R-890SLM
3. COOLING FAN OPERATION
OPERATION MODE
PREHEAT
CONV. (OVEN)
Others
After cooking
4. CONVECTION POWER SETTING
4.1. PREHEATING
TEMP
HEATING ELEMENT
COOLING FAN
CONV. FAN
4.2. CONVECTION
TEMP
✩WITHOUT PREHEATING
✩WITH PREHEATING
COOLING FAN
CONV. FAN
4.3. COMBI-1 (Micro + Conv)
TEMP
✩WITHOUT PREHEATING
✩WITH PREHEATING
MICRO
COOLING FAN
CONV. FAN
NOTE: ✩The oven temp was checked by the thermometer when each stage is started.
If the oven temp is same or higher than 105°C, the oven was judged as "with preheating".
When the oven temp is lower than 105°C or the cooling fan stops, the oven was judged as "without preheating".
Micro and Top heating element can't be on at the same time.
Service_R-890SLM.indd 10
DEVICE
Cooling 60%
Cooling fan 60% 60 min. then 100%
Cooling fan 100%
A cooling fan continues the rotation when Oven temperature is more than 120°C.
Cooling fan
Then, it stops when it is less than 105°C
NOW COOLING is indicated during the cooling fan movement after operation is
Indication
finished. (It isn't indicated during a fan movement to stop on the way.)
250°C, 230°C, 220°C, 200°C, 180°C, 160°C, 130°C, 100°C, 70°C, 40°C
TOP
BOTTOM
250°C 230°C 220°C 200°C 180°C 160°C 130°C 100°C
TOP 50%
HEATING
ELEMENT
BOTTOM 100%
TOP 50%
HEATING
ELEMENT
BOTTOM 90%
250°C 230°C 220°C 200°C 180°C 160°C 130°C 100°C
TOP 50%
HEATING
ELEMENT
BOTTOM 100%
TOP 50%
HEATING
ELEMENT
BOTTOM 90%
POWER CONTROL
100%
100%
60%
0%
40% 40% 30% 20%
90% 80% 70% 70%
40% 40% 30% 20%
70% 60% 50% 50%
60% 60min, then 100%
100%
40% 40% 30% 20%
90% 80% 70% 70%
40% 40% 30% 20%
70% 60% 50% 50%
10%, 30%, 50%
100%
100%
5 - 4
70°C
10% 10% 10% 10%
60% 50% 40% 30%
10% 10% 10% 10%
50% 50% 40% 30%
70°C
10% 10% 10% 10%
60% 50% 40% 30%
10% 10% 10% 10%
50% 50% 40% 30%
40°C
10%
20%
10%
20%
0%
40°C
10%
20%
10%
20%
0%
