  • Page 1 ® Digital Color Imaging System Documentation Model No. DP-C106 Options DA-TL28C/TL26C/RM64C/RM128C/DU26C/SM112C/S27C...
  • Page 2 NDPS, NDS, , IPX, IPX/SPX, NDS Admin, NDS Administrator are either registered trademarks or trademarks of Novell, Inc., in the United States and/or other countries. Panasonic Document Imaging Company has made every effort to supply trademark information about company names, products and services mentioned in this documentation. All third party and/or other trademarks identified herein are the property of their respective owners.

  • Page 3: Safety Notes

    Panasonic's negligence or other fault. Safety Notes Your DP-C106 and its supplies have been designed and tested to meet strict safety requirements. These include safety agency examination and approval, and compliance with established environmental standards. Please read the following instructions carefully before operating the DP-C106.

  • Page 4: Maintenance Safety

    The DP-C106 is designed to prevent user access to unsafe areas and to ensure that the device will not operate with the covers opened. Never attempt any maintenance function that is not specified in the DP-C106 Operating Instructions.

  • Page 5: Ozone Safety

    Safety Notes, Compliances, Certifications, and Other Notices Unplug the DP-C106 from the wall outlet and refer servicing to qualified service personnel under the following conditions: • When the power cord is damaged or frayed • If liquid has been spilled into the DP-C106 •...
  • Page 6 Responsible Party: Matsushita Electric Corporation of America One Panasonic Way, Secaucus, NJ 07094 Technical Support: Panasonic Document Imaging Company/ Technical Support Department...
  • Page 7 Please contact your local authorized Panasonic representative for a list of approved accessories. WARNING In order to allow this equipment to operate in proximity to Industrial, Scientific and Medical (ISM) equipment, the external radiation from the ISM equipment may have to be limited or special mitigation measures taken.
  • Page 8 Safety Notes, Compliances, Certifications, and Other Notices WARNING This is a Class A product. In a domestic environment this product may cause radio frequency interference in which case the user may be required to take adequate measures. The user could lose the authority to operate this equipment if any unauthorized changes or modifications are made to this equipment.

  • Page 9: Table Of Contents

    1. Setting Up the DP-C106 ..................1-1 Preparing for the Installation..................1-1 Selecting a Location....................1-1 Space Requirements for the DP-C106 Printer ............1-2 Space Requirements Without the Optional 10 Bin Sorter........1-2 Space Requirements With the Optional 10 Bin Sorter........1-3 Checking the Installation Components ..............
  • Page 10 Windows Computers Using Windows Printing ............4-9 Unix and Windows NT. 4.0 Workstations on a TCP/IP Network......4-10 Parallel Port Connection ..................4-11 Connecting the DP-C106 to the Network..............4-12 5. Preparing for the Setup ..................5-1 Levels of Access and Control ................... 5-1 Printer Connections....................
  • Page 11 Setting Up a NetWare Print Queue for Bindery............. 6-7 Setting Up NetWare Windows Clients for Printing ............ 6-7 The DP-C106 on a TCP/IP Network with Windows NT 4.0........6-8 Configuring a Windows NT 4.0 Server ..............6-9 Adding the DP-C106 to the TCP/IP Network (Windows NT 4.0) ....................
  • Page 12 Table of Contents Operating Instructions SMB Setup......................7-15 Print Information Pages ..................7-16 8. Installing User Software in a Windows 95/98/Me Environment ......8-1 Overview of Installation..................... 8-2 Before You Begin...................... 8-2 Installing PostScript or PCL Print Drivers ..............8-3 Installing the PostScript or PCL Print Drivers (Windows 95/98/Me) ......
  • Page 13 11. Installing User Software in a Macintosh OS Environment......11-1 General Steps for Installing the User Software............11-1 Setting Up the DP-C106 as a PostScript Printer ..........11-2 Setting Up the DP-C106 in the Chooser ............. 11-4 Installing Fiery Software and Fonts ..............11-6 Installing Mac OS Software ................
  • Page 14 Table of Contents Operating Instructions 12. Installing the Fiery Software for Windows and Macintosh ......12-1 Installing the Fiery Link Software ................12-1 Using the Software for the First Time ..............12-2 Configuring a Connection for Fiery Link for Windows and Macintosh OS ................12-2 Configuring the Connection to Fiery Servers in a Local Subnet.....................
  • Page 15 Operating Instructions Table of Contents Setting Print Options Using Shortcuts ............... 13-12 Setting Print Options Using Page Shortcuts............13-12 Working with Custom Page Sizes in Windows 95/98/Me or Windows 2000 ..13-13 Defining a Custom Page Size ................13-13 Printing a Custom Page Size ................13-14 Saving Files to Print at a Remote Location............
  • Page 16 Table of Contents Operating Instructions 17. Using Fiery WebSpooler................... 17-1 Tracking and Managing Jobs with Fiery WebSpooler..........17-1 Accessing the Fiery WebSpooler Window ............17-2 About the Fiery WebSpooler Window ..............17-3 Job Icons......................17-3 Job Types ......................17-3 Manipulating Job Options and Job Flow ............. 17-4 Overriding Job Option Settings ................
  • Page 17 Operating Instructions Table of Contents To Restore Default Calibration Measurements..........19-6 Expert Mode......................19-6 Color Editor......................19-6 Editing Profiles ....................19-7 To Edit a Simulation Profile in Master Mode or an Output Profile in Custom Mode .............. 19-7 To Edit a Simulation in Quick or Full Mode............19-9 Undoing Simulation Edits ..................
  • Page 18 Table of Contents Operating Instructions 21. Copy Features ....................21-1 Reduce/Enlarge ...................... 21-1 Using the Reduce/Enlarge Feature ..............21-2 Paper Supply ......................21-4 Using Paper Trays 1, 2, and 3 ................21-4 Using the Bypass Tray ..................21-5 Loading the Bypass Tray................. 21-5 Loading Transparencies into the Bypass Tray..........
  • Page 19 Operating Instructions Table of Contents Auto Mode Change ................... 22-12 Limit Copy Set....................22-13 Timer Preset ..................... 22-14 Sound Preset ....................22-16 User Password....................22-17 ADMIN Password....................22-19 Version Information ................... 22-20 Self Diagnostics ....................22-21 Transporting the Scanner.................. 22-22 23.
  • Page 20 Job Management Problem Solving ............... 23-61 Job Management Error Messages ..............23-61 Unexpected Printing Results................23-63 Clearing the Printer ................... 23-64 Users are Unable to Connect to the DP-C106 ..........23-64 24. Maintenance ...................... 24-1 Cleaning Procedures ....................24-1 Cleaning the Printer Covers ................24-1 Cleaning the Scanner..................
  • Page 21 Operating Instructions Table of Contents 25. Technical Data ....................25-1 Printer Specifications ....................25-1 Electrical Specifications ..................25-3 Emissions ....................... 25-3 Supplies........................25-4 Fiery Server Hardware Components ..............25-5 Font List........................25-6 PostScript Printer Fonts ..................25-6 Adobe Type 1 Fonts ..................25-6 PostScript TrueType Fonts ................

  • Page 22: Setting Up The Dp-C106

    • The power cord cannot be stepped on, or be a tripping hazard. • The location has a level, stable surface. DO NOT install the DP-C106 in a location that has any of the following conditions: • • In direct sun light Near an air conditioner or heater •...

  • Page 23: Space Requirements For The Dp-C106 Printer

    Space Requirements for the DP-C106 Printer CAUTION The Panasonic DP-C106 has ventilation openings on the side and rear, which must remain unobstructed for safe operation. The Printer should be located at least 6 and 1/2 inches (165 mm) from the wall. Obstructing the ventilation openings could present a fire hazard.

  • Page 24: Space Requirements With The Optional 10 Bin Sorter

    Preparing for the Installation Setting Up the DP-C106 Space Requirements With the Optional 10 Bin Sorter The following illustration shows the dimensions for the largest configuration of the Copier/Printer, which includes a Duplex Unit/Kit and a 10 Bin Sorter. 6.5 inches...

  • Page 25: Checking The Installation Components

    Duplex Kit (Except North America) (optional) You may need a phillips head and a flat blade screwdriver in order to perform the installation of the DP-C106. Following the instructions ensures that the DP-C106 components are installed in the following order: System Console...

  • Page 26: Installing The System Console

    Installing the System Console Setting Up the DP-C106 Installing the System Console To install the System Console, perform the following steps. WARNING You will need at least two people to remove it from the carton. Open the System Console carton.
  • Page 27 Setting Up the DP-C106 Installing the System Console Remove all the tape from the outside of the System Console. Pull the top paper tray open until it stops, and remove the packing shown below. Close the top tray and repeat step 7 for the lower paper tray.
  • Page 28 Installing the System Console Setting Up the DP-C106 12. Remove the tape from the paper feed area access door, and then open the door. 13. Remove the cardboard packing shown below. CAUTION Open the Harness Access Cover before placing the Printer on top of the System Console.
  • Page 29 Setting Up the DP-C106 Installing the System Console This page is intentionally left blank.

  • Page 30: Unpacking The Printer

    Unpacking the Printer Setting Up the DP-C106 Unpacking the Printer Read all the steps before performing this procedure. There are decisions to make before removing the Printer from the packing. Ensure that the following items are included in the carton: Remove the four cardboard supports and the Styrofoam packing from the top of the Printer.
  • Page 31 Setting Up the DP-C106 Unpacking the Printer WARNING The Printer weighs 153 pounds (69.5 kg) without the Toner Cartridges and the Print/Copy Cartridge installed. ALWAYS USE FOUR PEOPLE TO LIFT THE PRINTER. Ensure that you keep the Printer LEVEL. Please note that the rear of the Printer is heavier than the front.
  • Page 32 Unpacking the Printer Setting Up the DP-C106 Carefully, lift the Printer from the pallet. CAUTION Ensure that the Harness Access Cover is open before placing the Printer on top of the System Console in step 8. Open the Harness Access Cover.
  • Page 33 Setting Up the DP-C106 Unpacking the Printer Remove the Paper Tray 2, and tighten the two Thumb Screws shown below. Do not over tighten the Thumb Screws. Reinstall the Paper Tray 2. Remove all the tape from the exterior of the Printer:...
  • Page 34 Unpacking the Printer Setting Up the DP-C106 Inside the Front Cover 10. Remove all the internal packing from the Printer by performing steps a through m. Remove the spacer styrofoam labeled B. Remove the cardboard collar labeled H from the knob shown below.
  • Page 35 Setting Up the DP-C106 Unpacking the Printer Pull and remove the narrow strip labeled G from the Toner chamber. Press the Anti-rotation button to release the rotating chambers. Turn the Rotary Knob in the direction of the arrow, until it stops.
  • Page 36 Unpacking the Printer Setting Up the DP-C106 Close the Paper Tray 1. Gently pull the Fuser area open and remove the spacer labeled A. Lift the Fuser Pressure Release Lever to remove the spacer labeled J, then lower the lever down until it stops.
  • Page 37 Setting Up the DP-C106 Unpacking the Printer Gently pull the handle until the Bypass Transport is completely opened, then remove the two spacers labeled D. Close the Bypass Transport. 11. Close the Front Cover. 12. After installing the Printer on the System Console, perform the following...
  • Page 38 Unpacking the Printer Setting Up the DP-C106 Open the Harness Access Cover. Connect the two small connectors from the System Console into the jacks in the Printer. While holding the Harness Access Cover on the System Console closed, align the Rear Connector Cover to the plastic rails, and slide it into the Printer.
  • Page 39 Setting Up the DP-C106 Unpacking the Printer This page is intentionally left blank. 1-18...

  • Page 40: Printer Installation

    Printer Installation Setting Up the DP-C106 Printer Installation Perform this procedure after the Printer is unpacked, and placed in a suitable location. If you are installing the 10 Bin Sorter, skip step 1 and go to step 2. Locate the Output Tray in the cardboard tray removed from the top of the printer.
  • Page 41 Setting Up the DP-C106 Printer Installation Place the left-hand arm of the tray into the corresponding hole as shown. 301033B Install the Print/Copy Cartridge: Open the Front Cover of the Printer. Rotate the beige lever A in the direction of the arrows, until the dot is aligned with the Unlocked symbol.
  • Page 42 Printer Installation Setting Up the DP-C106 Install the Print/Copy Cartridge: Remove the Print/Copy Cartridge from the box. Tear open the notched end of the silver protective bag and remove the Print/Copy Cartridge. CAUTION DO NOT touch the blue surface of the drum. If the drum is scratched, or contaminated with oil from your hand, the output can be degraded.
  • Page 43 Setting Up the DP-C106 Printer Installation Holding the cartridge by the strap, align the guide with the Printer rail. Push the cartridge all the way into the Printer until it snaps into place. Rotate lever B in the direction of the arrow until the dot is aligned with the Locked symbol.
  • Page 44 Printer Installation Setting Up the DP-C106 Rotate lever A in the direction of the arrow until the dot is aligned with the Locked symbol. Install the Toner Cartridges: Each Toner Cartridge chamber is designated for a specific color. Ensure that the correct Toner Cartridge is installed into the corresponding color on the chamber.
  • Page 45 Setting Up the DP-C106 Printer Installation Align the arrow visible on the top of the cartridge with the Red Dot sticker on the chamber (located at 11 o’clock position), insert the cartridge into the Printer as far as it will go.
  • Page 46 Printer Installation Setting Up the DP-C106 Press and release the Anti-rotation button. Rotate the Rotary Knob in the direction of the arrow until it stops at the next chamber. If the Toner Cartridge is not in the Printer all the way, the knob will not rotate.
  • Page 47 Setting Up the DP-C106 Printer Installation Close the Printer Front Cover. The Next Step If you have ordered the optional Duplex Unit/Kit, go to the Installing the Duplex Unit/Kit procedure. If you do not have a Duplex Unit/Kit, go to Loading Paper in the Paper Tray procedure.

  • Page 48: Installing The Duplex Unit/Kit (Option)

    Installing the Duplex Unit/Kit Setting Up the DP-C106 Installing the Duplex Unit/Kit (option) The Duplex Unit/Kit enables the DP-C106 to print two-sided output. Open the Duplex Unit/Kit box and remove the contents: • Duplex Unit/Kit • Upper Inverter • Lower Inverter •...
  • Page 49 Setting Up the DP-C106 Installing the Duplex Unit/Kit Open Paper Tray 1. 301128A-WOL Using a phillips head screwdriver, remove the screw shown below. 301050B-WOL To remove the cover, shift it to the right then pull it away from the Printer.
  • Page 50 Installing the Duplex Unit/Kit Setting Up the DP-C106 Install the Duplex Unit/Kit: Align the rails on the tray with the rails in the Printer. Partially close the Duplex Unit/Kit and the paper tray. Install the Lower Inverter: Skip step a and go to step b, if the Output Tray is not installed.
  • Page 51 Setting Up the DP-C106 Installing the Duplex Unit/Kit Using a screwdriver, remove the two screws from lower left-hand cover of the Printer as shown below. 301054B Remove the cover by shifting it to the front of the Printer then pulling it away from the Printer. Discard the cover.
  • Page 52 Installing the Duplex Unit/Kit Setting Up the DP-C106 Remove the Left Connector Cover (Plain) located on the lower left-hand side of the Printer. DO NOT discard this cover. CAUTION Ensure that the small connector and cable on the left-hand side of the Lower Inverter are pulled back out of the way.
  • Page 53 Setting Up the DP-C106 Installing the Duplex Unit/Kit Connect the small connector from the Lower Inverter to the small jack located at the rear of the left-hand side of the Printer. Reinstall the Left Connector Cover (Plain). 11. Install the Upper Inverter: Install the Upper Inverter into the Printer as shown.
  • Page 54 Installing the Duplex Unit/Kit Setting Up the DP-C106 Connect the tiny connector on the rear of the Upper Inverter to the small jack in the access hole, as shown below. Install the new Connector Cover (w/ Cutout) into the access hole, guiding the wires through the cutout in the cover.
  • Page 55 Setting Up the DP-C106 Installing the Duplex Unit/Kit 12. Reinstall the Output Tray if it was removed in step 7. The Next Step Go to the Loading the Paper in the Paper Tray procedure. 1-34...

  • Page 56: Loading Paper In The Paper Tray

    Loading Paper in the Paper Tray Setting Up the DP-C106 Loading Paper in the Paper Tray When loading paper, use paper weight between 14 to 23 lbs. Refer to Types of Paper in the Operating Instructions or the Color Materials Usage Guide on the CD.
  • Page 57 Setting Up the DP-C106 Loading Paper in the Paper Tray Pinch the Horizontal and Vertical Paper Guides and move them away from the center of the tray as far as they will go. Place the right edge of the paper stack against the right metal edge and under the front right-hand side paper tab as shown below.
  • Page 58 Loading Paper in the Paper Tray Setting Up the DP-C106 Moving the guides too tight against the paper stack can cause a jam. Ensure that the vertical Paper Guide is aligned with the appropriate paper size mark on the bottom of the tray.
  • Page 59 Setting Up the DP-C106 Loading Paper in the Paper Tray This page is intentionally left blank. 1-38...

  • Page 60: Installing The Scanner Rack

    Installing the Scanner Rack Setting Up the DP-C106 Installing the Scanner Rack You will need a phillips head screwdriver to perform this installation Open the Scanner Rack carton. Ensure that the following parts are included in the carton: Right Leg...
  • Page 61 Setting Up the DP-C106 Installing the Scanner Rack Attach the Left Leg and Right Leg to the Rear/Bottom Plate using eight screws (M4 x 10) as shown below. Install the Spacer Bar between the tops of the two legs using four screws (M4 x 10).
  • Page 62 Installing the Scanner Rack Setting Up the DP-C106 Place the table top face-down on the floor. Place the Left Support and the Right Support into the table top and install the two screws (M4 x 10). This is the Upper Assembly Install four screws (M4 x 10) through the supports and into the top of the table.
  • Page 63 Setting Up the DP-C106 Installing the Scanner Rack Turn the Upper Assembly over, and slide it into the legs of the Lower Assembly. Line up the alignment mark of the Upper Assembly with the height mark (3 settings) of the Lower Assembly according your height requirements.
  • Page 64 Installing the Scanner Rack Setting Up the DP-C106 10. Install the two Bumpers into the rear slots of the bottom plate. If the optional Duplex Unit/Kit is being installed, insert the Bumpers into the front slots of the bottom plate.
  • Page 65 Setting Up the DP-C106 Installing the Scanner Rack The Next Step Go to the Installing the Scanner with ADF procedure. 1-44...

  • Page 66: Installing The Scanner With Adf

    Installing the Scanner with ADF Setting Up the DP-C106 Installing the Scanner with ADF Open the Scanner with ADF carton. Ensure that the following items are in the carton. • Scanner with ADF • Power Cord • Printer Interface Cable •...
  • Page 67 Setting Up the DP-C106 Installing the Scanner with ADF Ensure that the front Scanner feet are placed into the round recessed areas on the top front of the Scanner Rack. Tighten the Thumb Screw, shown below, in order to secure the Scanner to the Table Top.
  • Page 68 Installing the Scanner with ADF Setting Up the DP-C106 Connect the Scanner cables by performing the following steps: Install one end of the Interface Cable to the rear of the Scanner, and the other end to the left-hand side (Rear view) of the Printer.
  • Page 69 Setting Up the DP-C106 Installing the Scanner with ADF Connect the cable to the back of the Scanner and tighten the two screws. 10. Connect the Scanner Power Cord to the wall outlet and to the rear of the Scanner.
  • Page 70 Installing the Scanner with ADF Setting Up the DP-C106 The Next Step If you are installing the optional 10 Bin Sorter, go to the Installing the 10 Bin Sorter procedure. Otherwise, go to the Printing the Test Page procedure. 1-49...
  • Page 71 Setting Up the DP-C106 Installing the Scanner with ADF This page is intentionally left blank. 1-50...

  • Page 72: Installing The 10 Bin Sorter

    Setting Up the DP-C106 Installing the 10 Bin Sorter The 10 Bin Sorter is an optional accessory for the DP-C106. It attaches to the left side of the unit and consists of 10 Bins and a high capacity bin. The 10 Bin Sorter functions are available to copy jobs only. Sorting functions are not available to print jobs.
  • Page 73 Setting Up the DP-C106 Installing the 10 Bin Sorter Review the 10 Bin Sorter components before installing the unit. 1 Sorter Bins 2 High Capacity Bin 3 Attachment Plate 4 Jam Clearance Cover 5 Interface Cable 6 Connector Cover 1-52...
  • Page 74 Installing the 10 Bin Sorter Setting Up the DP-C106 Unpacking the 10 Bin Sorter Read all the steps before performing this procedure. Open the box. Remove the plastic bag with the Left Connector Cover (w/ Cutout). Remove the plastic bag.
  • Page 75 Setting Up the DP-C106 Installing the 10 Bin Sorter Remove the cardboard inserts that hold the unit in place. Move any plastic away from the bottom wheels of the 10 Bin Sorter. Gently tip the box so the 10 Bin Sorter is standing on its wheels...
  • Page 76 Installing the 10 Bin Sorter Setting Up the DP-C106 CAUTION When rolling an unattached 10 Bin Sorter, hold the unit from the inboard side, not the bins. Do not press down on the attachment plate as this may cause the unit to tip.
  • Page 77 Setting Up the DP-C106 Installing the 10 Bin Sorter Remove the tape and cardboard from the inboard side of the 10 Bin Sorter. Remove the cardboard from the top of the 10 Bin Sorter. Remove the cardboard protector and tape from the sorting bins. Remove the strap around the high capacity bin.
  • Page 78 Installing the 10 Bin Sorter Setting Up the DP-C106 CAUTION Do not remove the plastic tie wrap on the metal roller under the jam clearance cover. The tie wrap holds a sensor wire out of the way, as illustrated in the figure below.
  • Page 79 Setting Up the DP-C106 Installing the 10 Bin Sorter Connecting the 10 Bin Sorter Read all the steps before performing this procedure. CAUTION Ensure that the power is Off on the Copier/Printer before you begin to install the 10 Bin Sorter.
  • Page 80 Perform one of the following: • If the DP-C106 does not have the optional Duplex Unit/Kit, ensure that the vertical edge of the spacer plate is positioned to the right, near the vertical edge of the attachment plate. No icon should be visible in the spacer plate cut out.
  • Page 81 Setting Up the DP-C106 Installing the 10 Bin Sorter Align the 10 Bin Sorter with the left side of the DP-C106 so the Thumb Screws on the plate align with the holes in the left cover of the Copier/Printer. The upper horizontal edges of the alignment plate should fit under Jam Clearance Area 5.
  • Page 82 Installing the 10 Bin Sorter Setting Up the DP-C106 Remove the Left Connector Cover (Plain) that is below the power plug on the left side (Rear view) of the Copier/Printer. Remove the protective plastic wrap from the 10 Bin Sorter Interface Cable and Connector.
  • Page 83 Setting Up the DP-C106 Installing the 10 Bin Sorter CAUTION Be careful not to squeeze or disconnect any of the wires or the Interface Cable with the cover in the following step. 10. Remove the new Left Connector Cover (w/ Cutout) from the plastic bag.
  • Page 84 Installing the 10 Bin Sorter Setting Up the DP-C106 11. Slide the 10 Bin Sorter to the right into position. 1-63...
  • Page 85 Setting Up the DP-C106 Installing the 10 Bin Sorter The Next Step Go to the Printing the Test Page procedure. 1-64...

  • Page 86: Switching The Power On

    Press the Power Switch to the On (I) position on the left-hand side of the Scanner. 0301232A - W O L The DP-C106 performs a registration setup, then after a few moments messages indicating the Scanner is ready are displayed on the Printer Control Panel and on the Scanner Control Panel.

  • Page 87: Switching The Power Off

    Do not switch Off the power if any other message is displayed. There may be a problem, or if the DP-C106 is networked, it may be receiving data. Press the Power Switch to the Off (O) position on the Scanner only.

  • Page 88: Printing A Test Page From The Printer Control Panel

    Printing the Test Page Setting Up the DP-C106 Printing a Test Page from the Printer Control Panel Print the test page in order to ensure that the Printer is functioning. An original document is not required. The Test Page can be generated from the Printer Control Panel.

  • Page 89: Making A Test Copy From The Scanner

    Printer procedure. • If you are adding memory to the Scanner, go to the Adding Memory to the Scanner procedure. • If you are not adding memory, go to Getting to Know the DP-C106 section of the Operating Instructions. 1-68...

  • Page 90: Adding Memory To The Printer

    Adding Memory to the Printer Setting Up the DP-C106 Adding Memory to the Printer You will need a phillips head screwdriver to perform this procedure. CAUTION • Protect the Memory Card from static electricity by keeping it in the anti- static bag until you are ready to install it.
  • Page 91 Setting Up the DP-C106 Adding Memory to the Printer Slide the panel to the rear and lift to remove. The memory card slots are located behind the panel. • The upper slot contains the 64MB memory card, already installed •...
  • Page 92 Adding Memory to the Printer Setting Up the DP-C106 To replace the 64MB memory card perform the following steps: In order to remove the 64MB memory card separate the two clips on the sides of the card slot using your thumbs.
  • Page 93 Setting Up the DP-C106 Adding Memory to the Printer Insert the left-hand side Printer panel into place as shown below. Press the panel closed and slide it to the front of the unit. Reinstall the three screws into the side panel.
  • Page 94 Adding Memory to the Printer Setting Up the DP-C106 10. Switch On the Printer and the Scanner power. 0301232A - W O L 11. After a few moments, READY is displayed on the control panel. 1-73...
  • Page 95 Setting Up the DP-C106 Adding Memory to the Printer The Next Step Perform one of the following steps: • If you are adding memory to the Scanner, go to Adding Memory to the Scanner procedure. • If you are not installing memory to the Scanner, go to the...

  • Page 96: Adding Memory To The Scanner

    Adding Memory to the Scanner Setting Up the DP-C106 Adding Memory to the Scanner The Scanner Memory Card enables 2-Sided copying. You will need a flat blade screwdriver to perform this procedure. CAUTION • Protect the Memory Card from static electricity by keeping it in the anti- static bag until you are ready to install it.
  • Page 97 Setting Up the DP-C106 Adding Memory to the Scanner Press the latch toward the front, and remove the access cover from the Printer. Using a Slotted Blade Screwdriver, loosen 2 screws on the Memory Protective Cover and remove it. Remove the Memory Card from the anti-static bag.
  • Page 98 Adding Memory to the Scanner Setting Up the DP-C106 Align the screws on the end of the memory card to the holes in the rear Printer cover. Use a Slotted Blade Screwdriver to tighten the screws. Replace the access cover, plug the Power Cord into the Scanner and switch On the power.
  • Page 99 Setting Up the DP-C106 Adding Memory to the Scanner The Next Step Go to the Installing the Oversize Paper Tray/Transparency Tray (option) section of the Operating Instructions. 1-78...

  • Page 100: Installing The Oversize Paper Tray/Transparency Tray (Option)

    Installing the Oversize Paper Tray/Transparency Tray (option) Setting Up the DP-C106 Installing the Oversize Paper Tray/Transparency Tray (option) The optional Oversize Paper Tray (DA-TL28C) can be used for oversized paper. The optional Transparency Tray (DA-TL26C) can be used for OHP.
  • Page 101 Place the Tray Label on the Front Panel of Tray , if necessary. <Oversize Paper Tray> <Transparency Tray> (DA-TL28C) (DA-TL26C) 12.9 x 18 A3-Over The Next Step Go to the Getting to Know the DP-C106 section of the Operating Instructions. 1-80...

  • Page 102: Getting To Know The Dp-C106

    Getting to Know the DP-C106 Printer, Front View Paper Tray 1 – place paper supply here Duplex Unit/Kit – option that allows two-sided printing Front Cover – open to access the Toner Cartridges and the Print/Copy Cartridge Control Panel – use to access the Printer menus and to view messages Printer Output Top Tray –...

  • Page 103: Printer, Rear View

    Getting to Know the DP-C106 Printer, Rear View Printer, Rear View 11. Scanner Power Connector –provides power to the Scanner 12. Scanner Interface Connector – provides interface to the Scanner 13. Area 4 Access Cover – open to access paper jams 14.

  • Page 104: Printer, Internal View

    Printer, Internal View Getting to Know the DP-C106 Printer, Internal View 17. Toner Carousel Access – the four Toner Cartridges are installed one at a time, through this opening 18. Fuser Jam Clearance Area – the Fuser applies heat to the Toner in order to adhere it to the paper 19.

  • Page 105: Printer Control Panel

    Getting to Know the DP-C106 Printer Control Panel 1010 0101 0010 Printer Control Panel Control Panel Screen – use to view the system status, menu options, problem messages, and fault codes ) ARROW buttons – use to view listed options in a menu MENU button –...

  • Page 106: Scanner And Automatic Document Feeder (Adf) Components

    The ADF comes mounted to the Scanner. Its components are illustrated and described by numbers 3 through 6. Scanner Control Panel – use to access the DP-C106 features and options Memory Expansion Slot – provided for the 1 to 2 Side Copy option Document Input Tray –...
  • Page 107 Getting to Know the DP-C106 Scanner and Automatic Document Feeder (ADF) Components Registration Guide– align the original with the Registration Guide Document Glass – supports the original for scanning...

  • Page 108: Scanner Control Panel

    Scanner Control Panel Getting to Know the DP-C106 Scanner Control Panel Control Panel Screen – use to view the system status, menu options, problem messages, and fault codes Copy button – use to change the system from the on-line mode to copying mode Tools button –...
  • Page 109 Getting to Know the DP-C106 Scanner Control Panel 15. Zoom ( ) ARROW buttons – use to select Reduce/Enlarge from 25- 400% 16. Reduce/Enlarge ( ) ARROW buttons – use to select one of the preset reduction or enlargement settings 17.

  • Page 110: Options And Supplies

    Getting to Know the DP-C106 Options and Supplies The DP-C106 is a digital Color Copier/Printer which can produce images with great color and clarity. Furthermore, its copying/printing functionality can also be greatly enhanced by the addition of the following options and supplies.
  • Page 111 Getting to Know the DP-C106 Options and Supplies Supplies Part Name Part No. 1 Black Toner Cartridge DQ-UR26K 1 Cyan Toner Cartridge DQ-UR26C 1 Magenta Toner Cartridge DQ-UR26M 1 Yellow Toner Cartridge DQ-UR26Y 1 Print/Copy Cartridge DQ-UH26X 1 Toner Waste Container...

  • Page 112: System Administrator Functions

    Using the Fiery WebTools. You should also refer to the table of contents and index for assistance in locating information. The DP-C106 is referred to as a Printer in chapters that refer primarily to its printing capabilities. 3–1...

  • Page 113: Map To The Networking Chapters

    Map to the Networking Chapters The following flowchart provides the general order of system administration tasks for the DP-C106 from installation through printing. Chapters that are below the main flowchart do not have to be performed in any particular order and may be used as needed after initial installation.

  • Page 114: Guide To The Networking Chapters

    System Administrator Functions Guide to the Networking Chapters Administration features are provided in the user software package and are built into the DP-C106. The following table indicates where information about these features is located. For these operations: And these tasks:...
  • Page 115 And these tasks: Refer to: Getting users started with Setting up printing to the Printing from the Windows printing Workstations DP-C106. Setting job-specific options. Printing from the Macintosh Using Fiery Utilities OS Workstations Setting printing options in Setting and overriding print...

  • Page 116: Connecting To The Network

    • Configuring UNIX, Windows NT 4.0 and IPX (Novell) network servers to provide client access to the DP-C106 as a color PostScript or PCL printer. No special configuration of AppleShare servers is required. Refer to Setting up the Network Server.
  • Page 117 Connecting to the Network • Preparing each client workstation that will be printing to the DP-C106. Install the appropriate printer drivers and print description files and connect the workstation to the network. When appropriate, install Fiery utilities and an Internet browser.

  • Page 118: Supported Network Protocols And Frame Types

    Connecting to the Network Supported Network Protocols and Frame Types The DP-C106 supports TCP/IP, IPX/SPX, and AppleTalk protocols (rules that enable computers on a network to communicate with each other). These protocols are supported on Mac OS, Windows, and UNIX platforms. All can be simultaneously active. Workstations that use other protocols can print through a server that uses one of the protocols mentioned.

  • Page 119: Quick Path To Installation

    Connecting to the Network Quick Path to Installation The DP-C106 can use Ethernet cabling to multiple workstations. It also supports a parallel cable connection to a single workstation. Ethernet Cabling The standard Ethernet cabling includes the following: • Unshielded Twisted Pair (UTP), defined as Category 5 for 100Base-TX (Fast Ethernet) •...
  • Page 120 Connecting to the Network The illustrations are logical diagrams are not intended to describe the physical arrangement (topology) of devices on the network. A variety of physical arrangements is possible with each logical arrangement. If the network uses more than one protocol or more than one type of workstation, combine the setups listed for each component of your system.

  • Page 121: Mac Os Environment With Appletalk

    Connecting to the Network Mac OS Environment with AppleTalk Another supported protocol Printer AppleTalk Mac OS Workstation Mac OS Workstation Mac OS Workstation Mac OS Workstation can print AppleTalk protocol directly and use Fiery Utilities 4–6...

  • Page 122: Windows Computers In A Novell Environment

    Connecting to the Network Windows Computers in a Novell Environment Another supported protocol Printer NetWare Server TCP/IP (http) for Fiery WebTools Windows Workstation: NetWare Client Windows Workstation: NetWare Client IPX protocol Windows Workstation: SPX protocol NetWare Client running SPX (TCP/IP or AppleTalk possible) Printing on this network: All Windows Workstations can print through the NetWare Server...

  • Page 123: Windows Nt 4.0 Server Environment

    Connecting to the Network Windows NT 4.0 Server Environment Another supported protocol Windows NT 4.0 Workstation Printer or Windows NT Server acting as Print Server LAN with NETBEUI, etc. TCP/IP (lpd) for Printing TCP/IP (http) for Fiery WebTools TCP/IP for Fiery Utilities Windows Workstation Windows...

  • Page 124: Windows Computers Using Windows Printing

    Connecting to the Network Windows Computers Using Windows Printing Another supported protocol Printer TCP/IP (SMB) Windows Workstation Windows Workstation Windows Workstation For Windows Printing: TCP/IP (SMB) protocol Windows 95/98/Me and NT 4.0 Workstation Window (SMB) printing enabled 4–9...
  • Page 125 Connecting to the Network Unix and Windows NT 4.0 Workstations on a TCP/IP Network Another supported protocol Printer UNIX Server or Workstation TCP/IP (lpd and http) TCP/IP Client Workstation Windows NT 4.0 Workstation with TCP/IP loaded TCP/IP (lpd) protocol Printing on this Network: UNIX Workstations with the TCP/IP (LPD) protocol can print directly and act as the host for shared printing...

  • Page 126: Parallel Port Connection

    Connecting to the Network Parallel Port Connection A supported network protocol Parallel input Printer Protocol not directly supported PC Workstation, Server or Laptop With the Parallel Port enabled, the printer can accept and print Parallel jobs sent to its parallel port 4–11...

  • Page 127: Connecting The Dp-C106 To The Network

    Connecting to the Network Connecting the DP-C106 to the Network Complete the following steps before you configure the DP-C106 and the workstations that will print to it: Ensure that the DP-C106 is plugged in, switched On, and functioning properly. Prepare the network servers to share DP-C106 software and to enable networked users to print to the printer.

  • Page 128: Preparing For The Setup

    Preparing for the Setup Successful printing requires careful setup. This chapter leads you through the pre-setup preparation. It also introduces Fiery WebTools, focusing on the utilities used in setup. Levels of Access and Control When you configure the printer during Setup as system administrator, you will implement a particular level of control by enabling or not enabling print connections, passwords, and access to Fiery WebTools.

  • Page 129: Printer Connections

    Preparing for the Setup Printer Connections The DP-C106 supports three print connections: • Hold Queue — Jobs that are sent to the Hold queue are spooled to the printer hard disk for printing at a later time or for repeated printing.
  • Page 130 Preparing for the Setup Passwords Passwords provide a means of controlling access to printer functions: • Administrator passwords provide the highest level of control, since the administrator has access to Setup and can control the printing and job management environment. Administrator privileges include publishing print connections, setting passwords, deleting fonts, clearing the printer of all job data, and setting the WebLink help page destination.
  • Page 131 Preparing for the Setup Control Level Scenarios Typical scenarios of access and control, ranging from least control to strictest control, are described below. Select the scenario that best matches your site requirements, and then refer to the corresponding number in the table for guidance on how to configure your system for those requirements.
  • Page 132 Preparing for the Setup • A designated administrator and a designated operator, no Fiery WebTool access Only an administrator can perform Setup, and only an operator or administrator can perform calibration and control jobs from the job management tools. Users can print to the Hold Queue and the Print Queue, but not to the Direct Connection.

  • Page 133: Fiery Webtools

    Preparing for the Setup Fiery WebTools The printer can support Internet or intranet access with Fiery WebTools from Windows 95/98/Me, Windows 2000, Windows NT 4.0,and Mac OS Workstation using the recommended browsers: Internet Explorer 4.x and higher or Netscape Navigator 4.x and higher. To enable use of Fiery WebTools, perform the following in Setup: •...

  • Page 134: Network Server Setup Requirements

    Preparing for the Setup Network Server Setup Requirements For Novell, and Windows NT 4.0 (using TCP/IP) networks, the network servers must be configured for printing before you configure printer network settings in Setup. The diagrams in Connecting to the Network provide references for network server setup.

  • Page 135: Ensuring The Printer Connection

    Ensuring the Printer Connection Complete the following steps before you configure the server and the workstations that will print to the DP-C106. A service technician may have performed some initial installation. Print a Test Page from the Printer Control Panel to ensure that the printer is functioning normally in a stand-alone mode.

  • Page 136: Setting Up The Network Server

    This chapter describes environments that typically include one or more Novell NetWare and Windows NT 4.0 network servers that share printing to the DP-C106. It describes setting up servers that use IPX/SPX or TCP/IP protocols for communicating with the printer.
  • Page 137 For information about client setup and printing refer to the installation and printing chapters that are appropriate for the operating system. The DP-C106 can receive print jobs from NetWare clients over the Ethernet network topologies. During printer setup, you select the frame type(s) that will be used for communication between the DP-C106 and the network servers.
  • Page 138 Setting Up the Network Server Overview of IPX Printing to the DP-C106 Setting up the DP-C106 is similar to setting up any other PostScript printer on the network. The following information is useful for experienced system administrators. The DP-C106 with IPX connections has these characteristics: •...
  • Page 139 Off and On after a queue is created or removed. When the DP-C106 is configured to connect to a NetWare server, it polls the NetWare server for jobs in each of its queues. If jobs are found, they are transferred over the network to the matching connection.
  • Page 140 Setting Up the Network Server Configuring NDS Connections On the NDS File Server In WebSetup At the Client Workstation • Port Setup: In NetAdmin: Install user software Ethernet Setup Create NDS print queues For printing: • Protocol Setup: Connect client to print queues Create the NDS printer and that you set up on the IPX/SPX Setup—...

  • Page 141: Setting Up An Nds Connection

    Setting the NetWare 4.x or 5.x Bindery Context You can connect only one directory tree to the DP-C106. If you need to connect additional NetWare 4.x or 5.x servers, you can do so by using bindery emulation, which causes the 4.x or 5.x server to behave like and be accepted as a NetWare 3.x server.

  • Page 142: Setting Up A Netware Print Queue For Bindery

    For printing to the DP-C106, connect all Windows clients to a Novell NetWare server and permit them to connect to the NetWare print server or servers on which you defined a print queue. After the Novell server and the DP-C106 have been set up, client setup consists of the following: •...
  • Page 143 The DP-C106 on a TCP/IP Network with Windows NT 4.0 When a Windows NT 4.0 workstation is configured to connect to the DP-C106 using TCP/IP, it can print directly to the printer. If the workstation shares the printer over the network, it is acting as a print server to Windows NT 4.0 clients.
  • Page 144 (optionally) share the printer on the network. • Enter the host name and remote printer name of the DP-C106 in the printer connection. • If the Windows NT 4.0 server is also a workstation, install the Fiery utilities.

This manual is also suitable for:

Da-tl28cDa-tl26cDa-rm64cDa-rm128cDa-du26cDa-sm112c ... Show all

Table of Contents
