input Settings-Modify Camera” window appears. 3. Enter the camera number, camera name, protocol, and stream type. Click OK. Note: The camera number must be between 1 and 999,999. TVK-800 User Manual...

  • Page 52: Output Settings

    You can add up to 128 macro commands. There can be up to a maximum of six numbers in a macro command. For instructions on setting up and using macros, see “Macro settings” on page 40 TVK-800 User Manual...

  • Page 53: Playback Files From An Encoder

    The pop-up window appears, “Restart of the system?” 2. Click to confirm, or to cancel. Shutdown 1. In the Main menu, click Shutdown. Select Shutdown. The pop-up window appears, “Shut down the system?” 2. Click to confirm, or to cancel. TVK-800 User Manual...

  • Page 54: Local Keypad Configuration By The Operator And Custom Users

    4. Click Login. The main screen appears with the list of menu options available displayed. Display list of accessible devices The Administrator assigns the devices that can be accessed by users with Manager rights. Managers can then assign their devices to operators and customized users. TVK-800 User Manual...

  • Page 55: Change Password

    2. Enter the current password and the new one. Confirm the new password. 3. Click Apply to accept the changes Shutdown 1. In the Main menu, click Shutdown. Select Shutdown. The pop-up window appears, “Shut down the system?” 2. Click to confirm, or to cancel. TVK-800 User Manual...

  • Page 56: Using The Keypad

    For instructions on using the Input menu, see “Local live view” on page 33. You can carry out shortcut actions to live view. To access local live view: 1. Press to enter local live view mode. 2. Enter the camera number and press CAM. TVK-800 User Manual...

  • Page 57: Display Decoded Video On A Monitor

    To view in full-screen or multiview mode: 1. Press the keys to select the monitor. 2. Press the MULT keys to select the multiview mode for the monitor. TVK-800 User Manual...
  • Page 58 4, and finally cameras 13 to 16 on video tiles 1 to 4. Note: The default dwell time is 30 seconds. An error message will appear in the Hint box of the shortcut screen when an invalid action is entered. TVK-800 User Manual...
  • Page 59 Camera group 3 and display it on video tile 2 of Monitor 1. Note: If you enter 0 + MON in live view mode, multiview mode is not supported as video is then displayed on the keypad. TVK-800 User Manual...
  • Page 60 The default dwell time is 30 seconds but it can be modified. Tour setups are not saved when the device is restarted. An error message will appear in the Hint box of the shortcut screen when an invalid action is entered. TVK-800 User Manual...
  • Page 61 Each user account can set up to eight tour groups. Each tour group can contain up to eight camera groups to specific monitors. Caution: Group tour setups are not saved when the keypad is rebooted. A group tour cannot be set up in playback mode. TVK-800 User Manual...
  • Page 62 If multiple camera groups have been set up to appear on the same monitor, then the monitor only displays the last programmed camera group. To call up a group tour: 1. Press the GROUP keys to call up the programmed group tour. TVK-800 User Manual...

  • Page 63: Instant Playback

    Note: The keypad takes the bidirectional audio from the nearest device. To start bidirectional audio with a camera: 1. Press and select the camera. 2. Press the AUX1/ AUX2 key that is configured to the bidirectional function to start bidirectional audio. TVK-800 User Manual...

  • Page 64: Saving Recordings

    There are two ways to record video: Method 1: To record video 1. Press the keys and select the monitor. 2. Press the keys and select the video tile. 3. Press the key to start recording. TVK-800 User Manual...

  • Page 65: Moving To Next/Previous Cameras

    Note: This method only works if the current window is in dynamic decoding mode. Method 2: To move to the next or previous camera 1. Press the keys and select the input channel. 2. Press the PREV or NEXT key and select the previous or next camera. TVK-800 User Manual...

  • Page 66: Operating Ptz Cameras

    Note: The action is invalid. 2. Using the joystick, move the PTZ camera to the desired position. 3. Press the keys and enter the preset number to set the current position as a preset. TVK-800 User Manual...

  • Page 67: Calling Up A Preset

    Method 2: To call up a preset using an input channel 1. Press the keys and select the camera. Note: The action is invalid. 2. Press the CALL keys and enter the desired preprogrammed preset. TVK-800 User Manual...

  • Page 68: Setting A Preset Tour

    Method 2: To set a preset tour using an input channel 1. Press the keys to select the camera. Note: The action is invalid. 2. Press the key to enter the Settings window. 3. Press the PATROL keys to enter the Preset Tour Settings window. TVK-800 User Manual...

  • Page 69: Calling Up A Preset Tour

    Method 2: To call up a preset tour using an input channel 1. Press the keys to select the camera. 2. Press the PATROL keys to enter the desired preprogrammed preset tour. TVK-800 User Manual...

  • Page 70: Setting A Shadow Tour

    Method 2: To set a shadow tour using an input channel 1. Press the keys and select the camera. 2. Press the key to enter the Settings window. 3. Press the PATTERN keys and set the shadow tour number. TVK-800 User Manual...

  • Page 71: Calling Up A Shadow Tour

    Method 2: To call up a preset tour using an input channel 1. Press the keys and select the camera. 2. Press the PATTERN keys to call up the shadow tour number. TVK-800 User Manual...

  • Page 72: Specifications

    Power consumption: Working temperature: -10 to +55°C (14 to 131 °F) Working humidity: 10 to 90% Size (H × W × D): 110 × 193 ×435 mm (4.33 × 7.59 × 17.12 in.) Weight: 2 kg (4.4 lb.) TVK-800 User Manual...

  • Page 73: Index

    50 playback files, 47 user management, 48 FTP settings Monitors browser setup, 21 camera groups, 56 local setup, 43 display cameras, 55 Functions keys display format, 55, 56 description, 7 Network setup, 24 Hardware configuration, 25 TVK-800 User Manual...
  • Page 74 Presets User set up, 64 browser setup, 16 PTZ control speed settings User management local setup, 43 admin local setup, 35 Manager, 48 Users Reboot types, 10 local, 44 Recordings saving, 62 Version information, 24 Remote control TVK-800 User Manual...
