Statistics Table:
IP/MAC Address
Packets
Total
Bytes
Packets
Bytes
ICMP
Tx
Current
UDP Tx
TCP
SYN Tx
Reset
Modify
Delete
There would be 5 entries on each page. Click Previous to return to the previous page and Next to
the next page.
Archer C5
The IP and MAC address are displayed with related statistics.
The total number of packets received and transmitted by the
router.
The total number of bytes received and transmitted by the router.
The total number of packets received and transmitted in the last
Packets Statistic interval seconds.
The total number of bytes received and transmitted in the last
Packets Statistic interval seconds.
The number of the ICMP packets transmitted to WAN per second
at the specified Packets Statistics interval. It is shown like
"current transmitting rate / Max transmitting rate".
The number of UDP packets transmitted to the WAN per second
at the specified Packets Statistics interval. It is shown like
"current transmitting rate / Max transmitting rate".
The number of TCP SYN packets transmitted to the WAN per
second at the specified Packets Statistics interval. It is shown like
"current transmitting rate / Max transmitting rate".
Reset the value of he entry to zero.
Delete the existing entry in the table.
