Connect Unit - Icom IC-F50V Service Manual

[FRONT UNIT]
REF ORDER
NO. NO.
C466 4030017420 S.CER ECJ0EC1H470J
C467 4030017420 S.CER ECJ0EC1H470J
C468 4030017420 S.CER ECJ0EC1H470J
C473 4030016790 S.CER ECJ0EB1C103K
C474 4030018860 S.CER ECJ0EB0J105K
C475 4030017460 S.CER ECJ0EB1E102K
C476 4030017460 S.CER ECJ0EB1E102K
C477 4030017420 S.CER ECJ0EC1H470J
C478 4030017420 S.CER ECJ0EC1H470J
C479 4030017460 S.CER ECJ0EB1E102K
C481 4030017460 S.CER ECJ0EB1E102K
C482 4030017460 S.CER ECJ0EB1E102K
C483 4030017460 S.CER ECJ0EB1E102K
C485 4030017460 S.CER ECJ0EB1E102K
C486 4030017460 S.CER ECJ0EB1E102K
C487 4030017460 S.CER ECJ0EB1E102K
C488 4030017460 S.CER ECJ0EB1E102K
C489 4030017460 S.CER ECJ0EB1E102K
C490 4030017460 S.CER ECJ0EB1E102K
C491 4030017460 S.CER ECJ0EB1E102K
C492 4030017460 S.CER ECJ0EB1E102K
C493 4030016930 S.CER ECJ0EB1A104K
C494 4030017460 S.CER ECJ0EB1E102K
C495 4030017460 S.CER ECJ0EB1E102K
C496 4550006760 S.TAN TEESVB21A336M8R
C497 4030018390 S.CER ECJ0EB1A563K
C498 4030017430 S.CER ECJ0EC1H101J
C499 4030017420 S.CER ECJ0EC1H470J
C500 4030016930 S.CER ECJ0EB1A104K
C501 4030017730 S.CER ECJ0EB1E471K
C502 4030016930 S.CER ECJ0EB1A104K
C503 4030018860 S.CER ECJ0EB0J105K
C504 4550007080 S.TAN TEESVA 1C 106M8R
C505 4030016960 S.CER ECJ0EB1C183K
C506 4030016960 S.CER ECJ0EB1C183K
C507 4030017730 S.CER ECJ0EB1E471K
C508 4030017730 S.CER ECJ0EB1E471K
C510 4550000460 S.TAN TEESVA 1C 105M8R
C512 4030018860 S.CER ECJ0EB0J105K
C513 4030018860 S.CER ECJ0EB0J105K
J401 6510026130 S.CNR IMSA-9681S-36Y900
J402 6510023831 S.CNR (G) SM04B-SRSS-TB(LF)(SN)
J403 6510026140 S.CNR 11FH-SM1-TB (LF) (SN)
DS401 5030002730 LCD L3-0048TAY-5
DS402 5040002420 S.LED SML-310MT T86
DS403 5040002420 S.LED SML-310MT T86
DS404 5040002961 S.LED SML-A12MT T86J
DS405 5040002961 S.LED SML-A12MT T86J
DS406 5040002670 S.LED CL-165HR/YG
MC401 7700002760 MIC EM6027P-46C33-G-01 <HOR>
S401 2260002840 SW SKHLLFA010
SP401 2510001330 SP 036D0803 <FG>
W401 8900016840 CBL OPC-1753 (P0.5,N36,L70) <TJM>
W402 7120000470 JMP ERDS2T0
W403 7120000470 JMP ERDS2T0
W404 8900017120 CBL OPC-1754 (P0.5,N11,L35) <TJM>
EP402 8930061530 LCT SRCN-2681-SP-N-W
DESCRIPTION M.
LOCATION
T 36.9/14.5
T 30.5/13.1
T 40.4/11.5
T 38.1/15.9
T
T
T 29.9/21.9
T 33.3/44.1
T 33.5/41.9
T 27.8/17.7
T
T 11.8/41.2
T 38.8/41.8
T
T 32.1/47.5
T 34.4/35.9
T 22.1/43.4
T
T
T 37.3/37.3
T
T 17.4/34.7
T 39.6/67.3
T
T 13.2/54.7
T
T 10.5/33.2
T 15.4/36.9
T
T 35.1/13.2
T 31.9/49.6
T 32.3/48.7
T 40.6/46.4
T
T
T
T 11.3/24.2
T 23.5/48.6
B 22.3/49.5
B 25.9/51.5
T
T 34.9/52.5
T
B 13.5/16.1
B 32.7/15.3
B
B
B 45.3/50.2
[VR UNIT]
H/V REF ORDER
NO. NO.
R601 7210003130 VAR
W601 8900012340 CBL
5/26.6
33/45.4

[CONNECT UNIT]

REF ORDER
6.4/38.1
NO. NO.
D701 1790001810 S.VSR AVR-M1005C080MTABB
33.7/48
D702 1790001810 S.VSR AVR-M1005C080MTABB
D703 1790001810 S.VSR AVR-M1005C080MTABB
D704 1790001810 S.VSR AVR-M1005C080MTABB
D705 1790001810 S.VSR AVR-M1005C080MTABB
9.9/30.9
40.3/27
R701 7410001130 S.ARY
6.8/18.2
C701 4030017460 S.CER ECJ0EB1E102K
10/40.5
C702 4030017460 S.CER ECJ0EB1E102K
C704 4030017460 S.CER ECJ0EB1E102K
8.1/37.9
J1 6510026140 S.CNR 11FH-SM1-TB (LF) (SN)
9.3/37.9
EP701 6910016330 S.BEA
EP702 6910016330 S.BEA
EP703 6910016330 S.BEA
6.3/25.3
EP704 6910016330 S.BEA
6.3/23.4
EP705 6910016330 S.BEA
5/23
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
30.9/6.2
29/43.5
6.2/38
42.8/38
6 - 2
DESCRIPTION M.
TP76N97N-13F-10KA-2497
OPC-1260
DESCRIPTION M.
T
T
T
T
T
EXB28V102JX T
T
T
T
T
MMZ1005S 601CT-S T
MMZ1005S 601CT-S T
MMZ1005S 601CT-S T
MMZ1005S 601CT-S T
MMZ1005S 601CT-S T
S.=Surface mount
H/V
LOCATION
H/V
LOCATION
9.5/31.8
9.2/32.8
4.7/32.3
3.4/32
4.8/20.7
6.5/32.5
4.6/9.9
4.4/14.2
3.9/17.1
3.6/37.1
6.4/9.9
4.8/12.9
4.9/16.5
4.4/18.4
4.8/19.4
