Vulcan-Hart VK Series Service Manual

W/wo kleenscreen plus
Hide thumbs Also See for VK Series:
Table of Contents

Advertisement

Quick Links

See also: Operation & Installation Manual
This Manual is prepared for the use of trained Vulcan Service
Technicians and should not be used by those not properly
qualified.
This manual is not intended to be all encompassing. If you have
not attended a Vulcan Service School for this product, you should
read, in its entirety, the repair procedure you wish to perform to
determine if you have the necessary tools, instruments and skills
required to perform the procedure. Procedures for which you do
not have the necessary tools, instruments and skills should be
performed by a trained Vulcan Service Technician.
The reproduction, transfer, sale or other use of this Manual,
without the express written consent of Vulcan, is prohibited.
This manual has been provided to you by ITW Food Equipment
Group LLC ("ITW FEG") without charge and remains the property
of ITW FEG, and by accepting this manual you agree that you will
return it to ITW FEG promptly upon its request for such return at
any time in the future.
A product of Vulcan-Hart
SERVICE MANUAL
VK and TR GAS FRYERS W/Wo
KleenScreen PLUS
VK Series
TR Series
- NOTICE -
3600 North Point Blvd Baltimore, MD 21222
F45474 (0413)

Advertisement

Table of Contents
loading

Related Manuals for Vulcan-Hart VK Series

Summary of Contents for Vulcan-Hart VK Series

  • Page 1 ITW FEG, and by accepting this manual you agree that you will return it to ITW FEG promptly upon its request for such return at any time in the future. A product of Vulcan-Hart 3600 North Point Blvd Baltimore, MD 21222 F45474 (0413)

  • Page 2: Table Of Contents

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS TABLE OF CONTENTS GENERAL ....................4 INTRODUCTION .
  • Page 3 VK and TR GAS FRYERS W/Wo KleenScreen PLUS MODULATING GAS VALVE ADJUSTMENTS ............27 BASKET LIFT ARM ADJUSTMENT .

  • Page 4: General

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - GENERAL GENERAL INTRODUCTION This service manual covers the specific service information related to the models listed in the chart below. The VK and TR series gas fryers come equipped with solid state analog (A), solid state digital (D) or programmable computer (C) controls.

  • Page 5: Models, Features And Options

    The KleenScreen PLUS® filtration system is stainless steel clip that holds the assembly together. integrated into the VK Series fryer battery. The filter is With the filter drawer closed, a self-sealing oil return housed in a pullout drawer assembly at the base of line provides the path to return the filtered shortening the fryer.

  • Page 6: Serial Number Location

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - GENERAL This system is designed to provide a through and easy method to filter the shortening. Some of the benefits include: • Self-contained system eliminating the use of external filter equipment •...

  • Page 7: Installation

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - GENERAL • VOM with A.C. current tester (any quality VOM with a sensitivity of at least 20,000 ohms per volt can be used). SPECIAL • Temperature tester (thermocouple type) • Manometer. •...
  • Page 8 VK and TR GAS FRYERS W/Wo KleenScreen PLUS - GENERAL unit). On fryers built after 12/1/12 an incoming gas pressure regulator is installed on the fryer. VKINPUT BTU RATING VK SERIES BTU/HR/SECTION VK45A, VK45AF, VK45D, VK45DF, VK45C, 70,000 VK45CF VK65A, VK65AF, VK65D,...

  • Page 9: Removal And Replacement Of Parts

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - REMOVAL AND REPLACEMENT OF PARTS REMOVAL AND REPLACEMENT OF PARTS COVERS AND PANELS Disconnect the electrical power to the machine and follow lockout / tagout procedures. Shut off the gas before servicing the unit.

  • Page 10: Analog Control

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - REMOVAL AND REPLACEMENT OF PARTS ANALOG CONTROL Disconnect the electrical power to the machine and follow lockout / tagout procedures. Shut off the gas before servicing the unit. Open the door. Unplug wiring harnesses from bottom of control box.

  • Page 11: Interface Control - D And Cseries

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - REMOVAL AND REPLACEMENT OF PARTS INTERFACE CONTROL - D and C POWER SWITCH - D and C SERIES SERIES Disconnect the electrical power to the machine and Disconnect the follow lockout / tagout procedures. electrical power to the machine and follow lockout / tagout procedures.

  • Page 12: High Limit Thermostat

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - REMOVAL AND REPLACEMENT OF PARTS Unplug temperature probe lead wire connector. Install new probe making sure that probe is installed into bracket shown. HIGH LIMIT THERMOSTAT Disconnect the electrical power to the machine and follow lockout / tagout procedures.

  • Page 13: Power Supply Box

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - REMOVAL AND REPLACEMENT OF PARTS POWER SUPPLY BOX Disconnect the electrical power to the machine and follow lockout / tagout procedures. Shut off the gas before servicing the unit. All gas joints disturbed during servicing must be checked for leaks.

  • Page 14: Power Supply Box Components Before 12/1/12

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - REMOVAL AND REPLACEMENT OF PARTS Fig. 23 Reverse procedure to install. POWER SUPPLY BOX COMPONENTS BEFORE 12/1/12 NOTE: The ignition module, blower control board and the time delay timers will not be available to the field any longer.

  • Page 15: 120 Volt Transformer

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - REMOVAL AND REPLACEMENT OF PARTS Fig. 24 Reverse procedure to install new relay. Reinstall power supply box and check operation. Fig. 25 120 Volt Transformer Reverse procedure to install new transformer. Remove POWER SUPPLY BOX.

  • Page 16: Control Board

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - REMOVAL AND REPLACEMENT OF PARTS Reinstall power supply box and check operation. Filter Relays Remove POWER SUPPLY BOX. Note location of wiring to the relays and remove wiring. Fig. 26 Fig. 28 Reverse the procedure to install new Remove screws and remove from box.

  • Page 17: Gas Valve

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - REMOVAL AND REPLACEMENT OF PARTS Reverse procedure to reinstall burner. GAS VALVE Disconnect the electrical power to the machine and follow lockout / tagout procedures. Shut off the gas before servicing the unit.

  • Page 18: Basket Lift Motor

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - REMOVAL AND REPLACEMENT OF PARTS Fig. 32 Remove screws securing basket lift motor to cam bracket, then remove motor from bracket. Fig. 31 Reverse procedure to install. BASKET LIFT MOTOR Disconnect the electrical power to the machine and follow lockout / tagout procedures.

  • Page 19: Basket Lift Cam Switch

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - REMOVAL AND REPLACEMENT OF PARTS BASKET LIFT CAM SWITCH BASKET LIFT CAM Disconnect the Disconnect the electrical power to the machine and electrical power to the machine and follow lockout / tagout procedures. follow lockout / tagout procedures.

  • Page 20: Filter Hose Switch (Ksp)

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - REMOVAL AND REPLACEMENT OF PARTS Fig. 37 Press tabs on rear of switch and push out front of fry cabinet. Reverse procedure to install new switch. FILTER PUMP AND MOTOR Fig. 36 (KLEENSCREEN FRYERS ONLY) Reverse procedure to reinstall valve.

  • Page 21: Drain Valve Interlock Switch (Dvi)

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - REMOVAL AND REPLACEMENT OF PARTS Fig. 38 Disconnect electric connections to filter pump motor. Unbolt filter pump motor from fryer frame. Carefully remove filter pump assembly through rear of fryer. Reverse procedure to reinstall filter pump Fig.

  • Page 22: Fry Tank

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - REMOVAL AND REPLACEMENT OF PARTS Remove hose clamp from rubber boot. Remove drain piping from drain valve. Fig. 41 Remove drain valve from fry tank. Fig. 40 Unplug drain valve interlock switch from wiring harness and remove switch from fryer.
  • Page 23 VK and TR GAS FRYERS W/Wo KleenScreen PLUS - REMOVAL AND REPLACEMENT OF PARTS Fig. 45 Cover plate is glued to tank and will have to be pried off. Order a replacement plate prior to replacing fry tank. If basket lifts are installed, they will have to be removed from rear of tank.

  • Page 24: Service Procedures And Adjustments

    FAULT ELECTRIC CONNECTIONS An open will display PROBE OPEN and a short or high The VK series fryers are supplied with a 120Volt cord COMPUTER temperature condition will and three prong plug. If local electrical codes require display PROBE SHORT.

  • Page 25: Cooking Control Calibration

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - SERVICE PROCEDURES AND ADJUSTMENTS [ Temp. (Lamp off) + Temp. (lamp on) ] ÷ 2 = TEMPERATURE (°F) RESISTANCE (Ω) Average Temp. Example: 360° + 340° ÷ 2 = 90,000 - 110,000 350°F.

  • Page 26: Flame Sense Current Check After 12/1/12

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - SERVICE PROCEDURES AND ADJUSTMENTS Locate two pins (FC- and FC+) on side of the ignition/ blower control board. Fig. 48 Remove the red flame sense wire. Place one Microamp meter lead on the red wire. Place the other meter lead on the terminal you removed the red flame sense wire from.

  • Page 27: Electronic Ignition System

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - SERVICE PROCEDURES AND ADJUSTMENTS flame has not been detected within 5 seconds red light MODULATING GAS VALVE on ignition module will blink. ADJUSTMENTS Disconnect the electrical power to the machine and follow lockout / tagout procedures.

  • Page 28: Solid State Control

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - SERVICE PROCEDURES AND ADJUSTMENTS Error Messages Refer to ALARM MESSAGES at end of section. Enter Service Mode NOTE: Control heat demand output signal is off and heat/ignition status input signal is ignored. Cycle power switch.
  • Page 29 VK and TR GAS FRYERS W/Wo KleenScreen PLUS - SERVICE PROCEDURES AND ADJUSTMENTS Control Programming PROGRAM KEY SEQUENCE DISPLAY ITEM Press left basket to increase or right basket to decrease cooking cycle lockout temperature (range 30 to 50F) Low Cook LOCKO 40 Temp Lockout (always in °F)

  • Page 30: Alarm Messages

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - SERVICE PROCEDURES AND ADJUSTMENTS Control Programming PROGRAM KEY SEQUENCE DISPLAY ITEM Default value shown in bold type. Temperature will change in one degree increments, accelerating if the button is held. NOTES Time will change in one second increments, accelerating if the button is held.

  • Page 31: Computer Control

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - SERVICE PROCEDURES AND ADJUSTMENTS ALARMS DESCRIPTION When drain valve is opened, the DVI switch contacts open, and the 24VAC input to the control is removed. The heat demand (heat on) and basket lift outputs are disabled.
  • Page 32 VK and TR GAS FRYERS W/Wo KleenScreen PLUS - SERVICE PROCEDURES AND ADJUSTMENTS Fig. 55 Fig. 54 NOTE: The controls heat demand output signal is off and the heat/ignition status input signal is ignored if the fryer is in cook mode or idling. Turn power switch on and when the program revision is displayed, press PROGRAM to enter Service Setting Mode.
  • Page 33 VK and TR GAS FRYERS W/Wo KleenScreen PLUS - SERVICE PROCEDURES AND ADJUSTMENTS CONTRAST - Press the L key on the keypad to lower the contrast or press the R key on the keypad to raise the contrast. Press PROGRAM key to return to DIAGNOSTICS MODE.
  • Page 34 VK and TR GAS FRYERS W/Wo KleenScreen PLUS - SERVICE PROCEDURES AND ADJUSTMENTS DISPLAY SERVICE ITEM KEY SEQUENCE DESCRIPTION SETTINGS FLASHES Press 5 to change offset temperature. Press toggle key to change offset value to (+) or (-) (positive or negative). Enter the offset value using the number keys on the OFF 00 F Degrees Fahrenheit and...

  • Page 35: Alarm Messages

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - SERVICE PROCEDURES AND ADJUSTMENTS DISPLAY SERVICE ITEM KEY SEQUENCE DESCRIPTION SETTINGS FLASHES Press 6 to adjust the left and right display screen settings. Refer to LCD display screen picture under ENTER SERVICE SETTINGS MODE. Press the left or right arrow key on control panel to select the screen to adjust.

  • Page 36: Display, Led And Keypad Test - Computer Control

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - SERVICE PROCEDURES AND ADJUSTMENTS DISPLAY, LED AND KEYPAD TEST - COMPUTER CONTROL Press and hold the 5 key while turning power on to Initiate test. Release the 5 key during display of software revision level and all LED<s and display segments should light.

  • Page 37: Air Filter

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - SERVICE PROCEDURES AND ADJUSTMENTS Fig. 60 SPARK GAP SETTING BEFORE 12/1/12 Fig. 59 NOTE: For fryers built after 12/1/12, the fire timers are replaced by a Ignition/Blower control board. The high and low fire time settings are programmed into the control board.

  • Page 38: Spark Gap Setting After 12/1/12

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - SERVICE PROCEDURES AND ADJUSTMENTS Fig. 63 There should be a gap of 1/8 to 3/16 of an inch Fig. 62 between igniter rod and ground rod. If the spark igniter rod is not adjusted correctly the gas could build up in the burner assembly and cause a delayed ignition of the burner.
  • Page 39 VK and TR GAS FRYERS W/Wo KleenScreen PLUS - SERVICE PROCEDURES AND ADJUSTMENTS Fig. 65 Page 39 of 55 F45474 (0413)

  • Page 40: Electrical Operation

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - ELECTRICAL OPERATION ELECTRICAL OPERATION COMPONENT FUNCTION - FRYER CONTROLS Ignitor/ Ground (After Ignites the gas burner and senses the presence of a flame. The flame presence generates 12/1/12) ....a micro-amp flame sense current that is rectified to the ignition control module.

  • Page 41: Component Function - Kleenscreen Filter Controls

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - ELECTRICAL OPERATION COMPONENT FUNCTION - KLEENSCREEN FILTER CONTROLS Fill Solenoid Valve . . . When energized by filter key, the solenoid valve opens to allow the flow of shortening thru filtering system. Pump Motor .

  • Page 42: Sequence Of Operation - A Series - After 12/1/12

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - ELECTRICAL OPERATION Shortening at proper level in fry tank and below last set point temperature used. Manual drain valve closed (drain valve interlock switch N.O. is closed). High limit thermostat closed. Turn power switch on.

  • Page 43: Sequence Of Operation D Andc Series

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - ELECTRICAL OPERATION message for the problem, disables keypad and SEQUENCE OF OPERATION D AND sounds the electronic alarm continuously. Refer to C SERIES SOLID STATE CONTROL ALARMS OR COMPUTER CONTROL ALARMS. Refer to SCHEMATIC AI3495 for Cooking Control 24VAC to P5 of interface board.
  • Page 44 VK and TR GAS FRYERS W/Wo KleenScreen PLUS - ELECTRICAL OPERATION 12. If shortening is allowed to cool over a long period Open drain valve to fryer section in need of of time, burner will operate on low heat to filtering and drain shortening into filter tank.

  • Page 45: Schematic Diagrams

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - ELECTRICAL OPERATION SCHEMATIC DIAGRAMS Analog Controls - No Options Page 45 of 55 F45474 (0413)
  • Page 46 VK and TR GAS FRYERS W/Wo KleenScreen PLUS - ELECTRICAL OPERATION Analog Controls - Kleenscreen F45474 (0413) Page 46 of 55...
  • Page 47 VK and TR GAS FRYERS W/Wo KleenScreen PLUS - ELECTRICAL OPERATION Solid State or Computer Control - No Options Page 47 of 55 F45474 (0413)
  • Page 48 VK and TR GAS FRYERS W/Wo KleenScreen PLUS - ELECTRICAL OPERATION Solid State of Computer Control - Kleenscreen F45474 (0413) Page 48 of 55...

  • Page 49: Wiring Diagrams

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - ELECTRICAL OPERATION WIRING DIAGRAMS VK Fryer (C and D Models) Page 49 of 55 F45474 (0413)
  • Page 50 VK and TR GAS FRYERS W/Wo KleenScreen PLUS - ELECTRICAL OPERATION Power Supply Box (Before 12/1/12) - VK Fryer with basket lifts and Kleenscreen F45474 (0413) Page 50 of 55...
  • Page 51 VK and TR GAS FRYERS W/Wo KleenScreen PLUS - ELECTRICAL OPERATION Power Supply Box (Before 12/1/12) - VK Fryer without basket lifts and Kleenscreen Page 51 of 55 F45474 (0413)
  • Page 52 VK and TR GAS FRYERS W/Wo KleenScreen PLUS - ELECTRICAL OPERATION VK Fryers with Electronic Ignition and Analog Control and Kleenscreen F45474 (0413) Page 52 of 55...
  • Page 53 VK and TR GAS FRYERS W/Wo KleenScreen PLUS - ELECTRICAL OPERATION VK Fryers with Electronic Ignition and Analog Control VK/TR D & C Fryer Wiring Diagram VK/TR Analog Control W/ Kleenscreen Fryer Wiring Diagram VK/TR Analog Control W/E.I. Stand Alone Fryer Wiring Diagram Page 53 of 55 F45474 (0413)

  • Page 54: Troubleshooting

    VK and TR GAS FRYERS W/Wo KleenScreen PLUS - TROUBLESHOOTING TROUBLESHOOTING TROUBLESHOOTING ALL MODELS SYMPTOMS POSSIBLE CAUSES Harness connection to gas valve. Gas valve or gas pressure. Air filter. All harness connections. Electrode. Ignition lockout, continuous loud beep Drain valve switch open or switch malfunction. Interconnecting wiring malfunction.
  • Page 55 VK and TR GAS FRYERS W/Wo KleenScreen PLUS - TROUBLESHOOTING ALL MODELS SYMPTOMS POSSIBLE CAUSES Incorrect temperature offset selected. Set temperature exceeding 400°F. Temperature probe malfunction. Excessive heat Cooking control malfunction. Interface board malfunction. Gas pressure incorrect. Incorrect temperature offset selected. Cooking control malfunction.

This manual is also suitable for:

Tr series

Table of Contents
