Thank you for purchasing a Panasonic Hybrid IP-PBX.
Please read this manual carefully before using this product and save this manual for future use.
KX-TDA100D: PDMPR Software File Version 5.1000 or later
Installation Manual
KX-TDA100D
Model No.
Hybrid IP-PBX
SD Logo is
a trademark of
SD-3C, LLC.

Advertisement

Table of Contents
loading

Related Manuals for Panasonic KX-TDA100D

Summary of Contents for Panasonic KX-TDA100D

  • Page 1 Thank you for purchasing a Panasonic Hybrid IP-PBX. Please read this manual carefully before using this product and save this manual for future use. SD Logo is KX-TDA100D: PDMPR Software File Version 5.1000 or later a trademark of SD-3C, LLC.

  • Page 2: System Components

    System Components System Components System Components Table Category Model No. Description Shelf KX-TDA100D Basic Shelf Main Processing Card Main Processing Card (DMPR) DMPR Option Card KX-TDA0196 Remote Card (RMT) Trunk Cards KX-TDA0180 8-Port Analogue Trunk Card (LCOT8) KX-TDA0181 16-Port Analogue Trunk Card (LCOT16)

  • Page 3: Equipment Compatibility

    Back-up Battery Cable KX-A258 Blank Slot Cover KX-T30865 Doorphone KX-T7765 Equipment Compatibility Compatible Panasonic Proprietary Telephones The PBX supports the following telephones: • Digital proprietary telephones (e.g., KX-DT300 series) • IP proprietary telephones (e.g., KX-NT300 series) • Portable stations (e.g., KX-TCA355, KX-TCA256) •...

  • Page 4: Safety Notices

    Note • Some optional hardware, software, and features are not available in some countries/areas. Please consult your certified Panasonic dealer for more information. • In this manual, the suffix of each model number (e.g., KX-TDA100DCE) is omitted unless necessary. Safety Notices Please observe the safety notices in this manual in order to avoid danger to users or other people, and prevent damage to property.

  • Page 5: Important Safety Instructions

    Important Safety Instructions Important Safety Instructions When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: • Do not use the product near water, for example, near a bathtub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool.

  • Page 6: Important Information

    Important Information Important Information SAVE THESE INSTRUCTIONS WARNING SAFETY REQUIREMENTS For All Telephone Equipment • Do not install the product in any other way than described in relevant manuals. • The product must only be installed and serviced by qualified service personnel. The product should be used as-is from the time of purchase;...
  • Page 7 Unplug this unit from the AC outlet if it emits smoke, an abnormal smell or makes unusual noise. These conditions can cause fire or electric shock. Confirm that smoke has stopped and contact an authorised Panasonic Factory Service Centre. •...
  • Page 8 Contact your telephone company. If all SLTs operate properly, there may be a problem with your PBX. Do not reconnect the PBX to the trunks until it has been serviced by an authorised Panasonic Factory Service Centre. Installation Manual...
  • Page 9 Precaution Precaution For users in the European Union only Information for Users on Collection and Disposal of Old Equipment and used Batteries These symbols on the products, packaging, and/or accompanying documents mean that used electrical and electronic products and batteries should not be mixed with general household waste.
  • Page 10 Introduction Introduction This Installation Manual is designed to serve as an overall technical reference for the Panasonic Hybrid IP-PBX, KX-TDA100D. It provides instructions for installing the hardware, and programming the PBX using the Maintenance Console. The Structure of this Manual...

  • Page 11: Table Of Contents

    Table of Contents Table of Contents 1 System Outline ..................13 Basic System Construction ...................14 1.1.1 Basic Shelf ........................14 1.1.2 System Connection Diagram ..................15 Optional Equipment ......................17 1.2.1 Optional Equipment ......................17 Specifications ........................20 1.3.1 General Description ......................20 1.3.2 Characteristics ........................22 1.3.3 System Capacity ......................23 2 Installation ....................29 Before Installation ......................30...
  • Page 12 Table of Contents 2.6.2 DPH4 Card (KX-TDA0161) ..................102 2.6.3 DPH2 Card (KX-TDA0162) ..................104 2.6.4 EIO4 Card (KX-TDA0164) ....................107 2.6.5 ECHO16 Card (KX-TDA0166) ..................110 2.6.6 MSG4 Card (KX-TDA0191) ..................111 2.6.7 ESVM2 Card (KX-TDA0192) and ESVM4 Card (KX-TDA0194) ........112 2.6.8 CTI-LINK Card (KX-TDA0410) ..................113 Connection of Extensions ....................115 2.7.1 Maximum Cabling Distances of the Extension Wiring (Twisted Cable) ......115...

  • Page 13: System Outline

    Section 1 System Outline This section provides general information on the PBX, including the system capacity and specifications. Installation Manual...

  • Page 14: Construction Of Basic Shelf

    1.1.1 Basic Shelf 1.1 Basic System Construction 1.1.1 Basic Shelf The basic shelf contains a power supply unit (PSU) and a DMPR card for starting and controlling the PBX. To use the system, install optional service cards in the basic shelf. Construction of the Basic Shelf Slots for Expansion DMPR Card...

  • Page 15: System Connection Diagram

    1.1.2 System Connection Diagram 1.1.2 System Connection Diagram Private IP Network Trunk (Telephone Company Lines) Analogue/BRI/PRI/T1/E1 Remote PC Router Batteries IP-PT IP Softphone Fax Machine CTI Server Printer Wireless Phone DSS Console External Sensor/ External Relay Device ISDN Telephone KX-T7636/ Doorphone &...
  • Page 16 1.1.2 System Connection Diagram KX-DT346/KX-DT343/ DLC16 KX-DT300/ KX-DT300/ LCOT4 LCOT4 (KX-TDA0172) KX-T7600 KX-T7600 KX-T7636/KX-T7633 (KX-TDA0183) (KX-TDA0183) DLC8 LCOT16 (KX-TDA0171) LCOT16 (KX-TDA0181) (KX-TDA0181) Voice LCOT8 Processing LCOT8 (KX-TDA0180) System PT-interface CS DSS Console (KX-TDA0180) MCSLC24 CID/PAY8 (KX-TDA1178) (KX-TDA0189) MCSLC16 (KX-TDA1176) CID8 (KX-TDA0193) Analogue Analogue...

  • Page 17: Optional Equipment

    1.2.1 Optional Equipment 1.2 Optional Equipment 1.2.1 Optional Equipment Model No. Model Name Description KX-TDA0143 4 Cell Station Interface Card 4-port CS interface card for 4 CSs. (CSIF4) KX-TDA0144 8 Cell Station Interface Card 8-port CS interface card for 8 CSs. (CSIF8) KX-TDA0161 4-Port Doorphone Card (DPH4)
  • Page 18 10BASE-T port. CSTA Phase 3 protocol compatible. KX-TDA0470 16-Channel VoIP Extension Card 16-channel VoIP extension card. Compliant with (IP-EXT16) Panasonic proprietary protocol, and ITU-T G. 729a and G.711 codec methods. KX-TDA0484 4-Channel VoIP Gateway Card 4-channel VoIP gateway card. Compliant with (IP-GW4E) VoIP H.323 V.2 protocol, and ITU-T G.729a, G.
  • Page 19 1.2.1 Optional Equipment Model No. Model Name Description KX-TDA1176 16-Port Single Line Telephone 16-port extension card for SLTs with Caller ID Extension with Caller ID and (FSK), Message Waiting Lamp control, and 2 Message Lamp Card (MCSLC16) power failure transfer (PFT) ports. Maximum power output of 90 V for Message Waiting Lamp control.

  • Page 20: Specifications

    1.3.1 General Description 1.3 Specifications 1.3.1 General Description Control Bus Original bus (16-bit, 8 MHz, 10 megabytes per second) Communication Bus H.100 bus conformity (1024 time slots) Switching Non-blocking Power Input 100 V AC to 130 V AC; 2.8 A/200 V AC to 240 V AC; 1.7 A; 50 Hz/60 Hz +36 V DC (+12 V DC ´...
  • Page 21 1.3.1 General Description Weight (when fully mounted) Under 12 kg Installation Manual...

  • Page 22: Characteristics

    1.3.2 Characteristics 1.3.2 Characteristics Terminal Equipment Loop Limit • PT: KX-DT300/KX-T7600 series DPT: 90 W • SLT: 600 W including set • Doorphone: 20 W • CS: 130 W; PT-interface CS: 65 W 15 000 W minimum Minimum Leakage Resistance Maximum Number of Extension for PT or SLT Instruments per Line...

  • Page 23: System Capacity

    1.3.3 System Capacity 1.3.3 System Capacity Maximum Optional Service Cards There are 2 types of optional service cards for installation: • Cards installed in the slots of the PBX • Cards mounted on other optional service cards Note • Any card that exceeds the capacity of the PBX will be ignored. •...
  • Page 24 1.3.3 System Capacity Card Type Maximum Number Installed in Trunk Card Total 7 LCOT4 LCOT8 LCOT16 CLCOT8 DID8 E&M8 Free Slots 1 to 7 BRI4 BRI8 PRI23 PRI30 IP-GW4E IP-GW16 Extension Card Total 7 DLC8 DLC16 MCSLC16 IP-EXT16 Free Slots 1 to 7 MCSLC24 CSIF4 CSIF8...
  • Page 25 1.3.3 System Capacity Cards Mounted on Other Optional Service Cards The following number of optional service cards can be mounted on the specified other optional service cards. Card Type Maximum Number Mounted on DMPR Card CID/PAY8 LCOT8 Card/LCOT16 Card CID8 CLCOT8E CLCOT8 Card DPH4...
  • Page 26 1.3.3 System Capacity Maximum Terminal Equipment The following number of items of terminal equipment can be supported by the PBX. For how to count the total number of items of equipment to be connected, refer to "Power Supply Unit Capacity". Terminal Equipment Type Maximum Number Telephone...
  • Page 27 1.3.3 System Capacity Power Supply Unit Capacity Calculate the load figure from the type and number of items of equipment to be connected. Load Figure Calculation Equipment Type Load Figure KX-DT300 series DPT/KX-DT300 series DSS console/KX-T7600 series DPT/KX-T7600 series DSS console IP-PT Trunk Card DID8...
  • Page 28 1.3.3 System Capacity Calculation Example Equipment Type Load Figure KX-DT300/KX-T7600 series DPT 4 units MCSLC24 4 cards 8 ports Total Installation Manual...

  • Page 29: Installation

    Section 2 Installation This section describes the procedures to install the PBX. Detailed instructions for planning the installation site, installing the shelves and optional service cards, and cabling of peripheral equipment are provided. Further information on system expansion and peripheral equipment installation is included.

  • Page 30: Before Installation

    2.1.1 Before Installation 2.1 Before Installation 2.1.1 Before Installation Please read the following notes concerning installation and connection before installing the PBX and terminal equipment. Be sure to comply with all applicable laws, regulations, and guidelines. Safety Installation Instructions WARNING When installing telephone wiring, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: •...
  • Page 31 2.1.1 Before Installation Wiring Precautions Be sure to follow these instructions when wiring the unit: CAUTION • Avoid using the same AC outlet for computers, telexes, and other office equipment, as noise generated by such equipment may hamper system performance or interrupt the system. •...

  • Page 32: Installation Of The Pbx

    2.2.1 Unpacking 2.2 Installation of the PBX 2.2.1 Unpacking Unpack the box and check the items below: Main Unit AC Cord Metal Bracket Screw A Screw B (Black) Anchor Plug SD Memory Card Ferrite Core (for the DMPR card) KX-TDA100DBX is supplied with 2 types of AC cord. Please use whichever is appropriate for the country/area. The larger of the two ferrite cores is used for the RJ45 cable.

  • Page 33: Names And Locations

    2.2.2 Names and Locations 2.2.2 Names and Locations Inside View RUN Indicator ALARM Indicator USB Port RS-232C Port Free Slots 1 to 7 (from the left) DMPR Card Slot PSU View Battery Switch Battery Connector Installation Manual...
  • Page 34 2.2.2 Names and Locations Power Switch Earth Terminal AC Inlet Installation Manual...

  • Page 35: Opening/Closing The

    2.2.3 Opening/Closing the Front Cover 2.2.3 Opening/Closing the Front Cover Opening the Front Cover Insert a flathead screwdriver into the opening (on the left of the screw cover) and unlatch the screw cover. Screw Cover Turn the screw anticlockwise to loosen. Slide the front cover to the right until it stops, then lift the front cover.
  • Page 36 2.2.3 Opening/Closing the Front Cover Closing the Front Cover Hook the front cover onto the shelf (line up the protrusions on the cover with the receptacles on the shelf). Then slide the front cover to the left until it locks. Turn the screw clockwise to tighten.

  • Page 37: Frame Earth Connection

    2.2.4 Frame Earth Connection 2.2.4 Frame Earth Connection Loosen the screw. Insert an earthing wire (user-supplied). Tighten the screw. Screw Connect the earthing wire to earth. Earthing wire To earth WARNING • Proper earthing (connection to earth) is very important to reduce the risk to the user of electrocution or to protect the PBX from the bad effects of external noise in the case of a lightning strike.

  • Page 38: Backup Battery Connection

    2.2.5 Backup Battery Connection 2.2.5 Backup Battery Connection The backup batteries and Back-up Battery Cable provide a backup power supply to allow full use of the PBX in the event of a power failure. In case of power failure, the backup batteries automatically maintain the power to the PBX without interruption.
  • Page 39 2.2.5 Backup Battery Connection Connect the Back-up Battery Cable to a set of 3 identical backup batteries. Battery Switch Battery Connector Back-up Battery Cable Fuse Black Backup Batteries (VRLA 12 V DC x 3) Installation Manual...

  • Page 40: Installing/Removing The Optional Service Cards

    2.2.6 Installing/Removing the Optional Service Cards 2.2.6 Installing/Removing the Optional Service Cards CAUTION • To protect the back board from static electricity, do not touch parts on the back board in the main unit and on the optional service cards. To discharge static electricity, touch ground or wear an earthing strap.
  • Page 41 2.2.6 Installing/Removing the Optional Service Cards Turn the 2 screws clockwise to fix the card in place. Screws Note Make sure the screws are tightened to earth the card securely. Installation Manual...
  • Page 42 2.2.6 Installing/Removing the Optional Service Cards Covering the Blank Slots Be sure to cover each slot in which no optional service card is installed by using a Blank Slot Cover. CAUTION Failure to install the Blank Slot Cover may cause electromagnetic interference. Installation Manual...
  • Page 43 2.2.6 Installing/Removing the Optional Service Cards Handling of the Cables When cables are connected to the PBX, run the cables to either the right or the left and then towards the back of the shelf as shown below. Note For safety reasons, do not stretch, bend, or pinch the AC power cord. Installation Manual...
  • Page 44 2.2.6 Installing/Removing the Optional Service Cards Removing the Optional Service Cards Turn the 2 screws anticlockwise to loosen them. Screws Pull the release lever in the direction of the arrow to disconnect the card from the back board. Pull the card from the shelf to remove it.

  • Page 45: Types Of Connectors

    2.2.7 Types of Connectors 2.2.7 Types of Connectors Connector Type Pin Number Used for • MCSLC16 (KX-TDA1176) RJ11 • MCSLC24 (KX-TDA1178) • CLCOT8 (KX-TDA1180) • CLCOT8E (KX-TDA1186) • LCOT8 (KX-TDA0180) • LCOT16 (KX-TDA0181) • LCOT4 (KX-TDA0183) • DMPR (Twisted pair cable) •...
  • Page 46 2.2.7 Types of Connectors Connector Type Pin Number Used for • DPH4 (KX-TDA0161) 10-pin 8-pin • DPH2 (KX-TDA0162) Terminal Terminal • EIO4 (KX-TDA0164) Block Block • DMPR RS-232C (Shielded cable) • DMPR Installation Manual...

  • Page 47: Attaching A Ferrite Core

    2.2.8 Attaching a Ferrite Core 2.2.8 Attaching a Ferrite Core A ferrite core must be attached when: • an RJ45 connector is connected to T1, E1, PRI, BRI, IP-GW16, IP-EXT16, or DMPR cards. • an Amphenol connector is connected to an extension card. •...
  • Page 48 2.2.8 Attaching a Ferrite Core For a BRI Card Attach the ferrite core, then close the case of the ferrite core. Attach the ferrite core as close to the card’s connector as possible. The ferrite core is included with the card. When only 1 or 2 cables are used for connection, wrap the cable(s) once around the ferrite core.
  • Page 49 2.2.8 Attaching a Ferrite Core Attaching to an RJ11 Connector For the DMPR Card Attach the ferrite core, then close the case of the ferrite core. Attach the ferrite core 3 cm away from the connector. The ferrite core is included with the PBX. When only 1 cable is used for connection, wrap the cable once around the ferrite core.
  • Page 50 2.2.8 Attaching a Ferrite Core Attaching to an Amphenol Connector For Extension Cards Pass the cable through the ferrite core, then close the case of the ferrite core. Attach the ferrite core 3 cm away from the connector. The ferrite core is included with the card. 3 cm If you need to open the ferrite core, use a flathead screwdriver to unlatch the case of the ferrite core.

  • Page 51: Fastening Amphenol Connector

    2.2.9 Fastening Amphenol Connector 2.2.9 Fastening Amphenol Connector An Amphenol 57JE-type connector is used on some of the optional service cards. To connect an Amphenol connector, use the spring latch or screw to fix the upper part and use Velcro® tape to fix the lower part of the connector.
  • Page 52 2.2.9 Fastening Amphenol Connector Amphenol Connector Pin Assignment Chart Below is an Amphenol connector pin assignment chart for all optional service cards that use the Amphenol connector. For more details, refer to the appropriate section in "2.4 Information about the Trunk Cards" and "2.5 Information about the Extension Cards".

  • Page 53: Wall Mounting

    2.2.10 Wall Mounting 2.2.10 Wall Mounting WARNING • Make sure that the wall that the shelf will be attached to is strong enough to support the shelf. If not, it is necessary for the wall to be reinforced. • Only use the wall-mounting equipment (anchor plugs, screws, metal bracket) included with the PBX.
  • Page 54 2.2.10 Wall Mounting Install 3 anchor plugs in the wall, using the metal bracket as a template. Fix the metal bracket with 3 screws (A). Anchor Plug Hammer Anchor Plug W a ll 8 mm Metal Bracket 30 mm Screw (A) Screw (A) Metal Bracket Note...

  • Page 55: Surge Protector Installation

    2.2.11 Surge Protector Installation 2.2.11 Surge Protector Installation Overview A massive electrical surge can be caused if lightning strikes a telephone cable 10 m above ground, or if a telephone line comes into contact with a power line. A surge protector is a device that is connected to a trunk to prevent potentially dangerous electrical surges from entering the building via the trunk and damaging the PBX and connected equipment.
  • Page 56 2.2.11 Surge Protector Installation Outside Installation (Main Building) Surge Protector Trunk (Another Building) Trunk Extn. PT-interface CS Terminal Board Surge Extn. Protector Extn. Extn. PT-interface CS Earth Extn.: Extension Line If you install an extension outside of the building, the following precautions are recommended: Install the extension wire underground.
  • Page 57 2.2.11 Surge Protector Installation Connect the earth rod to the surge protector using an earthing wire with a cross-sectional area of at least 1.3 mm Bury the earth rod near the protector. The earthing wire should be as short as possible. The earthing wire should run straight to the earth rod.

  • Page 58: Information About The Main Processing Card

    • To prevent data leakage, render the SD Memory Card physically unusable before disposal. Notice • Use only the SD Memory Card included with the PBX, or a Panasonic optional upgrade SD Memory Card. Installation Manual...

  • Page 59: Pin Assignments

    2.3.1 DMPR Card • The SD Memory Card must be inserted in the SD Memory Card slot of the DMPR card before startup. Note • For details about connecting peripherals, refer to "2.9.1 Connection of Peripherals". • For details about System Initialise Switch, refer to "2.11.1 Starting the PBX". •...

  • Page 60: Rmt Card (Kx-Tda0196)

    2.3.2 RMT Card (KX-TDA0196) 2.3.2 RMT Card (KX-TDA0196) Function Analogue modem card for remote communication with the PBX. ITU-T V.90 support. To be mounted on the DMPR card. inside Screw RMT Card Accessories and User-supplied Items Accessories (included): Screws ´ 2 User-supplied (not included): none Installation Manual...

  • Page 61: Lcot4/8/16 & Clcot8 Cards

    2.4.1 LCOT4 Card (KX-TDA0183), LCOT8 Card (KX-TDA0180), LCOT16 Card (KX-TDA0181), and CLCOT8 Card (KX- TDA1180) 2.4 Information about the Trunk Cards 2.4.1 LCOT4 Card (KX-TDA0183), LCOT8 Card (KX-TDA0180), LCOT16 Card (KX-TDA0181), and CLCOT8 Card (KX-TDA1180) Function LCOT4: 4-port analogue trunk card with 2 power failure transfer (PFT) ports. LCOT8: 8-port analogue trunk card with 2 power failure transfer (PFT) ports.
  • Page 62 2.4.1 LCOT4 Card (KX-TDA0183), LCOT8 Card (KX-TDA0180), LCOT16 Card (KX-TDA0181), and CLCOT8 Card (KX- TDA1180) Pin Assignments Amphenol Connector Signal Name Function Signal Name Function Ring port 1 Tip port 1 Ring port 2 Tip port 2 Ring port 3 Tip port 3 Ring port 4 Tip port 4...

  • Page 63: Did8 Card (Kx-Tda0182)

    2.4.2 DID8 Card (KX-TDA0182) 2.4.2 DID8 Card (KX-TDA0182) Function 8-port DID trunk card. Amphenol To DID line Accessories and User-supplied Items Accessories (included): Screws ´ 2 User-supplied (not included): Amphenol connector Note • To connect the Amphenol connector, refer to "2.2.9 Fastening Amphenol Connector". •...
  • Page 64 2.4.2 DID8 Card (KX-TDA0182) LED Indications Indication Colour Description CARD STATUS Green/Red Card status indication • OFF: Power Off • Green ON: Normal (all ports are idle) • Green Flashing (60 times per minute): Normal (a port is in use) •...

  • Page 65: Cid/Pay8 Card (Kx-Tda0189)

    2.4.3 CID/PAY8 Card (KX-TDA0189) 2.4.3 CID/PAY8 Card (KX-TDA0189) Function 8-port Caller ID signal type FSK/FSK (with Call Waiting Caller ID [Visual Caller ID])/DTMF, and 8-port Pay Tone Service (12 kHz/16 kHz). To be mounted on the LCOT8/LCOT16 card. Set all DIP switches for ports 09-16 at "OFF"...

  • Page 66: Cid8 Card (Kx-Tda0193)

    2.4.4 CID8 Card (KX-TDA0193) 2.4.4 CID8 Card (KX-TDA0193) Function 8-port Caller ID signal type FSK/FSK (with Call Waiting Caller ID [Visual Caller ID])/DTMF. To be mounted on the LCOT8/LCOT16 card. LCOT16 card only inside CID8 Card Screw S W 1 Accessories and User-supplied Items Accessories (included): Screws ´...

  • Page 67: Clcot8E Card (Kx-Tda1186)

    2.4.5 CLCOT8E Card (KX-TDA1186) 2.4.5 CLCOT8E Card (KX-TDA1186) Function 8-port analogue trunk daughter card with Caller ID. Caller ID signal type FSK/FSK (with Call Waiting Caller ID [Visual Caller ID])/DTMF compatible. To be mounted on the CLCOT8 card. inside Screw inside Accessories and User-supplied Items Accessories (included): Screws ´...

  • Page 68: E&M8 Card (Kx-Tda0184)

    2.4.6 E&M8 Card (KX-TDA0184) 2.4.6 E&M8 Card (KX-TDA0184) Function 8-port E & M (TIE) trunk card. Type 5 support. Amphenol To terminal board from the E & M (TIE) line Accessories and User-supplied Items Accessories (included): Screws ´ 2 User-supplied (not included): Amphenol connector Note •...
  • Page 69 2.4.6 E&M8 Card (KX-TDA0184) Signal Name Function Signal Name Function Tip 1 port 3 Ring 1 port 3 E line port 3 M line port 3 Tip port 4 Ring port 4 Tip 1 port 4 Ring 1 port 4 E line port 4 M line port 4 Tip port 5...

  • Page 70: T1 Card (Kx-Tda0187)

    2.4.7 T1 Card (KX-TDA0187) 2.4.7 T1 Card (KX-TDA0187) Function 1-port T1 trunk card. EIA/TIA standard compliant. LEDs RJ45 To NT1 / Extension Accessories and User-supplied Items Accessories (included): Ferrite core ´ 1 User-supplied (not included): RJ45 connector CAUTION • When connecting this optional service card to the trunk, connect through NT1; do not connect to the trunk directly.
  • Page 71 2.4.7 T1 Card (KX-TDA0187) Pin Assignments RJ45 Connector for Trunk Use Signal Name Level [V] Function Receive data (+) Receive data (-) Reserved – – Transmit data (-) Transmit data (+) Reserved – – RJ45 Connector for Extension Use Signal Name Level [V] Function Transmit data (-)
  • Page 72 2.4.7 T1 Card (KX-TDA0187) Indication Colour Description SYNC Green Synchronisation status indication • OFF: Not synchronised • ON: Synchronised • Flashing (60 times per minute): Synchronised (Clock Master) Maximum Cabling Distance of Extension Connection The maximum length of the extension cable that connects the T1 cards is shown below: Diameter Maximum Distance 0.5 mm:...

  • Page 73: E1 Card (Kx-Tda0188)

    2.4.8 E1 Card (KX-TDA0188) 2.4.8 E1 Card (KX-TDA0188) Function 1-port E1 trunk card. ITU-T standard compliant. LEDs RJ45 BNC (TX) outer conductor J 3 0 8 J 3 0 8 To NT1/Extension For Frame For Frame To NT1/Extension Ground Open Ground Short For RJ45 BNC (TX)

  • Page 74: Switch Settings

    2.4.8 E1 Card (KX-TDA0188) Switch Settings Switch Type Usage and Status Definition Select 120 W (default) or 75 W to match the connector type to be Termination Slide used. Slide When using an RJ45 connector, select A (default) for trunk or B for extension use.
  • Page 75 2.4.8 E1 Card (KX-TDA0188) BNC (coaxial) Connector (RX) Signal Name Level [V] Function Receive data (-) Receive data (+) LED Indications Indication Colour Description CARD STATUS Green/Red Card status indication • OFF: Power Off • Green ON: Normal (all ports are idle) •...

  • Page 76: Bri4 Card (Kx-Tda0284) And Bri8 Card (Kx-Tda0288)

    2.4.9 BRI4 Card (KX-TDA0284) and BRI8 Card (KX-TDA0288) 2.4.9 BRI4 Card (KX-TDA0284) and BRI8 Card (KX-TDA0288) Function BRI4: 4-port ISDN Basic Rate Interface card with 1 power failure transfer port. EURO-ISDN/ETSI compliant. BRI8: 8-port ISDN Basic Rate Interface card with 1 power failure transfer port. EURO-ISDN/ETSI compliant.
  • Page 77 2.4.9 BRI4 Card (KX-TDA0284) and BRI8 Card (KX-TDA0288) Switch Settings Switch Type Usage and Status Definition Slide Select A (default) for trunk or B for extension use. Pin Assignments RJ45 Connector for Trunk Use Signal Name Level [V] Function Reserved –...
  • Page 78 2.4.9 BRI4 Card (KX-TDA0284) and BRI8 Card (KX-TDA0288) Indication Colour Description LINE 8 Green Line status indication (LINE 1 to LINE 8): LINE 7 Refer to "LINE LED Pattern" below for details. LINE 6 Note LINE 5 LINE 5 to LINE 8 are for BRI8 card only. LINE 4 LINE 3 LINE 2...
  • Page 79 2.4.9 BRI4 Card (KX-TDA0284) and BRI8 Card (KX-TDA0288) Maximum Cabling Distance of S0 Bus Connection The maximum length of the extension cable that connects the PBX and the ISDN terminal equipment (TE) is shown below: CAT 5: Under 1000 m Point-to-Point CAT 5: Under 150 m Point-to-Multipoint...

  • Page 80: Pri30 Card (Kx-Tda0290Ce/Kx-Tda0290Cj)

    2.4.10 PRI30 Card (KX-TDA0290CE/KX-TDA0290CJ) 2.4.10 PRI30 Card (KX-TDA0290CE/KX-TDA0290CJ) Function 1-port ISDN Primary Rate Interface card (30B channels). EURO-ISDN/ETSI compliant. LEDs RJ45 To NT1 / Extension To NT1/Extension For RJ45 BNC (TX) BNC (RX) 120Ω 120Ω For BNC 75Ω 75Ω Accessories and User-supplied Items Accessories (included): Ferrite core ´...
  • Page 81 2.4.10 PRI30 Card (KX-TDA0290CE/KX-TDA0290CJ) Switch Settings Switch Type Usage and Status Definition Select 120 W (default) or 75 W to match the connector type to be Termination Slide used. Slide When using an RJ45 connector, select A (default) for trunk or B for extension use.
  • Page 82 2.4.10 PRI30 Card (KX-TDA0290CE/KX-TDA0290CJ) LED Indications Indication Colour Description CARD STATUS Green/Red Card status indication • OFF: Power Off • Green ON: Normal (all ports are idle) • Green Flashing (60 times per minute): Normal (a port is in use) •...

  • Page 83: Pri23 Card (Kx-Tda0290)

    2.4.11 PRI23 Card (KX-TDA0290) 2.4.11 PRI23 Card (KX-TDA0290) Function 1-port ISDN Primary Rate Interface card (23B channels). NI (North American standard ISDN protocol) compliant. LEDs RJ45 To NT1/ Extension Accessories and User-supplied Items Accessories (included): Ferrite core ´ 1 User-supplied (not included): RJ45 connector CAUTION •...
  • Page 84 2.4.11 PRI23 Card (KX-TDA0290) Pin Assignments RJ45 Connector for Trunk Use Signal Name Level [V] Function Receive data (+) Receive data (-) Reserved – – Transmit data (-) Transmit data (+) Reserved – – RJ45 Connector for Extension Use Signal Name Level [V] Function Transmit data (-)
  • Page 85 2.4.11 PRI23 Card (KX-TDA0290) Indication Colour Description SYNC Green Synchronisation status indication • OFF: Not synchronised • ON: Synchronised • Flashing (60 times per minute): Synchronised (Clock Master) D-LINK Green Data link status indication • OFF: Not established • ON: Established Maximum Cabling Distance of Extension Connection The maximum length of the extension cable that connects the PRI23 cards is shown below: Diameter...

  • Page 86: Ip-Gw4E Card (Kx-Tda0484)

    For programming instructions and other information about the IP-GW4E card, refer to the documentation for the IP-GW4E card. When referring to the IP-GW4E documentation, information for the KX-TDA100 applies to the KX-TDA100D. To programme the IP-GW4E card, use the web programming designed for the IP-GW4E card.
  • Page 87 2.4.12 IP-GW4E Card (KX-TDA0484) LED Indications Indication Colour Description CARD STATUS Green/Red Card status indication • OFF: Power Off • Green ON: Normal (all ports are idle) • Green Flashing (60 times per minute): Normal (a port is in use) •...

  • Page 88: Ip-Gw16 Card (Kx-Tda0490)

    For programming instructions and other information about the IP-GW16 card, refer to the documentation for the IP-GW16 card. When referring to the IP-GW16 documentation, information for the KX-TDA100 applies to the KX-TDA100D. To programme the IP-GW16 card, use the web programming designed for the IP-GW16 card.
  • Page 89 2.4.13 IP-GW16 Card (KX-TDA0490) LED Indications Indication Colour Description CARD STATUS Green/Red Card status indication • OFF: Power Off • Green ON: Normal (all ports are idle) • Green Flashing (60 times per minute): Normal (a port is in use) •...

  • Page 90: Information About The Extension Cards

    2.5.1 CSIF4 Card (KX-TDA0143) and CSIF8 Card (KX-TDA0144) 2.5 Information about the Extension Cards 2.5.1 CSIF4 Card (KX-TDA0143) and CSIF8 Card (KX-TDA0144) Function CSIF4: 4-port CS interface card for 4 CSs. CSIF8: 8-port CS interface card for 8 CSs. RJ45 (LINE 1 to LINE 8) To CS Accessories and User-supplied Items...
  • Page 91 2.5.1 CSIF4 Card (KX-TDA0143) and CSIF8 Card (KX-TDA0144) Pin Assignments RJ45 Connector Signal Name Function Reserved – Data port (High) POWH Power (High) POWL Power (Low) Data port (Low) Reserved – LED Indications Indication Colour Description CARD STATUS Green/Red Card status indication •...

  • Page 92: Dlc8 Card (Kx-Tda0171)

    2.5.2 DLC8 Card (KX-TDA0171) 2.5.2 DLC8 Card (KX-TDA0171) Function 8-port digital extension card for DPTs, DSS consoles, and PT-interface CSs. Amphenol To extensions Accessories and User-supplied Items Accessories (included): Screws ´ 2, Ferrite core ´ 1 User-supplied (not included): Amphenol connector Note •...
  • Page 93 2.5.2 DLC8 Card (KX-TDA0171) Pin Assignments Amphenol Connector Signal Signal Function Function Name Name Reserved – Reserved – Data port 1 (Low) Data port 1 (High) Reserved – 28-29 Reserved – Data port 2 (Low) Data port 2 (High) Reserved –...

  • Page 94: Dlc16 Card (Kx-Tda0172)

    2.5.3 DLC16 Card (KX-TDA0172) 2.5.3 DLC16 Card (KX-TDA0172) Function 16-port digital extension card for DPTs, DSS consoles, and PT-interface CSs. Amphenol To extensions Accessories and User-supplied Items Accessories (included): Screws ´ 2, Ferrite core ´ 1 User-supplied (not included): Amphenol connector Note •...
  • Page 95 2.5.3 DLC16 Card (KX-TDA0172) Pin Assignments Amphenol Connector Signal Signal Function Function Name Name Data port 1 (Low) Data port 1 (High) Data port 2 (Low) Data port 2 (High) Data port 3 (Low) Data port 3 (High) Data port 4 (Low) Data port 4 (High) Data port 5 (Low) Data port 5 (High)

  • Page 96: Mcslc16 Card (Kx-Tda1176) And Mcslc24 Card (Kx-Tda1178)

    2.5.4 MCSLC16 Card (KX-TDA1176) and MCSLC24 Card (KX-TDA1178) 2.5.4 MCSLC16 Card (KX-TDA1176) and MCSLC24 Card (KX-TDA1178) Function MCSLC16: 16-port extension card for SLTs with Caller ID (FSK), Message Waiting Lamp control, and 2 power failure transfer (PFT) ports. Maximum power output of 90 V for Message Waiting Lamp control.
  • Page 97 2.5.4 MCSLC16 Card (KX-TDA1176) and MCSLC24 Card (KX-TDA1178) Pin Assignments Amphenol Connector Signal Name Function Signal Name Function Ring port 1 Tip port 1 Ring port 2 Tip port 2 Ring port 3 Tip port 3 Ring port 4 Tip port 4 Ring port 5 Tip port 5 Ring port 6...
  • Page 98 2.5.4 MCSLC16 Card (KX-TDA1176) and MCSLC24 Card (KX-TDA1178) LED Indications Indication Colour Description CARD Green/Red Card status indication STATUS • OFF: Power Off • Green ON: Normal (all ports are idle) • Green Flashing (60 times per minute): Normal (a port is in use) •...

  • Page 99: Ip-Ext16 Card (Kx-Tda0470)

    2.5.5 IP-EXT16 Card (KX-TDA0470) 2.5.5 IP-EXT16 Card (KX-TDA0470) Function 16-channel VoIP extension card. Compliant with Panasonic proprietary protocol, and ITU-T G.729a and G.711 codec methods. LEDs RJ45 (10BASE-T/100BASE-TX Full Duplex) To LAN Accessories and User-supplied Items Accessories (included): Ferrite core ´ 1...
  • Page 100 If the LINK indicator is OFF, the ONLINE indicator will also be OFF. ALARM Alarm indication • OFF: Normal • ON: Alarm VoIP BUSY Green Panasonic proprietary VoIP protocol process indication • OFF: VoIP process inactive • ON: VoIP process active LINK Green Link status indication •...

  • Page 101: Information About The Other Cards

    2.6.1 OPB3 Card (KX-TDA0190) 2.6 Information about the Other Cards 2.6.1 OPB3 Card (KX-TDA0190) Function Optional 3-slot base card for mounting a maximum of 3 option cards from the following: • DPH4 card • DPH2 card • EIO4 card • ECHO16 card •...

  • Page 102: Dph4 Card (Kx-Tda0161)

    2.6.2 DPH4 Card (KX-TDA0161) 2.6.2 DPH4 Card (KX-TDA0161) Function 4-port doorphone card for 4 doorphones and 4 door openers. To be mounted on the OPB3 card. Fully insert the connectors through the panel openings. DPH4 Card OPB3 Card 8-pin Screw To doorphones To door openers 10-pin...
  • Page 103 2.6.2 DPH4 Card (KX-TDA0161) Pin Assignments 8-pin Terminal Block Signal Name Function Doorphone 4 transmit com4 Doorphone 4 receive Doorphone 3 transmit com3 Doorphone 3 receive Doorphone 2 transmit com2 Doorphone 2 receive Doorphone 1 transmit com1 Doorphone 1 receive 10-pin Terminal Block Signal Name Function...

  • Page 104: Dph2 Card (Kx-Tda0162)

    2.6.3 DPH2 Card (KX-TDA0162) 2.6.3 DPH2 Card (KX-TDA0162) Function 2-port doorphone card for 2 German-type doorphones and 2 door openers. To be mounted on the OPB3 card. Fully insert the connectors through the panel openings. DPH2 Card OPB3 Card 8-pin Screw To doorphones/ door openers...
  • Page 105 2.6.3 DPH2 Card (KX-TDA0162) Pin Assignments 8-pin Terminal Block Proprietary Standard Function Signal Name Signal Name Path_2b b (2) Doorphone 2 transmit Path_2a a (2) Doorphone 2 receive Call_2b RT b (2) Doorphone 2 call button Call_2a RT a (2) Doorphone 2 call button com Path_1b b (1)
  • Page 106 2.6.3 DPH2 Card (KX-TDA0162) Connection Diagram for German-type Doorphones and Door Openers German-type Doorphone 2 BL: Light RT: Call Button OP: Door Opener Connection Terminal Door Opener 2 DC: Doorphone Current Supply Control Terminal Path: Doorphone Call Path L O U B Call_2b Call_2a : Speaker...

  • Page 107: Eio4 Card (Kx-Tda0164)

    2.6.4 EIO4 Card (KX-TDA0164) 2.6.4 EIO4 Card (KX-TDA0164) Function 4-port external input/output card. To be mounted on the OPB3 card. Fully insert the connectors through the panel openings. EIO4 Card OPB3 Card 8-pin Screw To external sensors To external relays 10-pin Accessories and User-supplied Items Accessories (included): Screws ´...
  • Page 108 2.6.4 EIO4 Card (KX-TDA0164) Pin Assignments 8-pin Terminal Block Signal Name Function Control 4 Control 4 com Control 3 Control 3 com Control 2 Control 2 com Control 1 Control 1 com 10-pin Terminal Block Signal Name Function Reserved – OP4b Opener 4 OP4a...

  • Page 109: External Sensor

    2.6.4 EIO4 Card (KX-TDA0164) External Sensor Power to the external sensor is provided from the EIO4 card and must be grounded through the EIO4 card as indicated in the diagram below. A pair of "sensor" and "common" lines are connected to the EIO4 card for each external sensor.

  • Page 110: Echo16 Card (Kx-Tda0166)

    2.6.5 ECHO16 Card (KX-TDA0166) 2.6.5 ECHO16 Card (KX-TDA0166) Function 16-channel card for echo cancellation during conferences. To be mounted on the OPB3 card. OPB3 Card inside ECHO16 Card Screw Accessories and User-supplied Items Accessories (included): Screws ´ 3 User-supplied (not included): none Note To establish a conference call involving 6 to 8 parties, install an ECHO16 card and enable echo cancellation for conferences using the Maintenance Console.

  • Page 111: Msg4 Card (Kx-Tda0191)

    2.6.6 MSG4 Card (KX-TDA0191) 2.6.6 MSG4 Card (KX-TDA0191) Function 4-channel message card. To be mounted on the OPB3 card. OPB3 Card inside MSG4 Card Screw Accessories and User-supplied Items Accessories (included): Screws ´ 3 User-supplied (not included): none Installation Manual...

  • Page 112: Esvm2 Card (Kx-Tda0192) And Esvm4 Card (Kx-Tda0194)

    2.6.7 ESVM2 Card (KX-TDA0192) and ESVM4 Card (KX-TDA0194) 2.6.7 ESVM2 Card (KX-TDA0192) and ESVM4 Card (KX-TDA0194) Function ESVM2: 2-channel simplified voice message card for Built-in Simplified Voice Message feature. Also supports MSG card features. To be mounted on the OPB3 card. ESVM4: 4-channel simplified voice message card for Built-in Simplified Voice Message feature.

  • Page 113: Cti-Link Card (Kx-Tda0410)

    2.6.8 CTI-LINK Card (KX-TDA0410) 2.6.8 CTI-LINK Card (KX-TDA0410) Function Ethernet card for CTI communication via 10BASE-T port. CSTA Phase 3 protocol compatible. LEDs RJ45 (10BASE-T) To LAN/ CTI Server Accessories and User-supplied Items Accessories (included): none User-supplied (not included): RJ45 connector Note •...
  • Page 114 2.6.8 CTI-LINK Card (KX-TDA0410) LED Indications Indication Colour Description CARD STATUS Green/Red Card status indication • OFF: Power Off • Green ON: Normal • Red ON: Fault (includes reset) • Red Flashing (60 times per minute): Out of Service LINK STATUS Green Link status indication •...

  • Page 115: Connection Of Extensions

    2.7.1 Maximum Cabling Distances of the Extension Wiring (Twisted Cable) 2.7 Connection of Extensions 2.7.1 Maximum Cabling Distances of the Extension Wiring (Twisted Cable) Cable Maximum Distance PT-interface CS ø 0.4 mm: 222 m ø 0.5 mm: 347 m ø 0.6 mm: 500 m CAT 5: 347 m...
  • Page 116 2.7.1 Maximum Cabling Distances of the Extension Wiring (Twisted Cable) "ü" indicates that the extension card or port supports the terminal. Installation Manual...

  • Page 117: Digital Extra Device Port (Digital Xdp) Connection

    2.7.2 Digital EXtra Device Port (Digital XDP) Connection 2.7.2 Digital EXtra Device Port (Digital XDP) Connection A DPT can be connected to another DPT on the Digital XDP connection. Note • Both DPTs must be KX-DT300/KX-T7600 series DPTs (except KX-T7640). Note that the KX-T7667 can only be connected as a slave DPT.
  • Page 118 2.7.2 Digital EXtra Device Port (Digital XDP) Connection With KX-T7600 Series DPT Using an EXtra Device Port To DLC8/DLC16 card 4-conductor wiring cord To DLC4 port on the Connect pins "T", "R", DMPR card "D1" and "D2". 4-conductor wiring cord Connect pins "T", "R", "D1"...

  • Page 119: First Party Call Control Cti Connection

    2.7.3 First Party Call Control CTI Connection 2.7.3 First Party Call Control CTI Connection CTI connection between a PC and a KX-DT343/KX-DT346/KX-T7633/KX-T7636 DPT provides first party call control. The CTI connection is made via a USB interface (version 2.0), and uses the TAPI 2.1 protocol. A USB Module must be connected to the DPTs.

  • Page 120: Connection Of Doorphones, Door Openers, External Sensors, And External Relays

    2.8.1 Connection of Doorphones, Door Openers, External Sensors, and External Relays 2.8 Connection of Doorphones, Door Openers, External Sensors, and External Relays 2.8.1 Connection of Doorphones, Door Openers, External Sensors, and External Relays The PBX supports a maximum of 16 doorphones (KX-T30865/KX-T7765 with a DPH4 card, or German-type doorphone with a DPH2 card), 16 door openers, 16 external sensors, and 16 external relays.
  • Page 121 2.8.1 Connection of Doorphones, Door Openers, External Sensors, and External Relays When loosening/tightening the screw, do not scratch the cabinet wall with the driver shaft. Cabinet Wall Pass the wires through the hole in the base cover, and attach the base cover to a wall using 2 screws. Screw To 8-pin terminal block Note...
  • Page 122 2.8.1 Connection of Doorphones, Door Openers, External Sensors, and External Relays Connection Use 8-pin and 10-pin terminal blocks (included with the card) for connection. While pressing down on the hole at the top of the terminal block using a screwdriver, insert the wire into the side hole as shown below.

  • Page 123: Connection Of Peripherals

    2.9.1 Connection of Peripherals 2.9 Connection of Peripherals 2.9.1 Connection of Peripherals Maximum Distance CTI Server Maximum Distance 10 m BGM/ Music on Hold Maximum Distance 10 m Pager: Amplifier/Speaker Maximum Distance RS-232C Printer BGM/MOH The PBX provides Background Music and Music on Hold. Up to 2 external music sources (e.g., user-supplied radios) can be connected to the PBX.
  • Page 124 2.9.1 Connection of Peripherals Pin Assignments Signal Name Level [V] Function MOH1 Nonpolar Music on Hold Jack: Port 1 MOH1 Nonpolar Music on Hold Jack: Port 1 PAG2 Nonpolar External Paging Jack: Port 2 PAG1 Nonpolar External Paging Jack: Port 1 PAG1 Nonpolar External Paging Jack: Port 1...
  • Page 125 2.9.1 Connection of Peripherals If this is not possible, connect the frame of the PBX to the frame of the PC/Printer using an earthing wire in order to prevent difference in the electrical potentials. Pin Assignments Circuit Type Signal Name Function CCITT RD (RXD)
  • Page 126 2.9.1 Connection of Peripherals RS-232C Signals • Receive Data (RXD):…(input) Conveys signals from the printer or the PC. • Transmit Data (TXD):…(output) Conveys signals from the unit to the printer or the PC. A "Mark" condition is held unless data or BREAK signals are being transmitted.
  • Page 127 2.9.1 Connection of Peripherals PC/CTI Server (via USB version 2.0) The PBX is equipped with a USB interface. This interface provides communication between the PBX and a PC or a CTI server. The PC is used for system programming, diagnostics and external system database storage (save/load) functions.

  • Page 128: Power Failure Connections

    2.10.1 Power Failure Connections 2.10 Power Failure Connections 2.10.1 Power Failure Connections When the power supply to the PBX fails, power failure transfer (PFT) will switch from the current connection to the Power Failure Connection. Refer to "2.4.1 Power Failure Transfer" in the Feature Guide for further information.
  • Page 129 2.10.1 Power Failure Connections Signal Name Function Ring port 2 Ring port 1 Tip port 1 Tip port 2 PFT Ports 3 and 4 (for LCOT16 card only) Signal Name Function Ring port 4 Ring port 3 Tip port 3 Tip port 4 RJ11 Connector Pin Assignments for Extension Card PFT Ports 1 and 2...
  • Page 130 2.10.1 Power Failure Connections Using BRI Card LINE 1 and LINE 2 of the BRI4 and BRI8 cards can be used for Power Failure Connections. Note When the power returns, the connection will switch back to normal configuration from the Power Failure Connection, and a trunk conversation established during power failure will be dropped.
  • Page 131 2.10.1 Power Failure Connections RJ45 Connector LINE 2 Pin Assignments Signal Name Level [V] Function Reserved – – Receive data 2 Transmit data 1 Transmit data 2 Receive data 1 Reserved – – Installation Manual...

  • Page 132: Starting The Pbx

    2.11.1 Starting the PBX 2.11 Starting the PBX 2.11.1 Starting the PBX Before Starting the PBX Before starting the PBX, please pay attention to the following: Notice The SD Memory Card must be inserted in the SD Memory Card slot of the DMPR card before startup. Starting the PBX CAUTION •...
  • Page 133 2.11.1 Starting the PBX Plug the AC power cord into the PBX and an AC outlet, and turn on the PBX. The RUN indicator will flash. Note For safety reasons, do not stretch, bend, or pinch the AC power cord. To AC Outlet While the RUN indicator is flashing, slide the System Initialise Switch back to the "NORMAL"...
  • Page 134 2.11.1 Starting the PBX Installation Manual...

  • Page 135: Guide For The Maintenance Console

    Section 3 Guide for the Maintenance Console Explains the installation procedure, structure, and basic information of the Maintenance Console. Installation Manual...

  • Page 136: Overview

    3.1.1 Overview 3.1 Overview 3.1.1 Overview The Maintenance Console is designed to serve as an overall system programming reference for the PBX. To programme and administer the PBX by PC, you need to install the Maintenance Console onto the PC. This section describes overview and installation of the Maintenance Console only.

  • Page 137: Pc Connection

    3.2.1 PC Connection 3.2 PC Connection 3.2.1 PC Connection Serial Interface Connection USB Port To USB Port To COM Port RS-232C Port CAUTION To protect the system, keep the following in mind: Make sure that both connector cases (frame ground) of the RS-232C cross cable (shielded cable)/USB cable are conductive.

  • Page 138: External Modem Connection

    3.2.1 PC Connection Note For pin assignments and maximum cabling distance, refer to "2.6.8 CTI-LINK Card (KX-TDA0410)". External Modem Connection Modem To RS-232C port (25-pin) To trunk/PBX extension RS-232C Port port assigned as the trunk destination (9-pin) External Modem (25-pin) PBX (9-pin) Signal Name Pin No.

  • Page 139: Installation Of The Maintenance Console

    3.3.1 Installing and Starting the Maintenance Console 3.3 Installation of the Maintenance Console 3.3.1 Installing and Starting the Maintenance Console System Requirements Required Operating System • Microsoft Windows XP, Windows Vista Business, or Windows 7 Professional operating system ® ® ®...
  • Page 140 3.3.1 Installing and Starting the Maintenance Console Installing the Maintenance Console Note • Make sure to install and use the latest version of the Maintenance Console. • To install or uninstall the software on a PC running Windows XP Professional, you must be logged in as a user in either the "Administrators"...
  • Page 141 3.3.1 Installing and Starting the Maintenance Console Select KX-TDA100D from PBX Model. Depending on the type of Maintenance Console used, you may not be required to select a PBX model. Select the USB tab. Enter the system password for installer (default: 1234).
  • Page 142 3.3.1 Installing and Starting the Maintenance Console Installation Manual...

  • Page 143: Troubleshooting

    Section 4 Troubleshooting This section provides information on the PBX and telephone troubleshooting. Installation Manual...

  • Page 144: Troubleshooting

    4.1.1 Installation 4.1 Troubleshooting 4.1.1 Installation PROBLEM PROBABLE CAUSE SOLUTION Extension does not operate. Bad extension card. • Exchange the card for a known working one. Bad connection between • Take the telephone and plug it into the the PBX and telephone. same extension port using a short telephone cord.

  • Page 145: Connection

    4.1.2 Connection 4.1.2 Connection Connection between the PBX and a PT: CAUSE SOLUTION Can you dial The T/R is connected to the D1/D2. Use the correct cord (the an extension? inner 2 wires are for T/R and the outer 2 wires are for D1/D2).
  • Page 146 4.1.2 Connection Connection between the trunk and the PBX: CAUSE SOLUTION (Continued from the Trunk is connected to the T2/T1. Reconnect the trunk to previous page.) the T1/R1 or T2/R2 of the telephone jack using 2-conductor wiring. Can you dial out on a Trunk trunk?

  • Page 147: Operation

    4.1.3 Operation 4.1.3 Operation PROBLEM PROBABLE CAUSE SOLUTION • • • When using the The "HEADSET" mode When the headset is not used, select the speakerphone/monitor is selected by Personal "HANDSET" mode by Personal mode with a DPT, Programming, Programming. nothing is audible.

  • Page 148: Using The Reset Button

    4.1.4 Using the Reset Button 4.1.4 Using the Reset Button If the PBX does not operate properly, use the Reset Button. Before using the Reset Button, try the system feature again to confirm whether there definitely is a problem or not. CAUTION In order to avoid possible corruption of data on the SD Memory Card, please ensure that the "SD ACCESS"...

  • Page 149: Error Log Display Format

    4.1.5 Troubleshooting by Error Log 4.1.5 Troubleshooting by Error Log When a major system error occurs in the PBX, the ALARM indicator on the front of the shelf turns on red, and the system logs the error information. Error Log Display Format Below is the display format of the error log.
  • Page 150 4.1.5 Troubleshooting by Error Log Item Description Sub Code The 5-digit sub code of the relevant hardware (1XXYY). • 1: Shelf number • XX: Slot number – 00 to 07, 11 (00: DMPR Card Slot; 01 to 07: Free Slots; 11: DLC4 Port on the DMPR Card) •...

  • Page 151: Index
