Phone Installation
•
•
•
•
Cisco Unified IP Phone 7931G Connections
The following figure and table show how to connect your phone.
1
2
Cisco Unified IP Phone 7931G Connections, page 1
Adjust the Handset Rest, page 2
TAPS Registration, page 3
Headset Support, page 3
DC Adaptor port (DC48V)
Network port (10/100 SW)
Cisco Unified IP Phone 7931G User Guide for Cisco Unified Communications Manager 9.0 (SCCP and SIP)
1
Advertisement
Related Manuals for Cisco 7931G
Summary of Contents for Cisco 7931G
-
Page 1: Phone Installation
Cisco Unified IP Phone 7931G Connections The following figure and table show how to connect your phone. DC Adaptor port (DC48V) Network port (10/100 SW) Cisco Unified IP Phone 7931G User Guide for Cisco Unified Communications Manager 9.0 (SCCP and SIP) -
Page 2: Phone Cable Lock
Phone Cable Lock You can secure the Cisco Unified IP Phone to a desktop using a laptop cable lock. The lock connects to the security slot on the back of the phone, and the cable can be secured to a desktop. -
Page 3: Taps Registration
An audible hum or buzz may be heard by either the remote party or by both the remote party and the Cisco Unified IP... -
Page 4: Audio Quality
Beyond physical, mechanical, and technical performance, the audio portion of a headset must sound good to the user and to the party on the far end. Sound quality is subjective and Cisco cannot guarantee the performance of any headsets. However, a variety of headsets from leading headset manufacturers are reported to perform well with Cisco Unified IP Phones.
