Travis Industries Xtreme 6020 Owner's Manual

Built-in direct-vent power-vent fireplace
Hide thumbs Also See for Xtreme 6020:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual, Installation Manual
•
Natural Gas - 98500325
•
LP (Propane) - 98500326
WARNING:
-
Do not store or use gasoline or other flammable vapors and liquids in the
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
-
Installation and service must be performed by a qualified installer, service
agency or the gas supplier.
Tested and Listed by
Report # 3183426
Owner's Manual
Installer: After installation give this manual to the home-
owner and explain operation of this fireplace.
© Copyright 2010, T.I.
Xtreme 6020 Fireplace
If the information in these instructions is not followed exactly, a
fire or explosion may result causing property damage, personal
injury or loss of life.
$10.00
100-01247_000
4100329
Built-In Direct-Vent Power-Vent Fireplace
This appliance is only for use with the type(s) of
gas indicated on the rating plate.
www.travisproducts.com
4800 Harbour Pointe Blvd. SW
Mukilteo, WA 98275

Advertisement

Table of Contents
loading

Related Manuals for Travis Industries Xtreme 6020

Summary of Contents for Travis Industries Xtreme 6020

  • Page 1 Xtreme 6020 Fireplace Built-In Direct-Vent Power-Vent Fireplace • Natural Gas - 98500325 This appliance is only for use with the type(s) of • LP (Propane) - 98500326 gas indicated on the rating plate. WARNING: If the information in these instructions is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.

  • Page 2: Introduction

    Introduction Introduction We welcome you as a new owner of a Xtreme 6020 gas fireplace. This manual details operation and maintenance of this fireplace. Please familiarize yourself with the Owner's Manual before operating your fireplace and save the manual for future reference.

  • Page 3: Table Of Contents

    Child Protection Feature ............. 12 Features • • Optional Extr-Room Blower for Heat Distribution Convenient Operating Controls • • Built-In Accent Lights Low Maintenance BTU Specifications Natural Gas Propane Maximum BTU Input Per Hour 90,000 90,000 4100329 © Travis Industries 100-01247_000...

  • Page 4: Safety Precautions

    Immediately call a qualified vicinity of this fireplace. service technician to inspect the appliance and to replace any part of the control system and any gas control that has been under water. 4100329 © Travis Industries 100-01247_000...
  • Page 5 If the fiber logs become damaged, replace with Travis Industries log set. Children and adults should be Travis Industries, Inc. grants alerted to the hazards of high no warranty, implied or stated, surface temperature and should for the installation or...

  • Page 6: Operation

    Remote Control The remote control controls all of the functions on the fireplace. It can be placed inside the holder and hung on the wall or it can be placed near the fireplace. Mode 4100329 © Travis Industries 100-01247_000...

  • Page 7: Setting Up The Remote (Time, Day, Swing, °F/°C)

    F. The minute of the hour will blink. Use the arrow keys to select the correct minute. Press the “Set” button to set the minute. G. The AM / PM designation will blink. Use the arrow keys to select the correct setting. Press the “Set” button to set AM / PM. 4100329 © Travis Industries 100-01247_000...

  • Page 8: Remote Synchronization

    To do this, hold down the LEARN button for approximately 10 seconds until the receiver beeps 3 times. This indicates the receiver has been re-set and can be synchronized using the instructions above. 4100329 © Travis Industries 100-01247_000...

  • Page 9: The Two Modes Of Operation

    Thermostat mode is not used on this fireplace. Because the fireplace is not intended for use as a fireplace, do not use the thermostat mode. Continue to press the “MODE” button on the remote until “ON” or “OFF” appear. Mode 4100329 © Travis Industries 100-01247_000...

  • Page 10: Remote Functions

    NOTE: The fireplace must be in manual mode, and on, for the timer function to work. PROGRAM (Programmable 7 day thermostat) This function allows the user to program specific on/off, temperature, weekday and weekend settings on the thermostat. Mode 4100329 © Travis Industries 100-01247_000...

  • Page 11: Program Function (7 Day Thermostat)

    This indicates the remote is in PROGRAM FUNCTION (Programmable thermostat). To Turn PROGRAM FUNCTION OFF Press the Function (“Fn”) Key to select either manual or thermostat mode. 4100329 © Travis Industries 100-01247_000...

  • Page 12: Continuous Pilot - Not Used For This Fireplace

    To turn this feature off, hold down the “Fn” and “Down” button for 5 seconds until “CP” (Child Protection) disappears on the screen in the “ROOM” temperature box 4100329 © Travis Industries 100-01247_000...

  • Page 13: Maintenance

    WARNING: do not operate the fireplace without the glass frame in place. Accent Light Bulb Replacement WARNING: Use only 35 Watt 120 Volt T4 Halogen Bulbs (G6.35 Base) Several accent lights are included in your fireplace to provide additional lighting. Contact your dealer for replacement information. 4100329 © Travis Industries 100-01247_000...

  • Page 14: Replacement Parts List

    Maintenance Replacement Parts List Caution: Use only Travis Industries replacement parts. Do not use substitute materials. Warning: Do not operate appliance with the glass front removed, cracked, or broken. Replacement of the glass should be done by a licensed or qualified service person.

  • Page 15: Wiring Diagram

    24V DC Converter Intake Power Vent Controller Damper Intake Damper Exhausto Blower Tubing Flue Damper Relay Exhaust Damper Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. 4100329 © Travis Industries 100-01247_000...

  • Page 16: Warranty

    2. Travis Industries has the option of either repairing or replacing the defective component. 3. If your dealer is unable to repair your appliance’s defect, he may process a warranty claim through TRAVIS INDUSTRIES, INC., including the name of the dealership where you purchased the appliance, a copy of your receipt showing the date of the appliance’s purchase, and the serial number on your appliance.
  • Page 17 Index 4100329 © Travis Industries 100-01247_000...

  • Page 18: Index

    Setting Up the Remote (Time, Day, Swing, °F/°C) ..7 Starting the Fireplace for the First Time ....... 6 The Two Modes of Operation ........9 Warranty............... 16 Wiring Diagram ............15 Yearly Service Procedure ..........13 4100329 © Travis Industries 100-01247_000...
