18-CHANNEL COMPUTER SYSTEMS
INSTRUCTION MANUAL
1M23N26403

Advertisement

Table of Contents
loading

Related Manuals for FUTABA T18MZ

Summary of Contents for FUTABA T18MZ

  • Page 1 18-CHANNEL COMPUTER SYSTEMS INSTRUCTION MANUAL 1M23N26403...
  • Page 2 TABLE OF CONTENTS...
  • Page 3 TABLE OF CONTENTS...

  • Page 4: In North America

    INTRODUCTION ® Thank you for purchasing a Futaba FASSTest-2.4GHz 18MZ series digital proportional R/C system. This system is extremely versatile and may be used by beginners and pros alike. In order for you to make the best use “off season” to ensure safe operation.
  • Page 5 Compliance Information Statement (for U.S.A.) operation. The responsible party of this device compliance is: Futaba Service Center America's involvement in this program is part of its commitment to protecting our environment and conserving natural resources. <Introduction>...

  • Page 6: Flying Safety

    Federal Communications Commission Interference Statement (for U.S.A.) 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. --Reorient or relocate the receiving antenna. --Consult the dealer or an experienced radio/TV technician for help. CAUTION: To assure continued FCC compliance: Any changes or modifications not expressly approved by the grantee of this device could void the user's...
  • Page 7 Battery Charge the batteries! pay attention to the duration of usage. Where to Fly Academy of Model Aeronautics <Introduction>...

  • Page 8: Important Precautions

    Lithium polymer(Li-po) Battery Safety and Handling instructions IMPORTANT! Use only the Futaba special charger charge the Li FIRE! IMPORTANT PRECAUTIONS Do not attempt to disassemble packs or cells. during storage. Do not leave a Do not attempt to charge permanent damage to the battery and charger could result.
  • Page 9 problem. 7. Complete a full range check. motor/engine. In order to maintain complete control of your aircraft it is important that it remains visible at all times. <Introduction>...

  • Page 10: Before Use

    T18MZ utilizes the world famous Microsoft Windows CE, which offers outstanding dependability and valuable resources. Color LCD T18MZ has a HVGA (640x240 pixels) wide screen full color LCD. It has a backlight and the screen is Music Play Voice Recording Camera function + picture paste function convenient.
  • Page 11 Editing The touch panel and rotary encoder editing system will allow you to edit your model in the manner that is easiest and most functional for you. Functions The internal dual processors operate the many 18MZ FEATURE functions and optimize the response time.
  • Page 12 Your 18MZAP/HP (packaged with a S.BUS receiver) includes the following components: The set contents depend on the type of set. Transmitter T18MZAP/HP Transmitting frequency: 2.4 GHz Current drain: 1 ampere maximum (RF power on and back light on) 700mA average Receiver R7008SB (FASSTest, S.BUS2, Diversity) Receiving frequency: 2.4 GHz FASSTest system...
  • Page 13 The following additional accessories are available from your dealer. Refer to a Futaba catalog for more information: another T18MZ system, as well as to any other models of Futaba transmitters. The T18MZ transmitter trainer cords are available. version with heavier wire, are available to aid in your larger model and other installations.

  • Page 14: Transmitter Controls

    Transmitter controls (J3) (J2) (J4) (J1) Cautions on handling antenna WARNING Do not touch the antenna during operation. *There is the danger of erroneous operation causing a crash. Do not carry the transmitter by the antenna. *There is the danger that the antenna wire will break and operation will become impossible.
  • Page 15 LED monitor Steerable antenna The status of the transmitter is displayed by The antenna rotating angle is 90 and its steerable angle is also 90 . Do not try to bend the antenna farther than this. The antenna may break. Also, the (LED Display) antenna cannot be detached and reattached.
  • Page 16 If you push the volume again, the lock will be released and become operative again. This volume is digital type (rotary encoder). This *T18MZ beeps when the volume knob reaches center. screen in the Linkage menu. <Before Use>...
  • Page 17 Model Menu Return 15:11:25 Danger Since the sensitivity of T18MZ of the touch panel improved, if a hook band etc. touch, it is Touch panel, rotary keys and direct keys are used dangerous. Even if you touch a panel during a touch panel lock in which for entering data.
  • Page 18 a stick lever either inwards or outwards from the center stick position. Use the attached 1.5mm hexagonal wrench inward. clockwise too far. sticks in line with your hand size. <Before Use>...
  • Page 19 *This transmitter has two ratchet plates, one for airplane and the other one for helicopter. If you tighten both screws, you *If you want to change the setting from airplane to helicopter (or from helicopter to airplane), turn counterclockwise until the throttle stick moves freely.
  • Page 20 connector slider Battery connector <Before Use>...
  • Page 21 Be careful to not drop the battery. transmitter while the LED monitor is blinking after turning off the power the T18MZ transmitter. * Internal devices such as memories may have been destroyed. * If there is any problem, the message “Backup Error” will be shown the next time when you turn on the power of the transmitter.
  • Page 22 Charge LED S.BUS setting connector Connector/Plug Trainer Connector Charge plug Audio plug (PHONE) S.BUS Connector Charge Plug Audio plug (PHONE) USB Connector USB(mini-B) Connector Unused SD Card Update Switch <Before Use>...
  • Page 23 SD card on the connector. market can be used for T18MZ. The card is locked when it is pushed in all the way. When removing the card, release the lock by pushing in the card again.
  • Page 24 Camera function This transmitter has a digital camera function. A picture of your favorite model and other pictures (300,000 pixels) can be allocated to transmitter model data. Camera Camera Model 1 Picture Resolution 600KB (640 * 480) Next Thumbnail Save to... Warning when starting the engine.

  • Page 25: Receiver Nomenclature

    Receiver nomenclature Before using the receiver, be sure to read the precautions listed in the following pages. Receiver R7008SB Link/Mode Switch It pushes with a plastic driver. It is used for CH mode change. Connector (It is not used by a link.) "1 through 6": outputs for the channels 1 through 6 [S.BUS Sevo S.BUS Gyro ] "S.BUS2": outputs of S.BUS2 port.
  • Page 26 R7008SB CH Mode [How to R7008SB CH mode change] R 7 0 0 8 S B c a n c h a n g e 8 C H a n d S . B U S . without your using S.BUS, the mode A of initial However, it is necessary for it to be necessary to change the mode by the following method, if you are required for 9 or more CH, and to use S.BUS,...

  • Page 27: Servo(Option) Toolbox

    Toolbox Servo(Option) Toolbox Servo(Option) you. *In the case of FASSTest12CH mode, an analog servo cannot be used. brushless servo is included) and an S.BUS servo. Servo accessories The servo accessories are: *Always use the servo horn mounting screws installed to the Hexagonal wrench (1.5mm and 2.5mm) servo at the factory.

  • Page 28: Receiver's Antenna Installation

    Receiver's Antenna Installation incorporate two separate antennas into their design which enables them to receive the radio frequency transmission at two different locations. *Must be kept as straight as possible. Antenna Coaxial cable R7008SB Receiver to ensure that there is no loss of signal. To obtain the best results of the diversity function, please refer to the following instructions: Antenna...

  • Page 29: Safety Precautions When You Install Receiver And Servos

    Safety precautions when you install Mounting the Servo receiver and servos Wood screw 2.3-2.6mm nut Warning washer Rubber Rubber grommet grommet Connecting connectors Brass eyelet Brass eyelet Servo mount Servo mount Be sure to insert the connector until it stops at 2.3-2.6mm screw the deepest point.

  • Page 30: S.bus Installation

    In addition, the wings can be quickly installed to the fuselage without any erroneous wiring by connecting only one wire even when there are many servos at the main wings. T18MZ) S.BUS Glider Usage example...
