■ Rapid charging

The optional BC-177 provides rapid charging of the battery
pack.
• Charging period: approx. 2.5 hours (with BP-256)
D Charging note
• Be sure to turn the transceiver power OFF.
Detach the battery pack from the transceiver then charge
the battery pack by itself, or charge the battery with regu-
lar charging when the transceiver power cannot be turned
OFF.
Otherwise the battery pack will not be charged
dicator on the BC-177 blinks orange about 10 sec. after the battery
.
pack is installed in BC-177)
• The desktop charger, BC-177, can only be charged
BP-256. Other types of rechargeable battery, Ni-Cd or
Ni-MH, cannot be charged.
• If the charging indicator blinks orange, there may be a
problem with the battery pack
tery pack or contact your dealer.
• The optional CP-12L and OPC-254L can be used instead
of the supplied AC adapter
these to the [DC 13.5V] jack in this case.
(charging in-
. Reinsert the bat-
(or charger)
. Connect one of
(BC-123A/E)
BATTERY CHARGING
Transceiver
(with battery pack)
Turn power OFF.
to AC outlet
AC adapter
(supplied
with BC-177)
to [AC ADAPTER]
Charging indicator
Charging : Orange
Finished : Green
3
Battery pack
CP-12L
OPC-254L
to [DC 13.5V]
Charging
terminal
BC-177 (optional)
Desktop charger
3
