Briggs & Stratton Generator System Installation & Start-Up Manual page 27

Menu
The following chart shows the icons for the buttons that control the system control panel.
MENU
ESCAPE (EXIT)
RIGHT ARROW
LEFT ARROW
MANUAL MODE
AUTOMATIC MODE
The following chart describes key sequences for accessing different programming modes;
ENTER THE MENU (VIEW SETTINGS)
PRESS TO CONFIRM SELECTION WHEN PROGRAMMING.
RETURN TO LAST MENU ITEM
TOGGLE THROUGH MENU OPTIONS
SETTING SYSTEM PARAMETERS
TOGGLE THROUGH MENU OPTIONS
SETTING SYSTEM PARAMETERS
USED TO MANUALLY START THE GENERATOR. PRESS AND HOLD BUTTON
TO START THE GENERATOR.
TURNS OFF RUNNING GENERATOR, PREVENTS UNIT FROM STARTING, AND
OFF
RESETS ANY DETECTED FAULTS.
NORMAL OPERATING POSITION. PRESS AND HOLD BUTTON TO PUT UNIT
INTO AUTOMATIC MODE. IF A UTILITY POWER OUTAGE IS SENSED, THE
SYSTEM WILL START THE GENERATOR. WHEN UTILITY POWER IS
RESTORED, AUTO LETS THE ENGINE STABILIZE INTERNAL TEMPERATURES,
SHUTS OFF THE GENERATOR, AND WAITS FOR THE NEXT UTILITY POWER
OUTAGE.
GENERAL
SET-UP
ADVANCED
SETTINGS
WIRELESS
LINK MODE
PRESS AND HOLD [ARROW LEFT AND ARROW RIGHT] FOR THREE
SECONDS TO ENTER THE PROGRAM MODE.
PRESS AND HOLD [ARROW LEFT, ARROW RIGHT AND ESC] FOR
THREE SECONDS TO ENTER THE ADVANCED SETTINGS MODE.
PRESS AND HOLD [MENU AND ESC] FOR THREE SECONDS TO
ENTER THE WIRELESS LINKING MODE.
27
