Viewing Your Maps

N o t e
This chapter contains information on:
I Displaying Topology Maps
I Using the Panner
Launching the Device View
I
I Options for Map Control
I Locating a Node

Displaying Maps

When HP TopTools is started, the discovery process discovers the devices on
your network. This information is used by the topology process to create a
network topology and the physical maps. Two maps are created automatically:
A map showing just the bridges, switches and segments
I
I A map showing the entire network.
Your hubs and switches must have the Community Name "public" set to READ
and WRITE in order for your devices to be mapped.
Click on the Maps button in the navigation frame to display the Maps-View
Maps page. This page lists the IP subnets that have been discovered by
HP TopTools. The following information is provided for each map:
Name—The name of this map
I
Type—Either a Network or Segment map
I
I Create Date—The date the map was created
I View—The style of the map, for example, hierarchical
Owner—System (default maps created) or the User Id of the person who
I
created the map
Maps appear in the list only after topology is complete. To display the map in
a separate browser window, check the Map in Separate Window box at the
bottom of the page, then double-click on a map in the list.
Click the Full Network button to generate a map of the entire network.
Select the Delete button to remove a map from the list and the map file on the
server. It may take a minute for the map list to reflect the deletion.
