SERVICE MANUAL
MODELS
7075/FORCE 75
7085/FORCE 85
FEBRUARY 2003
CSM-7075/F75/7085/F85

Advertisement

Table of Contents
loading

Related Manuals for Konica Minolta 7085/FORCE 85

Summary of Contents for Konica Minolta 7085/FORCE 85

  • Page 1 Return to Main Form Return to Copier Form SERVICE MANUAL MODELS 7075/FORCE 75 7085/FORCE 85 FEBRUARY 2003 CSM-7075/F75/7085/F85...
  • Page 3 7075/FORCE 75/7085/ FORCE 85 SERVICE MANUAL FEBRUARY 2003...
  • Page 4 IMPORTANT NOTICE Because of the possible hazards to an inexperienced person servicing this equipment, as well as the risk of damage to the equipment, Konica Business Tech- nologies strongly recommends that all servicing be performed by Konica-trained service technicians only. Changes may have been made to this equipment to improve its performance after this service manual was printed.

  • Page 5: Table Of Contents

    7075/FORCE 75 ............. xxix [13] Optics Drive Section ......... 1-17 7075/7085 ............... xxx [14] Web Drive Section ........1-18 7085/FORCE 85 ............. xxxi FORCE 75 OUTLINE OF SYSTEM ......xxxii 2. UNIT EXPLANATION FORCE 85 OUTLINE OF SYSTEM ......xxxiii EXTERNAL SECTION ........
  • Page 6 CONTENTS [5] M23 (Charger Cleaning ) Control ..2-F-4 FIXING UNIT ............2-O-1 [6] M18 (Transfer/Separation Cleaning) [1] Composition ..........2-O-1 Control ............ 2-F-5 [2] Mechanisms ..........2-O-1 [7] PCL/TSL Control ........2-F-6 [3] M16 (Web Drive) ........2-O-4 DEVELOPING UNIT ..........2-G-1 [4] Fixing Temperature Control ....
  • Page 7 CONTENTS PAPER FEED UNITS OF TRAYS 1 AND 2 ..3-J-1 [4] Cleaning the Toner Control Sensor Board ............3-E-3 [1] Removing and Reinstalling Paper Feed [5] Removing, Cleaning and Reinstalling Trays 1 and 2 ........... 3-J-1 the Drum ..........3-E-4 [2] Removing and Reinstalling the Front [6] Removing and Reinstalling the Separation Covers of Trays 1 and 2 ......
  • Page 8 CONTENTS [5] Removing and Reinstalling the Fixing ADU UNIT ............3-N-1 [1] Drawing out and Reinstalling the ADU Upper Roller ......... 3-O-3-1 Stand ............3-N-1 [6] Removing and Reinstalling the Fixing [2] Cleaning the Paper Dust Removing Lower Roller ..........3-O-4 Brush for Registration Roller ....

  • Page 9: Safety And Important Warning Items

    SAFETY AND IMPORTANT WARNING ITEMS SAFETY AND IMPORTANT WARNING ITEMS Read carefully the Safety and Important Warning Items described below to understand them before doing service work. IMPORTANT NOTICE Because of possible hazards to an inexperienced person servicing this copier as well as the risk of damage to the copier, Konica Corporation strongly recommends that all servicing be performed only by Konica-trained service technicians.

  • Page 10: Safety Warnings

    SAFETY AND IMPORTANT WARNING ITEMS SAFETY WARNINGS [1] MODIFICATIONS NOT AUTHORIZED BY KONICA Konica copiers are renowned for their high reliability. This reliability is achieved through high-quality design and a solid service network. Copier design is a highly complicated and delicate process where numerous mechanical, physical, and electrical aspects have to be taken into consideration, with the aim of arriving at proper tolerances and safety factors.
  • Page 11 SAFETY AND IMPORTANT WARNING ITEMS [2] CHECKPOINTS WHEN PERFORMING ON-SITE SERVICE Konica copiers are extensively tested before shipping, to ensure that all applicable safety standards are met, in order to protect the customer and customer engineer (hereafter called the CE) from the risk of injury. However, in daily use, any electrical equipment may be subject to parts wear and eventual failure.
  • Page 12 SAFETY AND IMPORTANT WARNING ITEMS WARNING: Power Plug and Cord • Do not bundle or tie the power cord. Overheating may occur there, leading to a risk of fire. • Check whether dust is collected around the power plug and wall outlet. Using the power plug and wall outlet without removing dust may result in fire.
  • Page 13 SAFETY AND IMPORTANT WARNING ITEMS WARNING: Ground Lead • Pay attention to the point to which the ground lead is connected. Connecting the ground lead to an improper point such as the points listed below results in a risk of explosion and electric shock: a.
  • Page 14 SAFETY AND IMPORTANT WARNING ITEMS CAUTION: Ventilation • The copier generates ozone gas during operation, but it is not sufficient to be harmful to the human body. If a bad smell of ozone is present in the following cases, ventilate the room. a.
  • Page 15 SAFETY AND IMPORTANT WARNING ITEMS DANGER: Work Performed with the Copier Powered • Take every care when servicing with the external cover detached. High-voltage exists around the drum unit. A risk of electric shock exists. WARNING: Safety Checkpoints • Check the exterior and frame for edges, burrs, and other damages. The user or CE may be injured.
  • Page 16 SAFETY AND IMPORTANT WARNING ITEMS WARNING: Safety Checkpoints • After replacing a part to which AC voltage is applied (e.g., optical lamp and fixing lamp), be sure to check the installation state. A risk of fire exists. • Check the interlock switch and actuator for loosening and check whether the interlock functions properly.
  • Page 17 SAFETY AND IMPORTANT WARNING ITEMS DANGER: Handling of Service Materials • Toner and developer are not harmful substances, but care must be taken not to breathe excessive amounts or let the substances come into contact with eyes, etc. It may be stimulative. If the substances get in the eye, rinse with plenty of water immediately.

  • Page 18: Safety Information

    SAFETY AND IMPORTANT WARNING ITEMS SAFETY INFORMATION SAFETY INFORMATION IMPORTANT INFORMATION The Center for Devices and Radiological Health (CDRH) of the U.S. Food and Drug Administration implemented regulations for laser products manufactured since August 1, 1976. Compliance is mandatory for products marketed in the United States.

  • Page 19: Safety Circuits

    SAFETY AND IMPORTANT WARNING ITEMS SAFETY CIRCUITS [2] Protection by L2, L3, and L4 (fixing This machine is provided with the following safety circuits to prevent machine faults from resulting in heaters) overheating prevention serious accidents. circuit [1] Overall protection circuit [2] L2, L3, and L4 (fixing heater lamps) overheating prevention circuit These safety circuits are described below to provide...
  • Page 20 SAFETY AND IMPORTANT WARNING ITEMS Protection by the hardware circuit The output voltages from TH1 and TH2 (fixing temperature sensor 2), TH3 (fixing temperature sensor 3), and TH4 (fixing temperature sensor 4) are compared with the abnormality judgement reference value in the comparator circuit. If the output voltage from TH1, TH2, TH3, or TH4 exceeds the reference value, L2, L3, L4, and RL1 are turned off in hardware means.

  • Page 21: Indication Of Warning On The Machine

    SAFETY AND IMPORTANT WARNING ITEMS SAFETY INFORMATION INDICATION OF WARNING ON THE MACHINE Caution labels shown below are attached in some areas on/in the machine areas. When accessing these areas for maintenance, repair, or adjustment, special care should be taken to avoid burns and shock hazards.
  • Page 22 SAFETY AND IMPORTANT WARNING ITEMS Unplug the machine before removing platen glass. WARNING <Read Section> Debrancher le copieur avant de retirer la vitre d'exposition. DANGER Vor Entfernen des Vorlagenglases Netzstecker ziehen. WARNUNG Desenchufe la maquina antes de quitar el vidrio. ADVERTENCIA Estrarre la spina dalla presa prima di rimuovere il vetro di esposizione.
  • Page 23 SAFETY AND IMPORTANT WARNING ITEMS <Tray 1> <Tray 2> CAUTION CAUTION DO NOT put your hand between the main body and tray; otherwise you may be injured. <Tray 3> <FS-108BM/211 only> CAUTION ATTENTION PRECAUCION CUIDADO CAUTION CAUTION ATTENTION VORSICHT Use care after opening the PRECAUCION ATTENZIONE paper exit outlet.
  • Page 24 SAFETY AND IMPORTANT WARNING ITEMS CAUTION WARNING WARNING Unplug the machine before removing panels. Débrancher l’appareil avant de retirer les panneaux arrières. Desenchufe la máquina antes de quitar los paneles. Desconecte a unidade da tomada antes de remover os painéis. Unplug the machine before removing panels.
  • Page 25 SAFETY AND IMPORTANT WARNING ITEMS WARNING Unplug the machine before removing panels. Débrancher l’appareil avant de retirer les panneaux arrières. Desenchufe la máquina antes de quitar los paneles. Desconecte a unidade da tomada antes de remover os painéis. Unplug the machine before removing panels.

  • Page 26: System Configurators

    SYSTEM CONFIGURATORS SYSTEM CONFIGURATORS 7075 Copier/Printer System Configurator Machine and Accessories Item Description Item Number 7075 Copier (w/RADF DF-313) 950635 Finisher (FS-108) 950656 Key Counter Finisher (FS-108B) 950636 Service Parts Post Insert (PPI-108) (Cover Feeder)*** 950639 Type Item No Receptacle Holder Trimmer Unit (TU-108)*** 950647...
  • Page 27 SYSTEM CONFIGURATORS FORCE 75 Printer System Configurator Machine and Accessories Item Description Item Number Key Counter FORCE 75 Printer 950643 Service Parts Finisher (FS-108)*** 950656 Type Item No Receptacle Holder Finisher (FS-108B)*** 950636 Standard 944907 Part Number Part Number Post Inserter (PI-108)**** 950639 U021-0020 6011969...
  • Page 28 SYSTEM CONFIGURATORS 7085 Copier/Printer System Configurator Machine and Accessories Item Description Item Number 7085 Copier w/RADF (DF-317) 950950 Finisher (FS-111)(Stapling) 950955 Key Counter Finisher (FS-211)(Booklet & Folding) 950956 Service Parts Post Process Insert (PPI-108) 950639 Type Item No Receptacle Holder Punch Unit (PU-108) 950957 Standard...
  • Page 29 SYSTEM CONFIGURATORS FORCE 85 Printer System Configurator Machine and Accessories Item Description Item Number Force 85 Printer 950960 Finisher (FS-111)(Stapling) 950955 Key Counter Finisher (FS-211)(Booklet & Folding) 950956 Service Parts Post Process Insert (PPI-108) * 950639 Standard Receptacle Wire Adapter Punch Unit (PU-108M) 950957 Part No...

  • Page 30: Force 75

    LIST OF DIFFERENCES LIST OF DIFFERENCES 7075/FORCE 75 Classification 7075 FORCE 75 Reason for change Specifications 1.E-RDH memory capacity · Specification change Standard : 64MB Standard : 128MB Maximum : 512MB Maximum : 512MB 2. Options · Specification change VIkit : VI-601(option) (Standard) 3.Weight ·...
  • Page 31 LIST OF DIFFERENCES 7075/7085 Reason of 7085 Classification 7075 changing First copy out time Less than 3.9 seconds Less than 3.3 seconds Specification (A4/8.5x11) change Continuous copy speed 75 copies 85 copies (A4/8.5x11) Magnification ratio x0.33~x4.00(400dpi) x0.25~x4.00(600dpi) x0.33~x2.00(600dpi) E-RDH memories Standard: 64MB Standard: 128MB Maximum: 512MB...

  • Page 32: 7085/Force 85

    LIST OF DIFFERENCES 7085/FORCE 85 Classification 7085 DP85 Reason for change Specifications 1.E-RDH memory capacity · Specification change Standard : 128MB Standard : 256MB Maximum : 512MB Maximum : 512MB 2. Options · Specification change VIkit : VI-602(option) (Standard) 3.Weight ·...

  • Page 33: Force 75 Outline Of System

    OUTLINE OF SYSTEM FORCE 75 PRODUCT SPECIFICATIONS FORCE 75 OUTLINE OF SYSTEM Expansion memory unit [MU-401/402] Paper exit tray LCT [LT-401] Finisher [FS-108] Post Inserter [PI-108] Trimmer Finisher [TU-108] [FS-108BM] LCT [LT-411] Network board [KN-302] Printer Controller [IP-601] Postscript 3 [PS-361] xxxi...

  • Page 34: Force 85 Outline Of System

    OUTLINE OF SYSTEM FORCE 85 OUTLINE OF SYSTEM Expansion memory unit [MU-401/402] Paper exit tray [LT-402] Puncher Finisher [PU-108] [FS-111] Post Inserter [PI-108] Puncher with Finisher z-folding [FS-211] [PZ-108] [LT-412] Network board [KN-306] Printer Controller [IP-602] Postscript 3 Trimmer [PS-362] [TU-108] xxxii...

  • Page 35: Force 75 Product Specifications

    PRODUCT SPECIFICATIONS FORCE 75 PRODUCT SPECIFICATIONS [1] Type Print setting guantity: 1 to 9999 Installation Type: E-RDH memory capacity: Console type (floor-mounted type) standard 128MB Print method: maximum 512MB Indirect electrostatic method Special functions: Photosensitive material: Interleaves, chapter, combination (2 in 1, 4 in 1, 8 in 1), booklet, OHP Sensitizing method: interleave, auto tray function, duplex...
  • Page 36 PRODUCT SPECIFICATIONS [5] Particulars of Machine Power supply: 230 VAC -14% to 10.6% 50 Hz/60 Hz Power consumption: 3450W max. (Full option) Weight: Approx. 573 lbs. Machine dimensions (inches): 35(W) x 30.5(D) x 39(H) [6] Maintenance Periodic maintenance: Every 250,000 prints [7] Consumables Developer: Common with Konica 7075 Toner :...

  • Page 37: Force 85 Product Specifications

    PRODUCT SPECIFICATIONS FORCE 85 PRODUCT SPECIFICATIONS Type Continuous print speed (life size, prints/min): Installation Type: Size Console type (floor-mounted type) Copying method: A4/8.5x11 Indirect electrostatic method E-RDH memory capacity: Document tray type: Standard 256MB Fixed Maximum 512MB Photosensitive material: [3] Applicable Print Paper Sensitizing method: Plain paper: Laser writing...
  • Page 38 PRODUCT SPECIFICATIONS [5] Particulars of Machine Power supply: 230 VAC -14% to 10.6% 50 Hz 208~240 VAC 60Hz Power consumption: 230 V Machine : 3450 W max. (Full option) 208~240 V Machine : 3840 W max. (Full option) Weight: Approx. 250 kg Machine dimensions: 887 (W) x 775 (D) x 990 (H) [6] Maintenance...

  • Page 39: Outline

    OUTLINE...
  • Page 40 Blank page.

  • Page 41: Outline Of System

    MAIN BODY OUTLINE OF SYSTEM Hard disk [7075: HD-102] [7085: Standard] Expansion memory unit VI kit [MU-401/402] [7075:VI-601] [7085:VI-602] Paper exit tray Finisher [7075:LT-401] [7075:FS-108] [7085:LT-402] Puncher [7085:FS-111] [PU-108] Post Inserter [PI-108] Puncher with z-folding Finisher [PZ-108] [7075:FS-108BM] [7085:FS-211] Network board [7075:LT-411] [7075:KN-302 (for IP-601)] [7085:LT-412]...

  • Page 42: 7075/7085 Product Specifications

    7075/7085 PRODUCT SPECIFICATIONS 7075/7085 PRODUCT SPECIFICATIONS Type Zoom magnifications: 7075 Installation Type: Console type (floor-mounted type) x0.33 to x4.00 (400 dpi, in 1% steps) Copying method: x0.33 to x2.00 (600 dpi, in 1% steps) Indirect electrostatic method 7085 Document tray type: x0.25 to x4.00 (600 dpi, in 1% steps) Fixed Vertical magnifications:...
  • Page 43 MAIN BODY [3] Applicable Copy Paper Particulars of Machine Plain paper: Power supply: High quality paper 60 g/m or 17 lbs 230 VAC -14% to 10.6% to 90 g/m or 24 lbs 50 Hz/60 Hz Special paper: 208~240 VAC 60Hz High quality paper 50 g/m or 13 lbs Power consumption:...

  • Page 44: Center Cross-Sectional View

    MAIN BODY CENTER CROSS-SECTIONAL VIEW Charging corona RADF Cleaning section Image processing section section Image read section Exposure lamp Image write section Fixing Developing section section Second paper feed section Paper exit By-pass tray section Transfer corona Paper reverse/ section exit section Vertical conveyance section...

  • Page 45: Drive System Diagram

    MAIN BODY DRIVE SYSTEM DIAGRAM [1] Main Drive Section FRONT Fixing unit upper roller Fixing unit Heating roller To paper conveyance and transfer/separation corona cleaning section Main motor (M1) Fixing unit lower roller 1 - 5...

  • Page 46: Drum Drive Section

    MAIN BODY [2] Drum Drive Section FRONT Drum Toner guide brush Drum motor (M2) Toner guide shaft Toner conveyance screws Separation claw unit Separation claw solenoid (SD4) Separation claw swing cam 1 - 6...

  • Page 47: Developing Drive Section

    MAIN BODY [3] Developing Drive Section FRONT Agitator screw Agitator wheel Developing sleeve Developing motor (M3) 1 - 7...

  • Page 48: Paper Feed Drive Section

    MAIN BODY [4] Paper Feed Drive Section FRONT To tray 1 paper feed/ tray up drive section To tray 2 paper feed/ tray up drive section To tray 3 paper feed/ tray up drive section Paper feed motor (M4) 1 - 8...

  • Page 49: Tray 1 And 2 Paper Feed Drive Section

    MAIN BODY [5] Tray 1 and 2 Paper Feed Drive Section Tray up motor 1/2 (M19/M20) FRONT Feed roller Pre-feed registration roller Pre-registration MC1/2 (MC4/MC6) Paper feed roller Double feed prevention roller Feed MC1/2 (MC3/MC5) From paper feed drive section 1 - 9...

  • Page 50: Tray 3 Paper Feed Drive Section

    MAIN BODY [6] Tray 3 Paper Feed Drive Section Feed roller FRONT Pre-feed registration roller Pre-registration MC3 (MC8) Tray up motor 3 (M21) Paper feed roller Double feed prevention roller From paper feed drive section Feed MC3 (MC7) 1 - 10...

  • Page 51: Vertical Conveyance Drive Section

    MAIN BODY [7] Vertical Conveyance Drive Section FRONT Vertical conveyance From bypass roller (Upper) paper feed drive section Vertical conveyance From paper roller (Middle) feed drive section Vertical conveyance From paper Vertical roller (Lower) feed drive conveyance section MC1 (MC9) Vertical conveyance MC2 (MC10)

  • Page 52: By-Pass Paper Feed Drive Section

    MAIN BODY [8] By-pass Paper Feed Drive Section Tray up/down motor (by-pass tray: M22) FRONT Paper feed roller Feed roller To ADU conveyance drive section To vertical conveyance Loop roller motor (M6) 1 - 12...

  • Page 53: Conveyance/Transfer And Separation Wire Cleaning Drive Section

    MAIN BODY [9] Conveyance/Transfer and Separation Wire Cleaning Drive Section FRONT Transfer/separation cleaning motor (M18) Thick paper conveyance rollers Conveyance belts From main drive section 1 - 13...

  • Page 54: Adu Conveyance Drive Section

    MAIN BODY [10] ADU Conveyance Drive Section Registration MC (MC1) Registration motor Loop roller (M12) Registration roller ADU pre-registration MC (MC2) Transfer motor (M9) ADU exit roller ADU conveyance motor (M8) FRONT ADU reverse roller ADU reverse motor (M7) Paper reverse/exit motor (M5) From by-pass paper feed...

  • Page 55: Paper Exit Drive Section

    MAIN BODY [11] Paper Exit Drive Section FRONT Paper exit motor (M10) Paper exit roller 1 - 15...

  • Page 56: Toner Supply Drive

    MAIN BODY [12] Toner Supply Drive Toner supply motor 2 (M15) FRONT Toner supply motor 1 (M11) Toner cartridge 1 - 16...

  • Page 57: Optics Drive Section

    MAIN BODY [13] Optics Drive Section First mirror Slit-glass Scanner drive motor (M13) Second mirror Third mirror Optics wire (Rear) FRONT Optics wire (Front) 1 - 17...

  • Page 58: Web Drive Section

    MAIN BODY [14] Web Drive Section Web drive motor (M16) FRONT Cleaning web 1 - 18...

  • Page 59: Unit Explanation

    UNIT EXPLANATION...
  • Page 60 Blank page.

  • Page 61: External Section

    EXTERNAL SECTION EXTERNAL SECTION [1] Composition Right side cover (upper) RADF Main switch Operation panel Front right door Cooling Bypass tray cover Tray 1 Tray 2 Optional cover Tray 3 Left side cover Rear cover Right side cover (middle) Left front door Right side cover Vertical (lower)
  • Page 62 EXTERNAL SECTION Blank page 2 - A - 2...

  • Page 63: Drive Section

    DRIVE SECTION DRIVE SECTION [1] Composition Drum motor (M2) Main motor (M1) Developing motor (M3) Paper exit motor (M10) Loop roller motor (M6) Paper feed motor (M4) [2] Mechanisms Mechanism Driven Parts Method *1 Drum drive Drum, clearer fur brush Gear drive (dedicated motor) *1 Developing drive Developing sleeve...

  • Page 64: M1 (Main) Control

    DRIVE SECTION [3] M1 (Main) Control [4] M2 (Drum) Control 24VDC 24VDC PGND PGND DCPS2 DCPS2 M2CONT M1 CONT M1 EM M2 F/R SGND (7085 only)CLK M2 EN PRCB PRCB M1 (main) is controlled by the PRCB (printer control M2 (drum) is controlled by the PRCB (printer control board) and the motor drive power is supplied from board) and the motor drive power is supplied from DCPS2 (DC power supply unit 2).

  • Page 65: Read Section

    READ SECTION READ SECTION [1] Composition Scanner drive wire Exposure unit Optics rail (R) V-mirror unit (2nd and 3rd mirrors) Slit glass CCD unit Scanner cooling fan (FM7) A/D converter board [2] Mechanisms Mechanism Method Light source Xenon lamp Exposure Light source shift slit exposure, static exposure Scanning Platen original scanning: 1st, 2nd, and 3rd mirrors are shifted.

  • Page 66: M13 (Scanner Drive) Control

    READ SECTION [3] M13 (Scanner Drive) Control M13 CLK M13 DRIVE U M13 F/R M13 DRIVE V M13 CSEL M13 DRIVE W M13 V0 M13 V1 M13 V2 5VDC SGND 5VDC SGND 7075 only 24VDC PGND DCPS2 5VDC SGND PRCB SCDB DCPS1 M13 (scanner drive) is driven by the SCDB (scanner...
  • Page 67 READ SECTION Exposure unit home position search For 7085 If the exposure unit is not at the home position L1 is turned ON, when black correction has been when the main switch is turned ON or when the completed after the home position search START PRINT button is pressed, the home operation, thus reading the light reflected by the position is searched for in the following manner:...
  • Page 68 READ SECTION Platen copy operation (3) PS6 (PS6 to SCDB to PRCB) For 7075 Original home position detection signal. In the platen mode, the reference position for the original's leading edge is detected. Scanner [L]: The exposure unit is detected. Scanner HP return Original HP...
  • Page 69 READ SECTION Blank page MODEL MANUAL REVISED EDITION DATE PAGE METHOD 2 - C - 5 2 - C -3 - 2 7075/7085 SERVICE HANDBOOK Jan. 2002 2-C-3-2 ADDITION...

  • Page 70: Exposure Control

    READ SECTION [4] Exposure control 24VDC L1 CONT L1 CONT L1 INVB 24VDC PGND PRCB SCDB DCPS2 L1 (exposure lamp) is driven by the L1 INVB (L1 inverter) and is controlled by the PRCB (printer control board) via the SCDB (scanner drive board). Operation L1 is a xenon lamp driven by the inverter circuit.

  • Page 71: Original Read Control

    READ SECTION [5] Original Read Control [6] APS Control 5VDC PS62 PS62 SGND PS63 PS63 PS64 PS64 PS65 PS65 PS66 PS66 PS67 PS67 PS68 PS68 5VDC SGND ICB IFB PRCB ICB IFB DCPS1 The APS method used in the platen mode is different Original read control is performed by the ADB (A/D from that used in the DF mode.
  • Page 72 READ SECTION (2) Platen mode APS detection timing The paper size is detected according to the com- The APS detection timing differs between the bination of ON/OFF states of PS62 (APS 1), platen mode and DF mode. PS63 (APS 2), PS64 (APS 3), PS65 (APS 4), (1) DF mode PS66 (APS 5), PS67 (APS 6), and PS68 (APS When the DF mode is selected or original is set...

  • Page 73: Ae Control

    READ SECTION [7] AE Control (3) DF mode The image at the leading edge of the original is read when the START button is pressed. The read data is used to measure the image density on the original. <AE sampling area> (1) Main scanning direction •...
  • Page 74 READ SECTION Blank page MODEL MANUAL REVISED EDITION DATE PAGE METHOD 2 - C - 10 7075/7085 SERVICE HANDBOOK Jan. 2002 2-C-8 REPLACEMENT...

  • Page 75: Write Unit

    WRITE UNIT WRITE UNIT [1] Composition Cylindrical lens 1 Polygon mirror Index sensor board Cylindrical lens 2 3rd mirror (7085 only) Laser driver board LD2 2nd mirror Collimator lens unit 2 fθ lens 1 fθ lens 2 Beam combining prism Collimator lens unit 1 Laser driver board LD1 [2] Mechanisms...

  • Page 76: M17 (Polygon ) Control

    WRITE UNIT [3] M17 (Polygon ) Control *2 Positioning Each laser beam is positioned by the compres- sion prism and fine adjustment prism. *3 Laser beam combining M17 EM SGND M17 CLK 24VDC Two laser beams output at right angle to each M17 CONT M17 MAG A' other are redirected in the same direction using...
  • Page 77 WRITE UNIT PRCB output signals (1) M17 CONT (PRCB to PMDB) This signal turns ON/OFF M17. [L]: M17 ON [H]: M17 OFF (2) M17 CLK (PRCB to PMDB) This is a reference clock signal for PLL-control- ling M17 in PMDB. c.

  • Page 78: Image Write Control

    WRITE UNIT [4] Image Write Control M24 PWR A M24 PWR B M24 DRIVE A M24 DRIVE A' M24 DRIVE B M24 DRIVE B' 5VDC SGND M INDEX 1 SGND M INDEX 2 SGND S INDEX1 SGND S INDEX 2 SGND HL VL SGND...
  • Page 79 WRITE UNIT Operation (2) APC (Auto Power Control) Image processing The ICB outputs an APC start instruction to the The following processing is performed by the ICB LDB1 and LDB2 at the following timing, after MPC (image control board): is set. (1) AOC (Auto Offset Control) <APC timing>...
  • Page 80 WRITE UNIT 2. Signals (9) LD1 VIDEO (ICB IFB to LDB1) a. ICB IFB input signals LD1 laser image signal. (1) M INDEX 1, 2 (INDEXSB to ICB IFB) (10) LD2 VIDEO (ICB IFB to LDB2) This is an index signal used to detect deviation LD2 laser image signal.

  • Page 81: Drum Unit

    DRUM UNIT DRUM UNIT [1] Composition Charging corona unit Developing unit Separation claws Cleaning/toner recycle unit Separation claw solenoid (SD4) Charging corona unit <7075> <7085> Charging corona unit Developing unit Developing unit Cleaning/toner Cleaning/toner recycle unit recycle unit Transfer and separation Transfer and separation corona unit corona unit...

  • Page 82: Separation Claw Control

    DRUM UNIT [3] Separation Claw Control [4] Paper Guide Plate Control 24VDC SD4 DRIVE GP CONT DCDB For 7075 SD4 CONT PRCB ADUSDB 24VDC SD4 DRIVE For 7085 24VDC PGND M2CONT M2EM DCPS2 PRCB MS2 MS1 24VDC 24VDC PGND PGND DCPS2 The separation claw is driven by SD4 (separation To prevent toner from adhering to the paper guide plate,...

  • Page 83: Drum Potential Control

    DRUM UNIT [5] Drum Potential Control Signals PRCB Input signals (1) DPS ANG (DPSB to PRCB) Analog signal corresponding to the drum charg- DPS DRIVE A DPS DRIVE B ing potential. DPS ANG 1 DPSB Input signals DPS ANG 2 DPS ANG (1) DPS ANG 1 and 2(DPS to DPSB) SGND...

  • Page 84: Htr1 (Drum Heater) Control (7075 Only) 2

    DRUM UNIT [6] HTR1 (drum heater) Control (7075 only) 12VDC 5VDC TH5 ANG1 DRUM TEMP AGND TH5 ANG2 12VDC DTSB 5VDC SGND HTR1 CONT DCPS1 PRCB AC(H) AC(C) HTR1 HTR1 CONT HTR1 DRIVE ACDB Signals The drum is heated by HTR1 (drum heater). The PRCB (printer control board) detects the drum temperature PRCB input signal with TH5 (drum temperature sensor) and controls...

  • Page 85: Corona Unit Section

    CORONA UNIT SECTION CORONA UNIT SECTION [1] Composition <Charging corona unit> <Transfer and separation corona unit> Transfer entrance guide plate Charging corona wires Guide rollers Transfer corona unit Plunging prevention plate Charging wire cleaning Charging motor (M23) wire cleaning Separation corona unit material *2 Cleaning the transfer and separation wires [2] Mechanisms...

  • Page 86: Charging Control

    CORONA UNIT SECTION [3] Charging Control Signals Input signal (1) C SIG (HV1 to PRCB) Leak or short detection signal. C CONT1 [L]: Normal C CONT2 C SHIFT [H]: Abnormal SGND C SIG Output signals CHARGING (1) C CONT1, 2 (PRCB to HV1) G SHIFT Charging 1/2 output ON/OF control signal.

  • Page 87: Transfer/Separation Control

    CORONA UNIT SECTION [4] Transfer/Separation Control PRCB output signals (1) T SHIFT (PRCB to HV2) Transfer corona unit output level control signal. 24VDC This signal controls the level of the output to the PGND transfer corona unit according to the duty ratio of DCPS2 SEPARATION the pulse (PWM) signal sent from the PRCB.

  • Page 88: M23 (Charger Cleaning ) Control

    CORONA UNIT SECTION [5] M23 (Charger Cleaning ) Control ADUSDB output signals (1) T CONT (ADUSDB to HV2) Transfer corona unit output ON/OFF control sig- nal. [L]: Transfer corona unit ON M23 CONT DRIVE1 5VDC [H]: Transfer corona unit OFF PS41 PS41 SGND...

  • Page 89: M18 (Transfer/Separation Cleaning) Control

    CORONA UNIT SECTION Signals [6] M18 (Transfer/Separation Cleaning) Input signals Control (1) M23 EM (DCDB to PRCB: 7075 only) M23 rotation state detection signal. [L]: Normal rotation. [H]: Abnormal rotation DRIVE1 (2) PS41 (PS41 to PRCB) DRIVE2 Charging wire cleaning pad home position de- tection signal.

  • Page 90: Pcl/Tsl Control

    CORONA UNIT SECTION [7] PCL/TSL Control Cleaning operation The home position of the transfer and separa- tion wire cleaning pads is on the front side of machine. The transfer and separation wire clean- ing pads operate as follows: 24VDC 24VDC PGND PCL CONT Tansfer/Separation wire...

  • Page 91: Developing Unit

    DEVELOPING UNIT DEVELOPING UNIT [1] Composition Developing unit cover Developing regulation plate Developing sleeve Agitator Developing sleeve wheel Splash prevention Agitator screws sheet (upper) [2] Mechanisms Drum Mechanism Method Developing regulation plate Developing 2-component developer Developing bias DC bias Developer Main agitator agitation Auxiliary agitator...

  • Page 92: M3 (Developing Unit Drive) Control

    DEVELOPING UNIT [4] Developing Bias Control [3] M3 (Developing Unit Drive) Control BIAS 24VDC 5VDC SGND B CONT 24VDC B SHIFT PGND B FB DCPS2 PRCB M3 CONT 5VDC M3 CLK SGND M3 EM DCPS1 PRCB 24VDC MS2 MS1 24VDC PGND DCPS2 M3 (developing) is controlled by the PRCB (printer...

  • Page 93: Toner Density Control

    DEVELOPING UNIT [5] Toner Density Control Signals Input signal (1) M11 FEM (DCDB to PRCB: 7075 only) Signal detecting whether the fuse for M11 is blown. 24VDC [L]: Not detected PGND [H]: Detected DCPS2 Output signals (1) M11 CLK (PRCB to DCDB: 7075 only) 24VDC 24VDC Reference clock signal for M11 rotational speed...

  • Page 94: Dmax Control

    DEVELOPING UNIT [6] Dmax Control 24VDC 24VDC PGND M2 CONT DCPS2 M2 F/R SGND M2 EM 12VDC 5VDC SGND M3 CONT M3 CLK DCPS1 M3 EM DPS DRIVE A DPS DRIVE B DPS ANG 1 DPS ANG DPS ANG 2 AGND DPSB 12VDC...
  • Page 95 DEVELOPING UNIT Signals PRCB input signals (1) Dmax SIG (TCSB to PRCB) Output voltage of the Dmax value detection sensor (PD1) on the TCSB. Reference voltage: 2.5V (2) Dmax MONI (TCSB to PRCB) This signal monitors the light reflected by the drum surface (without toner).

  • Page 96: Gradation Correction Control

    DEVELOPING UNIT [7] Gradation Correction Control 24VDC 24VDC PGND M2 CONT DCPS2 M2 F/R SGND M2 EM 12VDC 5VDC SGND M3 CONT M3 CLK DCPS1 M3 EM DPS DRIVE A DPS DRIVE B DPS ANG 1 DPS ANG DPS ANG 2 AGND DPSB 5VDC...

  • Page 97: Dot Diameter Correction Control

    DEVELOPING UNIT [8] Dot Diameter Correction Control PRCB Output signals (1) γ LED CONT, γ CONT(PRCB to TCSB) ON/OFF control signal for gradation detection LED. [L]: LED ON [H]: LED OFF (2) γ /Dmax LED Vref, Vref (PRCB to TCSB) Power supply line to the γ...

  • Page 98: Fm2 (Developing Suction) Control

    DEVELOPING UNIT [9] FM2 (Developing Suction) Control For 7085 FM2 CONT FM2 DRIVE For 7075 FM2 EM FM2 EM PGND FM2 FEM PRCB 24VDC PGND DCPS2 ACDB FM2 (Developing suction) is controlled by the PRCB Signals (printer control board) via the ACDB (AC drive board). PRCB input signals When the front right or left door of this machine opens (1) FM2 EM (FM2 to ACDB to PRCB: 7075)

  • Page 99: Toner Supply Unit

    TONER SUPPLY UNIT TONER SUPPLY UNIT [1] Composition Toner cartridge Toner supply motor 1 (M11) Push pressure lever Shutter Toner supply motor 2 (M15) [2] Mechanisms The agitator plates prevent the toner from clumping and accumulating on TLD (remaining toner detection Mechanism Method sensor).

  • Page 100: Toner Level Detection Control

    TONER SUPPLY UNIT [3] Toner Level Detection Control Toner cartridge When the toner cartridge rotates, toner is fed to the outlet of the cartridge through the spiral 24VDC groove on the surface of the toner cartridge. PGND When the outlet of the cartridge faces downward, DCPS2 toner flows out of the outlet into the agitation/ supply section of the toner supply unit.
  • Page 101 TONER SUPPLY UNIT Signals a. Input signal (1) TLD (TLD to PRCB) When the level of toner in the cartridge becomes low, this signal goes low [L], displaying a message on the LCD connected to the OB1. (2) M15 EM (M15 to PRCB) M15 fault detection signal.

  • Page 102: M11 (Toner Supply 1) Control

    TONER SUPPLY UNIT [4] M11 (Toner Supply 1) Control Paper size Supply time (sec.) A3 (11 x 17) 1.14 B4 (8.5 x 14) 0.86 0.86 24VDC PGND A4 (8.5 x 11) 0.57 DCPS2 A4R (8.5 x 11R) 0.57 0.43 5VDC 0.43 /Dmax LED Vref TCSB...

  • Page 103: Cleaning/Toner Recycle Unit

    CLEANING/TONER RECYCLE UNIT CLEANING/TONER RECYCLE UNIT [1] Composition Blade drive motor (M14) Blade 2 Blade 1 Toner guide shaft Toner guide brush Toner conveyance screw Vibration sheet [2] Mechanisms Mechanism Method *1 Drum cleaning Cleaning blades (switched automatically) Toner collection Toner guide brush *2 Toner recycle Toner conveyance by...

  • Page 104: M14 (Blade) Control

    CLEANING/TONER RECYCLE UNIT [3] M14 (Blade) Control 5VDC PS30 PS30 SGND PS31 PS31 M14 DRIVE 1 M14 DRIVE 1 M14 PL M14 DRIVE 2 M14 DRIVE 2 M14 NL M14 PR M14 NR M14 CEM M14 24FEM DCDB For 7085 5VDC SGND DCPS1...
  • Page 105 CLEANING/TONER RECYCLE UNIT Blade auto switching control This unit uses two blades with M14 rotating to automatically replace blades. During automatic blade replacement, M2 (drum), M3 (developing), developing bias, guide plate voltage, and PCL are turned ON, toner is adhered to the drum, and then the blade cleans it to prevent blade peeling.
  • Page 106 CLEANING/TONER RECYCLE UNIT Blank page MODEL MANUAL REVISED EDITION DATE PAGE METHOD 2 - I - 4 7075/7085 SERVICE HANDBOOK Jan. 2002 2-I-4 REPLACEMENT...

  • Page 107: Tray 1/2 Paper Feed Unit

    TRAY 1/2 PAPER FEED UNIT TRAY 1/2 PAPER FEED UNIT [1] Composition Feed roller Side guides Paper feed roller Double feed prevention roller Trailing edge stopper Drive pulley Wire A Wire B Paper size detection VR1,2 Up drive motor1(M19), 2(M20) Paper size detection PS1-1, 2-1(PS32, PS33) Paper size detection PS1-2, 2-2(PS35, PS36) Caution: Trays 1 and 2 have the same shape...
  • Page 108 TRAY 1/2 PAPER FEED UNIT b. Lowering of up/down plate *3 Paper size detection When the paper feed tray is pulled out, the Length: The rear guide of the tray moves, caus- guide lever shown below is disengaged from ing the paper size detection actuator to the rail, thus releasing the coupling gear that move as well.

  • Page 109: First Paper Feed Control

    TRAY 1/2 PAPER FEED UNIT [3] First Paper Feed Control 24VDC M4 CONT PGND M4 EM DCPS2 M4 CLK For 7085 M4 F/R 5VDC SGND 5VDC DCPS1 PS47 PS47 PS SGND PS48 PS48 PS 5VDC PS49 PS49 PS SGND PS50 PS50 PS 24VDC 24VDC...
  • Page 110 TRAY 1/2 PAPER FEED UNIT b. Feed timing (pre-registration drive) PRCB output signals (1) ON timing (1) MC3 CONT (PRCB to DCDB to MC3: 7075) For 7075 (PRCB to MC3: 7085) When a drive signal is received from PRCB. MC3 drive control signal (tray 1). For 7085 [L]: MC3 ON First sheet: When a preset time interval has...

  • Page 111: Paper Up Drive Control

    TRAY 1/2 PAPER FEED UNIT [4] Paper Up Drive Control 5VDC 5VDC SGND PS14 PS14 DCPS1 SGND PS20 PS20 24VDC 24VDC PGND PGND DCPS2 PS34 PS34 5VDC PS15 PS15 SGND M19 CONT 24VDC M19 EM M19 CONT PS21 M19 FEM PS21 SD5 CONT 24VDC...
  • Page 112 TRAY 1/2 PAPER FEED UNIT Remaining Paper Detection Control (7) M19 EM (DCDB to PRCB: 7075 only) The level of paper remaining in each tray is de- M19 fault (excessive current) detection signal tected according to the time that M19 or M20 (tray 1).

  • Page 113: Paper Size Detection Control

    TRAY 1/2 PAPER FEED UNIT [5] Paper Size Detection Control Signals Input signals (1) PS32 (PS32 to PRCB) Paper size detection switch ON/OFF signal (tray 5VDC PS32 PS32 SGND (2) PS33 (PS33 to PRCB) Paper size detection switch ON/OFF signal (tray PS33 PS33 (3) PS35 (PS35 to PRCB)

  • Page 114: No Paper Detection Control

    TRAY 1/2 PAPER FEED UNIT [6] No Paper Detection Control 5VDC PS26 PS26 SGND 5VDC PS27 PS27 SGND 5VDC SGND PRCB DCPS1 No paper in the tray is detected by PS26 (no paper 1) and PS27 (no paper 2) which are controlled by the PRCB (printer control board).

  • Page 115: Tray 3 Paper Feed Unit

    TRAY 3 PAPER FEED UNIT TRAY 3 PAPER FEED UNIT [1] Composition Paper feed roller Feed roller Side guide Double feed prevention roller Trailing edge stopper Drive pulley Front cover Wire A Paper size detection PS1-3(PS38), 2-3(PS39) Wire B Paper size detection VR3 Up drive motor 3 (M21) [2] Mechanisms...
  • Page 116 TRAY 3 PAPER FEED UNIT b. Lowering of up/down plate *3 Paper size detection When the paper feed tray is pulled out, the guide Length: The rear guide of the tray moves, caus- lever shown below is disengaged from the rail, ing the paper size detection actuator to move as thus releasing the coupling gear that transmits well.

  • Page 117: First Paper Feed Control

    TRAY 3 PAPER FEED UNIT [3] First Paper Feed Control 24VDC 24VDC PGND PGND DCPS2 M4 CONT M4 EM M4 CLK For 7085 5VDC M4 F/R SGND DCPS1 5VDC PS51 PS51 SGND MC3 CONT 24VDC PS52 MC7 CONT PS52 MC4 CONT SD8 CONT 24VDC MC8 CONT...

  • Page 118: Paper Up Drive Control

    TRAY 3 PAPER FEED UNIT [4] Paper Up Drive Control Remaining Paper Detection The level of paper remaining in the tray is de- tected according to the time that M21 requires to 5VDC 5VDC lift up the paper up/down plate when the tray is SGND PS16 PS16...

  • Page 119: Paper Size Detection Control

    TRAY 3 PAPER FEED UNIT [5] Paper Size Detection Control [6] No Paper Detection Control 5VDC PS38 PS38 SGND 5VDC PS28 PS28 SGND PS39 PS39 5VDC SGND PRCB DCPS1 5VDC SGND PRCB DCPS1 The paper size in tray 3 is detected using PS38 (paper No paper in the tray is detected by PS28 (no paper 3) size 1-3), PS39 (paper size 2-3) and paper size which is controlled by the PRCB (printer control board).
  • Page 120 TRAY 3 PAPER FEED UNIT Blank page 2 - K - 6...

  • Page 121: By-Pass Tray

    BY-PASS TRAY BY-PASS TRAY [1] Composition By-pass feed roller By-pass paper feed roller By-pass feed tray By-pass double feed prevention roller [2] Mechanisms Mechanism Method *1 First paper feed Swivel roller Pick up solenoid (SD11) Pick up solenoid (SD11) *2 Paper lift-up Paper up/down plate Paper feed swivel plate Up/down motor...

  • Page 122: First Paper Feed Control

    BY-PASS TRAY [3] First Paper Feed Control Paper up/down plate Up/down motor (by-pass) (M22) 24VDC SD11 SD11 CONT 24VDC 24VDC M6 DRIVE A M6 DRIVE A M6 DRIVE B For 7085 M6 DRIVE B MS2 MS1 24VDC 24VDC PGND PGND DCPS2 24VDC SD11...

  • Page 123: Paper Up/Down Control

    BY-PASS TRAY [4] Paper Up/down Control (4) M6 VREF (PRCB to DCDB: 7075 only) M6 current limitation signal (L: ON). (5) M6 F/R (PRCB to DCDB: 7075 only) M6 rotational direction switching signal (L: CW 5VDC 5VDC (bypass)) SGND PS23 PS23 SGND DCPS1...

  • Page 124: Paper Size Detection Control

    BY-PASS TRAY Signals [5] Paper Size Detection Control Input signals (1) PS23 (PS23 to PRCB) Paper upper limit position detection signal (by- 5VDC pass tray). PS55 PS55 SGND [L]: Detected [H]: Not detected (2) PS43 (PS43 to PRCB) PS56 PS56 Paper lower limit position detection signal (by- pass tray).

  • Page 125: No Paper Detection Control

    BY-PASS TRAY [6] No Paper Detection Control 5VDC PS29 PS29 SGND 5VDC SGND PRCB DCPS1 No paper in the tray is detected by PS29 (no paper (by-pass tray)) which is controlled by the PRCB (printer control board). Operation When the tray becomes empty, PS29 is turned ON, displaying a message on the LCD via the OB1 (operation board 1).
  • Page 126 BY-PASS TRAY Blank page 2 - L - 6...

  • Page 127: Vertical Paper Conveyance Section

    VERTICAL PAPER CONVEYANCE SECTION VERTICAL PAPER CONVEYANCE SECTION [1] Composition Loop PS (PS54) Vertical conveyance roller (upper) Vertical conveyance Vertical conveyance MC1 roller (middle) (MC9) Vertical conveyance Vertical conveyance MC2 roller (lower) (MC10) [2] Mechanisms Mechanism Method Paper conveyance Rollers Conveyance drive Vertical conveyance roller (upper): Loop roller motor (M6) Vertical conveyance roller (middle): Paper feed motor (M4)

  • Page 128: Vertical Paper Conveyance Control

    VERTICAL PAPER CONVEYANCE SECTION Operation [3] Vertical Paper Conveyance Control Paper supplied from one of trays 1-3 is then fed to the second paper feed unit by the M4 and M6's drive force transmitted via MC9 and MC10. Since M4 CONT M4 EM the linear velocity of the vertical conveyance M4 CLK...
  • Page 129 VERTICAL PAPER CONVEYANCE SECTION PRCB output signals (1) M4 CONT (PRCB to M4) M4 drive control signal. [L]: M4 ON [H]: 4 OFF (2) MC9 CONT (PRCB to DCDB to MC 9: 7075) (PRCB to MC9: 7085) MC9 drive control signal. [L]: MC9 ON [H]: MC9 OFF (3) MC10 CONT (PRCB to DCDB to MC10: 7075)
  • Page 130 VERTICAL PAPER CONVEYANCE SECTION Blank page 2 - M - 4...

  • Page 131: Adu

    [1] Composition Paper gate Thick paper conveyance roller Paper reverse/exit entrance Pre-transfer roller section roller Conveyance belts Registration roller Loop roller Paper exit roller Paper reverse/ exit roller 1 Pre-registration ADU reverse Paper reverse/ loop roller roller exit roller 3 Paper reverse/ Pre-registration exit roller 2...

  • Page 132: Mechanisms

    [2] Mechanisms Mechanism Method Second paper feed paper loop Loop roller *1 Second paper feed mis-centering correction Write information is corrected according to the information detected by PS1 (paper mis-centering PS) *2 Second paper feed auxiliary mechanism Pre-transfer section roller Second paper feed paper conveyance drive Registration motor (M12) drive *3 Second paper feed jam removal mechanism...
  • Page 133 *1 Second paper feed paper mis-centering *3 Second paper feed unit jam removal mechanism correction The registration roller is sandwiched between the PS1 (paper mis-centering) is mounted at the exit registration loop jam removal section and the pre- of the registration roller to detect mis-centering transfer jam removal section.
  • Page 134 *5 Paper conveyance unit paper suction *7 Paper path selection to paper reverse/exit mechanism section A paper suction duct is provided in the middle of The paper gate determines whether the paper the paper conveyance and leads to the develop- fed out from the fixing unit is to be ejected straight, ing suction fan (FM2) installed at the back of the or reversed and ejected.
  • Page 135 b. Straight ejection When paper is ejected straight, SD2 is turned ON to close the paper gate. The paper fed by the paper reverse/exit entrance roller is fed through the path over the paper gate because Paper reverse/exit this gate is closed, then fed to the paper exit roller. entrance roller Paper gate Thus, the paper is ejected to the paper exit with...
  • Page 136 c. ADU paper conveyance *8 Paper reverse/exit section jam removal In the two-sided copy mode, the paper finished mechanism with printing on the front side is fed, through the a. Jam access guide plate path under the paper gate, into the paper reverse When a jam occurs in the paper gate section, /exit section just like paper reverse/exit opera- the jammed paper can be removed by opening...
  • Page 137 *9 Nonstack paper feed mechanism *10 ADU pre-registration mechanism In the two-sided copy mode, the paper fed from In the ADU, paper is looped by the pre-registra- the paper reverse/exit section is conveyed to the tion roller and pre-registration loop roller to cor- ADU section by the ADU reverse roller.
  • Page 138 *11 ADU section jam removal mechanism *12 ADU jam indication When a jam occurs in the ADU horizontal con- The ADU has a jam indicator that indicates the veyance section, the jammed paper can be re- location of the jam (ADU,second paper feed unit, moved by opening the ADU horizontal convey- conveyance unit, or fixing unit).

  • Page 139: Loop/Second Paper Feed Control

    [3] Loop/Second Paper Feed Control 5VDC PS54 PS54 24VDC SGND M12 CONT M12 CLK 24VDC M12 EM SGND 24VDC PGND M6 F/R M6 CLK M6 DRIVE A M6 RES M6 DRIVE A M6 OFF M6 VREF M6 DRIVE B 24VDC M6 24FEM M6 DRIVE B MC1 CONT...

  • Page 140: Paper Conveyance Control

    [4] Paper Conveyance Control Signals PRCB input signals (1) PS54 (PS54 to PRCB) Loop formation reference timing detection signal. The leading edge or trailing edge of paper is 24VDC 24VDC detected. M9 DRIVE A [L]: Paper exists. M9 DRIVE A [H]: Paper does not exist.

  • Page 141: Paper Reverse And Exit Control

    [5] Paper Reverse and Exit Control 24VDC 24VDC M10 DRIVE A M10 DRIVE A 24VDC M10 DRIVE B 24VDC For 7085 M10 DRIVE B M5 DRIVE A 5VDC M5 DRIVE A PS61 PS61 SGND M5 DRIVE B M5 DRIVE B 24VDC SD2 CONT 5VDC...
  • Page 142 2) Linear velocity is changed to high speed when (5) PS8, SIG (PS8 to ADUSDB to PRCB) the trailing edge of the paper conveyed at low Detection of paper passage in reversal/convey- speed by M5 passes the nip of the fixing roller. ance section Then M5 rotates backward at high speed and [L]: Paper exists.

  • Page 143: Adu Paper Feed/Reversal Control

    [6] ADU Paper Feed/Reversal Control 24VDC 24VDC 24VDC 24VDC M5 DRIVE A M7 DRIVE A M5 DRIVE A M7 DRIVE A M5 DRIVE B M7 DRIVE B M5 DRIVE B M7 DRIVE B 5VDC PS58 PS58 SGND 5VDC PS59 PS59 SGND 5VDC PS60...
  • Page 144 Signals ADUSDB input signals (1) PS58 (PS58 to ADUSDB to PRCB) Detection of paper passage in ADU paper reversal section. M7 is rotated in the opposite direction or turned OFF with reference to this signal. The leading edge or trailing edge of paper is detected. [L]: Paper exists.

  • Page 145: Adu Paper Conveyance/Feed Control . 2

    [7] ADU Paper Conveyance/Feed Control 24VDC 24VDC M12 CONT 24VDC M12 CLK M12 EM M8 DRIVE A PGND M8 DRIVE A M8 DRIVE B M8 DRIVE B 5VDC 24VDC PS59 SD1 CONT PS59 SGND 24VDC MC2 CONT PS60 PS60 5VDC SGND PS10 PS10...
  • Page 146 M8 (ADU conveyance) control (1) On timing When M8 is turned on at start of copying (2) OFF timing When PS58 is turned OFF at passage of the last paper ADU lock control The ADU handle is locked by SD1. PS10 detects the handle position to determine whether the handle is locked or released.

  • Page 147: Fixing Unit

    FIXING UNIT FIXING UNIT [1] Composition Cleaning web Fixing upper cover unwinding Cleaning web Pressure roller Cleaning web shaft wind-up shaft Fixing web motor (M16) Fixing heater lamp 1 (L2) Cleaning Fixing heater lamp 2 (L3) Fixing upper roller Fixing claw (upper) Thick paper conveyance...
  • Page 148 FIXING UNIT *1 Fixing heater lamps *3 Fixing heat roller Two halogen lamps are used for the fixing upper The fixing heat roller incorporating one halogen roller and one halogen lamp is used for the fixing lamp rotates keeping contact with the fixing lower heat roller.
  • Page 149 FIXING UNIT *5 Jam detection *6 Thick paper conveyance When a jam occurs in the paper exit section in When a thick paper is fed, the fixing guide the fixing unit, the jammed paper presses down solenoid (SD3) installed on the ADU side is turned the actuator, causing the fixing jam sensor (PS3) ON and the thick paper conveyance auxiliary plate to detect a jam via the jam detection plate and...

  • Page 150: M16 (Web Drive)

    FIXING UNIT [3] M16 (Web Drive) Control 5VDC 5VDC SGND SGND DCPS1 24VDC 24VDC PGND PGND DCPS2 M16 DRIVE A M16 CONT M16 DRIVE A M16 CLK M16 DRIVE B M16 VEM M16 DRIVE 1 M16 DRIVE B M16 DRIVE 2 ACDB For 7085 For 7075...

  • Page 151: Fixing Temperature Control

    FIXING UNIT [4] Fixing Temperature Control TH1 ANG 1 TH1 ANG 2 TH2 ANG 1 TH2 ANG 2 TH3 ANG 1 TH3 ANG 2 TH4 ANG 1 TH4 ANG 2 24VDC RL1 CONT L2 CONT L3 CONT L2&L3 CONT L4 DRIVE L4 CONT AC(H) AC(C)
  • Page 152 FIXING UNIT Protection against abnormality (4) L4 CONT (PRCB to ACDB) Thermostats are used to prevent the temperature L4 drive control signal of the fixing rollers from rising abnormally. TS1 [L]: L4 ON (thermostat 1 (upper)) is used for the fixing upper [H]: L4 OFF roller and TS2 (thermostat 2 (lower)) is used for ACDB output signals...

  • Page 153: Sd3 (Fixing Guide) Control

    FIXING UNIT [5] SD3 (fixing guide) Control 24VDC SD3 CONT 5VDC PS45 PS45 SGND ADUSDB PRCB 5VDC 24VDC SGND PGND DCPS1 DCPS2 SD3 (fixing guide) is driven by ADUSDB (ADU stand drive board) and controled by serial data sent from PRCB (printer control board).
  • Page 154 FIXING UNIT Blank page 2 - O - 8...

  • Page 155: Other Kinds Of Control

    OTHER KINDS OF CONTROL OTHER KINDS OF CONTROL [1] Parts Energized when the SW1 (Main) is OFF AC(H) AC(H) 5VDC CBR1 AC(C) DCPS1 PSMB TRANS- FOMER TRANS- TRANS- FORMER FORMER AC30V(H) AC30V(C) ACDB For 7085 For 7075 Operation HTR2-HTR4 are turned ON only when HTR1 is If the power cord is plugged in the wall outlet, OFF.
  • Page 156 OTHER KINDS OF CONTROL [2] Parts that Operate when the SW1 (Main) is Turned ON 5VDC From ACDB RL1 CONT Fixing heater power supply AC(H) AC(H) 5VDC -5VDC AC(C) AC(C) 12VDC SGND Power supplies for boards, 5VDC DCPS1 motors, fans, solenoids, etc. AC(H) 24VDC PGND...

  • Page 157: Cooling Fan Control

    OTHER KINDS OF CONTROL [3] Cooling Fan Control 7085 only FM10 DRIVE For 7075 FM10 FM10 EM PGND FM5/FM8 DRIVE FM5 CONT FM11 DRIVE FM5/FM8 H/L FM5 H/L FM11 FM10 EM FM5 EM FM5 EM PGND PGND FM5 FEM FM1 DRIVE DCDB FM1 EM PGND...
  • Page 158 OTHER KINDS OF CONTROL FM5, FM8 [H]: 24 V power OFF (1) ON timing (5) FM5 EM (FM5 to DCDB to PRCB: 7075) Turned ON after power-on. (FM5 to PRCB: 7085) 7075: FM5 fault detection signal. • Always rotates at low speed during idling. [H]: Fault is detected.
  • Page 159 OTHER KINDS OF CONTROL (4) FM4 H/L (PRCB to ACDB to FM4: 7075) ADUSDB output signal (PRCB to FM4: 7085) (1) FM1 DRIVE (ADUSDB to FM1) FM4's rotational speed control signal. FM1 ON/OFF control signal. [L]: Low speed [L]: FM1 ON [H]: High speed [H]: FM1 OFF (5) FM5 CONT (PRCB to DCDB: 7075)

  • Page 160: Operation Panel Control

    OTHER KINDS OF CONTROL [4] Operation Panel Control 7075 OB1 TXD OB1 RXD OB1 TXD ACK OB1 RXD ACK OB1 TXD REQ OB1 RXD REQ OBINVB WT LED ST LED PSMB SGND 5VDC JAM L1 JAM L2 12VDC JAM L3 5VDC JAM L4 SGND...
  • Page 161 OTHER KINDS OF CONTROL The operation panel consists of OB1 (operation board Signals 1), OB2 (operation board 2), and LCD (indicator board). PRCB input signals On the backlight control board is mounted an LCD. (1) OB1 RXD (OB1 to ICB) The LCD has a backlight which is driven by the Serial data which informs ICB of the operation OBINVB (OB inverter board) and touch switches which...

  • Page 162: Counter Control

    OTHER KINDS OF CONTROL [5] Counter Control Operation This machine counts copies using a software counter. (1) Paper ejection counter The count increases by 1 each time PS61 which has been ON is turned OFF (two counts in the dual-sided copy mode). <Operation of each counter>...

  • Page 163: Option Control

    OTHER KINDS OF CONTROL [6] Option Control (LT-401/LT-411) (LT-402/LT-412) (FS-108/FS-108BM) (FS-111/FS-211) LAN RB HD for OP IFB 7085 ICB IFB SCSI IFB VI-601 for 7075 VI-602 IP-601J HD-102 DF-313 INDICATOR IP-601M DF-317 LAMP for 7075 IP-602 5VDC SGND DCPS1 PRCB COIN VENDOR 24VDC...
  • Page 164 OTHER KINDS OF CONTROL <Functions and output timings of signals for coin vendors> Connector Pin No. Signal name Description Output timing Signal type DC24V Key counter power supply Always 24 V, 300 mA C(K) SIG Key counter connection recognition – C(K) GND Signal ground C(K) DRIVE...

  • Page 165: Disassembly/Assembly

    DISASSEMBLY/ASSEMBLY...
  • Page 166 This section explains how to disassemble and reassemble the machine. When disassembling and reassembling the machine, follow the precautions given below. 1. Be sure the power cord has been unplugged from the wall outlet. 2. The disassembled parts must be reassembled following the disassembly procedure in reverse unless otherwise specified.

  • Page 167: External Section

    EXTERNAL SECTION EXTERNAL SECTION [1] Replacing Ozone Filters [2] Removing and Reinstalling the External Cover Caution: Be sure the power cord has been unplugged from the wall Caution: Be sure the power cord has outlet. been unplugged from the wall Caution: When replacing ozone filters, insert outlet.

  • Page 168: Removing And Reinstalling The Front Right Door

    EXTERNAL SECTION [3] Removing and Reinstalling the Front (4) Remove the four screws to detach the right side cover (top). Right Door Caution: Be sure the power cord has been unplugged from the wall Right side cover (upper) outlet. Procedure (1) Open the front right door.

  • Page 169: Removing And Reinstalling The Front Left Door

    EXTERNAL SECTION [4] Removing and Reinstalling the Front [5] Removing and Reinstalling the Left Door Operation Panel Caution: Be sure the power cord has Caution: Be sure the power cord has been unplugged from the wall been unplugged from the wall outlet.
  • Page 170 EXTERNAL SECTION (6) Remove the six screws to detach the top cover Caution: When removing the operation panel, (middle). pay attention to the following points: (7) Open the front right door and the front left door. • The operation panel and main body are connected with a wiring harness.

  • Page 171: Drive Section

    DRIVE SECTION DRIVE SECTION [1] Removing and Reinstalling the (4) Loose the two setscrews to remove the gear Drum Motor holder, gear, and pin from the shaft. Caution 1: Install the gear with the shaft pin fit Caution: Be sure the power cord has into the groove at the back of the been unplugged from the wall gear.

  • Page 172: Removing And Reinstalling The Main Motor

    DRIVE SECTION [2] Removing and Reinstalling the Main (6) Disconnect the connector (CN180) and remove the four screws and two locking supports to Motor remove the drum motor from the drum motor unit. Caution: Be sure the power cord has been unplugged from the wall Screw (4) outlet.

  • Page 173: Read Section

    READ SECTION READ SECTION [1] Screw that Must not be Removed/ One screw securing the read position Loosened adjusting plate and two screws securing the glass stopper plate (right) 14 (7075) or 13 (7085) screws securing the CCD unit Read position Screws that must 7075 adjusting plate...

  • Page 174: Removing And Reinstalling The Ccd Unit

    READ SECTION [2] Removing and Reinstalling the CCD Unit Caution: Be sure the power cord has been unplugged from the wall outlet. Caution: Be sure to perform image adjustment after installing the CCD unit. (See “ADJUSTMENT.”) Procedure (1) Remove the original stopper plates (right, rear, and left), platen glass, and top cover (middle).
  • Page 175 READ SECTION Blank page MODEL MANUAL REVISED EDITION DATE PAGE METHOD 3 - C - 3 3 - C - 1 - 2 7075/7085 SERVICE HANDBOOK Jan. 2002 3-C-1-2 REPLACEMENT...
  • Page 176 READ SECTION (4) Remove the eight screws to detach the lens light (7) Remove two relay connectors (CN1, 821). (7085 blocking cover 1. only) (8) Remove two screws and detach the HDD unit. (7085 only) Screws (8) Screws Relay connector (CN1) Lens light blocking cover 1 (5) Remove the left side cover.

  • Page 177: Replacing The Exposure Lamp

    READ SECTION [3] Replacing the Exposure Lamp (11) Remove the two screws to detach the CCD unit. Caution 1. Be sure the power cord has been unplugged from the wall outlet. Screws (2) Caution 2. Do not touch the exposure lamp with bare hands.
  • Page 178 READ SECTION (4) Remove the connector and two screws to detach the exposure unit. Connector Screws (2) Exposure lamp (5) Reinstall the above parts following the removal steps in reverse. MODEL MANUAL REVISED EDITION DATE PAGE METHOD 3 - C - 6 7075/7085 SERVICE HANDBOOK Jan.
  • Page 179 READ SECTION Blank page MODEL MANUAL REVISED EDITION DATE PAGE METHOD 3 - C - 7 3 - C - 3 - 2 7075/7085 SERVICE HANDBOOK Jan. 2002 3-C-3-2 REPLACEMENT...

  • Page 180: Replacing And Reinstalling The Exposure Unit

    READ SECTION [4] Replacing and Reinstalling the 7085 Exposure Unit Exposure unit fixing screw Caution: Be sure the power cord has been unplugged from the wall outlet. Caution 1: When installing the exposure unit, use the optical unit positioning jig. Caution 2: Be sure to perform image adjust- ment after installing the exposure lamp.
  • Page 181 READ SECTION Installation procedure (1) Insert the optics unit position adjusting jig in the hole at the exposure unit mounting position (7075: exposure unit fixing hole B/7085: exposure unit fixing hole A) from the front. (2) Slide the exposure unit to the paper feed side until it touches the optics unit position adjusting jig.
  • Page 182 READ SECTION Blank page MODEL MANUAL REVISED EDITION DATE PAGE METHOD 3 - C - 10 7075/7085 SERVICE HANDBOOK Jan. 2002 3-C-4-2 ADDITION...

  • Page 183: Installing The Optics Wire

    READ SECTION [5] Installing the Optics Wire (4) Insert the optics unit position adjusting jig in the hole at the exposure unit mounting position (7075: Caution: Be sure the power cord has been exposure unit fixing hole B/7085: exposure unit unplugged from the wall outlet.
  • Page 184 READ SECTION (5) The exposure unit mounting plate is installed on each optics wire. The position of mounting plate differs depending on whether it is installed on the front or rear wire. Use the wire on which the mounting plate is installed nearer to the metal bead at the end, at the rear.
  • Page 185 READ SECTION Five turns Five turns Four Four Metal bead Wire stopper Front Rear Metal bead Metal bead Optics wire Pulley 1 V-mirror unit (rear) Pulley 1 Drive Metal pulley bead Rear Wire stopper Pulley 3 Metal bead Spring Optics wire (front) Pulley 2 V-mirror unit Wire stopper...

  • Page 186: Cleaning The Slit Glass And White Color Reference Plate Glass

    READ SECTION [6] Cleaning the Slit Glass and White [7] Cleaning the Platen Glass Color Reference Plate Glass Caution: Be sure the power cord has been unplugged from the wall outlet. Caution: Be sure the power cord has (1) Open the RADF. been unplugged from the wall (2) Remove the original stopper plates (right, rear, outlet.

  • Page 187: Write Section

    WRITE UNIT WRITE SECTION [1] Removing and Reinstalling the Write (3) Disconnect the four connectors (CN190, 191, Unit 192, and 193) from the write unit. Warning: (1) Do not energize the write unit when it is CN190 CN193 not in the correct position. (2) Never remove the write unit cover and the CN191 CN192...
  • Page 188 WRITE UNIT (7) Remove three connectors (for 7075: CN76, 474, 583) or four connectors (for 7085: CN76, 78, 471, 583). (8) Remove the four screws to detach the write unit cover. Screws (4) Write unit cover Connector Connectors (7075:CN474 (7075:CN76, CN583 7085:CN474) 7085:CN76, CN78, CN583) MODEL...
  • Page 189 WRITE UNIT Blank page MODEL MANUAL REVISED EDITION DATE PAGE METHOD 3 - D - 3 3 - D - 1 - 2 7075/7085 SERVICE HANDBOOK Jan. 2002 3-D-1-2 REPLACEMENT...

  • Page 190: Cleaning The Dust-Proof Glass

    WRITE UNIT [2] Cleaning the Dust-proof Glass (9) Loosen the two screws to draw out and remove the write unit. Caution: Be sure the power cord has been unplugged from the wall Screw (loosen) outlet. Procedure (1) Draw out the drm unit. (See “Drum Unit.”) (2) Remove the dust-proof glass assembly by draw- ing it out forward.

  • Page 191: Removing And Reinstalling The Image Control Board

    WRITE UNIT [3] Removing and Reinstalling the (5) Remove the CCD flat cable connector (CN110), Image Control Board Ethernet cable connector (CN111), and connec- tor (CN140: 7085 only). Caution: Be sure the power cord has (6) Remove the two screws and the image control been unplugged from the wall board.
  • Page 192 WRITE UNIT Blank page MODEL MANUAL REVISED EDITION DATE PAGE METHOD 3 - D - 6 7075/7085 SERVICE HANDBOOK Jan. 2002 3-D-4 REPLACEMENT...

  • Page 193: Drum Unit

    DRUM UNIT DRUM UNIT [1] Removing and Reinstalling the (3) With the solenoid release lever under the ADU Drum Unit frame held down to the left, turn down the ADU frame drawing lever. Caution: Be sure the power cord has (4) Remove the two screws securing the drum unit.

  • Page 194: Cleaning And Installing The Coupling

    DRUM UNIT [2] Cleaning and Installing the Coupling [3] Removing and Reinstalling the Drum Temperature Sensor Board Caution: Be sure the power cord has been unplugged from the wall outlet. Caution: Be sure the power cord has Procedure been unplugged from the wall (1) Clean the outer surface of the coupling with drum outlet.

  • Page 195: Cleaning The Toner Control Sensor Board

    DRUM UNIT [4] Cleaning the Toner Control Sensor (3) Remove one connector (7075: CN455; 7085: CN351) and three (7075) or one (7085) screws, Board and detach the drum temperature sensor. Caution: Be sure the power cord has been unplugged from the wall 7075 outlet.

  • Page 196: Removing, Cleaning And Reinstalling The Drum

    DRUM UNIT [5] Removing, Cleaning and (3) Remove the screw at the back of the sensor Reinstalling the Drum guide and loosen the screw at the front to move the sensor guide (to prevent the drum from being Caution: Be sure the power cord has damaged during reinstallation).

  • Page 197: Removing And Reinstalling The Separation Claws

    DRUM UNIT [6] Removing and Reinstalling the (5) Remove the retaining ring and slide the shaft to Separation Claws remove the three separation claws. Caution 1: Clean the separation claw drive Caution: Be sure the power cord has shaft with alcohol when installing been unplugged from the wall outlet.
  • Page 198 DRUM UNIT (6) Reinstall the above parts following the removal [Reference] steps in reverse. When you removed the separation claw unit (you Caution: When installing the separation claw need not remove it usually but you need to remove unit, be sure to fit the pin in the guide it only when replacing the solenoid), install it in hole as shown below.

  • Page 199: Corona Unit Section

    CORONA UNIT SECTION CORONA UNIT SECTION [1] Screws that Must not be Removed/ [2] Removing and Reinstalling the Loosened Charging Corona Unit Five screws securing the transfer entrance Caution: Be sure the power cord has guide plate been unplugged from the wall outlet.

  • Page 200: Removing And Reinstalling The Charge Control Plate

    CORONA UNIT SECTION [3] Removing and Reinstalling the (4) Remove the springs of wires (one each) to re- Charge Control Plate move the wires. Caution 1: Do not drop or lose the support Caution: Be sure the power cord has rubbers when removing wires.

  • Page 201: Removing And Reinstalling The Charging Wire Cleaning Pad

    CORONA UNIT SECTION [5] Removing and Reinstalling the [6] Removing and Reinstalling the PCL Charging Wire Cleaning Pad Caution: Be sure the power cord has been unplugged from the wall Caution: Be sure the power cord has outlet. been unplugged from the wall Procedure outlet.

  • Page 202: Cleaning The Charging Corona Unit/Pcl

    CORONA UNIT SECTION [7] Cleaning the Charging Corona Unit/ [8] Removing and Reinstalling the Transfer/Separation Corona Unit Caution: Be sure the power cord has Caution: Be sure the power cord has been unplugged from the wall been unplugged from the wall outlet.

  • Page 203: Removing And Reinstalling The Plunger Prevention Plate

    CORONA UNIT SECTION [9] Removing and Reinstalling the [10] Replacing the Transfer/Separation Plunger Prevention Plate Wires, Transfer/Separation Wire Cleaning Block and Support Caution: Be sure the power cord has been unplugged from the wall Rubbers outlet. Caution: Be sure the power cord has Procedure been unplugged from the wall (1) Open the toner supply unit.
  • Page 204 CORONA UNIT SECTION (7) Remove the three wires from cleaning blocks 7085 along with support rubbers. Transfer/cleaning block Transfer wire 7075 Separation Transfer wire Transfer/cleaning wires Spring block Spring Springs Separation wires Separation wire cleaning block Separation wire cleaning blocks Support rubbers Suport rubbers MODEL...
  • Page 205 CORONA UNIT SECTION (8) Turn the transfer/separation corona unit upside down, remove the retaining rings (two for 7075, three for 7085), and remove the transfer wire cleaning block and separation wire cleaning blocks (one for 7075, two for 7085) from the front side. 7075 Coupling Retaining rings...
  • Page 206 CORONA UNIT SECTION Blank page MODEL MANUAL REVISED EDITION DATE PAGE METHOD 3 - F - 8 7075/7085 SERVICE HANDBOOK Jan. 2002 3-F-6-2 ADDITION...

  • Page 207: Removing And Reinstalling The Tsl Unit

    CORONA UNIT SECTION [11] Removing and Reinstalling the TSL (6) Disconnect the relay connector (CN567) to re- Unit move the TSL unit. Caution: Each relay connector consists of a Caution: Be sure the power cord has male side and a female side. Be sure been unplugged from the wall to remove only the male side (shown outlet.
  • Page 208 CORONA UNIT SECTION Blank page MODEL MANUAL REVISED EDITION DATE PAGE METHOD 3 - F - 10 7075/7085 SERVICE HANDBOOK Jan. 2002 3-F-8 REPLACEMENT...

  • Page 209: Developing Unit

    DEVELOPING UNIT DEVELOPING UNIT [1] Screws that must not be Removed/ [2] Removing and Reinstalling the Loosened Developing Unit Procedure Caution: Be sure the power cord has (1) Two screws securing the toner transfer regulation been unplugged from the wall plate.

  • Page 210: Replacing The Developer

    DEVELOPING UNIT [3] Replacing the Developer (4) Supporting the developing unit at the positions shown below with both hands, remove it from the Caution 1: When replacing the developer in drum unit. the developing unit, take care not to allow dirt to get into it. Caution 2: To rotate the developing sleeve, Developing unit rotate the developing gear counte-...
  • Page 211 DEVELOPING UNIT (4) Tilt the developing unit about 45° and rotate the (8) Rotate the developing gear counterclockwise to developing gear counterclockwise using a check that the developer bristles along the entire standard screwdriver to discharge all of the length of the toner transfer sleeve. developing adhering to the inside of the developing unit and magnet roller.

  • Page 212: Removing And Reinstalling The Developing Suction Filter

    DEVELOPING UNIT [4] Removing and Reinstalling the Developing Suction Filter Caution: Be sure the power cord has been unplugged from the wall outlet. Procedure (1) Draw out the drum unit from the main body. (See “DRUM UNIT.”) (2) Open the lid of the developing suction filter case and remove the suction filter.

  • Page 213: Toner Supply Unit

    TONER SUPPLY UNIT TONER SUPPLY UNIT [1] Replacing and Cleaning the Toner [2] Drawing out the Toner Supply Unit Cartridge Warning: The hinge used in the toner Procedure supply unit mounting section (1) Open the front left and right doors to pull forward moves in two steps.

  • Page 214: Removing And Reinstalling The Toner Supply Sleeves 1 And 2

    TONER SUPPLY UNIT [3] Removing and Reinstalling the (3) Pull forward the toner supply unit. Gripping the portion shown below, pull out the unit completely. Toner Supply Sleeves 1 and 2 Caution: Be sure the power cord has been unplugged from the wall Toner supply unit outlet.

  • Page 215: Removing And Reinstalling The Toner Supply Unit

    TONER SUPPLY UNIT [4] Removing and Reinstalling the (4) Remove toner supply sleeves 1 and 2. Caution: Toner supply sleeves 1 and 2 must be Toner Supply Unit installed observing the correct Caution: Be sure the power cord has orientation shown below. been unplugged from the wall outlet.
  • Page 216 TONER SUPPLY UNIT Blank page 3 - H - 4...

  • Page 217: Cleaning/Toner Recycle Unit

    CLEANING/TONER RECYCLE UNIT CLEANING/TONER RECYCLE UNIT [1] Removing and Reinstalling the Procedure Cleaning/Toner Recycle Unit (1) Manually turn the drum once. Caution: Must turn the drum once to prevent Caution: Be sure the power cord has toner on the brush falling. been unplugged from the wall (2) Draw out the drum unit from the main body.

  • Page 218: Cleaning The Cleaning/Toner Recycle Unit

    CLEANING/TONER RECYCLE UNIT [2] Cleaning the Cleaning/Toner [3] Removing and Reinstalling the Recycle Unit Cleaning Blade Procedure Caution: Be sure the power cord has (1) Remove the cleaning unit. been unplugged from the wall (2) Clean the areas shown below with a blower brush outlet.
  • Page 219 CLEANING/TONER RECYCLE UNIT Procedure (7) Pull down the blade release arm. (1) Remove the cleaning unit. Caution: Must keep the blade replacement (2) Remove one screw to detach cleaning blade 2. lever being rotated in the arrow direction by hand. Screw (1) (8) Release the blade replacement lever.

  • Page 220: Removing And Reinstalling The Toner Guide Brush And Plunger Prevention Felt

    CLEANING/TONER RECYCLE UNIT [4] Removing and Reinstalling the Toner Procedure Guide Brush and Plunger Prevention (1) Remove the cleaning unit. (2) Remove the two screws to detach the toner seal Felt plate. Caution 1: Be sure to replace the following Caution: When installing the toner seal plate, parts at the same time: must start securing the front screw...
  • Page 221 CLEANING/TONER RECYCLE UNIT (3) Remove the two screws to detach the two side (5) Remove one retaining ring and one bearing, then seals (front/rear). the plunging prevention felt from the toner guide brush shaft. Toner guide brush Toner prevention collar (Do not lose.) Splash prevention felt...

  • Page 222: Replacing Guide Plate Assembly

    CLEANING/TONER RECYCLE UNIT [5] Replacing Guide Plate Assembly E-ring Caution: Be sure the power cord has Paper feed bearing been unplugged from the wall Cleaner drive outlet. gear B Procedure E-ring (1) Remove the toner guide brush. (2) Remove one E-ring, and one cleaning unit Toner guide mounting lever collar.
  • Page 223 CLEANING/TONER RECYCLE UNIT (8) Remove one retaining ring from the toner guide shaft, then the cleaner bearing. (9) Remove the toner guide shaft. Caution: When removing the toner guide shaft, remove it from the side plate R first, then from the side plate F. (10) Remove two screws to detach the guide plate assembly.
  • Page 224 CLEANING/TONER RECYCLE UNIT Blank page 3 - I - 8...

  • Page 225: Paper Feed Units Of Trays 1 And 2

    PAPER FEED UNITS OF TRAYS1 AND 2 PAPER FEED UNITS OF TRAYS 1 AND 2 [2] Removing and Reinstalling the Front Caution: The shape and mechanism of tray 1 is the same as those of tray2. The Covers of Trays 1 and 2 procedure for removing and reinst- Caution: Be sure the power cord has alling tray 1 is explained below.

  • Page 226: Cleaning The Paper Dust Removing Brush

    PAPER FEED UNITS OF TRAYS 1 AND 2 [3] Cleaning the Paper Dust Removing [4] Cleaning the Paper Pre-registration Brush PS/Paper Feed PS Procedure Procedure (1) Draw out paper feed tray 1. (1) Draw out paper feed tray 1. (2) Release the two latches to detach the paper dust (2) Clean the paper pre-registration PS1 (PS48) / the removing brush.

  • Page 227: Paper Feed

    PAPER FEED UNITS OF TRAYS1 AND 2 [5] Removing and Reinstalling the (3) Remove the following parts from the paper pick- Paper Feed Roller and the Feed up roller unit to remove individual rollers: • Retaining rings (three) Roller • Bearing (one) Procedure •...

  • Page 228: Removing And Reinstalling The Double Feed Prevention Roller

    PAPER FEED UNITS OF TRAYS 1 AND 2 [6] Removing and Reinstalling the (5) Remove the retaining ring to detach the double Double Feed Prevention Roller feed prevention shaft with roller. (6) Slide the double feed prevention roller out of the Procedure shaft.

  • Page 229: Replacing The Pre-Registration And The Feed Clutches (Mcs)

    PAPER FEED UNITS OF TRAYS1 AND 2 [7] Replacing the Pre-registration and [8] Removing and Reinstalling the Up/ the Feed Clutches (MCs) Down Unit Procedure a. Procedure (1) Draw out paper tray 1. (1) Draw out paper feed tray 1. (2) Remove four screws to detach the paper convey- (2) Remove the front cover of the tray.

  • Page 230: Replacing The Up/Down Plate Wires

    PAPER FEED UNITS OF TRAYS 1 AND 2 [9] Replacing the Up/Down Plate Wires Caution 1: This section explains how to replace the rear wires. To replace the front wires, remove the front cover of tray and paper up/down unit. The replacement procedure is the same as that for the rear wires.
  • Page 231 PAPER FEED UNITS OF TRAYS1 AND 2 <Wire Lengths> Wire A, C: 207.5±1 mm 207.5 mm (trays 1, 2) Wire B, D: 497.5±1 mm Wire A, C 497.5 mm (trays 1, 2) Wire B, D <Installing Wires> (2) Install the pulley, pass wire D through the pulley, and install the wire restraining cover and retaining ring.
  • Page 232 PAPER FEED UNITS OF TRAYS 1 AND 2 Blank page 3 - J - 8...

  • Page 233: Tray 3 Paper Feed Unit

    TRAY 3 PAPER FEED UNIT TRAY 3 PAPER FEED UNIT [1] Removing and Reinstalling the [2] Removing and Reinstalling the Front Paper Feed Tray 3 Cover of Paper Tray 3 Warning: When removing the tray, stand Caution: Be sure the power cord has in a proper position so that you been unplugged from the wall do not hurt your back and waist.

  • Page 234: Cleaning The Paper Dust Removing Brush

    TRAY 3 PAPER FEED UNIT [3] Cleaning the Paper Dust Removing [4] Cleaning the Paper Pre-registration Brush PS/the Paper Feed PS Procedure Procedure (1) Draw out paper feed tray 3. (1) Draw out paper feed tray 3. (2) Release the two latches to detach the paper dust (2) Clean the paper pre-registration PS3 (PS52)/ the removing brush.

  • Page 235: Removing And Reinstalling The Paper Feed Roller And The Feed Roller

    TRAY 3 PAPER FEED UNIT [5] Removing and Reinstalling the (3) Remove the following parts from the paper feed Paper Feed Roller and the Feed roller unit to remove individual rollers: • Retaining rings (3) Roller • Bearing (1) Procedure •...

  • Page 236: Removing And Reinstalling The Double Feed Prevention Roller

    TRAY 3 PAPER FEED UNIT [6] Removing and Reinstalling the (5) Remove the retaining ring to detach the double Double Feed Prevention Roller feed prevention roller shaft with roller. (6) Slide the double feed prevention roller out of the Procedure shaft.

  • Page 237: Replacing The Pre-Registration Mc3

    TRAY 3 PAPER FEED UNIT [7] Replacing the Pre-registration MC3 [8] Removing and Reinstalling the Up/ (MC8) and the Feed MC3 (MC7) Down Unit Procedure a. Procedure (1) Draw out paper tray 3. (1) Draw out paper feed tray 3. (2) Remove the four screws to detach the paper (2) Remove the front cover of the tray.

  • Page 238: Replacing The Up/Down Plate Wires

    TRAY 3 PAPER FEED UNIT [9] Replacing the Up/Down Plate Wires Caution 1: This section explains how to replace the rear wires. To replace the front wires, remove the front cover of tray and paper up/down unit. The replacement procedure is the same as that for the rear wires.
  • Page 239 TRAY 3 PAPER FEED UNIT <Wire Lengths> Wire A, C: 309±1 mm 309 mm (tray 3) Wire B, D: 599±1 mm Wire A, C 599 mm (tray 3) Wire B, D <Installing Wires> (2) Install the pulley, pass wire D through the pulley, and install the wire restraining cover and retaining ring.
  • Page 240 TRAY 3 PAPER FEED UNIT Blank page 3 - K - 8...

  • Page 241: By-Pass Tray

    BY-PASS TRAY BY-PASS TRAY [1] Removing and Reinstalling the By- [2] Cleaning the Paper Size Detection pass Tray Sensors Caution: Be sure the power cord has Procedure been unplugged from the wall (1) Open the bypass tray. outlet. (2) Clean the two paper size sensors (PS55, PS56) Procedure with a blower brush.

  • Page 242: Replacing The Paper Feed Roller/The Feed Roller Rubbers

    BY-PASS TRAY [3] Replacing the Paper Feed Roller/the [4] Replacing the Double Feed Feed Roller Rubbers Prevention Roller Rubber Procedure Procedure (1) Remove the by-pass tray. (1) Remove the by-pass tray and place the tray (2) Remove the two retaining rings and slide the two upside down.

  • Page 243: Vertical Conveyance Section

    VERTICAL CONVEYANCE SECTION VERTICAL CONVEYANCE SECTION [1] Removing and Reinstalling the [2] Removing and Reinstalling the Vertical Conveyance Section Vertical Conveyance MC (MC9, MC10) Caution: Be sure the power cord has been unplugged from the wall Caution: Be sure the power cord has outlet.

  • Page 244: Replacing The Vertical Conveyance Roller (Upper)

    VERTICAL CONVEYANCE SECTION [3] Replacing the Vertical Conveyance [4] Removing and Reinstalling the Roller (Upper) Vertical Conveyance Rollesrs (Middle/Lower) Caution: Be sure the power cord has been unplugged from the wall Caution: Be sure the power cord has outlet. been unplugged from the wall Procedure outlet.

  • Page 245: Cleaning The Vertical Conveyance Ps/ Loop

    VERTICAL CONVEYANCE SECTION [5] Cleaning the Vertical Conveyance PS/Loop PS Caution: Be sure the power cord has Caution: Be sure the power cord has been unplugged from the wall been unplugged from the wall outlet. outlet. Procedure Procedure (1) Remove the vertical conveyance unit. (1) Remove the vertical conveyance unit.
  • Page 246 VERTICAL CONVEYANCE SECTION Blank page MODEL MANUAL REVISED EDITION DATE PAGE METHOD 3 - M - 4 7075/7085 SERVICE HANDBOOK Jan. 2002 3-M-4 REPLACEMENT...

  • Page 247: Adu Unit

    ADU UNIT ADU UNIT [1] Drawing out and Reinstalling the [2] Cleaning the Paper Dust Removing ADU Stand Brush for Registration Roller Caution: Be sure the power cord has been Caution: Be sure the power cord has unplugged from the wall outlet. been unplugged from the wall Warning: The interlock which is turned off outlet.

  • Page 248: Cleaning The Paper Dust Removing Brushes For The Registration Roller

    ADU UNIT [3] Cleaning the Paper Dust Removing [4] Cleaning PS44 (Registration PS) Brushes for the Registration Roller Caution: Be sure the power cord has been unplugged from the wall Caution: Be sure the power cord has outlet. been unplugged from the wall Warning: The interlock which is turned outlet.

  • Page 249: Cleaning Paper Mis-Centering Ps (Ps1)/Leading Edge Detection Ps (Ps45)

    ADU UNIT [5] Cleaning Paper Mis-centering PS [6] Cleaning Paper Reverse PS (PS57)/ (PS1)/Leading Edge Detection PS ADU Deceleration PS (PS59) (PS45) Caution: Be sure the power cord has been unplugged from the wall Caution: Be sure the power cord has outlet.

  • Page 250: Removing And Reinstalling The Adu Cover

    ADU UNIT [7] Removing and Reinstalling the ADU (4) Loosen the four screws to detach the ADU cover. Cover Caution: Be sure the power cord has been unplugged from the wall outlet. Warning: The interlock which is turned off when the front right or left door opens/closes, should never been turned on forcibly with the ADU stand drawn out.

  • Page 251: Removing And Reinstalling Registration Mc (Mc1)

    ADU UNIT [8] Removing and Reinstalling (5) Remove the retaining ring to detach registration Registration MC (MC1) MC (MC1). Caution: When reinstalling MC1, pay attention Caution: Be sure the power cord has to the position of the stopper. been unplugged from the wall outlet.

  • Page 252: Removing And Reinstalling Adu Pre-Registration Mc (Mc2)

    ADU UNIT [9] Removing and Reinstalling ADU [10] Removing and Reinstalling the Pre-registration MC (MC2) Second Paper Feed Unit Caution: Be sure the power cord has Caution: Be sure the power cord has been unplugged from the wall been unplugged from the wall outlet.

  • Page 253: Removing And Reinstalling The Adu Stand

    ADU UNIT [11] Removing and Reinstalling the ADU (4) Remove the four screws to remove the second paper feed unit. Stand Caution: When reinstalling the second paper Caution: Be sure the power cord has feed unit, pay attention to the position been unplugged from the wall of the stopper of second paper feed outlet.
  • Page 254 ADU UNIT (7) Remove the two screws to remove the cable arm 2nd paper feed side stay from the ADU stand. <Paper feed side> Relay connector Relay connector (CN542) (CN540) Relay connector (CN541) Screws Guide rail Paper reverse/exit side stay <Paper exit side>...

  • Page 255: Removing And Reinstalling The Registration Roller

    ADU UNIT [12] Removing and Reinstalling the (6) Slide the registration roller to the front, then Registration Roller remove it by lifting its rear end. Caution: Be sure the power cord has Bearing been unplugged from the wall outlet. Warning: The interlock which is turned off when the front right or left door opens/closes, should never been turned on forcibly with the...

  • Page 256: Removing And Reinstalling The Registration Motor (M12) Assembly

    ADU UNIT [13] Removing and Reinstalling the (5) Release the wiring harness from the registration Registration Motor (M12) Assembly motor assembly and stay. (6) Remove one screw to detach the stay. Caution: Be sure the power cord has (7) Remove the three screws to detach the registration been unplugged from the wall motor (M12) assembly.

  • Page 257: Removing And Reinstalling The Loop Roller, Adu Paper Exit Roller, And Pre-Registration Roller

    ADU UNIT [14] Removing and Reinstalling the Loop (9) Remove the two screws to release the bearing Roller, ADU Paper Exit Roller, and fitting. (10) Pull out the loop roller, ADU paper exit roller, and Pre-registration Roller pre-registration roller. Caution: Be sure the power cord has been unplugged from the wall outlet.

  • Page 258: Removing And Reinstalling The Pre-Transfer Roller And Pre-Registration Loop Roller

    ADU UNIT [15] Removing and Reinstalling the Pre- (12) Remove the two E-rings and one bearing from the ADU paper exit roller. transfer Roller and Pre-registration Loop Roller Caution: Be sure the power cord has been unplugged from the wall outlet.
  • Page 259 ADU UNIT (4) Disconnect eight relay connectors (CN561, 567, (8) Remove one E-ring from the pre-transfer roller to 574, 576, 587, 593). detach the gear. Caution: Each relay connector (CN567, 574, (9) Remove one E-ring from the pre-registration loop 576, 593) consists of two plugs and roller to detach one spacer.
  • Page 260 ADU UNIT (13) Pull one pin from each roller. (18) Remove the two E-rings from the pre-registration (14) Remove the two screws to slide the pre-transfer loop roller. roller bearing to the front, and remove the two screws to slide the pre-registration loop roller pulley to the front.

  • Page 261: Removing And Reinstalling The Adu Reverse Roller

    ADU UNIT [16] Removing and Reinstalling the ADU (5) Remove the three screws to detach the ADU Reverse Roller reverse motor (M7) assembly. Caution: Be sure the power cord has been unplugged from the wall Screws Relay connector outlet. (CN553) Warning: The interlock which is turned off when the front right or left door opens/closes, should never...

  • Page 262: Removing And Reinstalling The Adu Stand Drive Board Assembly

    ADU UNIT [17] Removing and Reinstalling the ADU (10) Pull out the ADU reverse roller. Stand Drive Board Assembly Caution: Be sure the power cord has Screw been unplugged from the wall outlet. Warning: The interlock which is turned OFF when the front right or left 7085 only door opens/closes, should never been turned ON forcibly...

  • Page 263: Horizontal Conveyance Rollers 1

    ADU UNIT [18] Removing and Reinstalling the ADU (4) Disconnect the fire relay connectors (CN523, 525, 559, 572, 573) . Horizontal Conveyance Rollers 1 Caution: Each relay connector consists of two and 2 plugs and one socket. For CN525, Caution: Be sure the power cord has disconnect two plugs.
  • Page 264 ADU UNIT (5) Disconnect eight relay connectors (CN561, 567, (8) Open ADU horizontal conveyance unit open/ 574, 576, 587, 593). close cover A. Caution: Each relay connector (CN567, 574, (9) Remove one E-ring and one spacer from each of 576, 593) consists of two plugs and ADU horizontal conveyance rollers 1 and 2.

  • Page 265: Removing And Reinstalling The Paper Reverse/Exit Rollers 1, 2, And 3

    ADU UNIT [19] Removing and Reinstalling the (14) Remove the two E-rings from each roller. Paper Reverse/Exit Rollers 1, 2, and E-rings Caution: Be sure the power cord has been unplugged from the wall outlet. Warning: The interlock which is turned OFF when the front right or left door opens/closes, should never been turned ON forcibly...
  • Page 266 ADU UNIT (9) Remove one E-ring to detach the idle gear. (17) Remove the two E-rings from paper reverse/exit (10) Remove one gear from paper reverse/exit roller roller 1. 1 and remove one pin. (7075 only) (11) Remove one E-ring from paper reverse/exit roller 3 and remove one spacer.

  • Page 267: Removing And Reinstalling The Paper Reverse/Exit Unit Entrance Roller

    ADU UNIT [20] Removing and Reinstalling the (19) Remove the two E-rings from paper reverse/exit roller 3. Paper Reverse/Exit Unit Entrance Roller Caution: Be sure the power cord has E-ring been unplugged from the wall outlet. Warning: The interlock which is turned off when the front right or left door opens/closes, should never been turned on forcibly with the...

  • Page 268: Removing And Reinstalling The Paper Reverse/Exit Switchover Gate

    ADU UNIT [21] Removing and Reinstalling the (6) Remove the three E-rings and one bearing from the paper reverse/exit unit entrance roller. Paper Reverse/Exit Switchover Gate Caution: Be sure the power cord has been unplugged from the wall E-ring E-rings outlet.
  • Page 269 ADU UNIT (5) Open the jam access guide plate to remove the (6) Reinstall the above parts following the removal paper reverse/exit switchover gate. steps in reverse. Caution: When installing the paper reverse/exit switchover gate, must perform the following adjustment. Bearing E-ring Gate drive...

  • Page 270: Removing And Reinstalling The Paper Exit Roller

    ADU UNIT [22] Removing and Reinstalling the (7) Remove the paper exit roller from the paper exit Paper Exit Roller unit. Caution: Be sure the power cord has been unplugged from the wall Stamp outlet. Warning: The interlock which is turned E-ring OFF when the front right or left Bering...

  • Page 271: Fixing Unit

    FIXING UNIT FIXING UNIT [1] Removing and Reinstalling the [2] Removing and Reinstalling the Fixing Unit Fixing Unit Top Cover Caution 1: Be sure the power cord has Caution: Before opening the fixing unit top been unplugged from the wall cover, be sure to rotate the outlet.

  • Page 272: Replacing The Cleaning Web

    FIXING UNIT [3] Replacing the Cleaning Web [4] Replacing the Fixing Heater Lamps (Upper/Roller) (L2, L3) Procedure (1) Draw out the ADU stand. (See "ADU UNIT.") Caution: Do not touch the fixing heater (2) Open the fixing unit top cover. lamp with bare hands.
  • Page 273 FIXING UNIT 7085 Lamp fixing plate cover Screws Front lamp fixing plate Screws (2) Faston Wiring terminals (2) harness clamps Faston terminals (remove 2) MODEL MANUAL REVISED EDITION DATE PAGE METHOD 3 - O - 3 7075/7085 SERVICE HANDBOOK Jan. 2002 3-O-2-1 ADDITION...
  • Page 274 FIXING UNIT Blank page MODEL MANUAL REVISED EDITION DATE PAGE METHOD 3 - O - 4 7075/7085 SERVICE HANDBOOK Jan. 2002 3-O-2-2 ADDITION...
  • Page 275 FIXING UNIT (7) Remove the two screws at the back to detach two (9) Pull out the fixing heater lamps (L2, L3) from the wiring harness clamps. front side of the fixing upper roller. (8) Remove the two Faston terminals at the back. 7075 Wiring harness...

  • Page 276: Removing And Reinstalling The Fixing Upper Roller

    FIXING UNIT [5] Removing and Reinstalling the C-ring collars Fixing Upper Roller Insulating sleeve Procedure Bearing (1) Remove the fixing unit from the main body. (2) Release the fixing unit lower contact with the upper roller. (3) Open the fixing unit top cover. (4) Remove the fixing upper roller heater lamps (L2, L3).
  • Page 277 FIXING UNIT Blank page MODEL MANUAL REVISED EDITION DATE PAGE METHOD 3 - O - 7 7075/7085 SERVICE HANDBOOK Jan. 2002 3-O-3-2 ADDITION...

  • Page 278: Removing And Reinstalling The Fixing Lower Roller

    FIXING UNIT [6] Removing and Reinstalling the [7] Removing and Reinstalling the Fixing Lower Roller Fixing Heat Roller Assembly Procedure Procedure (1) Remove the fixing upper roller. (1) Remove the fixing unit from the main body. (2) Remove one screw to detach the fixing knob. (2) Remove the two springs and one screw (along (3) Remove the fixing lower roller upward.

  • Page 279: Replacing The Heater Lamp (Lower) (L4)

    FIXING UNIT [8] Replacing the Heater Lamp (Heat Caution: When installing the fixing heat roller assembly, be sure to fit the guide pin roller) (L4) in the guide hole on the rear side. Caution: Do not touch the fixing heater (6) Reinstall the above parts following the removal lamp (heat roller)(L4) with bare steps in reverse.

  • Page 280: Removing And Reinstalling The Fixing Heat Roller

    FIXING UNIT (6) Remove the heater lamp (L4) from the front side. [9] Removing and Reinstalling the Fixing Heat Roller Cable tie (for heat Caution: Do not touch the fixing heater insulation) lamp (lower)(L4) with bare Faston terminal hands. Procedure (1) Remove the fixing heat roller assembly.

  • Page 281: Removing And Reinstalling The Cleaning Roller (7075 Only)

    FIXING UNIT [10] Removing and Reinstalling the [11] Removing and Reinstalling the Cleaning Roller (7075 only) Fixing Separation Claws (Lower) Procedure Procedure (1) Open the fixing paper exit unit. (1) Open the fixing paper exit unit. (2) Remove the two screws to detach the cleaning (2) Remove the two screws to detach the fixing roller assembly.

  • Page 282: Removing And Reinstalling The Fixing Separation Claws (Upper)

    FIXING UNIT [12] Removing and Reinstalling the [13] Removing and Reinstalling the Fixing Separation Claws (Upper) Actuator for Fixing Exit PS (PS2) Procedure Procedure (1) Open the fixing paper exit unit. (1) Open the fixing paper exit unit. (2) Remove the six springs connected to the fixing (2) Disconnect the two connectors (CN464, 465) separation claws.

  • Page 283: Removing And Reinstalling Fixing Temper-Ature Sensors 1 And 2

    FIXING UNIT [14] Removing and Reinstalling Fixing (5) Remove one screw (on the fixing plate side) to Temperature Sensors 1 and 2 detach fixing temperature sensor 2. Caution 1: After reinstalling fixing tempe- rature sensor 2, make sure that the sensor touches the fixing upper Fixing temperature sensor 1 (CN466)

  • Page 284: Removing And Reinstalling Fixing Temper-Ature Sensors 3 And 4

    FIXING UNIT [15] Removing and Reinstalling Fixing (a) Set the distance "a" between the fixing temperature sensor 1 and fixing upper roller so Temperature Sensors 3 and 4 that it is equal to the thickness of the positioning Caution 1: After reinstalling fixing tempe- jig.
  • Page 285 FIXING UNIT (4) Disconnect one connector (CN468) and remove Reinstallation procedure four screws to detach two wire clamps. (1) Secure fixing temperature sensor 4 with a screw. (5) Remove the two screws to detach fixing (2) Make sure that fixing temperature sensor 4 temperature sensor 3.

  • Page 286: Removing And Reinstalling The Thermostat (Upper)

    FIXING UNIT [16] Removing and Reinstalling the (4) Apply screw lock agent to the two screws securing fixing temperature sensor 3. Thermostat (Upper) (5) Secure the wires of fixing temperature sensors 3 and 4 with wire clamp and ties, and connect the Caution: This is an important safety part.
  • Page 287 FIXING UNIT (3) Remove one screw and remove two Faston terminals to detach the thermostat. Screw Thermostat (upper) Faston terminals (2) MODEL MANUAL REVISED EDITION DATE PAGE METHOD 3 - O - 13 7075/7085 SERVICE HANDBOOK Jan. 2002 3-O-12-1 ADDITION...
  • Page 288 FIXING UNIT Blank page MODEL MANUAL REVISED EDITION DATE PAGE METHOD 3 - O - 14 7075/7085 SERVICE HANDBOOK Jan. 2002 3-O-12-2 ADDITION...
  • Page 289 FIXING UNIT Reinstallation procedure (3) Apply screw lock agent to the screw securing the (1) Connect two Faston terminals to the thermostat thermostat (upper). (upper). (4) Reinstall other parts following the removal steps (2) Set a thermostat PS jig/A (55VAJG031) between in reverse.

  • Page 290: Removing And Reinstalling The Thermostat (Lower)

    FIXING UNIT [17] Removing and Reinstalling the Reinstallation procedure Thermostat (Lower) (1) Set a thermostat PS jig/B (55VAJG041) between the thermostat (lower) and fixing heat roller, and secure the thermostat (lower) with one screw so Caution: This is an important safety part. that the distance between the roller and thermostat (P/N:SP00-0040) Be sure to equal to the thickness of the jig.
  • Page 291 FIXING UNIT (2) Connect two Faston terminals to the thermostat (lower). (3) Apply screw lock agent to the screw securing the thermostat (lower). (4) Reinstall other parts following the removal steps in reverse. 3 - O - 17 3 - O - 15...
  • Page 292 FIXING UNIT Blank page 3 - O - 18 3 - O - 16...
  • Page 293 MODELS 7075/FORCE 75 7085/FORCE 85 SERVICE SECTION FEBRUARY 2003...
  • Page 295 CONTENTS CONTENTS 1. ADJUSTMENT [12] Distortion Adjustment (Copier) ..... 1-85 [13] Non-image area erase check (7085 only) ..1-86 HOW TO USE THIS SECTION ........1-1 [14] Recall standard data (Image adjustment) ... 1-86 [1] Scope and Precautions ........1-1 [15] Running Test Mode ........
  • Page 296 CONTENTS [25] FNS Adjusting the Tension of the Lower [5] FNS [FS-108], [FS-111] ......... 3-12 Alignment Plate Drive Timing Belt [6] FNS [FS-108BM], [FS-211] ......3-12 (FS-108BM/211 only) ........1-137 [7] LCT [LT-401/411], [LT-402/412] ....3-13 [26] FNS Adjusting the Stapling Position [8] PI [PI-108] ............
  • Page 297 CONTENTS [10] Fixing Unit ............4-16 PU-108 OVERALL WIRING DIAGRAM ....4-34-1 [11] Paper Exit Section ......... 4-16 PZ-108 OVERALL WIRING DIAGRAM ....4-34-2 [12] Toner Supply Unit .......... 4-17 FS-111 OVERALL WIRING DIAGRAM ....4-34-3 [13] Write Section ..........4-17 FS-211 OVERALL WIRING DIAGRAM ....
  • Page 298 SAFETY AND IMPORTANT WARNING ITEMS SAFETY AND IMPORTANT WARNING ITEMS Read carefully the Safety and Important Warning Items described below to understand them before doing service work. IMPORTANT NOTICE Because of possible hazards to an inexperienced person servicing this copier as well as the risk of damage to the copier, Konica Corporation strongly recommends that all servicing be performed only by Konica-trained service technicians.
  • Page 299 SAFETY AND IMPORTANT WARNING ITEMS SAFETY WARNINGS [1] MODIFICATIONS NOT AUTHORIZED BY KONICA Konica copiers are renowned for their high reliability. This reliability is achieved through high-quality design and a solid service network. Copier design is a highly complicated and delicate process where numerous mechanical, physical, and electrical aspects have to be taken into consideration, with the aim of arriving at proper tolerances and safety factors.
  • Page 300 SAFETY AND IMPORTANT WARNING ITEMS [2] CHECKPOINTS WHEN PERFORMING ON-SITE SERVICE Konica copiers are extensively tested before shipping, to ensure that all applicable safety standards are met, in order to protect the customer and customer engineer (hereafter called the CE) from the risk of injury. However, in daily use, any electrical equipment may be subject to parts wear and eventual failure.
  • Page 301 SAFETY AND IMPORTANT WARNING ITEMS WARNING: Power Plug and Cord • Do not bundle or tie the power cord. Overheating may occur there, leading to a risk of fire. • Check whether dust is collected around the power plug and wall outlet. Using the power plug and wall outlet without removing dust may result in fire.
  • Page 302 SAFETY AND IMPORTANT WARNING ITEMS WARNING: Ground Lead • Pay attention to the point to which the ground lead is connected. Connecting the ground lead to an improper point such as the points listed below results in a risk of explosion and electric shock: a.
  • Page 303 SAFETY AND IMPORTANT WARNING ITEMS CAUTION: Ventilation • The copier generates ozone gas during operation, but it is not sufficient to be harmful to the human body. If a bad smell of ozone is present in the following cases, ventilate the room. a.
  • Page 304 SAFETY AND IMPORTANT WARNING ITEMS DANGER: Work Performed with the Copier Powered • Take every care when servicing with the external cover detached. High-voltage exists around the drum unit. A risk of electric shock exists. WARNING: Safety Checkpoints • Check the exterior and frame for edges, burrs, and other damages. The user or CE may be injured.
  • Page 305 SAFETY AND IMPORTANT WARNING ITEMS WARNING: Safety Checkpoints • After replacing a part to which AC voltage is applied (e.g., optical lamp and fixing lamp), be sure to check the installation state. A risk of fire exists. • Check the interlock switch and actuator for loosening and check whether the interlock functions properly.
  • Page 306 SAFETY AND IMPORTANT WARNING ITEMS DANGER: Handling of Service Materials • Toner and developer are not harmful substances, but care must be taken not to breathe excessive amounts or let the substances come into contact with eyes, etc. It may be stimulative. If the substances get in the eye, rinse with plenty of water immediately.
  • Page 307 SAFETY INFORMATION SAFETY AND IMPORTANT WARNING ITEMS SAFETY INFORMATION IMPORTANT INFORMATION The Center for Devices and Radiological Health (CDRH) of the U.S. Food and Drug Administration implemented regulations for laser products manufactured since August 1, 1976. Compliance is mandatory for products marketed in the United States.
  • Page 308 SAFETY INFORMATION SAFETY CIRCUITS [2] Protection by L2, L3, and L4 (fixing This machine is provided with the following safety circuits to prevent machine faults from resulting in heaters) overheating prevention serious accidents. circuit [1] Overall protection circuit [2] L2, L3, and L4 (fixing heater lamps) overheating prevention circuit These safety circuits are described below to provide ACDB...
  • Page 309 SAFETY INFORMATION Protection by the hardware circuit The output voltages from TH1 and TH2 (fixing temperature sensor 2), TH3 (fixing temperature sensor 3), and TH4 (fixing temperature sensor 4) are compared with the abnormality judgement reference value in the comparator circuit. If the output voltage from TH1, TH2, TH3, or TH4 exceeds the reference value, L2, L3, L4, and RL1 are turned off in hardware means.
  • Page 310 SAFETY INFORMATION INDICATION OF WARNING ON THE MACHINE Caution labels shown below are attached in some areas on/in the machine areas. When accessing these areas for maintenance, repair, or adjustment, special care should be taken to avoid burns and shock hazards. Do not remove caution labels.
  • Page 311 SAFETY INFORMATION WARNING Unplug the machine before removing platen glass. <Read Section> Debrancher le copieur avant de retirer la vitre d'exposition. DANGER Vor Entfernen des Vorlagenglases Netzstecker ziehen. WARNUNG ADVERTENCIA Desenchufe la maquina antes de quitar el vidrio. Estrarre la spina dalla presa prima di rimuovere il vetro di esposizione. AVVERTIMENTO Elektrische Teile <Board Cover>...
  • Page 312 SAFETY INFORMATION <Tray 1> <Tray 2> CAUTION CAUTION DO NOT put your hand between the main body and tray; otherwise you may be injured. <Tray 3> <FS-108BM/211 only> CAUTION ATTENTION PRECAUCION CUIDADO CAUTION CAUTION ATTENTION VORSICHT Use care after opening the PRECAUCION ATTENZIONE paper exit outlet.
  • Page 313 SAFETY INFORMATION CAUTION WARNING WARNING Unplug the machine before removing panels. Débrancher l’appareil avant de retirer les panneaux arrières. Desenchufe la máquina antes de quitar los paneles. Desconecte a unidade da tomada antes de remover os painéis. Unplug the machine before removing panels.
  • Page 314 SAFETY INFORMATION WARNING Unplug the machine before removing panels. Débrancher l’appareil avant de retirer les panneaux arrières. Desenchufe la máquina antes de quitar los paneles. Desconecte a unidade da tomada antes de remover os painéis. Unplug the machine before removing panels.

  • Page 315: Adjustment

    ADJUSTMENT...

  • Page 317: How To Use This Section

    ADJUSTMENT HOW TO USE THIS SECTION [1] Scope and Precautions Take care not to damage the drum with tools and so on. This section provides detailed information about the Do not touch IC pins with bare hands. adjustment items and procedures. Before addressing customer complaints, perform the following checks: Check whether the power supply voltage meets the specifications.

  • Page 318: Adjustments Made When Replacing Parts

    ADJUSTMENT ADJUSTMENTS MADE WHEN REPLACING PARTS Adjustments (including checks) and settings are not only required when a customer complaint about the copy image quality is received, but also after replacing or reassembling parts. [How to Read Tables] Components of the tables used in this section are as follows: Mode Adjustment mode to be selected.

  • Page 319: List Of Adjustment Items

    ADJUSTMENT LIST OF ADJUSTMENT ITEMS Process High Voltage High Voltage Auto 1-67 adjust- Adjustment Adjustment ment Drum Blade setting mode 1-68 Peculiarity Auto drum potential Adjustment 1-69 adjustment Auto maximum density 1-69 adjustment (Dmax adjustment) Auto dot diameter 1-70 adjustment LD1 offset adjustment 1-70 LD2 offset adjustment...
  • Page 320 ADJUSTMENT 1-94-1 Finisher Stapling and folding stopper adjustment (FS-108BM/211 only) adjust- Folding stopper adjustment (FS-108BM/211 only) 1-94-1 ment Cover sheet tray size adjustment (PI-108 only) 1-94-2 1-94-2 Trimmer stopper adjustment (TU-108 only) Punch vertical position adjustment (PU-108/PZ-108 only) 1-94-3 Punch horizontal position adjustment (PU-108/PZ-108 only) 1-94-3 Punch registration loop adjustment (PU-108/PZ-108 only) 1-94-4...

  • Page 321: Lcd Adjustment

    LCD ADJUSTMENT LCD ADJUSTMENT [1] Control Panel Adjustment [2] Panel Contrast/Key Sound Adjustment Enter the key operator mode and select " Control Enter the key operator mode and select " Panel con- panel adjustment" to adjust the LCD touch panel. trast/Key sound adjustment"...

  • Page 322: Settings And Adjustments Made With The P Function

    P ADJUSTMENT SETTINGS AND MODE CHANGING ADJUSTMENTS MADE MENU WITH THE P FUNCTION [1] Mode Selection You can select a mode from the following [Mode The P function allows you to perform following checks changing menu: Select mode] without turning using the P button: OFF and ON the power switch.

  • Page 323: Mode

    25 ADJUSTMENT 25 MODE [1] Selecting and Canceling the 25 [2] Setting Software DIP Switches Mode Procedure Bring up the Software DIP SW Setting screen This machine has an adjustment mode called the “25 and set software DIP switches. Mode.” Select this mode to rewrite data in the non- volatile memory or make various settings.
  • Page 324 25 ADJUSTMENT < List of Software Switches > Initial Value DIPSW No. Function Japan Inch Metric Condition for stopping copying after indication of toner supply Ditto Method for stopping copying after indication of toner supply DIPSW 1 Ditto Inhibition of copying when PM count is Not inhibited Inhibited reached...
  • Page 325 25 ADJUSTMENT NOTE: Bit number of the initial value in parentheses is the initial value for 7085. Initial Value DIPSW No. Function Japan Inch Metric Toner concentration threshold Ditto – – – DIPSW5 – – – 2 dot PWM density in photo mode (7085 only) * 9 Ditto –...
  • Page 326 25 ADJUSTMENT Initial Value DIPSW No. Function Japan Inch Metric Page memory allocation at power on * 19 * 19 Ditto * 19 * 19 Page memory allocation at job start * 28 * 28 – – – DIPSW10 – –...
  • Page 327 25 ADJUSTMENT Initial Value DIPSW No. Function Japan Inch Metric Size detection 5 (main unit) B4 · 11 x 17/ 8K/16K B5 · 8.5 x 11 – – – – – – Size detection 5 (by-pass feed) B4 · 11 x 17/ 8K/16K DIPSW14 B5 ·...
  • Page 328 25 ADJUSTMENT NOTE: Bit number of the initial value in parentheses is the initial value for 7085. Initial Value DIPSW No. Function Japan Inch Metric – – – Fixing temperature setting switching (7085 only) *35 Ditto DIPSW19 Ditto PZ faulty part isolation Normal Unavailable PU faulty part isolation...
  • Page 329 25 ADJUSTMENT Initial Value DIPSW No. Function Japan Inch Metric – – – Output operation when EKC user ID Enabled (counted by Disabled (registered unmatching (IP-601, IP-602) other user acaunt) non-output list) Toner density selection of developer Ditto Correspondence of firmware version up Older than 5.0 5.0 or later DIPSW23 of IP-601 (7075 only) Tray heater control during power on...
  • Page 330 25 ADJUSTMENT Initial Value DIPSW No. Function Japan Inch Metric – – – – – – – – – – – – DIPSW29 – – – – – – – – – SCSI parameter initialization when Not initialized Initialized HDD is connected (Note 1) (7075 only) –...
  • Page 331 25 ADJUSTMENT Initial Value DIPSW No. Function Japan Inch Metric Colored paper process control switchover *36 Ditto Ditto DIPSW34 Ditto (7085 only) Special paper process control switchover *36 Ditto Ditto Ditto High-quality paper process control switching *36 Ditto Ditto Ditto DIPSW35 Exclusive paper A process control switching *36 (7085 only)
  • Page 332 25 ADJUSTMENT * 1 Condition for stopping copying after indication of * 5 Electrode cleaning cycle (after power is turned toner supply request 7075 Mode Mode Stops after printing 1500 copies 20,000 copies Stops after printing 3000 copies 30,000 copies Stops after printing 4000 copies 40,000 copies...
  • Page 333 25 ADJUSTMENT * 8 Toner concentration threshold * 11 Transfer/separation corona unit output for thick paper This bit sets the read level of the toner concen- This bit is used when “Thick 1”, “Thick 2” or “Tab tration patch formed on the drum to determine paper”...
  • Page 334 25 ADJUSTMENT * 13 Transfer/separation corona unit output for recy- * 15 Fixing roller initial rotation cled paper (7075 only) Fixing may be insufficient in the morning if the This bit is used when “Recycle” is selected for temperature of the place where the machine is “Paper type/special size setting”...
  • Page 335 25 ADJUSTMENT * 18 Copy count limit * 23 Maximum number of sheets that can be stapled Mode Except for FS-111 No limit Mode 15-2 15-1 1 copy 50 sheets 3 copies 45 sheets 5 copies 40 sheets 9 copies 35 sheets 10 copies FS-111 (When the length in the paper feed di-...
  • Page 336 25 ADJUSTMENT Selection of discrimination level * For rectangular original density (dark original When the original is dark or external light (from /darker original) the fluorescent lamp or sun) enters the machine, Use this mode to set the density level it becomes sometimes difficult to discriminate threshhold value to the dark when copying a between the area inside the original and the area...
  • Page 337 25 ADJUSTMENT * 26 WT summer time setting Mode 10-2 No allocation. Mode 17-3 17-2 17-1 17-0 Allocated. 0 minute 10 minutes If DIP switches 10-0 and 10-1 are set to allocate 20 minutes the page memory, they take priority over this 30 minutes mode.
  • Page 338 25 ADJUSTMENT * 34 Developing potential control of image area (7085 * 36 Paper type process control switchover (7085 only) only) Setting method Change the charging potential and developing This bit is used when "-----," "Normal," "Recy- bias to decrease the developing potential of cled,"...

  • Page 339: Setting The Paper Size

    25 ADJUSTMENT [3] Setting the Paper Size Paper type (1) High-quality paper for printing press When the LCT paper type is changed, it must be stored in the main unit. This setting is effective when an op- This paper has only little difference in paper tional LCT is added.
  • Page 340 25 ADJUSTMENT Blank page MODEL MANUAL REVISED EDITION DATE PAGE METHOD 1 - 20 7075/7085 SERVICE HANDBOOK Jan. 2002 1-18-4 ADDITION...
  • Page 341 25 ADJUSTMENT Setting the non-standard size 3. Setting the wide paper Step Operation Step Operation Enter the 25 mode. Enter the 25 mode. [25 Mode Menu Selection] [25 Mode Menu Screen] Select Paper size setting. Select “ Tray Size Setting.” [Paper Size Setting Mode Screen] [Paper Size Setting Screen] Press the...

  • Page 342: Pm Count Resetting

    25 ADJUSTMENT [4] PM Count Resetting [5] Setting the PM Cycle Care should be taken not to reset the PM count by This function allows you to change the PM cycle. mistake. Caution: The PM cycle is factory-set. Use this function to change the factory-set PM Step Operation...
  • Page 343 25 ADJUSTMENT Blank page 1 - 19 1 - 19 - 2...

  • Page 344: Collecting Data

    25 ADJUSTMENT [6] Collecting Data Viewing Collecting Data No.1 to No.4 This function allows you to view various data retained Step Operation by the machine. Enter the 25 mode. Reference: The above data can also be viewed [25 Mode Menu Screen] using the data collection function of Select “...
  • Page 345 25 ADJUSTMENT Details on Display Data (1) Collecting data No.1 to No.3: Total/copy/print counts of each paper size KRDS parameter Destination Maximum count Remarks (B1, B6, B8) Japan Inch area Metric area 17x22 99999999 All counters are 8-digit counters. 11x17 99999999 8.5x14 B4 (8K)
  • Page 346 25 ADJUSTMENT (2) Collecting data No.4: RADF mode KRDS Maximum parameter Items Remarks count (F0) Number of originals fed in ADF mode 99999999 All counters are 8-digit counters. Number of originals fed in RADF mode 99999999 Number of 1-sided SDF original fed 99999999 Number of 2-sided SDF original fed 99999999...
  • Page 347 25 ADJUSTMENT (4) Collecting data No.6 (7075), No.8 (7085): JAM count / Collecting data No.10 (7075), No.11 (7085): JAM count of each section Description of jam position KRDS Code displayed Maximum display para- when display of Counting condition count Location of jam meter jam code is operation...
  • Page 348 25 ADJUSTMENT Description of jam position Code displayed KRDS Maximum display when display of para- Counting condition count Location of jam jam code is meter operation selected by 25- (J0) panel mode DIP switch 62-4 999999 62-5 999999 62-6 999999 62-7 999999 62-8...
  • Page 349 25 ADJUSTMENT Description of jam position Code displayed KRDS Maximum display when display of para- Counting condition count Location of jam jam code is meter operation selected by 25- (J0) panel mode DIP switch 71-2 999999 72-38 999999 72-39 999999 72-40 999999 72-41...
  • Page 350 25 ADJUSTMENT (5) Collecting Data No.7 (7075), No.9 (7085): Count of each copy mode KRDS Maximum parameter Item Counting condition count (F1) 1-1 mode 99999999 All counters are 8-digit counters. 1-2 mode 99999999 2-1 mode 99999999 2-2 mode 99999999 ADF1-1 mode 99999999 ADF1-2 mode 99999999...
  • Page 351 25 ADJUSTMENT KRDS Maximum parameter Item Counting condition count (F1) Sub-tray: Group (FACE DOWN) 99999999 All counters are 8-digit Sub-tray: Group (FACE UP) 99999999 counters. Sub-tray: Sort (FACE DOWN) 99999999 Sub-tray: Sort (FACE UP) 99999999 Sub-tray: Non sort (FACE DOWN) 99999999 Sub-tray: Non sort (FACE UP) 99999999...
  • Page 352 25 ADJUSTMENT KRDS Maximum parameter Item Counting condition count (F1) Preset magnification E2 99999999 All counters are 8-digit counters. Preset magnification E1 99999999 Preset magnification R4 99999999 Preset magnification R3 99999999 Preset magnification R2 99999999 Preset magnification R1 99999999 User lens mode 1 99999999 User lens mode 2 99999999...
  • Page 353 25 ADJUSTMENT KRDS Maximum parameter Item Counting condition count (F1) Numbering 99999999 Set quantity 1 99999999 Set quantity 2-5 99999999 Set quantity 6-10 99999999 Set quantity 11 or more 99999999 Time while power remote 1 is on 99999999 Total period of time dur- ing which image control board is energized (re- mote power supply 1 is...
  • Page 354 25 ADJUSTMENT KRDS Maximum parameter Item Counting condition count (F1) Time during warm up time 99999999 Total period of time dur- ing which fixing unit heater is ON when ma- chine is not ready for fus- ing. count incremented by 1 per second.
  • Page 355 25 ADJUSTMENT KRDS Maximum parameter Item Counting condition count (F1) Time during APS sensor on 99999999 Total period of time during which APS sensor is ON. The count is incremented by 1 per second. Data is output per minute. N of main tray used jobs 99999999 Job count N of sub tray tray used jobs...
  • Page 356 25 ADJUSTMENT KRDS Maximum parameter Item Counting condition count (F1) Wide paper count (A3W) 99999999 Wide paper count (A4W) 99999999 Wide paper count (A4RW) 99999999 Wide paper count (A5W) 99999999 Wide paper count (Others) 99999999 Punch 99999999 Z-Folding 99999999 Shift amount abnormality in repeat mode 99999999 MODEL MANUAL...
  • Page 357 25 ADJUSTMENT (6) Collecting data No.8 (7075), No.10 (7085), : SC count / Collecting data No.12: SC count of each section KRDS Trouble Maximum parameter Description Remarks count code (E0) Paper feed MT EM 9999 All counters are 4- digit counters. LCT conveyance MT EM 9999 Loop roller motor fuse blowing...
  • Page 358 25 ADJUSTMENT KRDS Trouble Maximum parameter Description Remarks count code (E0) Drum temperature sensor grounding 9999 error detection Drum heater open detection 1 (7075 only) 9999 Drum heater open error detection 2 (7075 only) 9999 Charging EM 9999 Transfer EM 9999 Separation EM 9999...
  • Page 359 25 ADJUSTMENT KRDS Trouble Maximum parameter Description Remarks count code (E0) Fixing upper roller high 9999 temperature error detection Fixing heat roller high 9999 temperature error detection Fixing upper roller low 9999 temperature error detection Fixing heat roller low 9999 temperature error detection Fixing upper roller sensor error 9999...
  • Page 360 25 ADJUSTMENT KRDS Trouble Maximum parameter Description Remarks count code (E0) Expansion device access error 9999 Compression device access error 9999 Filter factor error 9999 Memory in data flow 9999 Data flow memory mode 9999 SVV off error 9999 Black/white collection error 9999 Level adjustment error 9999...
  • Page 361 25 ADJUSTMENT KRDS Trouble Maximum parameter Description Remarks count code (E0) Printer control 12V detection 9999 Excessive AC voltage detection (7075 only) 9999 5V fuse blowing detection (7075 only) 9999 SD/MC fuse blowing detection 1 9999 SD/MC fuse blowing detection 9999 Initial communication failure 9999...
  • Page 362 25 ADJUSTMENT KRDS Trouble Maximum parameter Description Remarks count code (E0) Sheet feeder up motor driving error 9999 Sub-CPU reception error 9999 Main CPU reception error 9999 Printer control ISW not written 9999 VIF control ISW not write 9999 ISW time-out 9999 ISW data error 9999...
  • Page 363 25 ADJUSTMENT KRDS Trouble Maximum parameter Description Remarks count code (E0) Fan motor driving error (7085 only) 9999 Anti-taking fan motor error (7085 only) 9999 Write unit cooling fan /2MT EM1 (7085 only) 9999 Write unit cooling fan /2MT EM2 (7085 only) 9999 Write unit cooling fan /2MT EM3 (7085 only) 9999...
  • Page 364 25 ADJUSTMENT Blank page MODEL MANUAL REVISED EDITION DATE PAGE METHOD 1 - 38 7075/7085 SERVICE HANDBOOK Jan. 2002 1-36-2 ADDITION...

  • Page 365: Copy Count By Parts To Be Replaced (Fixed Parts)

    25 ADJUSTMENT [7] Copy Count by Parts to be Replaced (Fixed Parts) This function allows you to display or rest the copy count for a fixed part or data. Step Operation Enter the 25 mode. [25 Mode Menu Screen] Select “ Parts counter.”...
  • Page 366 25 ADJUSTMENT KRDS Maximum para- Part name Part No. Counting condition meter count (Z1) Charging grid 55VA2508 99999999 25DIPSW8-6 =0: Count 1 per ejected paper for single sided, 2 for double sided =1: For A3, 11x17, count 2 per ejected paper for single sided, 4 for double sided Charging unit cleaning 55VA-255...
  • Page 367 25 ADJUSTMENT KRDS Maximum para- Part name Part No. Counting condition meter count (Z1) Cleaning rollers 55VA5386 99999999 25DIPSW8-6 (7075) =0: Count 1 per ejected paper for single sided, Fixing Cleaning Sheet 56GA-547 2 for double sided (7085) =1: For A3, 11x17, count 2 per ejected paper for Temperature sensor 55VA-209 99999999...
  • Page 368 25 ADJUSTMENT KRDS Maximum para- Part name Part No. Counting condition meter count (Z1) Tray 1 feed count 55VA-400 99999999 1 is counted each time the paper from tray 1 is (7075) ejected. 56GA-400 (7085) Tray 2 feed roller 55VA-464 99999999 1 is counted each time the paper from tray 2 is ejected.
  • Page 369 25 ADJUSTMENT KRDS Maximum para- Part name Part No. Counting condition meter count (Z1) Tray 4 feed clutch 55VA8201 99999999 1 is counted each time the paper from LCT is (7075) ejected. 56AA8201 (7085) Tray 4 convey clutch 55VA8201 99999999 (7075) 56AA8201 (7085)
  • Page 370 25 ADJUSTMENT KRDS Maximum para- Part name Part No. Counting condition meter count (Z1) Saddle stitch stop M 129X8011 99999999 1 is counted each time paper is ejected in stapling and folding or folding mode. FNS folding motor 129U8004 99999999 FNS feed clutch(PI) 25SA8203 99999999 1 is counted each time PI cover sheet is ejected.
  • Page 371 25 ADJUSTMENT KRDS Maximum para- Part name Part No. Counting condition meter count (Z1) Door switch 40AA8501 99999999 1 is counted each time front door is opened. Web motor 55VA8017 99999999 1 is counted each time 1-sided paper is ejected; (7075) 2 is counted each time 2-sided paper is ejected.
  • Page 372 25 ADJUSTMENT Blank page 1 - 44...

  • Page 373: Copy Count By Parts To Be Replaced (Optional Parts)

    25 ADJUSTMENT [8] Copy Count by Parts to be Replaced Changing the data on the Copy Count by Parts to be Replaced (Optional Parts) (Optional Parts) This function allows you to change the limit value, This function allows you to make the following settings part number, or part name for the desired op- for an optional part or data: tional copy count by parts to be replaced (op-...

  • Page 374: Setting Passwords

    25 ADJUSTMENT [9] Setting Passwords Reference 1: The characters entered in the data field of each data This function allows you to set the following passwords: item will be shifted to the left one after another. 1. Key operator password (4 digits) Reference 2: This password is required to enter the key When the number of entered characters exceeds...

  • Page 375: Setting The Telephone Number And/Or Fax Number Of The Service Center

    25 ADJUSTMENT [10] Setting the Telephone Number and/ Reference 1: The digits entered in the data field of each data or Fax Number of the Service Center item will be shifted to the left one after another. This function allows you to set the telephone number Reference 2: and/or fax number of the service center displayed when When the number of entered digits exceeds 4 or...

  • Page 376: Setting The Serial Number

    25 ADJUSTMENT [11] Setting the Serial Number [13] Setting KRDS This function allows you to display, set, or change the KRDS enables to call the host computer from the copier serial number of the main unit or option. regularly or when any error occurs; query the various Serial number data can also be read from KRDS.

  • Page 377: Krds Set Up

    25 ADJUSTMENT [14] KRDS Set Up *1: Host password must be 5-digit. *2: Host password 1 must be specified. Step Operation *3: For both the copier and the host side, telephone number 1 must be specified. Turn off the modem, connect the copier to the *4: Refer to the manual of the modem about specifi- modem using a modem cable, and connect the cations for connecting with the modular cable.
  • Page 378 25 ADJUSTMENT Initializing KRDS Memory (1) Turn off the main switch of the copier. (2) Turn on the main switch while holding both the copy quantity setting button 4 and 7 simulta- neously. (3) Press the start print button after pressing the copy quantity setting button 1, 5 and P button, then 9, 8, finally P button again.
  • Page 379 25 ADJUSTMENT Blank page MODEL MANUAL REVISED EDITION DATE PAGE METHOD 1 - 51 7075/7085 SERVICE HANDBOOK Jan. 2002 1-49-2 ADDITION...
  • Page 380 25 ADJUSTMENT Setting KRDS software SW (1) Setting type of modem and line This function sets KRDS software switch. • Using the switch No. 01, enter the modem and Caution: Set the software switch while checking line data into the bits 0 to 7, referring to the the switch and bit number since the following table.
  • Page 381 25 ADJUSTMENT <List of KRDS Software DIP SW> Initial set value Bit Pattern Initial Value Function Description (Hexadecimal) byte bit 7 6 5 4 3 2 1 0 Select modem 0 0 0 0 0 0 0 No setting (No data is sent to modem.) 0 0 0 0 0 0 1 AT&FE0Q0V1X0S0=1&S0 0 0 0 0 0 1 0...
  • Page 382 25 ADJUSTMENT Bit Pattern Initial Value Function Description (Hexadecimal) byte bit 7 6 5 4 2 1 0 Set DTR signal operation No setting DTR signal &D0:Disregards DTR signal. ON: Can keep &D1:Turning ON to OFF of DTR signal status ready to results in command mode.
  • Page 383 25 ADJUSTMENT Bit Pattern Initial Value Function Description (Hexadecimal) byte bit 7 6 5 4 3 2 1 0 S10: Allowable carrier No setting stop time S10=:Effective data S11: Tone succession and No setting interval time in tone dialing S11=:Effective data don't Reserved care...
  • Page 384 25 ADJUSTMENT Bit Pattern Initial Value Function Description (Hexadecimal) byte bit 7 6 5 4 2 1 0 Set up flag not yet finished Redial interval 1 min. 3 min. 5 min. 7 min. Redial count no limit Delay after DTR ON/OFF –...
  • Page 385 25 ADJUSTMENT Bit Pattern Initial Value Function Description (Hexadecimal) byte bit 7 6 5 4 3 2 1 0 39 0-1 Reserved Don't care RS-232 line error copy enable PJ2 (Note 1) copy disable Modem AT command error copy enable FJ3 (Note 1) copy disable Communication error between...
  • Page 386 25 ADJUSTMENT Setting host password Step Operation This function sets host password. Enter the 25 mode. • Up to 2 types can be set as host passwords. [25 mode Menu Screen] (1) Screen selection Press KRDS setting. Select KRDS setting in the 25 Mode Menu [KRDS Setting Screen] Screen to display KRDS Setting Screen as an Host password setting.
  • Page 387 25 ADJUSTMENT Calling KRDS set up (2) Setting method a. Select an iterm to enter. <Auto set up> b. Enter 20 or less characters of digits and alphabet In the host call setting, call the designated host letters from the alphanumeric keypad on the computer in the set date and time, and transmit screen.
  • Page 388 25 ADJUSTMENT • Operation for the host computer Step Operation For the operation of the host computer, refer Enter the 25 mode. to the KRDS Host Application Administrator’s [25 mode Menu Screen] Manual. Press KRDS setting. [KRDS Setting Screen] Press the KRDS software switch setting.

  • Page 389: Calling Time Setting Menu Mode (Arbitrary)

    25 ADJUSTMENT [15] Calling Time Setting Menu Mode • Selecting key displays the setting Change (Arbitrary) screen for the associated function. Refer to Transmit the serial number and telephone number data (1) thru (3). of the copier to the KRDS host computer for automatic (3) End of setting registration.
  • Page 390 25 ADJUSTMENT Setting regular date & time calling Step Operation Press key associated Change Enter the 25 mode. with key on the Calling Regular date & time [25 mode Menu Screen] Time Setting Screen to display the Regular Date & Time Call Setting Screen. Press KRDS setting.
  • Page 391 25 ADJUSTMENT (3) Setting the day, day of the week, and time (i) When the every month mode is selected: (a) Press key associated with the desired Change Step Operation mode. Using the numeric keys on the screen, enter (b) Enter a day of the week, hour, and minute using “day”...

  • Page 392: Krds Host Calling

    25 ADJUSTMENT Setting regular count calling [16] KRDS Host Calling If KRDS is connected, the key operator can call Press key associated with Change the host in the service center. key on the Calling Time Setting Regular count (a) Select one of the items shown below according to Screen to display the Regular Count Call the situation: Setting Screen.

  • Page 393: Reference

    25 ADJUSTMENT [17] Reference ASCII is 1 byte code specified by ANSI. It enables to indicate control code, alphabet and number. character binary hexadecimal character binary hexadecimal character binary hexadecimal character binary hexadecimal 0000 0000 0010 0000 0100 0000 ‘ 0110 0000 0000 0001 0010 0001...

  • Page 394: Data To Be Processed

    25 ADJUSTMENT [18] Data to be Processed • For the data that KRDS can process, refer to the Service Hand Book for copier, [6] collecting Data in the 25 mode “Adjustments”. • You can refer to the data that KRDS can process.

  • Page 395: Error Code Table

    25 ADJUSTMENT [20] Error Code Table Error Code Contents Countermeasure K00_00 Connection NG. (No CONNECT from modem, Time out.) Redial, repeat reception standby. K00_01 No response from other party. Redial, repeat reception standby. (No detection of start text from host after establishing connection.) K00_02 Because copying is taking place, it is impossible to write to the Temporarily stop copying.
  • Page 396 25 ADJUSTMENT Blank page MODEL MANUAL REVISED EDITION DATE PAGE METHOD 1 - 66 7075/7085 SERVICE HANDBOOK Jan. 2002 1-64-2 ADDITION...

  • Page 397: List Of Adjustment Items In The 25 Mode

    25 ADJUSTMENT [21] List of Adjustment Items in the 25 Mode Adjustment Item Menu Remarks Software SW setting. See “List of Software DIP Switches.” Paper size setting PM count Resetting PM Count Setting PM Cycle Data collection Total count of each paper size Copy count of each paper size Print count of each paper size RADF count...

  • Page 398: Mode

    36 ADJUSTMENT 36 MODE [1] Setting Method [2] High Voltage Adjustment A special adjustment mode called the 36 Mode is pro- Adjusting the high voltage for charging, transfer, sepa- vided. This mode is used to perform various adjust- ration, and development. ments.

  • Page 399: High Voltage Adjustment

    36 ADJUSTMENT High Voltage Auto Adjustment High Voltage Adjustment (Charge) Charging, separation (AC), separation (DC), de- High Voltage Adjustment (Charge) is inhibited in velopment bias current and voltage are adjusted the field. in sequence. Preparation: Be sure the drum frame is set. High Voltage Adjustment (Transfer) Default setting value must be set under the Step...

  • Page 400: Drum Peculiarity Adjustment

    36 ADJUSTMENT Blade setting mode [3] Drum Peculiarity Adjustment In this mode, toner stuck on the drum surface Adjusting the blade set, drum potential, maximum den- during replacement of the cleaning blade or drum sity (Dmax), dot diameter, laser offset and gamma. is removed to prevent damage to the drum and Select Process adjustment in the 36 Mode...
  • Page 401 36 ADJUSTMENT Auto drum potential adjustment Auto maximum density adjustment Automatically adjusting the development bias and (Dmax adjustment) drum applied voltage by measuring the drum po- Automatically adjusting maximum density tential. (Dmax). This adjustment should be performed when the This adjustment should be performed when the drum or developer is replaced.
  • Page 402 36 ADJUSTMENT LD1 offset adjustment Auto dot diameter adjustment Adjusting the LD1 laser write position. Automatically adjusting the dot diameter. This adjustment should be performed when the This adjustment should be performed when the drum or developer is replaced. (Adjusting 400 dpi drum, developer, write unit, or dust-proof glass and 600 dpi must be completed for 7085.) is replaced.
  • Page 403 36 ADJUSTMENT Step Operation Check the test pattern. If the specification is not satisfied, press Specification: The density of test pat- the C button while pressing the P but- tern image resulting from two laser out- ton. put (vertical and horizontal scanning) [LD1 offset adjustment Screen] must be even vertically and horizontally Enter an offset value using the numeric...
  • Page 404 36 ADJUSTMENT LD1 bias adjustment (7085 only) 10. Auto Gamma Adjustment (1 dot) LD1 bias adjustment is not performed in the field. Performing gamma adjustment automatically. This adjustment should be performed when the LD2 bias adjustment (7085 only) drum, developer, write unit, or dust-proof glass LD2 bias adjustment is not performed in the field.

  • Page 405: Drum Characteristic Adjustment (Manual)

    36 ADJUSTMENT 11. Cartridge set mode [4] Drum Characteristic Adjustment This adjustment should be performed when black (manual) dots appear on the copy after the drum removing Maximum density adjustment and installing. Maximum density manual adjustment should be performed under the guidance of Konica Tech- Step Operation nology Support Center.
  • Page 406 36 ADJUSTMENT Blank page MODEL MANUAL REVISED EDITION DATE PAGE METHOD 1 - 74 7075/7085 SERVICE HANDBOOK Jan. 2002 1-72-2 ADDITION...

  • Page 407: Recall Standard Data (Process Adjustment)

    36 ADJUSTMENT [6] Recall Standard Data (Process [7] Tray Adjustment Adjustment) This adjustment should be performed when the Restoring process adjustment settings to stand- tray or by-pass unit is replaced. ard values (data after process adjustment). Step Operation Enter the 36 mode. Step Operation [36 Mode Menu Screen]...

  • Page 408: Magnification Adjustment

    36 ADJUSTMENT Printer vertical magnification adjustment [8] Magnification Adjustment Adjusting the printer vertical magnification. Adjusting the printer and copy vertical and horizontal magnifications. Step Operation Select Image adjustment in the 36 Mode Menu Enter the 36 mode. Screen to display the Image adjustment mode [36 Mode Menu Screen] menu Screen.
  • Page 409 36 ADJUSTMENT Printer horizontal magnification adjust- Scanner (platen) vertical adjustment ment Adjusting vertical magnification during platen copy. Adjusting the printer horizontal magnification. Caution: There is no horizontal magnification adjustment for the scanner. Step Operation Enter the 36 mode. Step Operation [36 Mode Menu Screen] Enter the 36 mode.
  • Page 410 36 ADJUSTMENT Scanner (RADF) vertical magnification [RADF drum clock Adjustment Screen] adjustment Enter a value with the numeric keys and Adjusting vertical magnification during RADF press the key. copy. Setting range: -40 to +40 1 step=0.05% Step Operation Repeat steps 5 to 11 until the specifica- Enter the 36 mode.

  • Page 411: Timing Adjustment

    36 ADJUSTMENT [9] Timing Adjustment Step Operation Adjusting the leading edge timing (paper feed restart Enter the 36 mode. timing), registration loop amount, and leading edge [36 Mode Menu Screen] erase amount. Press “ Image adjustment.” Select Image adjustment in the 36 Mode [Image adjustment mode menu Screen] Menu Screen to display the Image adjustment Press “...
  • Page 412 36 ADJUSTMENT Printer regist loop adjustment Printer pre-regist adjustment Adjusting the printer regist loop amount for trays Adjusting the pre-regist for tray 1, tray 2, tray 3, (tray 1, 2, 3), by-pass tray, and ADU. tray 4 (LCT), and ADU. Step Operation Step...
  • Page 413 36 ADJUSTMENT Printer lead edge timing adjustment Scanner restart timing adjustment Adjusting the printer lead edge timing (Image Adjusting the scanner restart timing during platen erasure amount). copy. Caution: Printer restart timing adjustment must Step Operation be completed before performing this Enter the 36 mode.
  • Page 414 36 ADJUSTMENT RADF restart timing adjustment RADF regist loop adjustment Adjusting the scanner restart timing during RADF Adjusting the regist loop amount during RADF copy. copy. Caution: Printer restart timing adjustment must Caution: Printer restart timing adjustment must be completed before performing this be completed before performing this adjustment.

  • Page 415: Radf Adjustment

    36 ADJUSTMENT [10] RADF Adjustment RADF density adjustment Performing RADF density adjustment, RADF original When the original reader slit glass is replaced, size adjustment, RADF sensitivity adjustment, and the density when reading original with RADF must RADF skew offset adjustment. be adjusted.
  • Page 416 36 ADJUSTMENT RADF original size adjustment RADF sensor sensitivity adjustment Perform this adjustment when the RADF origi- Perform this adjustment when replacing the nal size detection does not operate properly or RADF control board. when replacing the RADF control board. Caution: RADF original size adjustment consists Step Operation...

  • Page 417: Centering Adjustment

    36 ADJUSTMENT RADF skew offset adjustment [11] Centering Adjustment Perform this adjustment when replacing the Perform this adjustment to center the image in the pa- RADF control board. per feed direction. Select Image adjustment in the 36 Mode Menu Step Operation Screen to display the Image Adjustment Menu Enter the 36 mode.
  • Page 418 36 ADJUSTMENT Printer Centering Adjustment Scanner centering adjustment Adjusting the printer centering. Adjusting the scanner (platen) centering. Preparation: Printer centering adjustment must Step Operation be completed before performing Enter the 36 mode. this adjustment. [36 Mode Menu Screen] Press “ Image adjustment.”...

  • Page 419: Distortion Adjustment (Copier)

    36 ADJUSTMENT RADF centering adjustment [12] Distortion Adjustment (Copier) Adjusting the RADF copy centering. This is to correct distortion during platen/RADF The adjustment items are as follows: copying. There are four adjustment items for • Small size front side(B5R) warp correction: •...

  • Page 420: Non-Image Area Erase Check (7085 Only)

    36 ADJUSTMENT [13] Non-image area erase check (7085 <Error message 2> only) A datum with potential not to function non-image- area-erase is found. When this machine is installed in a place or is moved Please confirm “adjustment” - “36 mode” columns to another location, research should be conducted on of the Service Hand book.

  • Page 421: Running Test Mode

    36 ADJUSTMENT [15] Running Test Mode [16] Test pattern output mode Testing continuous copy operation. Output test pattern. Select Running Test Mode in the 36 Mode Menu Select [4] Test pattern output mode in the 36 Mode Screen. Menu Screen to display the Test Pattern Output Mode This adjustment consists of the following items: Screen.
  • Page 422 36 ADJUSTMENT No. 1 Overall halftone [Check item] • When density is set to 70 (halftone) If there are white stripes, black stripes, or uneven density, determine whether the fault is with the scanner or the printer. • When density is set to 0 (white) If the test pattern is blurred, determine whether the fault is with the scanner or the printer.
  • Page 423 36 ADJUSTMENT No. 2 Gray scale pattern [Check Item] If the test pattern is blurred or the density is light, determine whether the fault is with the processing system or with γ correction. If the copy image is abnormal despite this test pattern being normal, either the image processing system or the scanner system is abnormal.
  • Page 424 36 ADJUSTMENT No. 3 Gray scale pattern [Check item] If the test pattern is abnormal, check whether the two lasers are emitting light normally. Test patterns 1 - 90...
  • Page 425 36 ADJUSTMENT No. 5 Gray scale pattern [Check Item] If the test pattern is abnormal, check whether the two laser outputs are uniform. Test patterns LD-2 LD-1 1 - 91...
  • Page 426 36 ADJUSTMENT No. 11 Beam misalignment check [Check Item] If the test pattern is abnormal, check to see if position correction of the two laser beams is normal. Test patterns 1 - 92...
  • Page 427 36 ADJUSTMENT No. 16 Linearity evaluation pattern [Check Item] Use this test pattern to determine whether the fault is with the scanner or the printer. The printer horizontal magnification, vertical magnification, tilt, and leading edge timing can be checked. If the copy image is defective despite no abnormality in the test pattern, the scanner is at fault.

  • Page 428: Test Pattern Density Setting

    36 ADJUSTMENT [18] Finisher adjustment [17] Test pattern density setting Adjusting the finisher, cover sheet tray, and trimmer. Setting the test pattern density. Select Finisher adjustment on the 36 Mode Select Test pattern density setting in the 36 Mode Menu Screen to display the Finisher adjustment Menu Screen to display the Test pattern density set- mode menu Screen.
  • Page 429 36 ADJUSTMENT Stapling and Folding stopper adjustment Folding stopper adjustment (FS-108BM/211 only) (FS-108BM/211 only) Adjusting the stapling position when stapling and Adjusting the folding position when stapling and folding mode. folding or folding mode. Step Operation Step Operation Enter the 36 mode. Enter the 36 mode.
  • Page 430 36 ADJUSTMENT Cover sheet tray size adjustment Trimming stopper adjustment (PI-108 only) (TU-108 only) This adjustment should be performed when the Adjusting the trimming amount. cover sheet tray size cannot be detected prop- erly. Step Operation Enter the 36 mode. Step Operation [36 Mode Menu Screen]...
  • Page 431 36 ADJUSTMENT Punch vertical position adjustment Punch horizontal position adjustment (PU-108/PZ-108 only) (PU-108/PZ-108 only) Adjusting the puncing position(vertical). Adjusting the puncing position(horizontal). Step Operation Step Operation Enter the 36 mode. Enter the 36 mode. [36 Mode Menu Screen] [36 Mode Menu Screen] Press “...
  • Page 432 36 ADJUSTMENT Punch registration loop adjustment 1st Z-folding position adjustment (PU-108/PZ-108 only) (PZ-108 only) Adjusting the registration loop amount. Adjusting the position at which the 1st Z-foldi ng is performed. Step Operation Enter the 36 mode. Step Operation [36 Mode Menu Screen] Enter the 36 mode.

  • Page 433: List Output Mode

    36 ADJUSTMENT [19] List Output Mode 2nd Z-folding position adjustment (PZ-108 only) Outputing various data. Adjusting the position at which the 2nd Z-foldi Select “ List output mode” in the 36 Mode ng is performed. Menu Screen to display the List output mode menu Screen.

  • Page 434: Tandem Mode Initial Setting (7075 Only)

    36 ADJUSTMENT [20] Tandem mode initial setting (7075 only) This identifies tandem connection. For details on how to connect tandem, refer to the un- packing and installation procedure for the main body. MODEL MANUAL REVISED EDITION DATE PAGE METHOD 1 - 96 7075/7085 SERVICE HANDBOOK Jan.

  • Page 435: Mode

    47 ADJUSTMENT 47 MODE [1] 47 Mode/Multi Mode Setting Method Step Operation 47 mode Turn on the main switch while holding This mode provides self-diagnostic functions (in- down 4 and 7 of the copy quantity but- put/output check function) to check and adjust ton.
  • Page 436 47 ADJUSTMENT Multi mode Step Operation This mode is entered from the 47 mode. It ena- Enter the 47 mode. bles multiple I/O checks using a single I/O check [47 Mode (I/O Check Mode) Screen] code. Use the copy quantity button and enter the code.

  • Page 437: Adjustment Data Display

    47 ADJUSTMENT [2] Adjustment Data Display (1) When the total capacity of the hard Displaying a list of machine adjustment values disk is checked (factory-set values and current values). The total capacity of the hard disk is No adjustment (data value change) can be made displayed after “OUT:”...

  • Page 438: Input Checklist

    47 ADJUSTMENT [4] Input checklist Code Symbol M u l t i Display and Classi- Signal Source Name mode fication Remaining toner detection signal Empty Drum (internal) temperature detection signal Fixing upper roller temperature detection signal Heat roller temperature detection signal Humidity sensor signal Dmax MONI signal Dmax signal...
  • Page 439 47 ADJUSTMENT Display and Classi- Code Symbol M u l t i Signal Source Name fication mode PS20 Tray 1 upper limit detection signal PS21 Tray 2 upper limit detection signal PS22 Tray 3 upper limit detection signal PS23 By-pass feed tray upper limit detection signal PS43 By-pass feed tray lower limit detection signal PS109...
  • Page 440 47 ADJUSTMENT Display and Classi- Code Symbol M u l t i Signal Source Name fication mode PS62 APS sensor 1 detection signal PS63 APS sensor 2 detection signal PS64 APS sensor 3 detection signal PS65 APS sensor 4 detection signal PS66 APS sensor 5 detection signal PS67...
  • Page 441 47 ADJUSTMENT Display and Classi- Code Symbol M u l t i Signal Source Name fication mode PS20 16:Stacker no paper detection PS21 17:Stapling and folding stopper release motor HP PS22 18:Folding knife HP PS23 19:Stapling and folding stopper HP PS24 20:Alignment plate/lower HP PS25...
  • Page 442 47 ADJUSTMENT Display and Classi- Code Symbol M u l t i Signal Source Name fication mode PS208 54:Sheet set PS209 55:Pre no paper PS201 56:Sheet passage no paper with paper PS202 57:No sheet PS203 58:Sheet tray lower limit PS204 59:Sheet tray upper limit PS205 60:Sheet size (small)

  • Page 443: Output Checklist

    47 ADJUSTMENT [5] Output checklist Cannot be set Code Symbol M u l t i Classi- Name or changed in fication mode field *1 Exposure lamp Toner supply motor ∞ Charging corona unit ∞ Transfer corona unit Separation corona unit (AC+DC) ∞...
  • Page 444 47 ADJUSTMENT Classi- Code Symbol M u l t i Cannot be set Name fication mode or changed in field *1 Scanner drive motor *2 Polygon motor 0: 400 dpi 1:600dpi *3 Shading correction 0: 400 dpi (7075 only) 1:600dpi Main motor Drum drive motor Fan motor...
  • Page 445 47 ADJUSTMENT Cannot be set Classi- Code Symbol M u l t i Name or changed in fication mode field Drum/developing/blade motor M2/M3/M14 Toner supply motor/1 Message test JAMIB Jam indicator board LED test (turn on all lights) Drive M302 1: Original feed motor (forward) M302 2: Original feed motor (backward)
  • Page 446 47 ADJUSTMENT Cannot be set Classi- Code Symbol M u l t i Name or changed in fication mode field 21: Alignment plate motor/lower (HP search) 22: Folding stopper motor (HP search) 23: Folding knife motor (HP search) 24: Folding conveyance motor 25: Stapling and folding stopper release motor (HP search) 26: Stapling and folding stopper release motor (set) 27: Stapling and folding stopper release motor (release)
  • Page 447 47 ADJUSTMENT Cannot be set Classi- Code Symbol M u l t i Name or changed in fication mode field M106 71: Holder motor (Move to lower limit) 72:Main motor M1,M6 72:Registration motor and conveyance motor 73:1st stopper motor (HP search) PU/PZ 74:2nd stopper motor (HP search) 75:Gate Solenoid/U...
  • Page 448 47 ADJUSTMENT Cannot be set Code Symbol M u l t i Classi- Name or changed in mode fication field 1: Paper gate solenoid 2: ADU lock solenoid 3: Fixing guide solenoid ADU paper feed MS Pre-transfer roller drive motor Second paper feed motor ADU reversal motor 1: Fast forward 2: Slow forward 3: Fast backward...

  • Page 449: Other Adjustments

    OTHER ADJUSTMENT OTHER ADJUSTMENTS [1] Centering Adjustment Adjustment method Caution: Centering adjustment need not be Step Operation performed normally because paper Draw out the tray. inclination is detected in the second Loosen the two screws at the center of paper feed section and original image the tray.
  • Page 450 OTHER ADJUSTMENT LCT tray centering adjustment a. Adjustment method Step Operation Guide plate/front Guide plate/rear Raise the up/down plate. Open the top cover. Remove the four screws to detach the side cover (right). Screws Screws Screws Screws Side cover Center positioning (right) Screws bracket...
  • Page 451 OTHER ADJUSTMENT Setting the LCT Rear Guide Standard value of mis-centering: within 3 mm (LT-411/412 only) Screws Rear guide Within 3 mm Center of image Center of paper Rear guide Screw Adjustment Method Step Operation Open the top cover. Press the SW100( LT tray down switch) to lower the up/down plate to the bot- tom.

  • Page 452: Paper Feed Roller Load Adjustment

    OTHER ADJUSTMENT [2] Paper Feed Roller Load Adjustment LCT paper feed roller load adjustments (LT-411/412 only) (7085 main body tray only) Caution: This adjustment is required when no feed of paper occurs. Spring Screws Tool • Screwdriver (Phillips) Paper feed roller load adjustment on trays 1, 2, 3 Weight plate Screws...

  • Page 453: Paper Up/Down Plate Horizontal Adjustment

    OTHER ADJUSTMENT [3] Paper up/down plate horizontal adjustment Caution: Paper up/down plate horizontal adjustment must be carried out when a paper feed jam occurs frequently or after replacement of the up/down wires of a tray. Tool • Screwdriver (Phillips) Tray 1/2/3 paper up/down plate horizontality adjustment.
  • Page 454 OTHER ADJUSTMENT LCT Up/Down Plate Horizontality Adjust- Adjustment Method ment Step Operation To remove the tray with the up/down plate up, set the tray with a small thing Screws (eraser, etc.) inserted under the up/down drive linkage lever. Up/down plate Up/down pulley Adjusting screws...
  • Page 455 OTHER ADJUSTMENT Adjustment Method Remove the two screws (LT-401/411) or Step Operation three screws (LT-402/412) to detach the Raise the up/down plate. clutch replacement cover. Open the top cover. Remove four screws (LT-401/411) or five Clutch replacement cover screws (LT-402/412) and detach the side cover/right.

  • Page 456: Skew Adjustment

    OTHER ADJUSTMENT [4] Skew Adjustment 3. LCT Skew Adjustment Caution: Skew adjustment is required when the paper supplied from the current tray is Adjustment Method (when All Printed different from the paper supplied from Sheets are Skewed) other trays in the way it is skewed. However, this adjustment has little ef- Step Operation...
  • Page 457 OTHER ADJUSTMENT ADU (Rear side) Skew Adjustment Adjustment Method (when Some of Printed Sheets are Skewed Irregularly) Adjustment Method Step Operation Print a test pattern (No.16) in the con- Step Operation tinuous copy mode to check for skew. Draw out the ADU stand and detach the Remove the side cover (right).
  • Page 458 OTHER ADJUSTMENT Blank page 1 - 112 - 2 1 - 114...

  • Page 459: Tray Spring Pressure Adjustment

    OTHER ADJUSTMENT [5] Tray Spring Pressure Adjustment Bypass paper feed spring pressure ad- justment Caution: Tray spring pressure adjustment must be performed when no feed or double feed of paper occurs. Tray spring pressure may be affected by a type of paper used or operating environment (under the low temperature condition, no feed of paper tends to occur.

  • Page 460: Paper Feed Height (Upper Limit) Adjustment

    OTHER ADJUSTMENT [6] Paper Feed Height (Upper Limit) LCT spring pressure adjustment Adjustment Caution 1: Paper feed height (upper limit) adjustment must be performed Spring when no paper feed occurs, when the leading edge of the fed paper is folded or when a convexly curled paper is fed.
  • Page 461 OTHER ADJUSTMENT Adjustment method Remove the two screws securing the sensor mounting bracket and install them Step Operation in the outside mounting holes (oblong To draw out the tray with the paper up/ holes) temporarily. down plate held up, set the tray with a <When the heights are not within eraser or the like inserted under the specifications>...
  • Page 462 OTHER ADJUSTMENT Adjustment method Remove the two screws securing the sensor mounting bracket and install then Step Operation in the outside mounting holes (oblong Move the paper up/down plate up. holes) temporarily. Open the top cover. <When the heights are not within Measure the distance between the top specifications>...

  • Page 463: Pick-Up Release Amount Adjustment

    OTHER ADJUSTMENT [7] Pick-up Release Amount a. Adjustment method Adjustment Step Operation Caution: Pick-up release amount adjustment To draw the tray with the paper up/down must be performed when a no-feed plate held up, set the tray with a eraser jam occurs frequently.
  • Page 464 OTHER ADJUSTMENT Adjustment of pick-up release amount of Adjustment method Step Operation Move the paper up/down plate up. Paper feed roller Open the top cover. Remove the spring from the paper feed roller unit. Top cover Spring Up/down plate Pick-up solenoid Remove Paper feed roller unit...

  • Page 465: Radf Mounting Position Adjustment

    OTHER ADJUSTMENT If both stopper pieces do not touch the [8] RADF Mounting Position Adjustment slit glass, make adjustments using ad- Tool justing screws A and B alternately. • Screwdriver (Phillips) Perform steps 2 and 3 repeatedly until the two stopper pieces touch the slit Adjustment method glass at the same time.

  • Page 466: Radf Skew Adjustment

    OTHER ADJUSTMENT [9] RADF Skew Adjustment Close the RADF, turn the skew Tools adjustment screws and adjust the skew. For skew pattern A: • Screwdriver (Phillips) Turn the skew adjustment screw Adjustment method counterclockwise. For skew pattern B: Turn the skew adjustment screw clockwise.

  • Page 467: Radf Paper Skew Adjustment

    OTHER ADJUSTMENT [10] RADF Paper Skew Adjustment Step Operation Face side (side 1) of original paper skew Move the registration pulley bracket one calibration in the direction below Note: Always perform this adjustment after according to the paper skew pattern. completing the RADF skew adjustment.
  • Page 468 OTHER ADJUSTMENT Back side (side 2) of original paper skew Step Operation adjustment Move the R range adjustment plate one calibration in the direction below according to the paper skew pattern. Open/close cover For skew in pattern A: Move the R range adjustment plate to left side.

  • Page 469: Radf Hinge Spring Pressure Adjustment

    OTHER ADJUSTMENT [11] RADF Hinge Spring Pressure Step Operation Adjustment Close the RADF. Tools Loosen the nut on the left side and the • Screwdriver (slotted) nut on the right side. • Wrench or flat-nose pliers Open the RADF. Turn the adjusting screws to adjust the Adjustment method pressure of hinge springs.

  • Page 470: Fns Adjusting The Magnets On Conveyance Guide Plate B

    OTHER ADJUSTMENT [12] FNS Adjusting the Magnets on (4) Remove the E-ring and the gear. Conveyance Guide Plate B (5) Adhere the magnets to conveyance guide plate A 1. Tool used and retighten the set screws. • Screwdriver (Phillips) Magnet 2.

  • Page 471: Fns Adjusting The Magnets On Conveyance Guide Plate C

    OTHER ADJUSTMENT [13] FNS Adjusting the Magnets on (4) Adhere the magnets to conveyance guide plate A Conveyance Guide Plate C and retighten the screws. 1. Tool used Magnet • Screwdriver (Phillips) (rear) Magnet (front) 2. Preparation (1) Open the front cover. (2) Check whether conveyance guide plate C makes contact with the cushioning rubber when the magnets are stuck to conveyance guide plate D.

  • Page 472: Fns Adjusting The Sub-Tray Paper Exit Gate

    OTHER ADJUSTMENT [14] FNS Adjusting the Sub-tray Paper (4) With SD2 ON, measure the gap between the Exit Gate solenoid plunger and the bracket stopper (indi- 1. Tools used cated by B in the illustration). • Screwdriver (Phillips) Spec value for gap: B = 5 ±0.5mm. •...

  • Page 473: Fns Adjusting The Paper-Path Switching Gate

    OTHER ADJUSTMENT [15] FNS Adjusting the Paper-Path (4) With SD1 (gate) ON, measure the distance be- Switching Gate tween the long gate and the guide plate, indicated 1. Tools used by A in the illustration. • Screwdriver (Phillips) Spec value for distance: A = 7.6±0.5mm. •...

  • Page 474: Fns Adjusting The By-Pass Gate

    OTHER ADJUSTMENT [16] FNS Adjusting the By-pass Gate (4) Remove the wirings from the clamps, and move 1. Tools used the FNS CB together with its bracket. • Screwdriver (Phillips) • Scale Clamps 2. Preparation (1) Remove the rear cover. Clamps (2) Open the front cover and the guide plate.
  • Page 475 OTHER ADJUSTMENT 3. Adjustment Procedure (1) Loosen the 2 set screws holding the solenoid in place, and move the solenoid as necessary to adjust. Solenoid Screws (2) Retighten the screws. (3) Reassemble in the opposite sequence to re- moval. 1 - 129...

  • Page 476: Fns Adjusting The Shift Position

    OTHER ADJUSTMENT [17] FNS Adjusting the Shift Position 3. Adjustment Procedure 1. Tool used (1) Loosen the screw holding the PS18 (roller shift • Screwdriver (Phillips) HP) bracket in place, and adjust the bracket position as necessary. 2. Preparation (1) Remove the following parts. Screw •...

  • Page 477: Fns Adjusting Opening/Closing At The Paper Exit

    OTHER ADJUSTMENT [18] FNS Adjusting Opening/Closing at 3. Adjustment Procedure the Paper Exit (1) Loosen the set screw holding the PS12 (paper 1. Tool used exit-opening detector) bracket in place, and ad- • Screwdriver (Philips) just the bracket position as necessary. 2.

  • Page 478: Fns Adjusting The Paper Exit-Opening Solenoid

    OTHER ADJUSTMENT [19] FNS Adjusting the Paper Exit- 3. Adjustment Procedure Opening Solenoid (1) Remove the 2 set screws holding the solenoid 1. Tools used bracket in place, and remove the solenoid to- • Screwdriver (Phillips) gether with the bracket. •...

  • Page 479: Fns Adjusting The Paper Exit-Opening Lower Guide Plate

    OTHER ADJUSTMENT [20] FNS Adjusting the Paper Exit- (3) Hold down the paper exit-opening lower guide Opening Lower Guide Plate plate with your hand so that the paper exit roller 1. Tools used makes contact, and check that the remaining •...

  • Page 480: Fns Adjusting The Mount Location Of The Paper Exit Arm

    OTHER ADJUSTMENT [21] FNS Adjusting the Mount Location [22] FNS Adjusting the Mount Location of the Paper Exit Arm of the Upper Alignment Plates 1. Tools used 1. Tools used • Screwdriver (Phillips) • Screwdriver (Phillips) • Scale 2. Adjustment Procedure 2.

  • Page 481: Fns Adjusting The Tension Of The Upper Alignment Plate Drive Timing Belt

    OTHER ADJUSTMENT [23] FNS Adjusting the Tension of the (2) Loosen the 2 set screws fixing the upper align- Upper Alignment Plate Drive Timing ment plates in place (one screw on each plate), Belt and adjust the plates so that distances A and B 1.

  • Page 482: Fns Adjusting The Mount Location Of The Lower Alignment Plates (Fs-108Bm/211 Only)

    OTHER ADJUSTMENT [24] FNS Adjusting the Mount Location (2) Loosen the 2 set screws fixing the lower align- of the Lower Alignment Plates ment plates in place (one screw on each plate), (FS-108BM/211 only) and adjust the plates so that distances A and B 1.

  • Page 483: Fns Adjusting The Tension Of The Lower Alignment Plate Drive Timing Belt (Fs-108Bm/211 Only)

    OTHER ADJUSTMENT [25] FNS Adjusting the Tension of the [26] FNS Adjusting the Stapling Position Lower Alignment Plate Drive Timing (Flat Stapling) Belt (FS-108BM/211 only) 1. Tools used 1. Tool used • Screwdriver (Phillips) • Scale • Screwdriver (Phillips) 2. Preparation 2.

  • Page 484: Fns Adjusting The Stapler Vertical Positioning (Fs-108/108Bm/211 Only)

    OTHER ADJUSTMENT 3. Adjustment Procedure [27] FNS Adjusting the Stapler Vertical Positioning (FS-108/108BM/211 only) (1) Loosen the 3 set screws holding the flat-stapling 1. Tools used stopper bracket in place, and position the bracket • Screwdriver (Phillips) so that distance A is within the specification •...
  • Page 485 OTHER ADJUSTMENT (4) Remove the cartridge, and install the plate that you took from the jig. Clincher Clincher unit Cartridge Plate Guide pin hole Caution: The positioning portion of the jig need not be engaged with the (5) Install the cartridge. clincher completely.

  • Page 486: Fns Adjusting The Angle Of The Stapling Stopper (Fs-108Bm/211 Only)

    OTHER ADJUSTMENT [28] FNS Adjusting the Angle of the Groove Stapling Stopper (FS-108BM/211 Plate only) 1. Tool used • Screwdriver (Phillips) 2. Preparation (1) If the staple orientation is not parallel with the paper edge, adjust as described below. Adjustment Procedure Stapler (1) Open the front cover and pull the stacker/stapler unit part of the way out.
  • Page 487 OTHER ADJUSTMENT (3) Remove the 4 set screws holding the cover in place, and remove the cover. Screws Cover Screws (4) Loosen 4 more set screws. (5) Rotate the stapling and folding stopper assembly as necessary to adjust the alignment. Scale Screws (6) Retighten the screws.

  • Page 488: Fns Adjusting The Angle Of The Folding Stopper (Fs-108Bm/211 Only)

    OTHER ADJUSTMENT [29] FNS Adjusting the Angle of the Adjustment Procedure Folding Stopper (FS-108BM/211 only) (1) Take a fold sample using A3 paper. 1. Tools used (2) Check the discrepancy along the folded set’s • Screwdriver (Phillips) trailing edge, and use this information to judge •...

  • Page 489: Fns Adjusting The Tension Of The Stapler-Movement Timing Belt (Fs-108/108Bm/ 211 Only)

    OTHER ADJUSTMENT [30] FNS Adjusting the Tension of the [31] FNS Adjusting the Tension of the Stapler- Movement Timing Belt Stapler- Rotation Timing Belt (FS-108/108BM/211 only) (FS-108/108BM/211 only) 1. Tools used 1. Tools used • Screwdriver (Phillips) • Screwdriver (Phillips) •...

  • Page 490: Fns Adjusting The Folding Force (Fs-108Bm/211 Only)

    OTHER ADJUSTMENT [32] FNS Adjusting the Folding Force [33] FNS Adjusting the Mount Location (FS-108BM/211 only) of the Folding Knife Motor (FS- 1. Preparation 108BM/211 only) 1. Tools used (1) If necessary, you can change the force of the • Screwdriver (Phillips) folding and pressure rollers as described below.

  • Page 491: Tu Trimming Parallelism Adjustment

    OTHER ADJUSTMENT [34] TU Trimming Parallelism Adjustment [35] Adjusting the PZ Paper-Path Switching Solenoid Tools • Screwdriver (Phillips) Tools • Screwdriver (Phillips) Adjustment Method Adjustment Method Press release lever Front door Registration guide plate Conveyance guide plate assembly Gate SD/L (SD1) OFF Screw (for Gate/L Gate SD/L (SD1)
  • Page 492 OTHER ADJUSTMENT Step Operation Reassemble in the opposite sequence Open the front door of FNS, remove the to removal. front cover of PZ-108 (three screws), and Caution: The conveyance unit must be remove PZ-108 from the main body. inserted so that the plate on Remove the AC cord and the rear cover the conveyance unit (see the figure below) is positioned in...

  • Page 493: Adjusting The Tension Of The Pz Punch Shift Timing Belt

    OTHER ADJUSTMENT [36] Adjusting the Tension of the PZ [37] Adjusting the PZ 1st Folding Skew Punch Shift Timing Belt Tools Tools • Screwdriver (Phillips) • Screwdriver (Phillips) Adjustment Method • Tension gauge or spring balance Adjustment Method Screw Ticks Left Supporting point Screw...
  • Page 494 OTHER ADJUSTMENT Pull out the z-folding/conveyance unit. Reassemble in the opposite sequence Remove two screws from the rail and to removal. further draw out the conveyance unit. Caution: The conveyance unit must be inserted so that the plate on Screws the conveyance unit (see the figure below) is positioned in side the rail on the enclosure.

  • Page 495: Adjusting The Position Of The Pz 2Nd Folding Stopper

    OTHER ADJUSTMENT [38] Adjusting the Position of the PZ 2nd Step Operation Folding Stopper Set paper into the tray and make a copy (required to place the paper stopper at its Caution: This adjustment affects the 2nd folding HP position). skew.

  • Page 496: Adjusting The Pz 2Nd Folding Skew 2Nd Stopper Assembly

    OTHER ADJUSTMENT [39] Adjusting the PZ 2nd Folding Skew Loosen the four screws holding the 2nd 2nd Stopper Assembly stopper assembly. Caution: Before beginning this operation, Make adjustments by moving the front complete the adjustment described in or rear side of the 2nd stopper assem the [38] Adjusting the Position of the bly upward using the ticks for reference.

  • Page 499: What Is Isw

    What is ISW ? ISW (In-System Writer) is a process of updating the control programs stored in flash ROM mounted on various control boards in a Konica digital copier without isolating the boards from the copier. Running ISW enables you to upgrade control programs without replacing the boards and maintain the boards during their replacement.

  • Page 500: Setup

    SETUP [1] ISW-compatible boards 25 mode The 25 mode works only where the copier has The 7075 allows ROM data residing on the both the image control and operation control pro- following boards to be updated via ISW Tool: grams installed. - Image control board (Some part of HELP+CHECK mode is used to - Printer control board...
  • Page 501 Instances of ISW transfer - Writing ROM data newly (Ex. after replacing boards) Normal startup display Writing method Condition Image control Flashing timer LED Writing is enabled with The copier does not have the No display on the operation LCD power turned ON.

  • Page 502: Help + Check Mode Operation Flow

    [4] HELP + CHECK mode operation flow Power ON (HELP + CHECK) From the 25 mode menu Some parts of this mode is used to update the operation control program from 25 mode. Choose “PC.” 1. PC Select “PC” for using ISW Tool as well. Chose one from followings.
  • Page 503 Start ISW Main Body Finish ISW Exit window Normal end *** NORMAL END *** 0. CONTINUE 9. EXIT Abnormal end *** ABNORMAL END *** DATA ERROR 0. CONTINUE 9. EXIT 2 - 5...

  • Page 504: Operating Procedure

    [5] Operating procedure (2) ISW device select menu HELP + CHECK mode Function: This window lets you select the control (prerequisite) board on which to update ROM data. Turn the main SW ON while pressing “HELP” and You can choose from among graphics “CHECK”...
  • Page 505 (3) Item select menu (4) Start confirmation window Function: This window lets you select write Function: This window prompts you to confirm items. whether to start running ISW or not. OPERATION CONTROL - ITEM SELECT MENU [MODE:PC] OPERATION CONTROL - 01 [MODE:PC] ISW START OK? PLEASE PUSH TEN-KEY...
  • Page 506 (6) Ending result window (5) Executing window Function: This window displays the status of ISW Function: This window displays the status of ending. execution in progress. *** NORMAL END *** EXECUTING PLEASE PUSH TEN-KEY 0. CONTINUE 9. EXIT Operating instructions 1) The executing indicator flashes.
  • Page 507 Error Code Description Action No. There is an error in the command to ISW processing unit. A program error is detected. Input data format error. (during ISW to operation board) Invalid machine name input data. (during ISW to operation board) Invalid board name input data.

  • Page 508: Preparing The Copier To Transfer

    (g) There is an error in the flash ROM on the operation board. Restart from ISW. If the error persists, the life of the operation board flash ROM may have expired. Replace the operation board. * The system may fail to restart. In that case, restart while pressing the "HELP"...

  • Page 509: Relationships Between Processing States And Operational Leds

    [7] Relationships between processing states and operational LEDs Note : This is only when installing the program to graphics control for the first time. TIMER POWER SAVE ON/OFF Timer LED Power Save LED Initializing CPU now Checking memory Memory check error (waiting for data from PC) Flashing ISW processing (receiving data) Flashing...

  • Page 510: Making The Isw Connector And The Power Connector Available

    [9] Making the ISW connector and the 2) Connect the PC parallel port and the copier power connector available ISW connector with parallel interface cable. The ISW connector and the power connector (7075 only) are hidden under the drum cover. Detach this ISW connector (36-pin) cover to run ISW.

  • Page 511: Service

    SERVICE...
  • Page 513 Main Precautions for Maintenance 1. Points to be confirmed before maintenance 4. When replacing the drum and developer, must Before starting maintenance, ask a user and perform neccessary adjustment by refering to collect information about troubles occurred on the List of Adjustment Items. the machine before the maintenance and the conditions of the machine to grasp key points 5.
  • Page 514 Blank page...

  • Page 515: Service Schedule

    SERVICE SERVICE SCHEDULE [1] Service Schedule 7075 Number of Service item copies 75 100 125 150 175 200 225 250 275 300 2800 2825 2850 2875 2900 2925 2950 2975 .... Main body Maintenance Every 250,000 copies .... Periodic check (I) Every 500,000 copies ....
  • Page 516 SERVICE Number of Service item copies 100 125 150 175 200 225 250 275 300 2800 2825 2850 2875 2900 2925 2950 2975 ......Maintenance Every 250,000 copies .... PU-108 Periodic check (I) Every 1,000,000 copies .... Maintenance Every 250,000 copies ....
  • Page 517 SERVICE 7085 Number of Service item copies 75 100 125 150 175 200 225 250 275 300 2800 2825 2850 2875 2900 2925 2950 2975 .... Main body Maintenance Every 500,000 copies .... Periodic check (I) Every 1,000,000 copies .... Periodic check (II) Every 3,000,000 copies ....

  • Page 518: Maintenance Items

    SERVICE Maintenance Items 7075 Main body (Every 250,000 copies) Implementation classification Number Materials/tools of parts Lubric- Replace- Clea- Inspe- Classification Service item used Supply replaced ation ning ction ment Preparation (1) Image check Fixing unit (1) Fixing separation claws Drum cleaner/ (upper and lower) cleaning cleaning pad Drum carriage...
  • Page 519 SERVICE Implementation classification Number Materials/tools of parts Lubric- Replace- Clea- Inspe- Classification Service item Supply used replaced ation ment ning ction (1) Horizontal conveyance Drum cleaner/ roller/others cleaning cleaning pad (2) Paper reverse/exit entrance Drum cleaner/ guide plate cleaning cleaning pad (3) Paper reverse/exit sensor Blower brush cleaning...
  • Page 520 SERVICE 7085 Main body (Every 500,000 copies) Implementation classification Number Materials/tools of parts Clea- Inspe- Lubric- Replace- Classification Service item used Supply replaced ation ning ction ment Preparation (1) Image check Fixing unit (1) Fixing separation claws Drum cleaner/ (upper and lower) cleaning cleaning pad (2) Fixing cleaning web (25 mode counter resetting)
  • Page 521 SERVICE Implementation classification Number Materials/tools of parts Replace- Lubric- Classification Service item Clea- Inspe- Supply used replaced ation ment ning ction Transfer/ (1) Transfer/separation corona Drum cleaner/ separation unit cleaning cleaning pad/ corona unit blower brush (2) Transfer/separation wire 55VA2613* (3) Transfer wire cleaning unit 56GA-276* (4) Separation wire cleaning unit/1...
  • Page 522 SERVICE RADF [DF-313] (Every 250,000 copies)/ [DF-317] (Every 500,000 copies) Implementation classification Number Materials/tools of parts Lubric- Replace- Clea- Inspe- Classification Service item Supply used replaced ning ction ation ment Preparation (1) Paper feeding check (2) Exterior Paper feed (1) Size detection sensor 1 Blower brush section (2) Size detection sensor 2...
  • Page 523 SERVICE FNS [FS-108] (Every 250,000 copies) Implementation classification Number Materials/tools of parts Lubri- Clea- Inspe- Replace- Classification Service item Supply used replaced cation ment ning ction Preparation (1) Paper feeding check Conveyance (1) Conveyance roller Drum cleaner/ section cleaning pad (2) Intermediate conveyance roller (sponge roller) 122H4825*...
  • Page 524 SERVICE FNS [FS-108BM] (Every 250,000 copies) Implementation classification Number Materials/tools of parts Clea- Inspe- Lubri- Replace- Classification Service item used Supply replaced cation ning ction ment Preparation (1) Paper feeding check Conveyance (1) Conveyance roller Drum cleaner/ section cleaning pad (2) Intermediate conveyance roller (sponge roller) 122H4825*...
  • Page 525 SERVICE FNS [FS-211] (Every 500,000 copies) Implementation classification Number Materials/tools of parts Lubri- Clea- Inspe- Replace- Classification Service item Supply used replaced cation ment ning ction Preparation (1) Paper feeding check Conveyance (1) Conveyance roller Drum cleaner/ section cleaning pad (2) Conveyance cleaning brush 13TR-272* Paper exit...
  • Page 526 SERVICE LCT [LT-401/411] (Every 250,000 copies)/ [LT-402/412] (Every 500,000 copies) Implementation classification Number Materials/tools of parts Lubri- Replace- Clea- Inspe- Classification Service item Supply used replaced cation ning ction ment Preparation (1) Paper feeding check Inside of (1) Paper dust removing brush Cleaning pad/ machine cleaning...
  • Page 527 SERVICE 11. TU [TU-108] (7075 : Every 250,000 copies/7085 : Every 500,000 copies) Implementation classification Number Materials/tools of parts Lubri- Clea- Inspe- Replace- Classification Service item Supply used replaced cation ment ning ction Conveyance (1) Conveyance rollers Drum cleaner/ section (2) Conveyance belts cleaning pad Trimmer section...
  • Page 528 SERVICE 13. PZ [PZ-108] (7075 : Every 250,000 copies/7085 : Every 500,000 copies) Implementation classification Number Materials/tools of parts Replace- Clea- Inspe- Lubric- Classification Service item Supply used replaced ation ment ning ction Punch section (1) Punch die Blower brush Conveyance (1) Entrance guide plate/A Cleaning pad...

  • Page 529: Main Unit Periodic Inspection Items

    SERVICE [3] Main Unit Periodic Inspection Items Periodic check (I) 7075 only:Every 500,000 copies Implementation classification Number Materials/tools of parts Replace- Clea- Inspe- Lubri- Classification Service item Supply used replaced cation ment ning ction Fixing unit (1) Fixing cleaning web (25 mode counter resetting) 55VA-524* Drum carriage...
  • Page 530 SERVICE Periodic check (II) 7075/Periodic check (I)/7085 :Every 1,000,000 copies Implementation classification Number Materials/tools of parts Lubri- Clea- Inspe- Replace- Classification Service item Supply used replaced ning ction cation ment Tray (1) Paper feed roller (500-sheet Actual replacement tray) 55VA-464* count: 300K feeds (2) Feed roller (500-sheet tray) 55VA-463*...
  • Page 531 SERVICE Periodic check (III) 7075/Periodic check (II) 7085:Every 3,000,000 copies Implementation classification Number Materials/tools of parts Lubri- Replace- Clea- Inspe- Classification Service item Supply used replaced ment cation ning ction Drum (1) Drum temperature sensor 55VA-952*(7075) 56GA-209*(7085) Transfer/ (1) Transfer/separation corona separation unit 55VA-270*(7075)
  • Page 532 SERVICE Periodic check (IV) 7075/Periodic check (III) 7085:Every 4,500,000 copies Implementation classification Number Materials/tools of parts Lubri- Replace- Clea- Inspe- Classification Service item Supply used replaced cation ment ning ction Tray (1) Feed clutch Actual replacement 55VA8201* (7075) count: 3,000K 56AA8201* (7085) feeds (2) 1st paper feed clutch...
  • Page 533 SERVICE Blank page MODEL MANUAL REVISED EDITION DATE PAGE METHOD 3 - 11 7075/7085 SERVICE HANDBOOK Jan. 2002 3-9-2 ADDITION...
  • Page 534 SERVICE Periodic check (V) 7075/Periodic check (IV) 7085:Every 6,000,000 copies Implementation classification Number Materials/tools of parts Lubri- Clea- Inspe- Replace- Classification Service item Supply used replaced cation ment ning ction Charging corona (1) Charging corona unit unit 55VA-250* (2) PCL 55VA-257* Developing (1) Developing unit...

  • Page 535: Radf [Df-313], [Df-317]

    SERVICE Periodic check (VI) 7075/Periodic check (V) 7085:Every 10,000,000 copies Implementation classification Number Materials/tools of parts Lubri- Replace- Classification Service item Clea- Inspe- used Supply replaced cation ning ction ment Vertical convey- (1) Vertical conveyance roller ance section (middle/lower) 55VA4411*(7075) 56GA4411*(7085) (1) Sensor actuator 25SA5046*(7075)

  • Page 536: Fns [Fs-108], [Fs-111]

    SERVICE [5] FNS [FS-108], [FS-111] Periodic check (I) (Every 1,000,000 copies) Implementation classification Number Materials/tools of parts Lubri- Replace- Clea- Inspe- Classification Service item Supply used replaced cation ment ning ction Actual replacement Stapler unit (1) Stapler unit count: Each 200K 129U4266*(FS-108) staples 13TQ4250*(FS-111)

  • Page 537: Lct [Lt-401/411], [Lt-402/412]

    SERVICE [7] LCT [LT-401/411], [LT-402/412] Periodic check (I) (LT-401/411 : Every 500,000 copies,LT-402/412 : Every 1,000,000 copies) Implementation classification Number Materials/tools of parts Lubri- Replace- Clea- Inspe- Classification Service item Supply used replaced cation ning ction ment Actual replacement Inside of (1) Paper feed roller 55VA-484* count: 500K feeds machine...

  • Page 538: Tu [Tu-108]

    SERVICE [9] TU [TU-108] Periodic check (I) (Every 10,000,000 copies) Implementation classification Number Materials/tools of parts Lubri- Replace- Clea- Inspe- Classification Service item Supply used replaced cation ment ning ction Trimmer section (1) Upper knife Actual replacement 13LHK001* count: 500K times (2) Lower knife 13LHK002* [10]...

  • Page 539: Replacement Parts List

    SERVICE [12] Replacement parts list 7075 Main body No. Classification Parts name Parts No. Q’ty Total count Actual count Parts count No. Maintenance Charging wire 55VA2509* 250,000 (Every 250,000 copies) Charging wire unit vibration proof rubber 25BA2501* 250,000 Periodic check (I) Fixing cleaning web 55VA-524* 500,000...
  • Page 540 SERVICE No. Classification Parts name Parts No. Q’ty Total count Actual count Parts count No. Periodic check (III) Drum temperature sensor 55VA-952* 3,000,000 (Every 3,000,000 copies) Transfer/separation corona unit 55VA-270* 3,000,000 Registration roller 55VA4603* 3,000,000 Registration bearing 55VA7552* 3,000,000 Registration loop roller 55VA-068* 3,000,000 Registration clutch...
  • Page 541 SERVICE 7085 Main body No. Classification Parts name Parts No. Q’ty Total count Actual count Parts count No. Maintenance Charging wire 55VA2509* 500,000 (Every 500,000 copies) Charging wire unit vibration proof rubber 25BA2501* 500,000 Fixing cleaning web 55VA-524* 500,000 Separation claw 55VA2919* 500,000 Cleaning blade...
  • Page 542 SERVICE No. Classification Parts name Parts No. Q’ty Total count Actual count Parts count No. Periodic check (II) Drum temperature sensor 56GA-209* 3,000,000 (Every 3,000,000 copies) Transfer/separation corona unit 56GA-270* 3,000,000 Registration roller 55VA4603* 3,000,000 Registration bearing 55VA7602* 3,000,000 Registration loop roller 55VA-068* 3,000,000 Registration clutch...
  • Page 543 SERVICE DF-313/317 No. Classification Parts name Parts No. Q’ty Total count Actual count Parts count No. Periodic check (I) Paper feed roller 13GA4604* 200,000 (Every 1,000,000 copies) Separation roller 13GA4605* 200,000 Double feed prevention roller 13GA4606* 200,000 Separation assist roller 13GA4601* 200,000 Periodic check (II)

  • Page 544: Important Maintenance Parts

    SERVICE PI-108 (7075 only) No. Classification Parts name Parts No. Q’ty Total count Actual count Parts count No. Periodic check (I) Feed roller assembly B 50BA-575* 100,000 (Every 500,000 copies) Double feed prevention roller assembly 13FG-406* 100,000 Periodic check (II) Feed roller assembly A 50BA-574* 200,000...
  • Page 545 SERVICE Blank page MODEL MANUAL REVISED EDITION DATE PAGE METHOD 3 - 23 7075/7085 SERVICE HANDBOOK Jan. 2002 3-13-8 ADDITION...

  • Page 546: Copy Materials

    SERVICE COPY MATERIALS [1] Consumables (Single unit supply) 7085: 500,000copies/kit 7075 Name Quantity Name Durability/copies Charging wire 55VA2509* Toner cartridge 55,000 Charging wire unit vibration Developer 1,000,000 proof rubber 25BA2501* Drum 1,000,000 Charging control plate 55VA2508* 7085 Charging wire cleaning unit 55VA-255* Resin ring (ø2) 45AA2040* Name...

  • Page 547: Service Material List

    SERVICE SERVICE MATERIAL LIST Material No. Material Name Appearance Remarks 000V-16-0 Drum cleaner 200 ml 000V-17-0 Roller cleaner 200 ml 00GR00020 Plus guard No.2 25 g 000V-19-0 Setting powder 25 g 000V-18-0 Cleaning pad 10 pcs 1 pack 3 - 15...
  • Page 548 SERVICE SPECIAL TOOLS LIST Material No. Material Name Appearance Quantity Remarks 55VAJG011 Temp. sensor PS jig/A (for upper fixing roller) 55VAJG021 Temp. sensor PS jig/B (for heating roller) 55VAJG031 Thermostat PS jig/A (for upper fixing roller) 55VAJG041 Thermostat PS jig/B (for heating roller) 7050K0020 Optics position...
  • Page 549 SERVICE Material No. Material Name Appearance Quantity Remarks 00VC-2-00 Drum cover 00VD-1000 Blower brush 00VE-1004 Tester For DF-313/ 120A1052 * PS jig 2pc/set For DF-313/ 120A9711 * ADJ chart For DF-313/ 120A9712 * White chart For FS-108/ 129XJG011 Stapler PS jig 108BM/211 3 - 17...
  • Page 550 SERVICE Blank page 3 - 18...

  • Page 551: Electric Partslist

    ELECTRICAL PARTS LIST/ WIRING DIAGRAMS...

  • Page 553: 7075/7085 Electrical Parts Layout Drawing

    7075/7085 PARTS LAYOUT DRAWING 7075/7085 ELECTRICAL PARTS LAYOUT DRAWING [1] Read Section/Operational Section OP IFB Image Optional I/F control board board ADF brake PS Scanner cooling fan Interlock 1 Scanner HP PS PS24 converter Front door open/close OB INVB board Scanner drive motor detection PS1 OB Inverter...

  • Page 554: Drum Unit

    7075/7085PARTS LAYOUT DRAWING [3] Drum Unit DPSB Drum potential sensor board HTR1 Drum potential sensor Drum heater (7075 only) DTSB Drum temperature sensor board (7075 only) Drum temperature sensor Separation claw SD TCSB Toner control sensor board [4] Cleaning Unit PS30 Blade PS1 Blade motor...

  • Page 555: Tray 1,2,3

    7075/7085 PARTS LAYOUT DRAWING [5] Tray 1,2,3 MC3/5/7 PS48/50/52 MC4/6/8 Feed clutch 1/2/3 Paper pre-registration PS 1/2/3 Pre-registration clutch 1/2/3 PS26/27/28 No paper PS 1/2/3 HTR2/3/4 PS20/21/22 Tray heater 1/2/3 Tray upper limit PS 1/2/3 PS47/49/51 Paper feed PS 1/2/3 PS33/36/39 Paper size detection SD8/9/10...

  • Page 556: By-Pass Feed Section

    7075/7085PARTS LAYOUT DRAWING [7] By-pass Feed Section FM12 Main body cooling fan 4 (7085 only) Write section SD11 Pick up SD (by-pass) cooling fan 2 Write section cooling fan 1 PS23 Up/down motor (by-pass) Tray upper limit PS (by-pass) PS43 Tray lower limit PS (by-pass) PS29...

  • Page 557: Adu Unit

    7075/7085 PARTS LAYOUT DRAWING [9] ADU Unit Transfer High voltage unit 2 synchronization lamp PS12 PS59 Transfer/separation wire ADU deceleration PS cleaning pad limit PS PS13 PS60 ADU No paper detection PS ADU Pre-registration PS FM11 PS46 ADU cooling fan 2 ADU exit PS (7085 only) PS11...

  • Page 558: Fixing Unit

    7075/7085PARTS LAYOUT DRAWING [10] Fixing Unit Fixing temperature sensor 2 Fixing temperature sensor 1 Thermostat (upper) Fixing temperature sensor 4 Web drive motor Fixing heater lamp 1 Fixing heater lamp 2 Fixing jam PS Fixing heater lamp 3 Fixing temperature sensor 3 Thermostat 2 (lower) Fixing exit PS...

  • Page 559: Toner Supply Unit

    7075/7085 PARTS LAYOUT DRAWING [12] Toner Supply Unit Toner supply motor 1 Toner supply motor 2 Toner level detection sensor [13] Write Section INDXSB Index sensor board Polygon motor PMDB Laser correction motor Polygon motor drive board LDB2 Laser driver board 2 Polygon cooling fan (7085 only) LDB1...

  • Page 560: Control/Drive Unit In Rear Section

    7075/7085PARTS LAYOUT DRAWING [14] Control/Drive Unit in Rear Section 1. For 7075 Main motor KRDS SCDB KRDS board Scanner drive board Developing section fan Scanner drive motor Drum motor LAN IFB Developing motor LAN I/F board Main unit cooling fan 2 High voltage unit 1 Main unit cooling...
  • Page 561 7075/7085 PARTS LAYOUT DRAWING 2. For 7085 Main motor KRDS SCDB KRDS board Scanner drive board Developing section fan Scanner drive motor Printer relay board Drum motor LAN IFB Developing motor LAN I/F board Main unit cooling fan 2 High voltage unit 1 Main unit cooling fan 1...
  • Page 562 7075/7085PARTS LAYOUT DRAWING Blank page MODEL MANUAL REVISED EDITION DATE PAGE METHOD 4 - 10 7075/7085 SERVICE HANDBOOK Jan. 2002 4-8-2 ADDITION...

  • Page 563: Df-313/317 Electrical Parts Layout Drawing

    OPTIONAL PARTS LAYOUT DRAWING DF-313/317 ELECTRICAL PARTS LAYOUT DRAWING PS301 RADF open/close detection PS SD303 Original exit gate SD SD301 SD302 Flapper drive SD Pressure roller release SD MS301 Cover open/close MS M303 PS316 Tray up/down drive motor Tray lower limit detection PS M301 Original conveyance motor M302...

  • Page 564: Lt-401/411 Electrical Parts Layout Drawing

    OPTIONAL PARTS LAYOUT DRAWING LT-401/411 ELECTRICAL PARTS LAYOUT DRAWING SW100 LT tray down drive switch PS108 MS101 LT No paper detection PS LT interlock MS1 PS110 PS107 LT jam access door LT pre-registration PS open/close detection PS MS102 SD100 LT interlock MS2 LT 1st paper feed SD PS100 PS109...

  • Page 565: Electrical Parts Layout Drawing

    OPTIONAL PARTS LAYOUT DRAWING TU-108 ELECTRICAL PARTS LAYOUT DRAWING TUDB TU drive board PS110 Upper limit PS DCPS DC power supply unit M101 Conveyance motor PS111 Lower limit PS PS107 Scraps box detection PS M106 Holder motor Coil Relay 2 Circuit breaker Relay 1 PS113...

  • Page 566: Electrical Parts Layout Drawing

    OPTIONAL PARTS LAYOUT DRAWING PU-108 ELECTRICAL PARTS LAYOUT DRAWING Passage PS Main motor Exit PS Main motor cooling fan Punch HP PS Gate solenoid Punch clutch Paper edge PS Punch motor Punch shift motor Front door MS Punch shift HP PS Punch scraps full PS Punch scraps FRONT...

  • Page 567: Electrical Parts Layout Drawing

    OPTIONAL PARTS LAYOUT DRAWING PZ-108 ELECTRICAL PARTS LAYOUT DRAWING Punch clutch Conveyance motor cooling fan Punch motor Punch HP PS Paper edge PS Punch shift motor Punch scraps conveyance motor Puncher HP PS Punch scraps full PS Punch scraps box PS PZCB FRONT PZ Control board...

  • Page 568: Fs-111/211 Electrical Parts Layout Drawing

    OPTIONAL PARTS LAYOUT DRAWING FS-111/211 ELECTRICAL PARTS LAYOUT DRAWING PS207 Paper exit-cover FNS conveyance motor open/close detection PS PS50 Sub-tray full PS Paper exit-opening motor Sub-tray paper exit PS Paper exit-roller motor Stapler-movement motor FIN entrance Gate solenoid passage PS PS13 Entrance paper detection PS...
  • Page 569 OPTIONAL PARTS LAYOUT DRAWING FS-111 Stapler motor/F Stapler (F, R) Stapler motor/R PS34 Stapler HP PS/F PS31 Stapler HP PS/R PS37 Staple detection PS/F PS20 PS36 PS40 Stacker no-paper detection PS Cartridge detection Staple detection PS/F PS/R PS39 PS38 Cartridge detection Stapler ready PS/F PS/R PS41...
  • Page 570 OPTIONAL PARTS LAYOUT DRAWING PS12 Paper exit-opening solenoid Paper exit-opening PS Paper exit-1 PS Stacker conveyance passage PS PS10 Paper exit-2 PS Sub-tray deceleration solenoid Roller-shift motor PS18 Roller-shift HP PS Staple paper exit upper-limit PS Tray upper-limit PS PS15 Tray no-paper detection PS Tray lower-limit PS MODEL...

  • Page 571: Electrical Parts Layout Drawing

    OPTIONAL PARTS LAYOUT DRAWING PI-108 ELECTRICAL PARTS LAYOUT DRAWING PS202 M201 PS201 No-sheet PS Sheet-tray motor Sheet passage PS PS204 MC201 Sheet-tray upper-limit PS Paper-feed clutch PS203 SD201 Sheet-tray lower-limit PS Paper-feed solenoid PS209 Pre no-paper PS PS206 Sheet-size PS (large) PS205 Sheet-size PS (small) PS208...
  • Page 572 OPTIONAL PARTS LAYOUT DRAWING Blank page MODEL MANUAL REVISED EDITION DATE PAGE METHOD 4 - 18 7075/7085 SERVICE HANDBOOK Jan. 2002 4-10-8 ADDITION...

  • Page 573: 7075/7085 Connector Layout Drawing

    7075/7085 CONNECTOR LAYOUT DRAWING 7075/7085 CONNECTOR LAYOUT DRAWING [1] Read Section 651 (W: 3pin) 640 (BK:4pin) 650 (W: 3pin) 652 (W: 3pin) 653 (W: 3pin) 660 (W: 3pin) 661 (W: 3pin) 662 (W: 3pin) 663 (W: 3pin) 665 (W: 3pin) 666 (W: 3pin) 664 (W: 3pin) 631 (BK:4pin)

  • Page 574: Drum Unit

    7075/7085 CONNECTOR LAYOUT DRAWING [3] Drum Unit 353 (W: 7pin) 350 (W: 4pin) 340 (B: 12pin) 351 (W: 4pin) 342 (W: 2pin) 341 (BK: 26pin) 341 (BK: 10pin) [4] Cleaning Unit 360 (W: 3pin) 361 (W: 3pin) 355 (BK: 9pin) 4 - 12...

  • Page 575: Tray 1,2,3

    7075/7085 CONNECTOR LAYOUT DRAWING [5] Tray 1,2,3 261, 278 (W: 2pin) 262, 279 (W: 6pin) 260, 277 (W: 2pin) 275 (W: 3pin) 276 (W: 3pin) 250, 252 (BK: 24pin) 274 (W: 3pin) 269, 307 (W: 2pin) 273 (W: 3pin) 263, 280 (W:6pin) 271, 288 (W: 3pin) 264 (W: 2pin) 277, 289...

  • Page 576: By-Pass Feed Section

    7075/7085 CONNECTOR LAYOUT DRAWING [7] By-pass Feed Section 471 (BK:9pin) 77 (BK:4pin) 247 (W:2pin) 470 (W:13pin) 254 (W:12pin) 248 (W:2pin) 254 (W:7pin) 76 (BK:4pin) 244 (W:3pin) 243 (W:3pin) 242 (W:3pin) 246 (W:3pin) 241 (W:3pin) 473 (W:13pin) [8] Second Paper Feed Section 599 (W: 3pin) 569 (W: 7pin) 598 (W: 3pin)

  • Page 577: Adu Unit

    7075/7085 CONNECTOR LAYOUT DRAWING [9] ADU Unit 557 (W: 6pin) 565 (W: 3pin) 569 (W: 7pin) 568 (W: 8pin) 678 (W: 6pin) 583 (W: 3pin) 593 (W: 2pin) 588 (W: 3pin) 586 (W: 3pin) 584 (W: 3pin) 585 (W: 3pin) 581 (W: 3pin) 557 (W: 6pin) 580 (W: 3pin)

  • Page 578: Fixing Unit

    7075/7085 CONNECTOR LAYOUT DRAWING [10] Fixing Unit 488 (W: 4pin) 487 (W: 3pin) 489 (W: 5pin) 486 (W: 2pin) 462 (W: 2pin) 451 (BK: 20pin) 450 (B: 8pin) 465 (W: 3pin) 464 (W: 3pin) FRONT [11] Paper Exit Section 177 (W: 3pin) 480 (W: 3pin) FRONT 4 - 16...

  • Page 579: Toner Supply Unit

    7075/7085 CONNECTOR LAYOUT DRAWING [12] Toner Supply Unit 482 (W: 6pin) 484 (W: 3pin) 184 (W: 4pin) 483 (W: 3pin) 473 (W: 13pin) [13] Write Section 193 (W: 6pin) 192 (W: 13pin) 190 (W: 12pin) 191 (W: 14pin) 583 (W: 5pin) 4 - 17...

  • Page 580: Printer Control Board

    7075/7085 CONNECTOR LAYOUT DRAWING [14] Printer Control Board 1. For 7075 224 (W: 7pin) 225 (GY: 20pin) 229 (W: 5pin) 230 (W: 3pin) 223 (GY: 20pin) 292 (N.C.) 216 (W: 15pin) 37 (N.C.) 291 (N.C.) 222 (W: 15pin) 215 (GY: 18pin) 228 (W: 8pin) 210 (GY: 30pin) 227 (W: 9pin)

  • Page 581: Power Supply Management Board

    7075/7085 CONNECTOR LAYOUT DRAWING [15] Power Supply Management Board 904 (W: 5pin) 902 (W: 3pin) (W: 18pin) 903 (W: 4pin) 900 (W: 8pin) [16] Image Control Board 1. For 7075 2. For 7085 117 (BK: 168pin) 119 (W: 3pin) 112 (BK: 120pin) 116 (BK: 168pin) 111 (GY: 8pin) 129 (W: 40pin)

  • Page 582: Icb I/F Board

    7075/7085 CONNECTOR LAYOUT DRAWING [17] ICB I/F Board 1. For 7075 127 (BK: 120pin) 100 (W: 10pin) 101 (W: 3pin) 134 (BK: 20pin) 145 (N.C.) 133 (W: 8pin) 135 (GY: 22pin) 137 (GY: 20pin) 132 (W: 13pin) 138 (W: 13pin) 131 (W: 14pin) 140 (W: 9pin) 139 (W: 8pin)

  • Page 583: Adu Stand Drive Board

    7075/7085 CONNECTOR LAYOUT DRAWING [18] ADU Stand Drive Board 1. For 7075 524 (W: 6pin) 528 (W: 8pin) 527 (W: 7pin) 523 (W: 6pin) 500 (W: 8pin) 520 (GY: 28pin) 501 (W: 2pin) 510 (W: 11pin) 525 (W: 12pin) 521 (GY: 16pin) 526 (W: 10pin) 593 (N.C.) 594 (N.C.) 522 (W: 12pin)

  • Page 584: Dc Drive Board (7075 Only)

    7075/7085 CONNECTOR LAYOUT DRAWING [19] DC Drive Board (7075 only) [21] DC Power Supply Unit 1 301 (W: 2pin) 324 (W: 6pin) 323 (W: 7pin) 59 (W: 4pin) 51 (W: 4pin) 60 (W: 6pin) 57 (W: 8pin) 54 (W: 5pin) (W: 12pin) (W: 6pin) 58 (W: 8pin)

  • Page 585: Dc Power Supply Unit 2

    7075/7085 CONNECTOR LAYOUT DRAWING [22] DC Power Supply Unit 2 [23] DC Power Supply Unit 3 (7085 only) 1. For 7075 71 (W: 7pin) 74 (W: 10pin) FT1 (W: 1pin) 76 (W: 9pin) 72 (W: 8pin) 75 (W: 4pin) 73 (W: 8pin) FT2 (W: 1pin) FT3 (W: 1pin) FT4 (W: 1pin)

  • Page 586: Scanner Drive Board

    7075/7085 CONNECTOR LAYOUT DRAWING [24] Scanner Drive Board [27] Jam Indicator Board 620 (W: 3pin) 623 (W: 7pin) 622 (W: 4pin) 621 (W: 3pin) 531 (W:7pin) 610 (W: 15pin) 600 (W: 6pin) [25] High Voltage Unit 1 [28] L1 Inverter 632 (W: 3pin) 2 (W: 2pin) 251 (W:9pin)

  • Page 587: Drum Temperature Sensor Board (7075 Only)

    7075/7085 CONNECTOR LAYOUT DRAWING [30] Drum Temperature Sensor Board [33] Optional I/F Board 1. For 7075 (7075 only) 123 (W: 120pin) 122 (BK: 60pin) 455 (W: 4pin) 456 (BK: 2pin) 124 (W: 120pin) 2. For 7085 [31] Operation Board 1 195 (GY: 40pin) 161 (BK: 14pin) 162 (W: 4pin)

  • Page 588: Toner Control Sensor Board

    7075/7085 CONNECTOR LAYOUT DRAWING [35] Toner Control Sensor Board [40] Polygon Motor Drive Board 130 (W: 5pin) 422 (W: 12pin) 454 (W: 9pin) [36] KRDS [41] Memory Board 219 (W: 11pin) 141 (W: 40pin) 217 (BK: 25pin) [37] Index Sensor Board 142 (W: 20pin) 442 (W: 11pin) [42] LAN I/F Board...
  • Page 589 7075/7085 CONNECTOR LAYOUT DRAWING Blank page MODEL MANUAL REVISED EDITION DATE PAGE METHOD 4 - 27 4 - 23 - 4 7075/7085 SERVICE HANDBOOK Jan. 2002 4-23-4 ADDITION...

  • Page 590: Df-313/317 Connector Layout Drawing

    OPTION CONNECTOR LAYOUT DRAWING DF-313/317 CONNECTOR LAYOUT DRAWING 61 (W: 2pin) 49 (W: 3pin) 57 (W: 2pin) 59 (W: 2pin) 7 (W: 9pin) 8 (GY: 24pin) 66 (W: 2pin) 6 (W: 6pin) 41 (W: 3pin) 10 (W: 6pin) 5 (W: 3pin) 11 (W: 6pin) 4 (W: 7pin) 11 (W: 6pin)

  • Page 591: Lt-401/411 Connector Layout Drawing

    OPTION CONNECTOR LAYOUT DRAWING LT-401/411 CONNECTOR LAYOUT DRAWING 744 (W: 3pin) 742 (W: 3pin) 784 (W: 2pin) 741 (W: 3pin) 747 (W: 3pin) 766 (W: 2pin) 746 (W: 3pin) 767 (W: 2pin) 773 (W: 3pin) 765 (W: 2pin) 740 (W: 3pin) 774 (W: 2pin) 773 (W: 2pin) 762 (W: 3pin)

  • Page 592: Connector Layout Drawing

    OPTION CONNECTOR LAYOUT DRAWING TU-108 CONNECTOR LAYOUT DRAWING 437 (W:2pin) 438 (W:3pin) 435 (W:3pin) 460 (W:3pin) 491 (W:15pin) 438 (W:3pin) 492 (W:14pin) 493 (BK:10pin) 461 (W:3pin) 416 (BK:2pin) 411 (W:11pin) 490 (W:2pin) 456 (W:3pin) 452 (W:3pin) 458 (W:3pin) 417 (BK:2pin) 459 (W:3pin) 455 (W:3pin) 459 (W:2pin)
  • Page 593 OPTION CONNECTOR LAYOUT DRAWING PU-108 CONNECTOR LAYOUT DRAWING 61 (W: 3pin) 74 (W: 6pin) 50 (B: 2pin) 41 (W: 6pin) 68 (W: 3pin) 65 (W: 3pin) 53 (W: 3pin) 25 (W: 7pin) 52 (W: 2pin) 47 (W: 2pin) 44 (W: 2pin) (W: 1pin) 45 (W: 6pin) (W: 1pin)

  • Page 594: Connector Layout Drawing

    OPTION CONNECTOR LAYOUT DRAWING PZ-108 CONNECTOR LAYOUT DRAWING 53 (W: 3pin) 52 (W: 2pin) 44 (W: 2pin) 47 (W: 2pin) 39 (W: 15pin) 96 (W: 6pin) 91 (W: 6pin) 95 (W: 12pin) 90 (W: 12pin) FRONT 42 (W: 6pin) 50 (B: 2pin) 9 (W: 13pin) 3 (W: 8pin) 46 (B: 2pin)

  • Page 595: Fs-111/211 Connector Layout Drawing

    OPTION CONNECTOR LAYOUT DRAWING FS-111/211 CONNECTOR LAYOUT DRAWING [1] FNS Control Board [2] Relay Board (FS-211 only) 51 (GY: 50pin) 1 (GY: 60pin) 7 (W: 12pin) 23 (GY: 34pin) 24 (GY: 22pin) 10 (W: 5pin) FAN connector 28 (GY: 20pin) 25 (GY: 24pin) (W: 9pin) 21 (GY: 60pin)
  • Page 596 OPTION CONNECTOR LAYOUT DRAWING Blank page MODEL MANUAL REVISED EDITION DATE PAGE METHOD 4 - 30 7075/7085 SERVICE HANDBOOK Jan. 2002 4-26-4 ADDITION...
  • Page 597 7075 OVERALL WIRING DIAGRAM (1/5) MAIN SWITCH CBR1 13-1 20-1 20-3 13-2 10-1 AC(H) 80-1 80-3 24VDC RESET SWITCH 10-5 80-2 80-4 PT-3 AC(H) 24VDC DCPS 1 DCPS 2 13-3 21-1 21-2 13-4 10-3 AC(H) F GND MAIN RELAY 10-2 AC(C) 10-4 10-6...

  • Page 598: Overall Wiring Diagram (1/5)

    7075 OVERALL WIRING DIAGRAM (2/5) 900-1 5VDC 900-2 SGND PSMB 900-6 REM/2 900-3 REM/1 900-5 5VDC 900-4 SW SIG 900-7 REM/3 900-8 CUREM 5VDC 903-1 RL3 DRIVE 903-2 5VDC 903-3 RL2 DRIVE 903-4 KRDS 350-5 197-5 410-5 -5VDC 350-4 197-4 410-4 SGND 350-3...
  • Page 599 7075 OVERALL WIRING DIAGRAM (3/5) SCANNER EXPOSURE LAMP INVB SCANNER SCANNER SCANNER ORIGINAL SCANNER BRAKE RETURN COOLING SENSOR SENSOR DRIVE MOTOR 601-7 601-1 600-3 24VDC 601-2 600-4 24VDC 601-3 TRAY 1 TRAY 2 TRAY 3 600-1 5VDC 601-4 600-2 SGND 601-5 600-5 PGND PAPER...
  • Page 600 7075 OVERALL WIRING DIAGRAM (4/5) DRUM DRUM TEMPARATURE SENSOR BY-PASS VERTICAL PAPER FEED FIXING PAPER SIZE PAPER SIZE PAPER SIZE TRAY TRAY LOOP VERTICAL VERTICAL VERTICAL OPEN/CLOSE TONER CONTROL SENSOR FIXING FIXING FIXING FIXING FIXING FIXING BLADE BLADE CHARGING CHARGING LOWER UPPER BOARD...
  • Page 601 7075 OVERALL WIRING DIAGRAM (5/5) PAPER FRONT FRONT EXIT DOOR DOOR SENSOR OPEN/CLOSE OPEN/CLOSE SENSOR SENSOR PS61 PS24 PS25 FS - 108 FS - 108BM 756-12-1 FIN TXD 218-1 756-11-2 SGND 218-2 756-10-3 FIN TXD REQ 218-3 756-9-4 SGND 218-4 756-8-5 FIN TXD ACK 218-5...

  • Page 602: Df-313/317 Overall Wiring Diagram

    DF-313/317 OVERALL WIRING DIAGRAM Original APS Timing Original skew Original skew conveyance RADF open Original Original Reverse Tray lower Tray upper No original Original Original Original Original Original Original exit Cover open Original exit detection PS2 detection PS1 detection /close detection exit reversal detection jam detection...

  • Page 603: Lt-401/411 Overall Wiring Diagram

    LT-401/411 OVERALL WIRING DIAGRAM 766-1-2 LT FEED DRIVE TOP COVER 723-3 24VDC 5VDC 722-A1 746-1 MC101 766-2-1 CLUTCH 723-4 MC101 DRIVE PS100 722-A4 746-2 PS100 OPEN/CLOSE SGND 722-A7 746-3 DETECTION SENSOR 765-1-2 LT FIRST PAPER FEED 723-5 24VDC MC102 765-2-1 723-6 MC102 DRIVE 5VDC...
  • Page 604 TU-108 OVERALL WIRING DIAGRAM [How to see the diagram] 1.The signals shown reflect levels present (3) RC is the flat cable. under normal idling conditions with (4) Signal flow The solid black circle ( ) among the main switch turned ON. the connector symbols ( 2.Wiring symbols in the figure are as follows.
  • Page 605 PU-108 OVERALL WIRING DIAGRAM PAPER EDGE SENSOR PUCB FT21 FT20 FRONT DOOR MS RELAY FT12 FT14 FT10 CN80-1 MAIN BODY INLET Y/GN FT13 FT15 FT11 CN80-3 DCPS FGND CN80-5 [How to see the diagram] (3) RC is the flat cable. 1.The signals shown reflect levels present [Color code] under normal idling conditions with...
  • Page 606 PZ-108 OVERALL WIRING DIAGRAM PAPER EDGE SENSOR PZCB MAIN BODY RELAY FRONT DOOR MS COIL FT21 FT23 CN78- 1 CN78- 2 FT12 FT14 FT10 INLET Y/GN DCPS FT22 FT24 FT13 FT15 FT11 [How to see the diagram] 1.The signals shown reflect levels present (2) Signal types are as follows: (3) RC is the flat cable.
  • Page 607 STAPLER M22 DRV F CN156-1 SUB-TRAY DECELERATION CN10-1 24V MOTOR/R M22 DRV R CN156-2 CN10-2 DRV SOLENOID CN170-1 CN201-1 24V CN5-1 STR_R_DRV1 STAPLER CN170-2 PS31 CN5-2 STR_R_DRV2 PS31 IN CN201-2 DRV HP SENSOR/R CARTRIGE CN171-15 CN171-1 CN4-A1 5V CN177-3 CN177-2 CN120-1 CN202-1 5V DETECTION...
  • Page 608 FS-211 OVERALL WIRING DIAGRAM TRAY UNIT FOLDING UNIT FNS CB MAIN BODY [How to see the diagram] 1.The signals shown reflect levels present (3) RC is the flat cable. under normal idling conditions with (4) Signal flow The solid black circle ( ) among the main switch turned ON.

  • Page 609: Overall Wiring Diagram

    PI-108 OVERALL WIRING DIAGRAM PAPER PAPER SHEET FEED FEED TRAY CLUTCH SOLENOID MOTOR SHEET SHEET SHEET SHEET TRAY TRAY SIZE SIZE SHEET SHEET SHEET PASSAGE NO SHEET LOWER LIMIT UPPER LIMIT SENSOR SENSOR NO PAPER SIZE SENSOR SENSOR SENSOR SENSOR (SMALL) (LARGE) SENSOR...
  • Page 610 Blank page MODEL MANUAL REVISED EDITION DATE PAGE METHOD 4 - 40 7075/7085 SERVICE HANDBOOK Jan. 2002 4-34-6 ADDITION...

  • Page 611: Jam/Error Code List

    JAM/ERROR CODE LIST...

  • Page 613: Jam Code List

    JAM CODE LIST JAM CODE LIST Countermeasure Cause Classification Machine response code By-pass tray J10-1 PS44 (registration) is not turned If there is paper in the Remove the paper ON within the specified time after copy process when from the by-pass SD11 (pick up (by-pass)) is in the this jam occurs, the tray and remove the...
  • Page 614 JAM CODE LIST Countermeasure Cause Classification Machine response code Tray 3 J13-1 PS52 (paper pre-registration 3) is If there is a paper in Draw out the tray not turned ON within the specified copying process and remove the time after MC8 (pre-registration when this jam occurs, jammed paper.
  • Page 615 JAM CODE LIST Countermeasure Cause Classification Machine response code Paper feed J17-2 PS54 (loop) is not turned ON If there is a paper in Open the vertical within the specified time after copying process conveyance door of conveyance PS47 (paper feed 1) is turned ON. when this jam occurs, the main body and (tray 1)
  • Page 616 JAM CODE LIST Countermeasure Cause Classification Machine response code Second J31-1 PS45 (leading edge detection) is If there is a paper in Open the front doors, paper feed not turned ON within the specified copying process draw out the ADU, time after MC1 (Registration) is when this jam occurs, and remove the...
  • Page 617 JAM CODE LIST Countermeasure Cause Classification Machine response code Front door J51-1 The front right or left door is The machine stops Open the front doors, opened during copying. immediately. draw out the ADU, J92-1 PS58 (ADU paper reverse ) is not If there is a paper in and remove the turned ON within the specified...
  • Page 618 JAM CODE LIST Countermeasure Cause Classification Machine response code J61-1 PS301 (RADF open/close RADF stops immedi- Open the jam detection) is turned OFF during ately. access cover and RADF operation. If there is a paper in remove jammed J61-2 MS301 (cover open/close) is copying process, the paper.
  • Page 619 JAM CODE LIST Countermeasure Cause Classification Machine response code J62-8 RADF stops immedi- Open the jam When a large-size two-sided original is ejected, PS307 ately. access cover and If there is a paper in remove jammed (original exit 1) is not turned ON copying process, the paper.
  • Page 620 JAM CODE LIST Countermeasure Cause Classification Machine response code J63-6 When a small-size one-sided RADF stops immedi- Open the jam original is ejected, PS314 (original ately. access cover and exit 2) is not turned OFF within If there is a paper in remove jammed the specified time after PS314 copying process, the...
  • Page 621 JAM CODE LIST Countermeasure Cause Classification Machine response code J65-20 PS314(original exit 2) is ON RADF stops Open the movable during idling. immedi-ately. cover and remove If there is a paper in jammed paper. J65-40 PS304(reverse jam detection) is copying process, the ON during idling.
  • Page 622 JAM CODE LIST Classification Cause Machine response Countermeasure code J72-26 PS25(folding paper exit) is not FNS/main body stops Remove jammed turned OFF within the specific immediately. paper from FNS/ time after it turns ON. main body. J72-27 PS20(stacker no paper detection) is OFF when the staple is started.
  • Page 623 JAM CODE LIST Classification Cause Machine response Countermeasure code PZ-108 J72-42 During the paper feeding operation PZ/main body stop Remove any jammed after the 2nd folding,PS1 (passage) immediately. paper in the PZ/main is not turned off within the specified boy. time after it has been turned on.
  • Page 624 JAM CODE LIST Classification Cause Machine response Countermeasure code J72-90 FNS does not stop within the FNS/main body stops Remove jammed specific time after it receives start- immediately. paper from FNS/ operation signal from the main main body. body. J73-1 PS6(paper exit 1) is ON during idling.
  • Page 625 JAM CODE LIST Blank page 5 - 13 5 - 11 - 2...

  • Page 626: Error Code List

    ERROR CODE LIST ERROR CODE LIST Warning Operation in case of Estimated abnormal Classification Causes code warning occurrence parts Drive F13-01 Check on M4 (paper feed) rotation The machine stops M4 (paper feed) abnormality signal. An abnormal immediately and RL1 PRCB (printer control board) detection signal is detected two (main) is turned OFF.
  • Page 627 ERROR CODE LIST Warning Operation in case of Estimated abnormal Classification Causes code warning occurrence parts Tray 2 F18-20 M20 (up drive 2) lock detection. An The machine stops M20 (up drive 2) M20 abnormal detection signal is immediately and RL1 DCDB (DC drive board) detected when M20 is ON.
  • Page 628 ERROR CODE LIST Warning Operation in case of Estimated abnormal Classification Causes code warning occurrence parts Tray 3 F18-33 PS22 (tray upper limit 3) which has Error code is not dis- M21 (up drive 3) been OFF is not turned ON within played on operation DCDB (DC drive board) specified time of upward movement...
  • Page 629 ERROR CODE LIST Warning Operation in case of Estimated abnormal Classification Causes code warning occurrence parts By-pass tray F18-51 PS23 (tray upper limit (by-pass)) or Operation panel dis- M22 (up/down (by-pass)) PS43 (tray lower limit (by-pass)) which plays jam error (J10- DCDB (DC drive board) has been OFF is not turned ON within 01).
  • Page 630 ERROR CODE LIST Warning Operation in case of Estimated abnormal Classification Causes code warning occurrence parts Wire F21-01 • When SW1 (main) has been ON The machine stops M23 (charger cleaning) cleaning and PS41 (charging wire cleaning immediately and RL1 DCDB (DC drive board) abnormality pad HP) has been OFF, PS41 is not...
  • Page 631 ERROR CODE LIST Warning Operation in case of Estimated abnormal Classification Causes code warning occurrence parts Wire F21-02 • PS42 (charging wire cleaning pad The machine stops M23 (charger cleaning) cleaning limit) is not turned ON within immediately and RL1 DCDB (DC drive board) abnormality specified time after detection of...
  • Page 632 ERROR CODE LIST Warning Operation in case of Estimated abnormal Classification Causes code warning occurrence parts Wire F21-05 • Check on blown fuse of M18 (transfer/ The machine stops M18 (transfer/sepa- cleaning separation cleaning) in ADUSDB. immediately and ration cleaning) abnormality When SW1 (main) has been ON and RL1 (main) is turned...
  • Page 633 ERROR CODE LIST Warning Operation in case of Estimated abnormal Classification Causes code warning occurrence parts Motor F23-03 M14 (blade) lock detection. An M14 The machine stops M2 (drum) abnormality abnormal detection signal (excessive immediately and RL1 M14 (blade) current) is detected. (main) is turned OFF.
  • Page 634 ERROR CODE LIST Warning Operation in case of Estimated abnormal Classification Causes code warning occurrence parts Motor F23-09 Check on M14 (blade) movement The machine stops M14 (blade) abnormality incompletion. The blade READY immediately and RL1 DCDB (DC drive board) signal (ready) is not detected within (main) is turned OFF.
  • Page 635 ERROR CODE LIST Warning Operation in case of Estimated abnormal Classification Causes code warning occurrence parts High voltage F28-01 Charging leakage detection. The If there is a paper in HV1 (high voltage unit1) power supply charging ON/OFF operation has copying process Power supply abnormality...
  • Page 636 ERROR CODE LIST Warning Operation in case of Estimated abnormal Classification Causes code warning occurrence parts Process F29-08 Correction abnormality. Dot diameter Error code is not dis- TCSB (toner control abnormality correction ended with an abnormal played on operation sensor board) value.
  • Page 637 ERROR CODE LIST Warning Operation in case of Estimated abnormal Classification Causes code warning occurrence parts F32-02 Check on blown fuse of FM2 The machine stops ACDB (AC drive board) abnormality (developing suction) in ACDB. The immediately and RL1 FM2 (developing suction) FM2 EM signal was abnormal at (main) is turned OFF.
  • Page 638 ERROR CODE LIST Warning Operation in case of Estimated abnormal Classification Causes code warning occurrence parts ADU stand F33-01 M12 (registration) rotation speed The machine stops M12 (registration) motor abnormality. An abnormal detection immediately and RL1 Connector abnormality signal is detected 2 consecutive (main) is turned OFF.
  • Page 639 ERROR CODE LIST Warning Operation in case of Estimated abnormal Classification Causes code warning occurrence parts Too high F34-03 7075: Overheating (228°C or higher) The machine stops PRCB (printer control board) fixing was detected for TH1 (fixing immediately. RL1 ACDB (AC drive board) temperature temperature 1) and TH2 (fixing (main) is turned OFF.
  • Page 640 ERROR CODE LIST Warning Operation in case of Estimated abnormal Classification Causes code warning occurrence parts Fixing F36-05 TH2 (fixing temperature 2) abnormal- The machine stops PRCB (printer control board) sensor ity detection (by hardware). immediately. RL1 ACDB (AC drive board) abnormality Underheating (-6°C or less) or over- (main) is turned OFF.
  • Page 641 ERROR CODE LIST Warning Operation in case of Estimated abnormal Classification Causes code warning occurrence parts Scanner F41-06 Check on excess over M13 (scanner The machine stops SCDB (scanner drive board) abnormality drive) movement time limit. During immediately. RL1 M13 (scanner drive) HP search operation, PS5 (scanner (main) is turned OFF.
  • Page 642 ERROR CODE LIST Warning Operation in case of Estimated abnormal Classification Causes code warning occurrence parts F42-02 Check on blown fuse of FM7 The machine stops SCDB (scanner drive board) abnormality (scanner cooling) in SCDB. The FM7 immediately. RL1 FM7 (scanner cooling) EM signal was abnormal at specified (main) is turned OFF.
  • Page 643 ERROR CODE LIST Warning Operation in case of Estimated abnormal Classification Causes code warning occurrence parts F42-08 Check on FM8 (write section cooling The machine stops DCPS2 (DC power abnormality 2) rotation and 24 V power supply. immediately. RL1 supply unit 2) The FM8 EM signal was abnormal at (main) is turned OFF.
  • Page 644 ERROR CODE LIST Warning Operation in case of Estimated abnormal Classification Causes code warning occurrence parts F42-14 Check on FM12 (main body cooling The machine stops DCPS2 (DC power abnormality 4) rotation. The FM12 EM signal was immediately. RL1 supply unit 2) abnormal at specified time after (main) is turned OFF.
  • Page 645 ERROR CODE LIST Warning Operation in case of Estimated abnormal Classification Causes code warning occurrence parts Image E46-02 Illegal address of FIFO for scanner. If copy operation is ICB (image control board) control During image read, image data being performed, the Damage to gate abnormality compression is not completed...
  • Page 646 ERROR CODE LIST Warning Operation in case of Estimated abnormal Classification Causes code warning occurrence parts Image E46-21 Decompression from the memory to If copy operation is PRCB (printer control board) control the page memory is not completed being performed, the ICB program abnormality within the specified time.
  • Page 647 ERROR CODE LIST Warning Operation in case of Estimated abnormal Classification Causes code warning occurrence parts Image E46-35 Dual page memory area error The RL1 (main) is ICB (image control board) control Due to the image area abnormality turned OFF. ICB program abnormality on the memory, image is not...
  • Page 648 ERROR CODE LIST Operation in case of Estimated abnormal Warning Classification Causes warning occurrence parts code Image E46-80 The message queue was insufficient If copy operation is ICB (image control board) control or destroyed. being performed, the abnormality E46-81 The parameter value is too large. machine stops after paper ejection.
  • Page 649 ERROR CODE LIST Warning Operation in case of Estimated abnormal Classification Causes code warning occurrence parts Communi- E50-10 Check on initial communication The machine stops PRCB (printer control board) cation between ICB and PRCB. Image immediately. RL1 ICB (image control board) abnormality processing board communication (main) is turned OFF.
  • Page 650 ERROR CODE LIST Operation in case of Estimated abnormal Warning Classification Causes warning occurrence parts code F52-05 Check on blown fuse of FM4 (main The machine stops ACDB (AC drive board) abnormality body coolign 2) in ACDB. The FM4 EM immediately.
  • Page 651 ERROR CODE LIST Operation in case of Estimated abnormal Warning Classification Causes warning occurrence parts code Motor F53-01 Check on M1 (main) rotation speed The machine stops M1 (main) abnormality abnormality. An abnormal detection immediately. RL1 signal has been detected two (main) is turned OFF.
  • Page 652 ERROR CODE LIST Operation in case of Estimated abnormal Warning Classification Causes warning occurrence parts code Power supply F53-11 Check on 24V power supply for SD/MC The machine stops Solenoids abnormality in PRCB. An abnormal detection signal immediately. RL1 Clutches (solenoid/clutch blown fuse) is detected (main) is turned OFF.
  • Page 653 ERROR CODE LIST Operation in case of Estimated abnormal Warning Classification Causes warning occurrence parts code F67-01 PS306 (original registration If there is a paper in PS306 (original abnormality detection) fault. copying process registration detection) F67-02 PS308 (original conveyance when this trouble oc- PS308 (original detection) fault.
  • Page 654 ERROR CODE LIST Operation in case of Estimated abnormal Warning Classification Causes warning occurrence parts code F77-7 M4 (stapler rotation) abnormality. The main body and FNS CB (FNS control board) abnormality FNS are stopped RB (relay board) immediately. RL1 M4 (stapler rotation) (main) is turned F77-8 Stapler/R rotation abnormality.
  • Page 655 ERROR CODE LIST Operation in case of Estimated abnormal Warning Classification Causes warning occurrence parts code The main body and F77-25 PS22(folding knife HP) does not go ON FNS CB (FNS control board) FNS are stopped abnormality within the specified time after M19(folding M19 (folding knife) immediately.
  • Page 656 ERROR CODE LIST Warning Operation in case of Estimated abnormal Classification Causes code warning occurrence parts The main body and PZ-108 F77-56 The M10 (conveyance motor fan) EM PZCB (PZ control board) FNS are stopped abnormality signal is abnormal at specified time after M10 (conveyance immediately.
  • Page 657 ERROR CODE LIST Warning Operation in case of Estimated abnormal Classification Causes code warning occurrence parts ADU stand E90-01 Check on initial communication between The machine stops ADUSDB (ADU abnormality ADUSDB and PRCB. ADU drive serial immediately and RL1 stand drive board) PRCB (printer control board) input error 1.
  • Page 658 ERROR CODE LIST Warning Operation in case of Estimated abnormal Classification Causes code warning occurrence parts ADU stand F93-06 An abnormal detection signal (blown The machine stops Solenoids abnormality solenoide/clutch fuse) is detected at the immediately and RL1 Clutches time of start. An abnormal detection (main) is turned off.

  • Page 659: Timing Charts

    TIMING CHARTS...
  • Page 661 TIMING CHARTS 7075 TIMING CHART (A4, LIFE SIZE, DOUBLE- SIDED COPY, 2 SET, TRAY 1) 6 - 1...
  • Page 662 (sec) Time (sec) Symbol Item M303 Tray up/down drive motor DOWN Tray upper limit detection PS PS315 PS316 Tray lower limit detection PS PS310 Original count detection PS PS305 No original detection PS 800mm/s Original feed motor M302 370mm/s 350mm/s PS306 Original registration detection PS PS308...

  • Page 663: Timing Chart (A4, Life Size, Double-Sided Copy, 2 Sets, Tray1)

    TIMING CHARTS DF-313 TIMING CHART (A4, DOUBLE-SIDED ORIGINALS, 3 SHEETS) 6 - 3...
  • Page 664 Time (sec) (sec) Symbol Item M101 LT paper feed motor 300ms min380ms 200ms LT feed drive clutch MC101 Loop amount Loop amount LT first paper feed SD100 solenoid LT first paper feed MC102 clutch LT pre-registration PS107 sensor LT feed sensor PS106 Start button ON...
  • Page 665 Time (sec) (sec) Symbol Item M101 LT paper feed min380ms min380ms motor 300ms MC101 LT feed drive clutch Loop amount Loop amount SD100 LT first paper feed solenoid MC102 LT first paper feed clutch Timer Timer (Second paper feed loop) (Second paper feed loop) Registration clutch Timer...
  • Page 666 Time (sec) Symbol Item Folding conveyance motor(FNS) Conveyance motor M101 PS101 Entrance PS Release 200ms M103 Stopper motor PS102 Conveyance PS 51.71S 43.14S Press motor M105 Press Release M102 Trimmer motor stopper press Stopper release motor M104 Lowering Release 50ms 200ms stopper M106...
  • Page 667 Time (sec) Symbol Item Folding conveyance motor(FNS) M101 Conveyance motor PS101 Entrance PS M103 Stopper motor PS102 Conveyance PS 51.71S 45.82S M105 Press motor M102 Trimmer motor stopper Stopper release motor M104 Lowering 200ms Release stopper M106 Holder motor 460ms 200ms M107 Pusher motor...
  • Page 668 Time (sec) Symbol Item Ejection from main body signal Paper edge PS (leading / trailing) 68mms 68mms 68mms Main motor 800mm/s 370mm/s Passage PS Exit PS FNS Entrance PS Punch shift motor Paper edge PS (side edge) Punch motor Punch clutch Punch scraps conveyance motor Gate solenoid (sec)
  • Page 669 Time (sec) Symbol Item Ejection from main body signal Paper edge PS (leading / trailing) Main motor 800mm/s 370mm/s Passage PS Exit PS FNS Entrance PS Punch shift motor Paper edge PS (side edge) Punch motor Punch clutch Punch scraps conveyance motor Gate solenoid (sec) Time (sec)

  • Page 670: Timing Chart (A4, Single-Sided Originals, 3 Sheets)

    TIMING CHARTS PZ-108 TIMING CHART (Z-FOLDING + PUNCH MODE, A3, SINGLE- SIDED COPY, 3 SHEETS) MODEL MANUAL REVISED EDITION DATE PAGE METHOD 6 - 10 7075/7085 SERVICE HANDBOOK Sep. 2001 6-10 REPLACEMENT...

  • Page 671: Timing Chart

    TIMING CHARTS 7085 TIMING CHART (A4, LIFE SIZE, DOUBLE- SIDED COPY, 2 SET, TRAY 1) MODEL MANUAL REVISED EDITION DATE PAGE METHOD 6 - 11 7075/7085 SERVICE HANDBOOK Jan. 2002 6-11 ADDITION...
  • Page 672 Time (sec) (sec) Symbol Item M303 Tray up/down drive motor DOWN Tray upper limit detection PS PS315 PS314 Tray lower limit detection PS PS310 Original count detection PS PS305 No original detection PS 800mm/s M302 Original feed motor 400mm/s 550mm/s PS306 Original registration detection PS PS308...
  • Page 673 Time (sec) (sec) Symbol Item M303 Tray up/down drive motor DOWN PS315 Tray upper limit detection PS PS314 Tray lower limit detection PS PS310 Original count detection PS PS305 No original detection PS 800mm/s Original feed motor M302 400mm/s 550mm/s Original registration detection PS PS306 PS308...

  • Page 674: Timing Chart

    TIMING CHARTS FS-111/211 TIMING CHART (SORT MODE, A4, 2 SHEETS ORIGINALS, 3 SETS, 1:1) MODEL MANUAL REVISED EDITION DATE PAGE METHOD 6 - 14 7075/7085 SERVICE HANDBOOK Jan. 2002 6-14 ADDITION...

  • Page 675: Fs-111/211 Timing Chart (Staple Mode, A4, 2 Sheets Originals, 3 Sets 1:1)

    TIMING CHARTS FS-111/211 TIMING CHART (STAPLE MODE, A4, 2 SHEETS ORIGINALS, 3 SETS, 1:1) MODEL MANUAL REVISED EDITION DATE PAGE METHOD 6 - 15 7075/7085 SERVICE HANDBOOK Jan. 2002 6-15 ADDITION...

  • Page 676: Fs-111/211 Timing Chart (Stitch And Fold, A4R, 3 Sheets Originals, 2 Sets 1:1, 1-1 Mode)

    TIMING CHARTS FS-111/211 TIMING CHART (STITCH & FOLD, A4R, 3 SHEETS ORIGINALS, 2 SETS, 1:1, 1-1 MODE) MODEL MANUAL REVISED EDITION DATE PAGE METHOD 6 - 16 7075/7085 SERVICE HANDBOOK Jan. 2002 6-16 ADDITION...

  • Page 677: Timing Chart (Auto Paper Feed (Online), 2 Staples Mode, A4, 2 Sheets Originals, 2 Sets)

    TIMING CHARTS PI-108 TIMING CHART (AUTO PAPER FEED (ONLINE) 2- STAPLES MODE, A4, 2 SHEETS ORIGINALS, 2 SETS) MODEL MANUAL REVISED EDITION DATE PAGE METHOD 6 - 17 7075/7085 SERVICE HANDBOOK Jan. 2002 6-17 ADDITION...
  • Page 678 TIMING CHARTS Blank page 6 - 18...
  • Page 679 INSTALLATION INSTRUCTIONS...
  • Page 681 UNPACKING AND INSTALLATION PROCEDURE FOR THE MAIN BODY AND OPTIONS Applied Machine: Konica 7075 I. Installation Space III. Unpacking (Unit:mm) <Main Body> [1] Package Size Fig. 01 (Unit : mm) Fig. 03 Main body 1096 <Main Body + Finisher + LCT> Packed weight: 320 kg Fig.
  • Page 682 1. Place the wooden spacers under the Adjuster feet. 5. Bring down the machine carefully on the floor by Then extend the Adjuster feet enough to remove two persons (Fig. 08). the cushions with the spanner attached to the Fig. 08 accessory box (Fig.
  • Page 683 4. Open the RADF, and remove the glass protecting V. Installation Procedure cushion and the glass protecting paper (Fig. 10). Caution: Fig. 10 Glass protecting Confirm the Main switch is OFF and the power cord cushion Glass protecting paper is unplugged. Locking guide 1.
  • Page 684 (2) Remove the locking tapes and locking guide (7) Release the ADU lock located at the bottom of tape of the Tray 1 (Fig. 13). ADU unit by turning it with a finger to the left. While the ADU lock in release, turn the Release Fig.
  • Page 685 (11) Reinstall the Pre-fixing unit cover. Caution: (12) Return the ADU unit to the original position. • Hold by the left hand at the impress marks (K) (13) Turn the Release lever to the locking position on the front panel. again and close the Front door.
  • Page 686 (7) Hold both ends of the Developing unit and (11) Reinstall the Developing unit cover. remove it carefully from the Drum unit support Caution: assembly. Confirm that both the bosses of the upper cover (8) Pull up the claws of the upper cover to remove are put into the slots on the Developing unit (See it (Fig.
  • Page 687 (14) Disconnect 3 connectors and loosen 2 screws Fig. 30 of the Stay. Remove the Stay (Fig. 27). Fig. 27 Sensors Screw Screw (19) Hold the both ends of the Drum in the position that the powder applied portion faces toward the Cleaner.
  • Page 688 (23) Reinstall the Developer suction box. Fig. 33 (24) Charge the 1st Cleaner blade (Fig.32). Toner guide brush Note: The 2nd Cleaner blade is charged at the factory. q Push up the Blade unlock arm for the arrow direction until it stops. w Rotate the Blade charge lever fully for the arrow direction.
  • Page 689 (30) Fix the Coupling with a screw. 10. Set the Toner bottle. (31) Reinstall the Drum cover. (1) Open the Front door and open the Toner supply (32) Return the bracket of Toner supply unit to the unit for 90 degree. original position and secure it with 3 screws.
  • Page 690 (2) Secure the Working table with the Upper cover Fig. 37 to the Main body with 2 truss head screws (M4 x 14). Then cover the screw holes with 2 caps (Fig. 40). Fig. 40 Caps Operation manual holder Adhesive tape Ventilation duct...
  • Page 691 VIII. Tandem mode setting 11. Touch to select “100M Full Duplex” on the Line Speed Setting Screen, then touch “OK”. [Caution] 12. Turn OFF the power switch. • The Master (primary) and Sub (secondary) [Caution] machines should be mounted with the main body Perform the above procedure from step 3 to 12 ROMs of the same version number.
  • Page 692 Blank page.
  • Page 693 UNPACKING AND INSTALLATION PROCEDURE FOR THE MAIN BODY AND OPTIONS Applied Machine : Konica 7085 I. Installation Space III. Unpacking (Unit:mm) [1] Package Size <Main Body> Fig. 01 Unit : mm Fig. 03 Main body 1096 <Main Body + Finisher + LCT> Packed weight: 320kg Fig.
  • Page 694 1. Place the wooden spacers under the Adjuster 5. Bring down the machine carefully on the floor by feet. Then extend the Adjuster feet enough to two persons (Fig. 08). remove the cushions with the spanner (Not Fig. 08 attached to the accessory box) (Fig. 05). Fig.
  • Page 695 V. Installation Procedure 4. Open the RADF, and remove the glass protecting cushion and the glass protecting paper (Fig. 10). Caution: Fig.10 Confirm the Main switch is OFF and the power Glass protecting cushion Glass protecting paper cord is unpluged. Locking guide 1.
  • Page 696 (2) Remove the locking tapes and locking guide (7) Release the ADU lock located at the bottom of tape of the Tray 1 (Fig. 13). ADU unit by turning it with a finger to the left. While the ADU lock in release, turn the Fig.
  • Page 697 (11) Reinstall the Front-fixing unit cover. Withdraw the Drum unit support assembly (12) Return the ADU unit to the original position. holding it as shown in the figure (Fig. 19). (13) Turn the Release lever to the locking position Caution: •...
  • Page 698 (7) Hold both ends of the Developing unit and (11) Reinstall the Developing unit cover. remove it carefully from the Drum unit support Caution: assembly. Confirm that both the bosses of the upper cover (8) Pull up the claws of the upper cover to remove are put into the slots on the Developing unit (See it (Fig.
  • Page 699 (14) Disconnect 3 connectors and loosen 2 screws Fig. 30 of the Stay. Remove the Stay (Fig. 27). Fig. 27 Sensors Screw Screw Stay (19) Hold the both ends of the Drum. Then insert the Drum, tilting as shown in the figure. When the rear end of the Drum reaches an end, (15) Loosen a screw (A) and remove a screw (B) place the front end at the position (Fig.
  • Page 700 Caution: (26) Install the Coupling on the Drum shaft, with Hold the Blade unlock arm pushing up. the keyway of the Drum shaft meeting the engraving (A) on the Coupling. Then insert a Fig. 32 Blade charge lever plus screwdriver in the cross recess in the Coupling and rotate it clockwise one rotation or more until the notch on the Coupling (B) is flush with the level of the Drum bearing (C)
  • Page 701 (32) Insert the Coupling to the Drum shaft, meet- Note: ing the keyway of Drum shaft and the engrav- This process takes about 13 seconds and stops ing (A) of Coupling. Then apply a plus with the completion message appears on the screwdriver to the cross recess of the Cou- screen.
  • Page 702 (4) Return the lever to the original position. 12. Install the Working table. (5) Close the Toner supply unit and the Front door. (1) Open the Right upper cover and remove 2 screws securing the Upper cover (Fig. 39). Note: Refer to the “Toner supply procedure”...
  • Page 703 VI. Non-image area erase check 2. Remove the cover sticker on the rear side of the main body, then connect the straight twisted-pair 1. Insert the plug into the socket. category 5 (100BASE-TX) cable to the main 2. Turn ON the power switch while pressing the body.
  • Page 704 Blank page.
  • Page 705 UNPACKING AND INSTALLATION PROCEDURE FOR THE MAIN BODY AND OPTIONS Applied Machine : Force85/DP-85 I. Installation Space III. Unpacking (Unit:mm) [1] Package Size <Main Body> Fig. 01 Unit : mm Fig. 03 Main body 1096 <Main Body + Finisher + LCT> Packed weight: 300kg Fig.
  • Page 706 1. Place the wooden spacers under the Adjuster 5. Bring down the machine carefully on the floor by feet. Then extend the Adjuster feet enough to two persons (Fig. 08). remove the cushions with the spanner (Not Fig. 08 attached to the accessory box) (Fig. 05). Fig.
  • Page 707 V. Installation Procedure (2) Remove the locking tapes and locking guide tape of the Tray 1 (Fig. 11). Caution: Fig. 11 Confirm the Main switch is OFF and the power Locking guide tape cord is unpluged. Locking tape 1. Inspect the outward of the Main body and confirm that there is no damage.
  • Page 708 (7) Release the ADU lock located at the bottom of (11) Reinstall the Front-fixing unit cover. ADU unit by turning it with a finger to the left. (12) Return the ADU unit to the original position. While the ADU lock in release, turn the (13) Turn the Release lever to the locking position Release lever to the right.
  • Page 709 Withdraw the Drum unit support assembly (7) Hold both ends of the Developing unit and holding it as shown in the figure (Fig. 17). remove it carefully from the Drum unit support assembly. Caution: (8) Pull up the claws of the upper cover to remove •...
  • Page 710 (11) Reinstall the Developing unit cover. (14) Disconnect 3 connectors and loosen 2 screws of the Stay. Remove the Stay (Fig. Caution: 25). Confirm that both the bosses of the upper cover are put into the slots on the Developing unit (See Fig.
  • Page 711 (18) Clean the surfaces of Gamma detection sen- Caution: sor and Maximum density detection sensor Hold the Blade unlock arm pushing up. with alcohol and a cotton swab (Fig. 28). Fig. 30 Blade charge lever Fig. 28 Blade unlock arm Sensors e Release the Blade unlock arm.
  • Page 712 (25) Return the Drum unit support assembly to the until the notch level of the Coupling (B) and original position. the level of Drum bearing (C) become to be (26) Install the Coupling on the Drum shaft, with same (Fig. 32). the keyway of the Drum shaft meeting the (33) Fix the Coupling with a screw.
  • Page 713 Note: (4) Return the lever to the original position. This process takes about 13 seconds and stops (5) Close the Toner supply unit and the Front door. with the completion message appears on the Note: screen. Refer to the “Toner supply procedure” on the help (5) Enter the "Automatic gamma adjustment (1 menu of the Operation panel, as for the Toner bot- dot)"...
  • Page 714 VI. Operation Check 9. Connect the printer relay wiring / 1 the printer relay board following procedure 1. Load paper in each tray, then output the internal below.(Fig.36) pattern (No.16) to check the quality of the copy (1) Connect the connector of the printer relay wir- image.

  • Page 715: Installation Procedure

    FS-108/108B/108BM INSTALLATION PROCEDURE Finisher Applied Machines: FS-108: Konica 7075, FORCE75/DP75 FS-108B/108BM: Konica 7055/7065, Konica7075, FORCE75/DP75 I. Accessory parts II. Confirmation before installation Caution: Name Shape Q’ty 1. When transporting the Finisher, be sure to move it 1. Main body in the direction illustrated below so as not to de- installation form the casters on the paper exit tray side.
  • Page 716 III. Installation procedure for 7055/7065 6. Stick the handle label (B) on the paper jam pro- cessing door of the ADU conveyance unit (induc- [1] Installation procedure tion part) on the left side of main body. 1. Turn OFF the power switch of the main body, and unplug the power cord from the power outlet.
  • Page 717 9. Remove three lock materials from each guide 13. Install the paper exit up-down tray on the up-down plate. portion (paper exit side) of the Finisher. (Truss 10. Remove two stacker lock materials (right and left). screw M4x6: 2) [Caution] When installing paper exit up-down tray, fit the four Three lock materials auxiliary fittings to the guide holes of the paper exit...
  • Page 718 15. Install the paper exit tray /1 on the secondary exit Lower view portion, then fix it with screws. (SEMS II M3x6: 2) Main body Finisher SEMS II M3x6 Paper exit tray /1 [Caution] If the gap between Finisher and main body is not 16.
  • Page 719 [2] Setting Change in DIP SW –] keys on the screen and numeric keypads. (5) Toucn [SET] to complete the setting. [Caution] (6) Return to the copy screen, make another copy This setting change should be performed only for sample, then check again the gap amount of FS-108B/108BM with black paper folding spring the copy sample.
  • Page 720 III. Installation procedure for 7075, 5. Install the main body installation plate (upper) on the upper left side of main body. (TP screw M4x18: FORCE75/DP75 [1] Installation procedure Main body installation plate (upper) 1. Turn OFF the power switch of the main body, and unplug the power cord from the power outlet.
  • Page 721 9. Remove two lock materials inside the stacker 11. Install the paper exit tray (lower) on the lower (lower). up-down portion (paper exit side) of the Finisher. [Caution] The paper exit tray (lower) is attached to FS-108B/ 108BM only. Two lock materials 10.
  • Page 722 14. Install the Finisher on the main body. (2) Fix the Finisher to the main body (front side (1) Fit the hooks on the main body installation only). (TP screw M4x6: 3) plates (upper and lower) into the upper and lower holes on the Finisher as illustrated be- low, then lock them by pushing the Finisher to the back.
  • Page 723 b. Confirmation of Stapling & Folding function [4] Confirmation of operation (FS-108B/108BM only) If the copies are not stapled at the position ad- 1. Turn ON the power switch. justed in step a, perform the following adjust- 2. Place three originals into the RADF. ment.
  • Page 724 Blank page.
  • Page 725 FS-111/FS-211 INSTALLATION PROCEDURE Finisher Applied Machine : Konica 7085 I. Accessory parts II. Confirmation before installation Name Shape Q’ty Caution 1. When transporting the Finisher, be sure to move it 1 Main body in the direction illustrated below so as not to installation deform the casters on the paper exit tray side.
  • Page 726 III. Installation procedure 4. Install the main body installation plate (lower) on the lower left side of main body. (TP screw M4x6: 2) [1] Installation procedure 1. Turn OFF the power switch of the main body, and unplug the power cord from the power outlet. 2.
  • Page 727 8. Remove the lock tapes and the lock materials 9. Install the paper exit up-down tray on the up- inside the stacker. down portion (paper exit side) of the Finisher. [For FS-111] (Truss screw M4x6: 2) [Caution] Remove the lock tapes and the three lock materials. When installing paper exit up-down tray, fit the four auxiliary fittings to the guide holes of the paper exit up-down tray before fixing screws.Set the software...
  • Page 728 12. Connect the two connectors of the Finisher to [Caution] the two connectors on the rear left side cover of If the gap between Finisher and main body is not the main body. equal from the top through the bottom, adjust it by the height of the front and rear casters on the paper exit side of the Finisher.(shown:FS-211) Main body...
  • Page 729 [3] Confirmation of operation (FS-211 only) b. Confirmation of Stapling & Folding function If the copies are not stapled at the position 1. Turn ON the power switch. adjusted in step a, perform the following adjust- 2. Place three originals into the RADF. ment.
  • Page 730 Blank page.
  • Page 731 IP-601 INSTALLATION PROCEDURE Applied Machines: Konica 7075, FORCE75/DP75 I. Accessory parts III. Installation Procedure 1. Attach the two side regulate pads to the IP-601, Name Shape Q’ty then set the IP-601 in the main unit. (Fig. 01) Power cord [Note] When installing in the 7075 machine, use the side regulate pads supplied with the VI-601.
  • Page 732 3. Connect the IP-601 to the power supply socket 5. Check installation of the VIF board following the inside the main unit frame following the procedure procedure below. (except with the FORCE75/DP75) (1) Enter the x b mode. below. (Fig. 03) (2) Enter .
  • Page 733 IP-602 INSTALLATION PROCEDURE Printer Controller Applied Machine : Konica 7085 I. Accessory parts III. Installation procedures 1. Set the IP-602 in the main unit. Name Shape Q’ty 1 IP-602 2 Power cord 3 Ferrite core 2. When connecting the network cable to the IP- 602, attach the ferrite core supplied with the IP- 602.
  • Page 734 3. Connect the other connector of the printer relay 5. Connect the IP-602 to the power supply socket wiring / 2 already connected to the printer relay inside the main unit frame following the proce- board / 2, to the video interface port of the IP- dure below.
  • Page 735 7. Check installation of the VIF board following the procedure below. (1) Enter the x b mode. (2) Enter . “Indication of ROM version”. (3) Check the version number indicated on the right of “VIF”. The indication of the version number confirms that ROM is installed.
  • Page 736 Blank page.
  • Page 737 KN-302 INSTALLATION PROCEDURE Network Board Applied Machine: IP-601 Printer controller [1] Accessory parts [3] Installation procedures 1. Remove the 4 screws from the rear side of the Name Shape Q’ty printer controller and remove the external cover. KN-302 body Utility software CD Ferrite core [2] Preparations...
  • Page 738 3. Remove the slot cover (one screw). 5. Use the screw that was taken out when removing the slot cover to secure the KN-302 board. 4. Install the KN-302 board in the PCI slot. Align the front edge of the connector to the socket’s slot and insert the board firmly.
  • Page 739 KN-306 INSTALLATION PROCEDURE Network Board Applied Machine : IP-602 Printer Controller I. Accessory parts V. Installation procedure 1. Remove the two screws on the rear of the printer Name Shape Q’ty controller and detach the rear cover. 1 KN-306 Network board II.
  • Page 740 3. Insert the KN-306 board using into an available 4. Secure the KN-306 board with the screw removed PCI slot. Adjust the board’s connector to the in procedure 2. slot’s socket and firmly insert the board. Make Caution: sure the board has been firmly connected to the When installing the KN-306 board, make sure to socket and that it does not touch other boards.
  • Page 741 LT-401 INSTALLATION PROCEDURE Large Capacity Tray Applied Machine: Konica 7075, FORCE75/DP75 3. Remove the Paper pass cover plate, by removing I. Accessory parts 2 screws. Then fix again those screws at their tapped holes (Fig. 02). Name Shape Q’ty Caution: LCT Fixing Be sure to close the Jam recovery door before Plate...
  • Page 742 6. Install the Earth plate on the Main body with the Fig. 07 screw (M3 x 6) enclosed in the accessory box (Fig. 05). Fig. 05 IV. Adjustment Insert 2 LCT Connector jacks to the connector 1. Confirm that there is no level gap between the LCT plugs on the Main body (Fig.
  • Page 743 (4) Loosen the screws fixing the center-pinion gear Fig. 09 to adjust the set position of the Center-pinion gear, then secure them again (Fig. 12). Fig. 12 screws Center-pinion gear (5) Secure the screw fixing the Paper size setting plate (Fig. 13). Fig.
  • Page 744 [Adjustment for skew] (3) Loosen the screw of the bottom plate to adjust Move the set position of the positioning pin at the the marking line to the altered paper size and LCT bottom plate (Fig. 15). secure it again (Fig. 17) Fig.
  • Page 745 LT-402 INSTALLATION PROCEDURE Large Capacity Tray Applied Machine: Konica 7155,7165,7085 I. Accessory parts Name Shape Q’ty Name Shape Q’ty LCT Fixing 13 TP Screw Plate (M4x16) (7155/ 7165 only) 14 TP Screw Earth Plate 1 (M4x20) (7155/ (7085 only) 7165 only) 15 Truss Screw Earth Plate 2 (M4x8)
  • Page 746 3. Remove the screws from the Main body. (TP screw 7. Install Earth plate 2 (2 plates) on the Main Body M4x6: 4 pcs.) with the screws (TP screw M4x6: 2pcs.) from the accessory parts. Earth plate 2 TP screws M4x6 4.
  • Page 747 11. Install Earth plate 1 on the Main body with the 13. Install the cover at the back of the right side of screw (TP screw M4x6: 1 pc.) from the accessory the Main body. parts. TP screw M4x6 Tighten the screws Earth plate 1 12.
  • Page 748 15. Open the LCT Front door and mount the LCT on 17. Place the LCT tray display label on the LCT in the LCT fixing plates. Be sure to meet the the following position. positioning pin of LCT fixing plate to the junction hole of the LCT bottom plate on mounting.
  • Page 749 4. Move the positioning pins on the 2 LCT fixing plates 8. Install the Main body earth plate/rear onto the Main to the front holes (1 screw each). body with TP screw M4x20 (1 screw) and TP screw M3x6 (1 screw) included in the accessory parts. 9.
  • Page 750 12. Open the door on the left side and mount the LCT IV. Adjustment on the LCT fixing plates. Be sure to meet the [7155/7165] positioning pin of the LCT fixing plate to the 1. Make the vertical opening even between the Main junction hole of the LCT bottom plate on mounting.
  • Page 751 3. Correct the paper stacking by the following (8) Secure the screws fixing the Paper size setting procedures, if the “centering-errored” or “skewed” plate. output appears. [Adjustment for centering-error] The differential less than 4mm is corrected automatically through the paper pass mechanism of the Main body.
  • Page 752 V. Alteration of the Paper Size The default paper size is A4 or 8.5 x 11. If paper size is to be altered to B5, go to the following procedures. (1) Open the Top cover of the LCT. (2) Loosen the screws of the Paper guide side plates, and secure it again adjusting to the marking line for the altered paper size.
  • Page 753 LT-411 INSTALLATION PROCEDURE Large Capacity Tray Applied Machines: Konica 7075, FORCE75/DP75 III. Installation procedures I. Accessory parts 1. Remove all the locking tapes put on the LCT. Name Shape Q’ty 2. Remove 4 Caps inserted at the bottom of right side LCT fixing exterior panel of the Main Body, by pushing them plate...
  • Page 754 4. Install 2 LCT Fixing plates on the Main body with 9. Insert 2 LCT Connector jacks to the connector 2 screws (M4x8) for each (Fig. 03). plugs on the Main body (Fig. 06). Caution: Fig. 03 Keep the connector portion of the LCT near to the Main body as close as possible, in order to avoid any damage against the connector wires owing to their short length.
  • Page 755 [Adjustment for centering-error] IV. Adjustment The differential less than 4mm is corrected 1. Confirm that there is no level gap between the LCT automatically through the paper pass mechanism of fixing plate and the LCT bottom plate. If there is the Main body.
  • Page 756 (5) Secure the screw fixing the Paper size setting V. Alteration of the Paper Size plate (Fig. 14). If paper size is to be altered, go to the following Fig. 14 procedures. (1) Turn ON the Main power switch. (2) Open the LCT top door, then press the paper loading button to lower the LCT stack plate completely.
  • Page 757 VI. Installation of the Operation manual (5) Loosen the screw on the LCT bottom plate indicated below, adjust the End guide plate to holder the copy paper temporarily loaded in the LCT, Glue the Operation manual holder with the double then secure it again (Fig.
  • Page 758 Blank page.
  • Page 759 LT-412 INSTALLATION PROCEDURE Large Capacity Tray Applied Machine: Konica 7155,7165,7085 I. Accessory parts Name Shape Q’ty Name Shape Q’ty LCT Fixing 13 TP Screw Plate (M4x16) (7155/ 7165 only) 14 TP Screw Earth Plate 1 (M4x20) (7155/ (7085 only) 7165 only) 15 Truss Screw Earth Plate 2 (M4x8)
  • Page 760 3. Remove the screws from the Main body. (TP screw 7. Install Earth plate 2 (2 plates) on the Main Body M4x6: 4 pcs.) with the screws (TP screw M4x6: 2pcs.) from the accessory parts. Earth plate 2 TP screws M4x6 4.
  • Page 761 11. Install Earth plate 1 on the Main body with the 13. Install the cover at the back of the right side of screw (TP screw M4x6: 1 pc.) from the accessory the Main body. parts. TP screw M4x6 Tighten the screws Earth plate 1 12.
  • Page 762 15. Open the LCT Front door and mount the LCT on 17. Place the LCT tray display label on the LCT in the LCT fixing plates. Be sure to meet the the following position. positioning pin of LCT fixing plate to the junction hole of the LCT bottom plate on mounting.
  • Page 763 8. Install the Main body earth plate/rear onto the Main 4. Move the positioning pins on the 2 LCT fixing plates to the front holes (1 screw each). body with TP screw M4x20 (1 screw) and TP screw M3x6 (1 screw) included in the accessory parts. 9.
  • Page 764 12. Open the door on the left side and mount the LCT IV. Adjustment on the LCT fixing plates. Be sure to meet the [7155/7165] positioning pin of the LCT fixing plate to the 1. Make the vertical opening even between the Main junction hole of the LCT bottom plate on mounting.
  • Page 765 3. Correct the paper stacking by the following (8) Secure the screws fixing the Paper size setting procedures, if the “centering-errored” or “skewed” plate. output appears. [Adjustment for centering-error] The differential less than 4mm is corrected automatically through the paper pass mechanism of the Main body.
  • Page 766 (5) Loosen the screw on the LCT bottom plate V. Alteration of the Paper Size indicated below, adjust the End guide plate to If paper size is to be altered, go to the following the copy paper temporarily loaded in the LCT, procedures.
  • Page 767 MU-401/402 INSTALLATION PROCEDURE Applied Machines: MU-401:Konica 7075/7085/FORCE75/DP75 Konica 7155/7165/IP-601/IP-601M/IP-602/IP-304 MU-402:Konica 7075/7085/FORCE75/DP75 Konica 7155/7165 I. Precautions on Handling III. Installation Procedure [Konica 7075/7085/FORCE75/DP75] 1. Precautions against static electricity • Keep the Memory unit in an antistatic bag while 1. Turn the Main switch OFF, and unplug the power transporting or storing.
  • Page 768 2. Remove the Control board cover (for FORCE75/ 3. Install the Memory unit in one of the Control board DP75). slots CN115, CN116 or CN117. (1) Remove the Upper cover by removing 8 screws. Note: The first installation of the optional Memory unit is recommended to install in the CN115 slot in order Upper cover to leave the easiness for full installation (3 Memory...
  • Page 769 5. Confirmation of the Memory Capacity 4. Remove the Control board cover. (6 screws) (1) Plug the power cord to the outlet. (2) Turn the Main switch ON pressing the ten key [4] and [7] simultaneously. (Enter the 47 mode.) (3) Press the ten key [9] and then [7].
  • Page 770 7. Confirmation of the Memory Capacity 3. Install the Memory unit. (1) Plug the power cord to the outlet. Note: (2) Turn the Main switch ON pressing the ten key The first installation of the optional Memory unit is [4] and [7] simultaneously. (Enter the 47 mode.) recommended to install in the slot to the right of the (3) Press the ten key [9] and then [7].
  • Page 771 2. Remove the outside cover by removing the two 5. Reinstall the Reinforcement board. (2 screws) screws on the rear of the printer controller. Caution: Press the Reinforcement board in the direction of the arrow, then fix it. Reinforcement board Screw 3.
  • Page 772 3. Remove the Reinforcement board. (2 screws) 6. Reinstall the outside cover. (2 screws) Caution: Reinstall the outside cover by pressing it down so that it slides into position. Reinforcement board Screw 4. Install the Memory unit. Note: The first installation of the optional Memory unit is recommended to install in the slot to the right of the one where a memory unit is already present in order to leave the easiness for full installation (3 Memory...
  • Page 773 PI-108 INSTALLATION PROCEDURE Cover Sheet Feeder Applied Machine: FS-111/FS-211 FS-108/FS-108B/FS-108BM I. Accessory parts Name Shape Q’ty Name Shape Q’ty Wire bundle Operation clamp control board Miniclamp Drive control board 10 Wire saddle Size detection sensor 11 Locking wire saddle 12 Locking Operation support label...
  • Page 774 2. Remove the rear cover from the finisher. II. Installation Truss screw M4x6: 5 1. Remove the top cover from the finisher. (1) Open the subtray cover,remove the fixing screws, and then remove the paper exit tray/1. Fixing screws Paper exit tray /1 (2) Remove the caps on the rear side of the top Rear cover cover and then remove the two screws.
  • Page 775 4. Install the accessories on the underside of the top 5. Install Pl-108. cover. (1) Install PI-108 on the top of finisher. (TP screw (1) Install the switch buttons. M4x6: 6) (2) Install the operation control board. (Tapping Note: screw M3x8: 2) When installing the Pl-108, make sure to position it (3) Install two size detection sensors.
  • Page 776 6. Arrange the wire bundle. 8. Attach the Wire bundle clamp to the top front part (1) Insert five locking wire saddles into the fin- of the finisher, and use it to secure the PI-108 wire isher. bundle. (2) Secure the bundle with three wire saddles on the top.
  • Page 777 10. Reinstall the top cover. (6) Install the paper exit tray/1 on the secondary (1) Connect the CN of the size detection sensor. exit portion, then fix it with the two screws re- moved in (1) of step 1. Fixing screws CN of the size detection sensor Paper exit tray /1...
  • Page 778 15. Install the finisher to the copier. 16. Adjust the size of the paper-width guide. 16. Adjust the size of the paper-width guide. [In case of 7075/7085, FORCE75/DP75] [In case of 7055/7065] (1) While holding down the numeric keys [3] and (1) While holding down the numeric keys [3] and [6] on the copier control panel simultaneously [6] on the copier control panel simultaneously...
  • Page 779 PS-361 PostScript 3 Option Setup Procedures Manual Applied Machine: IP-601 Printer controller [1] Accessory parts 2. Remove the parallel port’s security board (one screw). Name Shape Q’ty PS-361 (Instruction manual/Drivers) Screw 3. Install the PS-361 on the parallel port’s security board.
  • Page 780 Blank page.
  • Page 781 PS-362 PostScript 3 Option Setup Procedures Manual Applied Machine: IP-602 Printer controller [1] Accessory parts [4] Setup procedure 1. Remove the 2 screws from the rear side of the Name Shape Q’ty printer controller and remove the external cover. PS-362 CD-ROM (Instruction manual/Drivers)
  • Page 782 4. Return the printer relay board / F to its original position, making sure that the board’s connector is firmly inserted in the socket of the PCI slot. Caution: Make sure that the board’s connector is firmly inserted in the socket. 5.
  • Page 783 PU-108 PUNCH UNIT INSTALLATION PROCEDURE Applied machines: Konica 7085, Konica 7075, Force 75, DP-75, Konica 7055/7065 I. Accessory parts Name Shape Q’ty Name Shape Q’ty Magnet Punch unit Binding band (for use when installing 7055 /7065) Main body installation stay 10 Sponge (for FS-106) Finisher...
  • Page 784 2. Remove the two lock materials and the two lock II. Confirmation before installation tapes from the PU-108. 1. For installation of the Finisher, refer to the installation procedure for each Finisher type. 2. Machines applicable to each Finisher type are as follows: FS-108: 7075, Force75, DP-75 FS-108B/108BM: 7075, 7055/7065, Force75, DP-75...
  • Page 785 5. Remove the two black magnets (2 screws each) (2) While tilting the PU-108, put it on the right side from the Finisher. Replace with the two white of the Finisher. magnets included in the accessory parts using Caution: the original screws removed. Be sure to perform this work by two persons.
  • Page 786 [For FS-106 Finisher] 1. Detach the FS-106 Finisher from the main body, if already installed. [Preparations] (1) Turn the power to the main body OFF, then The front-door assembly has been set up for the unplug the power cord from the power outlet. FS-108/108B/108BM, FS-111/211 Finisher at the (2) Remove the screws fixing the Finisher to the factory.
  • Page 787 3. Open the Finisher front door. 5. Remove the two black magnets from the Finisher. 4. Install the front-door assembly on the Finisher front (2 screws each) door. Replace with the two white magnets included in (1) Remove the two magnet catcher plates. (1 the accessory parts using the original screws screw each) removed.
  • Page 788 8. Install the Finisher installation stay on the upper- 12. Attach the sponge for FS-106 on the upper-right- right side of the Finisher. (TP screw M4x6: 2 pcs., center side of the Finisher. TP screw M3x6: 1pc.) Caution: Sponge • Tighten the screws in sequence from the rear. •...
  • Page 789 5. Connect the two PU-108 connectors to the IV. Installation procedure for main body connectors on the rear paper-exit side of the main body. [For Konica 7085/ 7075/ Force 75/ DP-75] [PU-108+FS-108/108B/108BM and PU-108+FS-111/211 installation procedure] 1. Turn the power to the main body OFF, then unplug the power cord from the power outlet.
  • Page 790 Caution: 7. Secure the PU-108 and the Finisher (lower front If the PU-108+the Finisher cannot be aligned side). (TP screw M4x6: 2 pcs.) correctly with the main body, adjust the height of Caution: the casters on the paper-exit side of the Finisher. Be sure to secure the main body and the PU-108 +the Finisher before tightening the screws to secure the PU-108 and Finisher to each other.
  • Page 791 9. Adjust the front-door assembly. (2) Confirming the ROM version (Force 75/DP-75) (1) While maintaining alignment of the opening at Confirm that the ROM version is set to 20 or the top of the Finisher front door and the opening higher for the main body.
  • Page 792 Punch horizontal position adjustment Use the numeric keys to enter a numerical Adjust the horizontal punching position. value, then press the SET key. Setting range: -20 to +20 Step Operation 1 step = 0.8 mm Set to 36 mode. Repeat steps 5 to 9 until the amount of [36 mode menu] punching-resistance loop is correctly set.
  • Page 793 5. Remove the sensor cover of the chad-collection [For Konica 7055/7065] duct. Change the position for insertion into the sensor cover from the 5th to the 4th ridge. [PU-108+FS-108B/108BM installation proce- dure] 1. Turn the power to the main body OFF, then unplug the power cord from the power outlet.
  • Page 794 8. Install the PU-108+the FS-108B/108BM on the Caution: main body. If the PU-108+the FS-108B/108BM cannot be (1) Lower the paper guide of the PU-108 (by aligned correctly with the main body, adjust the pushing up the lever). height of the casters on the paper-exit side of the FS-108B/108BM.
  • Page 795 9. Secure the PU-108 and the Finisher (lower front 11. Adjust the front-door assembly. side). (TP screw M4x6: 2 pcs.) (1) While maintaining alignment of the opening at the top of the Finisher front door and the opening Caution: at the top of the PU-108 front-door assembly, Be sure to secure the main body and the PU-108 run in the screws.
  • Page 796 (2) Setting the software DIP switches (7055/7065) Set paper in the tray, then set the original Set the DIP switches for 25-mode software if and press the Start button. the PU-108 for either 2, 3 or 4 punching holes Confirm the horizontal punching position. has been installed.
  • Page 797 5. Remove the sensor cover of the chad-collection [For Konica 7055/7065] duct. Change the position for insertion into the sensor cover from the 5th to the 4th ridge. [PU-108+FS-106 installation procedure] 1. Turn the power to the main body OFF, then unplug the power cord from the power outlet.
  • Page 798 (2) Connect the two PU-108 connectors to the Caution: connectors on the rear paper-exit side of the If the main body and the PU-108+the FS-106 cannot main body. be set correctly, adjust by turning the level adjustment bolts on the front and rear sides of the FS-106.
  • Page 799 (4) Fix the PU-108+the FS-106 to the main body. 10. Adjust the front-door assembly. When fixing the unit, tighten the knob screw (1 (1) While maintaining alignment of the opening at pc.) and the lower screws (TP screw M4x8: 2 the top of the Finisher front door and the opening pcs.) in sequence.
  • Page 800 (2) Setting the software DIP switches (7055/7065) Set paper in the tray, then set the original Set the DIP switches for 25-mode software if and press the Start button. the PU-108 for either 2, 3 or 4 punching holes Confirm the horizontal punching position. has been installed.
  • Page 801 PZ-108 Z-FOLDING+PUNCH UNIT INSTALLATION PROCEDURE Applied machines: Konica 7155/7165, 7075, Force 75, DP-75,7085 I. Accessory parts Name Shape Q’ty Name Shape Q’ty Knob screw Punch unit TP screw M4x6 (7155/7165:2 remainders) 10 S-tight screw M3x6 Main body installation stay 11 Truss screw M4x6 12 B-tight flat screw...
  • Page 802 3. Open the Finisher front door. II. Confirmation before installation 4. Install the front-door assembly on the Finisher front 1. Turn the power to the main body OFF, then unplug door. the power cord from the power outlet. (1) Loosen the two screws fixing the cover plate on 2.
  • Page 803 (6) Temporarily secure the actuator removed in 7. Install the Finisher installation stay on the upper- Step 4-(1) to the front door of the Finisher using right side of the Finisher. (S-tight screw M3x6: 4 the two screws removed. pcs.) (7) Fully tighten the two screws for the cover plate 8.
  • Page 804 (6) Push the pin of the positioning plate into the 3. Remove the installation plate (1 screw) from the connecting part of the PZ-108 and Finisher, and main body installation plate (upper) <Finisher temporarily secure the positioning plate with accessory part>, then install it on the main body screws.
  • Page 805 6. Install the PZ-108+the Finisher on the main body. Caution: (1) Lower the paper guide of the PZ-108 (by If the PZ-108+the Finisher cannot be aligned pushing up the lever). correctly with the main body, adjust the height of the casters on the paper-exit side of the Finisher. Lever Adjust inclination.
  • Page 806 7. Secure the PZ-108 and the Finisher (lower front 9. Adjust the front-door assembly. side). (TP screw M4x6: 2 pcs.) (1) Adjust the gap in the upper portion between the front door of the Finisher and the front-door Caution: assembly of the PZ-108. Be sure to secure the main body and the PZ-108 Adjust it by loosening the five screws indicated +the Finisher before tightening the screws to secure...
  • Page 807 11. Open the Finisher front door, pull out the stacker, 14. Connecting the power cord move the paper-exit arm to the position shown in (1) Secure the rear cover of the PZ-108 with 3 of the illustration, and cut the tab off the paper-exit the 4 screws, temporarily omitting the screw for arm (for the FS-108/108B/108BM only).
  • Page 808 (3) Adjustment Step Operation [Punch horizontal position adj menu] Punch Vertical position adjustment Use the numeric keys to enter a numerical Adjust the vertical punching position. value, then press the SET key. Step Operation Setting range: -50 to +50 Set to 36 mode. 1 step = 0.1 mm [36 mode menu] Repeat steps 5 to 9 until the horizontal...
  • Page 809 Z-folding position adjustment Z-folding adjustment value Unit(mm) Step Operation Length of second fold Deviance on Length of first Set to 36 mode. (L) adjustment value edge (a) fold (b) [36 mode menu] 11x17 3.5±1.5 (108) Press 6 Finisher adjustment. 3.5±1.5 (105) [Finisher adjustment mode menu] 3.5±1.5...
  • Page 810 (2) Detach the Finisher from the main body. Installation procedure for (3) Disconnect the two connectors linking the 7155/7165+FS-110/210 Finisher to the main body. 2. Remove the lock materials and the lock tapes from Caution: the PZ-108. In order to install the 7155/7165 + FS-110/210 to the PZ-108, you will need the A-kit.
  • Page 811 (3) Install the fan unit. (TP screw M3x4: 2 pcs.) (7) Reinstall the stacker stopper screws that you removed in Step 3 (2 screws). (8) If the Punch Kit is installed in the Finisher, stick TP screws M3 4 the Punch Label 2 on the handle of the waste basket.
  • Page 812 (3) Remove the upper and lower magnet catcher (7) Temporarily secure the actuator removed in plates (1 screw for each) and remove the Step 4-(3). actuator from the front door of the Finisher. (8) Loosen the screws fixing the two magnet Loosen the upper screw and remove the lower catcher plates (2 screws for each).
  • Page 813 7. Remove the stay fixed on the upper-left side of (3) While tilting the PZ-108, put it on the right side the PZ-108 (2 screws), then fix it again in the lower of the Finisher. position (with 106 mark). Caution: Be sure to perform this work by two persons.
  • Page 814 5. Connect the two PZ-108 connectors to the [3] Installation procedure for main body connectors on the rear paper-exit side of the main 1. Turn the power to the main body OFF, then unplug body. the power cord from the power outlet. 2.
  • Page 815 Caution: 7. Secure the PZ-108 and the Finisher (lower front If the PZ-108 + FS-110/210 cannot be aligned side). (Knob screw : 1 pc.)(Finisher parts) correctly with the main body, adjust the height of Caution: the casters on the paper-exit side of the Finisher. Be sure to secure the main body and the PZ-108 + Finisher before tightening the screws to secure the PZ-108 and Finisher to each other.
  • Page 816 11. Hook the Finisher I/F wire bundle (For ISW) to 9. Adjust the front-door assembly. the wire saddle on the bottom of the board as (1) Adjust the gap in the upper portion between the shown below. front door of the Finisher and the front-door assembly of the PZ-108.
  • Page 817 (2) Setting the software DIP switches Step Operation Set the DIP switches for 25-mode software if Confirm the horizontal punching position. the PZ-108 for either 2, 3 or 4 punch holes has Standard: 10.5mm(AB size)/9.5mm(inch size) been installed. (See the table below.) If the horizontal punching position is not DIPSW 22-1 22-2...
  • Page 818 Z-folding position adjustment Z-folding adjustment value Unit(mm) Step Operation Length of second fold Deviance on Length of first Set to 36 mode. (L) adjustment value edge (a) fold (b) [36 mode menu] 11x17 3.5±1.5 (108) Press 6 Finisher adjustment. 3.5±1.5 (105) [Finisher adjustment mode menu] 3.5±1.5...

  • Page 819: Trimmer Unit

    TU-108 INSTALLATION PROCEDURE TRIMMER UNIT Applicable Machine: FS-108B/FS-108BM/FS-211 I. Accessory parts Name Shape Q’ty Name Shape Q’ty 11 Truss screw Trimmer unit M4x6 12 TP screw M4x6 13 TP screw M3x6 Inlet pressure plate assembly CAUTION For your safety operation of TU-108 choose suitable power supply cable with following instruction.
  • Page 820 4. Unfold the inlet guide plate assembly, hook the (2) Put the six NK clamps onto the positions front and rear fixing plates on two ribs, then fix indicated below. them with two TP screws (M4x6). Inlet guide plate assembly NK clamps TP screw TP screw...
  • Page 821 (4) Fix the ground wire of the finisher wiring/N at 6. Set the trimmer unit into the finisher. the position indicated below using a screw fixing (1) Open the finisher front door, then remove three the folder unit. TP screws (M3x6: 2 and M4x6: 1) to remove the upper paper exit guide plate.
  • Page 822 (5) Stick the inlet guide sheet to the paper exit guide (8) Connect the three connectors of the trimmer unit plate. to those of the finisher wiring/N laid in step 5. • Clean the paper exit guide plate of the finisher using a cloth slightly dampened with alcohol.
  • Page 823 (10) Push the lock plate back, then fix it with a screw. III. Adjustment [Caution] Be sure to perform the parallelizing adjustment first, then proceed to the trimmer stopper adjustment, as described below. Parallelizing adjustment 1. Turn on the power of the main body. 2.
  • Page 824 Trimmer stopper adjustment (5) Return the conveyance guide pressure lever. (6) Tighten two fixing screws. For Konica 7075/Force75/DP75/7085 (7) Close the left door of the trimmer unit. [Caution] Perform this adjustment for all paper sizes to be Trimmer stopper adjustment used for making trimmed copies (Use two originals For Konica 7055/7065 for this adjustment).
  • Page 825 VI Kit VI-601 INSTALLATION PROCEDURE Applied Machine: Konica 7075 I. Accessory parts Name Shape Q’ty Name Shape Q’ty Printer 13 Side regulate relay board / 1 II. Preparations Printer relay board / 2 1. Always carry out installation of the VI-601 together with the IP-601.
  • Page 826 III. Installation Procedure Fig. 02 [Preparations] 1. If a finisher is connected, remove the finisher from the main unit. 2. Remove the left side panel, rear panel / 1, rear panel / 2, upper panel (rear) following the procedure below. Positioning of each of the outer panels is indicated in Fig.
  • Page 827 [Installation of the printer relay board and relay Fig. 05 wiring] 1. Install the printer relay board / 1 following the Printer relay board / 2 procedure below. (Fig. 04) (1) Hold the printer relay board / 1 so that its supporting metal bracket is on the left side, and TP screw the connectors of the board face the main unit,...
  • Page 828 4. Connect the printer relay wiring / 1 and the board Fig. 08 power cable to the printer relay board / 1 following Printer relay wiring / 2 the procedure below. (Fig. 07) Fix with the mounting (1) Connect the connector of the printer relay wiring clamps.
  • Page 829 VI Kit VI-602 INSTALLATION PROCEDURE Applied Machine: Konica 7085 I. Accessory parts II. Preparations Name Shape Q’ty 1. Always carry out installation of the VI-602 together Printer with the IP-602. relay board / 1 2. Before you start the installation procedure, turn off the power switch of the IP-602 and the main switch of the main unit, and make sure to disconnect the power cord from the power point.
  • Page 830 (4) Unscrew the 2 screws for each of the right and III. Installation Procedure left ADF stoppers on the ADF rear, and remove the stoppers. Then open and set the ADF in an [Preparations] upright position, unscrew the 3 screws, and 1.
  • Page 831 3. After having installed the upper panel (rear), fix [Installation of the printer relay board] the ADF stopper with the screws. 1. Install the printer relay board / 1 following the procedure below. 4. Install the rear panel. (1) Hold the printer relay board / 1 so that its 5.
  • Page 832 Blank page.
  • Page 833 APPENDIX 7085 OVERALL WIRING DIAGRAM...
  • Page 835 7085 OVERALL WIRING DIAGRAM APPENDIX [1] 7085 OVERALL WIRING DIAGRAM FT41 CN19-1 MS 2 MS 1 FT10 FT12 MAIN SW INTERLOCK MS2 INTERLOCK MS1 CN13-1 CN13-2 CN10-1 88-1A 88-1B 89-1B 89-1A 900-1 5V DC CN2-1 CN20-1 CN20-3 AC_HOT CN80-1 CN80-3 900-2 SGND FT14 FT16...
  • Page 836 7085 OVERALL WIRING DIAGRAM (VIEW A) FT41 CN19-1 MAIN SW FT10 FT12 CN13-1 CN13-2 CN10-1 CN2-1 CN20-1 CN20-3 FT14 FT16 AC_HOT RESET FT18 FT19 SWITCH CN21-2 CN10-3 CN1-1 TRAY CN13-3 CN21-1 CN13-4 FT20 AC_HOT FT21 DCPS1 HEATER SWITCH FT101 FT100 CN2-2 CN10-2 AC_NEU...
  • Page 837 CN52-2 SGND CN55-7 SGND CN52-3 REM/2 CN57-1 12V DC CN52-4 REM/1 CN57-4 12V DC CN52-5 SW_SIG CN57-5 SGND CN58-3 12V DC CN51-1 S.GND CN58-4 12V DC CN51-2 5V DC CN58-8 SGND CN51-3 SGND CN60-1 -5V DC CN51-4 REM/2 CN60-3 -5V DC CN60-5 SGND 60-5-2 60-6-1...
  • Page 838 7085 OVERALL WIRING DIAGRAM (VIEW C) 55VA8841 FT24 FT25 CN11-1 219-1 CB5V 219-2 TxD IPRL 219-3 RTS 219-4 DTR FT112 FT113 CN90-1 KRDS 903-1 5V DC 219-5 RxD CN90-2 903-2 RL3 DRIVE 219-6 CTS CN90-3 219-7 DSD 903-3 5V DC CN90-4 903-4 RL2 DRIVE 219-8 DSR...
  • Page 839 7085 OVERALL WIRING DIAGRAM (VIEW D) WRITE SECTION 200V SYSTEM SCANNER EXPOSURE LAMP INDEX SB LDB1 LDB2 SENSOR1 SENSOR2 SENSOR3 SENSOR4 SENSOR5 SENSOR6 SENSOR7 SCANNER LASER PS62 PS63 PS64 PS65 PS66 PS67 PS68 CORRECTION MOTOR SCANNER COOLING L1 INVB LAMP UNIT SCANNER ADF BRAKE...
  • Page 840 7085 OVERALL WIRING DIAGRAM (VIEW E) CN 141 (EXTENTION) EU ONLY CN162 OTHER -DIRECTRY CN150 LDB2 CN161 178-1-9 141-1-6 150-1 DATA_M 178-2-8 141-2-5 150-2 DATA_OP 178-3-7 141-3-4 150-3 ACK_M 178-4-6 141-4-3 150-4 ACK_OP 178-5-5 141-5-2 150-5 REQ_M 178-6-4 141-6-1 150-6 REQ_OP 475-3 24bit CN151-5 WT_LED...
  • Page 841 7085 OVERALL WIRING DIAGRAM (VIEW F) VI-602 MEMORY BOARD CN 113 CN 196 CN 197 173-8-1 CN137-B1 RXD 173-7-2 CN137-B2 REQ_R 173-6-3 CN137-B3 ACK_R 173-5-4 CN137-B4 TXD 173-4-5 DF-317 CN137-B5 REQ_T 173-3-6 CN137-B6 ACK_T 173-2-7 CN137-B7 DDF_VV 173-1-8 CN137-B8 COVER CN137-B9 SGND IP-602 CONNECT...
  • Page 842 7085 OVERALL WIRING DIAGRAM (VIEW G) 300-2 PGND2 301-1 24V DC 301-2 PGND3 401-1 24V DC 401-2 PGND3 DRUM DPSB PS42 PS41 PS31 PS30 TEMPERATURE SENSOR SEPARATION CHARGER CHARGER BLADE BLADE BLADE TONER CLAW SD CLEANING CLEANING SENSOR2 SENSOR1 MOTOR SUPPLY LIMIT HP SENSOR...
  • Page 843 7085 OVERALL WIRING DIAGRAM (VIEW H) PRCB COPY LOOP VENDOR PAPER ROLLER EXIT MOTOR MOTOR DEVELOPING MAIN MOTOR MOTOR POLYG MOTO ADU STAND TRANSFER REGISTRATION PAPER TRANSFER/ PAPER FIXING PAPER REGIST- MOTOR REVERSE SEPARATION EXIT FAN GATE LOCK REVERSE PRE- RATION MOTOR REVERSE...
  • Page 844 7085 OVERALL WIRING DIAGRAM (VIEW I) 218-6 SGND 756-6-7 218-7 FIN_RXD 756-5-8 218-8 SGND 756-4-9 218-9 FIN_RREQ 756-3-10 218-10 SGND 756-2-11 218-11 FIN_RACK 756-1-12 218-12 SGND PMDB MAIN MOTOR PAPER FEED MOTOR DRUM MOTOR POLYGON MOTOR PAPER REGIST- REGIST- LEADING LOCK REVERSE PRE-...

This manual is also suitable for:

7075/force 75

Table of Contents
