Replacing the Auxiliary Control Unit—Part Number CTS-LIGHT-CTRL
Make sure all system power is turned off before beginning this disassembly.
Caution
Remove the cables from the audio/video extension unit. Label each cable with masking tape for
Step 2
identification as it is removed.
See
Use the screwdriver to remove the two screws that attach the extension unit and remove the unit from
Step 3
the display structure.
Attach the new audio/video extension unit to its bracket, then attach the unit and bracket to the display
Step 4
structure. See
Attach the cables to the new extension unit using the masking tape labels as a guide.
Step 5
Power on the system by completing the steps in the
Step 6
Test the microphone by performing the procedures in the
Step 7
page
Replacing the Auxiliary Control Unit—Part Number
CTS-LIGHT-CTRL
To remove and replace the auxiliary control unit Cisco TelePresence 3200, you need the following tools
and equipment:
•
•
•
Remove and replace the auxiliary control unit by performing the following procedure:
Power off the system by completing turning off the following units:
Step 1
•
•
•
Make sure all system power is turned off before beginning this disassembly.
Caution
Remove the cables from the auxiliary control unit. Label each cable with masking tape for identification
Step 2
as it is removed.
See
Use the screwdriver to remove the two screws that attach the auxiliary control unit and remove the unit
Step 3
from the display structure.
Attach the new auxiliary control unit to its bracket, then attach the unit and bracket to the display
Step 4
structure. See
Cisco TelePresence System 3200
12-16
Chapter 9, "Routing Power and Signal Cables"
Figure 8-12 and
10-13.
Medium Phillips head screwdriver (for attaching the unit to its bracket)
Large Phillips head screwdriver (for attaching the unit and bracket to the display structure)
Masking tape
The two left PDUs on the left accessory cabinet
The single right PDU on the right accessory cabinet
The auxiliary control unit on the center display structure
Chapter 9, "Routing Power and Signal Cables"
Figure 8-14 for more information.
for additional information.
Figure 8-13 for more information.
"Powering On the System" section on page
for additional information.
Chapter 12 Field-Replaceable Unit Guide
"Setting Up the Microphones" section on
12-1.
