Parts List - Icom IC-F50V Service Manual

SECTION 6
[FRONT UNIT]
REF ORDER
NO. NO.
IC401 1140010191 S.IC HD64F2268TF20V
IC403 1110005340 S.IC NJM12902V-TE1
IC405 1110006770 S.IC TDA8547TS/N
IC406 1130011741 S.IC TC7W66FK (TE85L,F)
IC407 1110005330 S.IC NJM12904V-TE1
IC408 1110006260 S.IC BD5242G-TR
IC409 1130012690 S.IC HN58X24256FPIE (SOP8)
IC410 1130011760 S.IC CD4094BPWR
IC411 1130013240 S.IC TC75S51FU (TE85L,F)
Q401 1550000090 S.FET RSQ035P03TR
Q402 1590003800 S.TR KTC811U-GR-RTK/P
Q406 1590003790 S.TR KRC404E RTK/P
Q407 1590003780 S.TR KRA304E-RTK/P
Q408 1590003790 S.TR KRC404E RTK/P
Q409 1590002370 S.TR XP4111 (TX)
Q411 1590003790 S.TR KRC404E RTK/P
Q412 1590003780 S.TR KRA304E-RTK/P
Q413 1560001330 S.FET RSR025N03
Q414 1590003790 S.TR KRC404E RTK/P
Q415 1530003091 S.TR 2SC4213-B (TE85R,F)
D401 1790001250 S.DIO MA2S111-(TX)
D402 1790001250 S.DIO MA2S111-(TX)
D403 1790001250 S.DIO MA2S111-(TX)
D404 1790001260 S.DIO MA2S077-(TX)
D406 1790001250 S.DIO MA2S111-(TX)
D407 1790001250 S.DIO MA2S111-(TX)
X401 6050011720 S.XTL CR-764 (19.6608 MHz)
R401 7030007290 S.RES ERJ2GEJ 222 X (2.2 k)
R402 7030005060 S.RES ERJ2GEJ 333 X (33 k)
R403 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R404 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R405 7030007340 S.RES ERJ2GEJ 153 X (15 k)
R406 7030005210 S.RES ERJ2GEJ 822 X (8.2 k)
R407 7030005230 S.RES ERJ2GEJ 334 X (330 k)
R408 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R409 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R410 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R411 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R412 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R413 7030005600 S.RES ERJ2GEJ 273 X (27 k)
R414 7030005600 S.RES ERJ2GEJ 273 X (27 k)
R415 7030005100 S.RES ERJ2GEJ 154 X (150 k)
R416 7030005100 S.RES ERJ2GEJ 154 X (150 k)
R417 7030005170 S.RES ERJ2GEJ 474 X (470 k)
R418 7030005170 S.RES ERJ2GEJ 474 X (470 k)
R420 7030005600 S.RES ERJ2GEJ 273 X (27 k)
R421 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R422 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R423 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R426 7030005160 S.RES ERJ2GEJ 105 X (1 M)
R427 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R428 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R429 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R430 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R432 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R433 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R434 7030005000 S.RES ERJ2GEJ 471 X (470)
R437 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R438 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R439 7030007290 S.RES ERJ2GEJ 222 X (2.2 k)
R440 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R441 7030005070 S.RES ERJ2GEJ 683 X (68 k)
R445 7030004980 S.RES ERJ2GEJ 101 X (100)
R446 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R455 7030005000 S.RES ERJ2GEJ 471 X (470)
R456 7030004980 S.RES ERJ2GEJ 101 X (100)
R457 7030005000 S.RES ERJ2GEJ 471 X (470)
R458 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R461 7030008300 S.RES ERJ2GEJ 184 X (180 k)
R462 7030005720 S.RES ERJ2GEJ 563 X (56 k)
R463 7030005220 S.RES ERJ2GEJ 223 X (22 k)
R464 7030005220 S.RES ERJ2GEJ 223 X (22 k)
R465 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R466 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R467 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R468 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R469 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R470 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R471 7030005110 S.RES ERJ2GEJ 224 X (220 k)
R472 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R473 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R474 7030005220 S.RES ERJ2GEJ 223 X (22 k)
R475 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R476 7030005070 S.RES ERJ2GEJ 683 X (68 k)
R477 7030005070 S.RES ERJ2GEJ 683 X (68 k)
R478 7030005070 S.RES ERJ2GEJ 683 X (68 k)
R479 7030005070 S.RES ERJ2GEJ 683 X (68 k)
R480 7030005070 S.RES ERJ2GEJ 683 X (68 k)
R482 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R483 7030005090 S.RES ERJ2GEJ 104 X (100 k)

PARTS LIST

DESCRIPTION M.
LOCATION
T
T 16.9/42.9
T 25.8/53.2
T
T
T
T 10.1/17.8
T 40.6/36.3
T
T 36.3/43.7
T
T 20.9/50.7
T
T
T
T 29.3/18.8
T 14.3/17.6
B
T 40.8/41.8
B 23.9/51.1
T 35.4/23.1
T 35.1/18.1
T
T
T
T
T 42.6/18.8
T
T 10.7/52.2
T 34.3/22.3
T 35.8/20.2
T
T 10.5/36.4
T
T
T 36.3/21.4
T
T 13.8/20.4
T 29.2/13.9
T 27.3/13.7
T 36.9/13.6
T
T 33.4/20.9
T
T
T 28.7/37.2
T 29.9/36.5
T 30.2/35.6
T 31.5/36.5
T 12.3/35.3
T 14.5/37.8
T 13.8/36.9
T 12.3/36.2
T 12.9/40.2
T 14.5/39.6
T 12.2/42.1
B
T 32.9/38.4
T 34.7/37.7
T 36.8/40.2
T 36.1/33.4
T 37.3/33.7
B 32.3/55.2
B 30.1/52.1
T 43.2/27.8
T 43.2/28.7
B 45.2/48.4
B 43.9/49.9
T 33.2/32.4
T
T 31.1/33.6
T 31.5/34.8
T 33.2/34.7
T 23.9/41.3
T
T 21.2/41.3
T
T 19.7/38.6
T 34.5/24.7
T 33.6/24.7
T 32.7/24.7
T 31.8/24.3
T 35.7/24.8
T 23.3/46.1
T 21.7/46.1
T 21.2/44.6
T 18.3/46.2
T
T
T 15.8/21.8
[FRONT UNIT]
H/V REF ORDER
NO. NO.
22.9/28 R484 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R485 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R486 7410001130 S.ARY
8.1/42.4 R487 7030005090 S.RES ERJ2GEJ 104 X (100 k)
7.1/31.6 R488 7030005090 S.RES ERJ2GEJ 104 X (100 k)
32/18.5 R489 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R490 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R491 7030005530 S.RES ERJ2GEJ 100 X (10)
6.2/21.3 R492 7030005160 S.RES ERJ2GEJ 105 X (1 M)
R493 7030008010 S.RES ERJ2GEJ 123 X (12 k)
R494 7030008010 S.RES ERJ2GEJ 123 X (12 k)
R495 7030008010 S.RES ERJ2GEJ 123 X (12 k)
35/39.6 R496 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R497 7030005050 S.RES ERJ2GEJ 103 X (10 k)
42/31.3 R500 7030005090 S.RES ERJ2GEJ 104 X (100 k)
26/39.2 R501 7030005090 S.RES ERJ2GEJ 104 X (100 k)
39.2/29 R502 7030010080 S.RES ERJ2RHD 104 X (100 k)
R503 7030010080 S.RES ERJ2RHD 104 X (100 k)
R506 7030007300 S.RES ERJ2GEJ 332 X (3.3 k)
32.3/53 R507 7030005600 S.RES ERJ2GEJ 273 X (27 k)
R508 7030007290 S.RES ERJ2GEJ 222 X (2.2 k)
R509 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R511 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R512 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R513 7030009290 S.RES ERJ2GEJ 562 X (5.6 k)
R515 7520000270 S.POS PRG21BC4R7MM1RA
15/16 R516 7030007290 S.RES ERJ2GEJ 222 X (2.2 k)
37/24 R517 7030008010 S.RES ERJ2GEJ 123 X (12 k)
36.5/36 R518 7030005050 S.RES ERJ2GEJ 103 X (10 k)
9/23.1 R519 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R520 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R521 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R522 7030005100 S.RES ERJ2GEJ 154 X (150 k)
R523 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R524 7030005090 S.RES ERJ2GEJ 104 X (100 k)
9.9/44.3 R525 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R526 7030007340 S.RES ERJ2GEJ 153 X (15 k)
R527 7030005230 S.RES ERJ2GEJ 334 X (330 k)
R528 7030009140 S.RES ERJ2GEJ 272 X (2.7 k)
9.6/35.1 R529 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R530 7030005160 S.RES ERJ2GEJ 105 X (1 M)
7.4/27.3 R532 7030005700 S.RES ERJ2GEJ 274 X (270 k)
6.8/36.3 R533 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R534 7030005170 S.RES ERJ2GEJ 474 X (470 k)
9.8/39.6 R535 7030005070 S.RES ERJ2GEJ 683 X (68 k)
R537 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R538 7030005060 S.RES ERJ2GEJ 333 X (33 k)
R539 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R541 7030005050 S.RES ERJ2GEJ 103 X (10 k)
39/23.4
17.5/19 C401 4030017460 S.CER ECJ0EB1E102K
5.3/16.3 C402 4030017460 S.CER ECJ0EB1E102K
C403 4030017460 S.CER ECJ0EB1E102K
C404 4030017460 S.CER ECJ0EB1E102K
C405 4030017760 S.CER ECJ0EB1H222K
C406 4030018110 S.CER ECJ0EB1H272K
C407 4030017430 S.CER ECJ0EC1H101J
C408 4030016930 S.CER ECJ0EB1A104K
C409 4030016930 S.CER ECJ0EB1A104K
C410 4030016930 S.CER ECJ0EB1A104K
C411 4030016930 S.CER ECJ0EB1A104K
C412 4030016930 S.CER ECJ0EB1A104K
C413 4030016930 S.CER ECJ0EB1A104K
35/55.4 C414 4030017640 S.CER ECJ0EC1H150J
C415 4030016790 S.CER ECJ0EB1C103K
C416 4030017630 S.CER ECJ0EC1H120J
C417 4030017580 S.CER ECJ0EC1H060C
C418 4030016930 S.CER ECJ0EB1A104K
C419 4550006050 S.TAN
C420 4030016930 S.CER ECJ0EB1A104K
C421 4030016930 S.CER ECJ0EB1A104K
C423 4030018890 S.CER ECJ0EB0J224K
C425 4030017440 S.CER ECJ0EC1H221J
C426 4030017460 S.CER ECJ0EB1E102K
C427 4550007080 S.TAN
C428 4030016930 S.CER ECJ0EB1A104K
32/33.2 C429 4030017460 S.CER ECJ0EB1E102K
C430 4030017460 S.CER ECJ0EB1E102K
C431 4030016790 S.CER ECJ0EB1C103K
C432 4030017460 S.CER ECJ0EB1E102K
C435 4550006760 S.TAN
23/41.3 C437 4030018860 S.CER ECJ0EB0J105K
C441 4030016780 S.CER ECJ0EB1C153K
18.5/39 C442 4030016930 S.CER ECJ0EB1A104K
C443 4030017740 S.CER ECJ0EB1E821K
C444 4030016930 S.CER ECJ0EB1A104K
C445 4030017460 S.CER ECJ0EB1E102K
C446 4030017460 S.CER ECJ0EB1E102K
C447 4030017760 S.CER ECJ0EB1H222K
C448 4030017690 S.CER ECJ0EC1H121J
C449 4030017770 S.CER ECJ0EB1E332K
C450 4030017420 S.CER ECJ0EC1H470J
C461 4030017420 S.CER ECJ0EC1H470J
C462 4030017420 S.CER ECJ0EC1H470J
12.5/45 C463 4030017420 S.CER ECJ0EC1H470J
36.5/32 C464 4030017420 S.CER ECJ0EC1H470J
C465 4030017420 S.CER ECJ0EC1H470J
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
6 - 1
DESCRIPTION M.
T
T
EXB28V102JX T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
B
B
B
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
TEESVA 0J 106M8R T
T
T
T
T
B
TEESVA 1C 106M8R T
T
T
T
T
T
TEESVB21A336M8R T
B
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
S.=Surface mount
H/V
LOCATION
15.6/20.9
14.2/21.7
13.6/24.7
33.9/23.5
31.9/31.3
32.9/31.2
33.8/31.2
38.5/18.4
38.5/20.1
37.6/19.3
38.4/25.8
37.2/20.5
11.3/22.8
11.9/21.9
29/21.1
28.1/20.3
38.4/14.3
39.3/14.3
7.6/23.9
7.6/24.8
5/25.7
26.2/18.9
9.6/33.2
6.2/26.9
7.7/36.3
34.2/46.7
37/38.7
31.1/50.8
30.7/48.7
30.4/53.8
30.4/52.2
30.5/55.1
30.2/49.6
21.1/52.3
21.1/53.7
21.5/54.9
5/24.8
5/23.9
5/19.6
6.6/19.6
10.4/24.2
36.7/41.5
35.1/41.5
36.9/34.9
11.9/33.5
22/50.7
22/52.3
25.5/52.8
10.3/53.4
10.7/51.3
15/20
31/22.6
10.3/43.1
10.5/34.8
9.6/36.7
7.4/26.4
29.6/37.7
27.8/37.6
30.5/37.7
31.7/37.4
36.7/19.3
38.1/24.6
38.1/21.4
34.6/20.2
39.4/19.2
39.4/20.8
39/24.6
24.6/16.9
24.9/18.5
13.5/35.7
12.9/39.2
14.5/38.7
35.6/54.2
40.6/44.3
37.6/47
36.7/47
34.7/36.8
32.9/39.3
38.9/42.7
18.5/54.3
34.1/55.4
23.4/42.9
22.1/41.3
22.2/42.5
19.7/39.5
33.2/33.8
22.5/45.2
20.1/45.7
22.5/44.3
13.7/45.7
12.2/43.7
39/22.5
32/21
17.5/19.9
4.4/16.3
26.4/13.7
