Chapter 12
Field-Replaceable Unit Guide

Removing and Replacing the Camera Cluster

Make sure to retain all screws, brackets, and other parts during the disassembly.
Note
Take care not to scratch or mar the display screen during the replacement procedure.
Caution
Note
The directions left and right refer to the assembly as you face it.
Power off the system by completing turning off the following units:
Step 1
Make sure all system power is turned off before beginning this disassembly.
Caution
Remove the top camera hood by removing the screws that secure it to the bracket.
Step 2
Remove the lens hood by removing the two screws on the bottom of the hood.
Step 3
At the back of the camera cluster, disconnect the six cables: one Ethernet and one signal cable from each
Step 4
of the three camera processors. As you remove each cable, attach a strip of temporary masking tape and
mark as "left," "right," or "center" for identification.
Tip
Remove the camera assembly by removing the screws from the top and side flanges of the camera
Step 5
assembly support bracket. Retain the screws and set the assembly aside.
Attach the new camera assembly to the mounting bracket using the same M8 screws that were removed.
Step 6
See
OL-14521-01
Power screwdriver with 2.5, 3, and 6 mm (standard or round) Allen bits, or standard 2.5, 3, and 6 mm
Allen wrenches
0.9mm Allen wrench for camera lens adjustments (if the lens uses a thumbscrew, no tools are
required)
Manual screwdrivers, Phillips and flat head types
Metric wrenches, 10 to 15 mm
Masking tape
Laptop computer attached to network
The two left PDUs on the left accessory cabinet
The single right PDU on the right accessory cabinet
The auxiliary control unit on the center display structure
To enable easier access to the loose cables, temporarily attach them to the upper back of the
display with masking tape.
Chapter 8, "Assembling the Remaining Cisco TelePresence Elements"
Replacing the Camera Cluster—Part Number CTS3K-CAM-CLST-G2
Cisco TelePresence System 3200
for more information.
12-3
