2-in-1 Air hAmmer
with 4 pc chisels & needle scAler
model
95801
Assembly And OperAtiOn instructiOns
Due to continuing improvements, actual product may differ slightly from the product described herein.
®
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our website at: http://www.harborfreight.com
tO preVent seriOus injury, reAd And understAnd
All wArnings And instructiOns befOre use.
©
®
Copyright
2007 by Harbor Freight Tools
. All rights reserved. No portion of this
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
for technical questions or replacement parts, please call 1-800-444-3353.
